IMS E3TA Series User manual

IMS
E3TA-
INSTRUCTION MANUAL
! WARNING
! CAUTION
Thank you for selecting IMS product.This sheet primarily describes precautions
required in installing and operating the product. Before operating the product,
read the sheet thoroughly to acquire sufficient knowledge of the product. For
your convenience, keep the sheet at your disposal.
Failure to follow these instructions may result in serious injury or death：
Fail-safe device must be installed when using the unit with machinery that may
cause serious injury or substantial economic loss. (e.g. nuclear power control,
medical equipment, ships, vehicles, railways, aircraft, combustion apparatus,
safety equipment, crime/disaster prevention devices,etc.)
Failure to follow these instructions may result in product damage：
Do not use this unit over rated voltage；
Do not use this unit where there is flammable or explosive gas；
Do not use this unit where there is vibration or impact；
In cleaning the unit, do not use water or an oil-based detergent.
Features
Ordering information
1ms
0.25msM
L Cable type
Connector type
C
D 1 M N L T C
Connection type
Tavailable
Fixed
Response time
Item E3TA
Number Sensing distance
Output
Sensing distance unit
Sensing distance
（slot series use 30/50 to refer slot distance）
Sensing method（slot series is none）
Operation mode
Sensitivity
T
D
R
Through-beam
Diffuse reflective
Retro reflective
V
B
（ ）
Light on
Dark on
Selectable
D
S
Unit：mm
Unit：m
Sensing method
Sensing distance
Model
NPN
PNP
Diffuse reflective Retro reflective
1m
Hysteresis
Directional angle
Response time
Operation mode
Power supply
Light source
Load current
Output
Dielectric strength
Vibration resistance
Shock resistance
Ambient humidity
Degree of protection
Material
Accessory
Weight
Indicators
Circuit protection
Max. 20% at rated sensing distance
Max. 1ms
Max. 40mA
10~30VDC（including voltage ripple of 10%(p-p)max.）
NPN/PNP(open collector)
Selectable Light ON or Dark ON by control cable
Power supply reverse polarity protection, Output short-circuit
protection, and Output reverse polarity protection
Operation indicator：Orange，Output indicator：Green
Key
Min. 20MΩ ( 500VDC )
1.5mm amplitude at frequency of 10 to 55Hz in each of X,Y,Z direction
for 2 hours
500m/s² in X,Y,Z directions for 3 times
Incandescent lamp：Max. 3，000lx /Sunlight：Max. 10，000lx
Operation：-25 ～ 55 ℃/Storage：-40 ～ 70 ℃（with no icing and
condensation）
Operation：35 ～ 85 %/Storage： 35%～95%(with no condensation)
Instruction、M18 nut( 2pcs )
Red LED (624nm)
Max.100mA (Residual voltage: Max. 3V)，Load voltage: Max.26.4VDC
IEC： IP65
ABS
Key
Lens
Nut
Case
PMMA
0.1~2m
Opaque: 75 mm dia.min
35×35mm（Sensing
distance of 500mm）
50×50mm（Sensing
distance of 1m）
Spot diameter
(reference value)
2°min.
POM
POM
E3TA-D500-N E3TA-D1M-N
E3TA-D500-P E3TA-D1M-P
E3TA-R2M-N
E3TA-R2M-P
Non-glossy white paper300*300mm
Specifications
Operating timing diagram
※
High performance ASIC based advance sensor
Long product life time, 5us modulated pulse with 1/10 duty cycle re-
duced aging of LED
Build in 100ms power on delay, self-recover short circuit protection,
reverse polarity, over voltage protection
Excellent noise immunity to DC light with modulated light source and
CDS signal process technology
Mode selection for light on and dark on
Visible super bright red light for easy alignment
Distance adjustable using teach in
IP65 grade
（orange）
（orange LED）
M18 Photoelectric Sensor
with Teach-in Function

1. Power on the sensor after it is fixed in position；
2. Placing the target object in front of the sensor ;
3. Press the "T" button for 3-5 seconds, then release
it. It means the sensor enters the automatic adjust-
ment state if the indicator start to flicker. After the
adjustment, the operation indicator is lighted up；
4. When the white wire is grounded for more than 3
seconds, the sensor enters the state of automatic
adjustment；
5. Repeat step 3 and 4 until the setting is met；
6. Due to the sensor built in hysteresis(+/-20% Maximun),
even if the target are moved further away from the
sensor, the sensor will still reliably detect the target
provided that the change of distance is within sensor
hysteresis limit.
Caution for using
Main product
Intellisense Microelectronics
Tel：[phone]
Tax：0592-8268997
Web：www.chinasensors.cn
E-mail：[email protected]
Add：1F NO. 34 Guanri Rd, Xiamen software Park,Xiamen P.R. China
Photoelectric sensor
Light curtain
Proximity sensor
Pressure sensor
Counting sensor
Distance sensor
Liquid level sensor
Label sensor
Hall sensor
Pressure meter
Counting machine
Dust sensor
Control output circuit diagram
Dimensions
Installation and sensitivity adjustment
PNP open collector output
NPN open collector output
Reflector
Nut
Sensor
Sensitivity adjuster
Operation indicator
（ orange ）
Stability indicator
（ green ）
Optical axis
of emitter
Optical axis
of receiver
Mounting hole dimension
Sensitivity
adjuster
Operation
indicator
Stability
indicator
Load
Over
current
protection
（C）White
Control
（+）Brown +V
10~30VDC
+
-
Max. 100mA
（OUT）Black
Output
（-）Blue 0V
Light on
Dark on
Operation
(orange)
Stability
(green)
Main circuit
Load
Over
current
protection
（C）White
Control
（+）Brown +V
10~30VDC
+
-
Max. 100mA
（OUT）Balck
Output
（-）Blue 0V
Light on
Dark on
Operation
Stability
(green)
(orange)
Main circuit
1. Please make sure the wiring is correct before power-on.
2. Use a visor or a hood so that excessive light（e.g. sunlight, spotlight）does not directly
enter into the inclination angle of the sensor.
3. When more than 2 sets of Through-beam type sensor are used closely,it might cause
interference each other. Be sure to put enough space between them in order to avoid
malfunction.
4. When more than 2 sets of diffuse reflective beam type or narrow beam reflective type are
installed adjacently, it can occur malfunction by light beam from the other target. So it must
be installed at an enough interval.
5. If the sensor is installed directly on a flat surface, the reflection off the surface may cause
malfunction. Make sure there is enough space between the sensor and the surface.
6. If the sensor is wired with a high voltage line or power line, it may cause product damage
or malfunction. Use separate wiring or a dedicated conduit.
7. Please use short cables for wiring the sensors. Power surge from extended wiring may cause
product malfunction；
8. When the lens is stained by foreign substances, clean the lens lightly with dry cloth. Do not
use chemical or organic solvents.
