Instructions and
warning book
*1.041321ENG*
EOLO MYTHOS
DOM 10-18-24 1E

Product not intended for EU countries.
Dear Customer,
Our compliments for having chosen a top-quality Immergas product, able to ensure well-being and safety for a long period of time. As an Immergas Customer,
you can also count on a qualied aer-sales service, prepared and updated to guarantee constant eciency of your boiler. Read the following pages carefully:
you will be able to draw useful suggestions regarding the correct use of the appliance. By respecting these suggestions, you will no doubt be satised with your
Immergas product.
For any assistance and scheduled maintenance please contact Authorised Aer-Sales centres: they have original spare parts and are specically trained by the
manufacturer.
General warnings
All Immergas products are protected with suitable transport packaging.
e material must be stored in a dry place protected from the weather.
e instruction book is an integral and essential part of the product and must also be given to the new user in the case of transfer or succession of ownership.
It must be stored with care and consulted carefully, as all of the warnings provide important safety indications for installation, use and maintenance stages.
is instructions manual provides technical information for installing Immergas boilers. As for the other issues related to boiler installation (e.g. safety at the work
site, environmental protection, injury prevention), it is necessary to comply with the provisions specied in the regulations in force and principles of good practice.
In compliance with the legislation in force, the systems must be designed by qualied professionals, within the dimensional limits established by the Law.
Installation and maintenance must be performed in compliance with the regulations in force, according to the manufacturer's instructions and by an agreed
company, intended as a company with specic technical skills in the system sector, as envisioned by the Law.
Improper installation or assembly of the appliance and/or Immergas components, accessories, kit and devices can cause unexpected problems to people, animals
and objects. Read the instructions provided with the product carefully to ensure proper installation.
Maintenance must be carried out by authorised technical personnel. e Authorised Aer-sales Service represents a guarantee of qualications and
professionalism.
e appliance must only be destined for the use for which it has been expressly declared. Any other use will be considered improper and therefore potentially
dangerous.
If errors occur during installation, operation and maintenance, due to non-compliance with technical laws in force, standards or instructions contained in
this book (or however supplied by the manufacturer), the manufacturer is excluded from any contractual and extra-contractual liability for any damages and
the appliance warranty is invalidated.
e manufacturer declines all liability due to printing or transcription errors, reserving the right to make any modications to its technical and commercial
documents without forewarning.

MAINTENANCE TECHNICIAN pageINSTALLER page USER page
INDEX
1 Boiler installation......................................5
1.1 Installation recommendations.................5
1.2 Main dimensions.......................................6
1.3 Antifreeze protection................................6
1.4 Gas connection..........................................7
1.5 Hydraulic connection...............................7
1.6 Electrical connection................................7
1.7 Remote controls and room chrono-
thermostats (Optional).............................8
1.8 Flue systems...............................................8
1.9 Tables of resistance factors and equivalent
lengths.......................................................10
1.10 Cover kit installation. .............................11
1.11 Concentric horizontal kit installation. .12
1.12 Concentric vertical Kit installation.......13
1.13 Separator kit installation........................14
1.14 Ducting of ues or technical slots.........16
1.15 Conguration type B22, open chamber
and forced draught for indoors. ............16
1.16 Flue exhaust to ue/chimney.................16
1.17 Flues, chimneys and chimney caps.......16
1.18 Water treatment system lling. .............16
1.19 System lling............................................16
1.20 Gas system start-up.................................16
1.21 Boiler start up (ignition). .......................17
1.22 Circulation pump....................................17
1.23 Kits available on request.........................17
1.24 Boiler components..................................18
2 Instructions for use and maintenance..19
2.1 Cleaning and maintenance. ...................19
2.2 General warnings....................................19
2.3 Control panel...........................................19
2.4 Fault and anomaly signals......................20
2.5 Information Menu. .................................22
2.6 Resetting the anomaly history. ..............22
2.7 Boiler shutdown. .....................................22
2.8 Restore central heating
system pressure........................................22
2.9 Draining the system................................22
2.10 Antifreeze protection..............................22
2.11 Case cleaning...........................................22
2.12 Decommissioning. ..................................22
3 Commissioning the boiler
(initial check)...........................................23
3.1 Hydraulic diagram. .................................23
3.2 Wiring diagram.......................................24
3.3 Troubleshooting. .....................................24
3.4 Converting the boiler to other types of
gas..............................................................24
3.5 Checks following conversion to another
type of gas.................................................25
3.6 Gas valve calibration...............................25
3.7 Programming the P.C.B..........................26
3.8 "Chimney sweep” function. ...................27
3.9 Heating Timer..........................................27
3.10 ree-way anti-block system.................27
3.11 Pump anti-block function......................27
3.12 Radiators antifreeze function. ...............27
3.13 P.C.B. periodical self-check....................27
3.14 Casing removal........................................28
3.15 Yearly appliance check and
maintenance.............................................29
3.16 Variable heat output................................29
3.17 Combustion parameters.........................31
3.18 Technical data..........................................32
3.19 Key for data nameplate...........................33

5
1-1
INSTALLERUSER
MAINTENANCE TECHNICIAN
NOYES
In the event of malfunctions, faults or incorrect
operation, turn the appliance o and contact an
authorised company (e.g. the Authorised Tech-
nical Assistance centre, which has specically
trained sta and original spare parts). Do not
attempt to modify or repair the appliance alone.
Failure to comply with the above implies personal
responsibility and invalidates the warranty.
• Installation Standards:
- installation of gas appliances, ue exhaust
pipes and combustion air intake pipes is
forbidden in places with a fire risk (for
example: garages, closed parking stalls), and
in potentially dangerous places.
- Installation is prohibited on the vertical
projection of the cooking surface.
- Installation is forbidden in places/rooms
that constitute public areas of apartment
buildings, internal stairways or other escape
routes (e.g. oor landings, entrance halls,
etc.).
- Installation is also forbidden in places/rooms
that constitute public areas of apartment
buildings such as cellars, entrance halls, attics,
los, etc., unless otherwise provided for by
local regulations in force.
Attention: wall mounting of the boiler must
guarantee stable and ecient support for the
generator.
e plugs (standard supply) are to be used only in
conjunction with the mounting brackets or xing
template to x the appliance to the wall; they only
ensure adequate support if inserted correctly
(according to technical standards) in walls made
of solid or semi-hollow brick or block. In the
case of walls made from hollow brick or block,
partitions with limited static properties, or in any
case walls other than those indicated, a static test
must be carried out to ensure adequate mount.
Note: the hex head screws supplied in the
blister pack are to be used exclusively to x the
relative mounting bracket to the wall.
ese boilers are used to heat water to below
boiling temperature in atmospheric pressure.
ey must be connected to a central heating
system and domestic hot water circuit suited to
their performance and capacity.
1BOILER INSTALLATION.
1.1 INSTALLATION
RECOMMENDATIONS.
e Eolo Mythos Dom 10-18-24 1E boiler has
been designed for wall mounted installation only,
for heating and production of domestic hot water
for domestic use and similar purposes.
e place of installation of the appliance and
relative Immergas accessories must have suitable
features (technical and structural), such as to al-
low for (always in safe, ecient and comfortable
conditions):
- installation (according to the provisions of
technical legislation and technical regulations);
- maintenance operations (including scheduled,
periodic, routine and special maintenance);
- removal (to outdoors in the place for loading
and transporting the appliances and com-
ponents) as well as the eventual replacement
of those with appliances and/or equivalent
components.
e wall surface must be smooth, without any
protrusions or recesses enabling access to the
rear part. ey are not designed to be installed
on plinths or oors (Fig. 1-1).
By varying the type of installation the classicati-
on of the boiler also varies, precisely:
- Type B22 boiler if installed using the relevant
terminal for air intake directly from the room
in which the boiler has been installed.
- Type C boiler if installed using concentric pipes
or other types of pipes envisioned for the sealed
chamber boiler for intake of air and expulsion
of fumes.
Only professionally enabled companies are
authorised to install Immergas gas appliances.
Attention: the manufacturer declines all liability
for damages caused by boilers removed from
other systems or for any non-conformities of
such equipment.
Installation must be carried out according to
regulation standards, current legislation and in
compliance with local technical regulations and
the required technical procedures.
Before installing the appliance, ensure that it
is delivered in perfect condition; if in doubt,
contact the supplier immediately. Packing ma-
terials (staples, nails, plastic bags, polystyrene
foam, etc.) constitute a hazard and must be kept
out of the reach of children. If the appliance is
installed inside or between cabinets, ensure su-
cient space for normal servicing; it is therefore
recommended to leave at least 45 cm between
the upper part of the boiler and the ceiling and
a gap of 3 cm between the boiler casing and the
vertical sides of the cabinet. Keep all ammable
objects away from the appliance (paper, rags,
plastic, polystyrene, etc.).
Do not place household appliances underneath
the boiler as they could be damaged if the safety
valve intervenes (if not conveyed away by a
draining funnel), or if there are leaks from the
hydraulic connections; otherwise, the manufac-
turer cannot be held responsible for any damage
caused to the household appliances.
For the aforementioned reasons, we recommend
not placing furnishings, furniture, etc. under
the boiler.
