Impex MARCY MCPL-105 User manual

NOTE:
Please read all instructions
carefully before using this
product
Safety Notice
Hardware Identifier
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
MCPL 105
Retain This
Manual for
Reference
100427
OWNER'S
MANUAL
MARCY BODY CYCLE
MCPL-105
IMPEX INC.
2801 S. Towne Ave., Pomona, CA 91766
Tel: [phone] Fax: [phone]
www.impex-fitness.com
[email protected]

TABLE OF CONTENTS
BEFORE YOU BEGIN...................................................................................….1
IMPORTANT SAFETY NOTICES..................................................................….2
HARDWARE IDENTIFIER.....…....................................................................….3
ASSEMBLY INSTRUCTIONS........................................................................….4
EXPLODED DIAGRAM……………………………………………………………….8
PARTS LIST...................................................................................................….9
COMPUTER................................................................................................……10
WARRANTY.................................................................................................…. 11
ORDERING PARTS.......................................................................................…11
BEFORE YOU BEGIN
Thank you for selecting the MARCY Body Cycle Fan Bike MCPL-105 by IMPEX
INC. For your safety and benefit, read this manual carefully before using the
machine. As a manufacturer, we are committed to provide you complete customer
satisfaction. If you have any questions, or find there are missing or damaged parts,
we guarantee you complete satisfaction through direct assistance from our factory.
To avoid unnecessary delays, please call our TOLL-FREE customer service
number. Our Customer Service Agents will provide immediate assistance to you.
1
Toll-Free Customer Service Number
1-800-999-8899
Mon. - Fri. 9 a.m. - 5 p.m. PST
www.impex-fitness.com
[email protected]

IMPORTANT SAFETY NOTICE
PRECAUTIONS
This exercise machine is built for optimum safety. However, certain precautions apply whenever
you operate a piece of exercise equipment. Be sure to read the entire manual before you
assemble or operate your machine. In particular, note the following safety precautions:
1. Keep children and pets away from the machine at all times. DO NOT
leave children unattended in the same room with the machine.
2. Only one person at a time should use the machine.
3. If the user experiences dizziness, nausea, chest pain, or any other abnormal
symptoms, STOP the workout at once. CONSULT A PHYSICIAN
IMMEDIATELY.
4. Position the machine on a clear, leveled surface. DO NOT use the machine
near water or outdoors.
5. Keep hands away from all moving parts.
6. Always wear appropriate workout clothing when exercising. DO NOT wear
robes or other clothing that could become caught in the machine. Running
or aerobic shoes are also required when using the machine.
7. Use the machine only for its intended use as described in this manual. DO
NOT use attachments not recommended by the manufacturer.
8. Do not place any sharp object around the machine.
9. Disabled person should not use the machine without a qualified person or
physician in attendance.
10. Before using the machine to exercise, always do stretching exercises to
properly warm up.
11. Never operate the machine if the machine is not functioning properly.
12. The Weight Capacity is up to 300 lbs.
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR PHYSICIAN.
THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS
WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING
ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR PERSONAL
INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS
PRODUCT.
SAVE THESE INSTRUCTIONS.
2

3

ASSEMBLY INSTRUCTION
Tools Required to Assemble the Machine: Two Adjustable Wrenches and Allen Wrenches
NOTE: It is strongly recommended this machine be assembled by two or more people to
avoid possible injury.
STEP 1 (See Diagram1)
A.) Attach the Front Stabilizer (#13) to the Main Frame (#1). Secure it with two M8 x 2 ½” Carriage
Bolts (#15), 5/8” Bent Washers (#14), and M8 Acorn Nuts (#16).
B.) Insert Rear Stabilizer (#10) into the rear bottom of Main Frame (#1). Secure it with three M8 x
5/8” Allen Bolts (#12) and 5/8” Washers (#11). Diagram 1
4

STEP 2 (See Diagram 2)
A.) Insert the Axle (# 4) into the Pivot on the Main Frame (#1). Attach the Left and Right
Handlebars (#2) & (#32) onto the Axle from both sides. Secure the Axle with two 7/8”
Washers (#7) and M8 Nylon Nuts (#8). Close both ends with two Axle End Caps (#9).
B.) Insert the Lower Handlebar (#3) into the Left Handlebar (#2). Secure it with two M6 x 5/8”
Allen Bolts (#6) and ½” Flat Washers (#5). Repeat same procedure to install the other side.
DIAGRAM 2
5

STEP 3 (See Diagram 3)
A.) Attach the Connecting Rod (#26) on the Lower Handlebar to the Crank. Align the hole. Insert a
Bushing (#29) into the hole on the Rod. Attach a Spacer (#30) to the Bushing. Then insert the
Left Pedal (#27) through the Rod into the Crank. Secure the Pedal with a 1/2” Nylon Nut
(#28).
B.) Repeat the above procedure (A) to install the other side.
DIAGRAM 3
6

STEP 4 (See Diagram 4)
A.) Attach the Seat (#18) to the Seat Post (#19). Secure it with three 5/8” Washers (#21),
Spring Washers (#22), and M8 Nylon Nuts (#23).
B.) Insert the Seat Post into the opening on the Main Frame (#1). Select the Seat height and
secure it with a Lock Knob (#17).
C.) Attach the Computer (#24) onto the computer holder on the Main Frame. Plug the Computer
Sensor Wire (#25) into the Computer.
DIAGRAM 4
7

EXPLODED DIAGRAM
8

PARTS LIST
KEY NO. DESCRIPTION QUANTITY
1 Main Frame 1
2 Left Handlebar 1
3 Lower Handlebar 2
4 Axle 1
5 ½” Flat Washer 4
6 M6 x 5/8” Allen Bolt 4
7 7/8” Washer 2
8 M8 Nylon Nut 2
9 Axle End Cap 2
10 Rear Stabilizer 1
11 5/8” Washer 3
12 M8 x 5/8” Allen Bolt 3
13 Front Stabilizer 1
14 5/8” Bent Washer 2
15 M8 x 2 ½” Carriage Bolt 2
16 M8 Acorn Nut 2
17 Lock Knob 1
18 Seat 1
19 Seat Post 1
20 Manual 1
21 5/8” Washer 3
22 ½” Washer 3
23 M8 Nylon Nut 3
24 Computer 1
25 Computer Sensor Wire 1
26 Connecting Rod 2
27 Left Pedal 1
28 1/2” Nylon Nut 2
29 Bushing 2
30 Spacer 2
31 Right Pedal 1
32 Right Handler 1
9
