inbody BPBIO750 User manual

BPBIO750
User’s Manual
BPBIO750 User Manual for Measurement Guide and Setup
Thank you for purchasing the BPBIO750. This user’s manual describes all the features of the
BPBIO750. Please read before use and keep it in a safe place. By following the manual
instructions, you will be able to use the BPBIO750 more safely and eectively.
使用手册
BPBIO750测量姿势引导及安装使用手册
󳘫󸙀󳕜󸟵󱔾󾙙󾙗󾙒󴂸󱛔󵥌󳡧󱩫󲳳󾙙󾙗󾙒󵯔󳡇󴁸󱰖󶾨󸱞󷼇󱕞󸘄󶮒󳻥󳝧󵯔󸘒󳻛󱛔󵥌󱮆󸘕󸗂󵳂󹟃󸘙󴂸󱛔󵥌󳡧󱩫󽙓󳅽󲴉
󱩎󲞑󲂅󱝫󶓺󲍨󳄜󸇘󵯔󱚅󶱭󵋺󵸔󳲊󱚝󳹂󴩰󱷷󴪒󳘍󱕥󹰙󽙓󱗵󱜹󱕨󳕜󶾨󲰈󱨴󴟽󵻗󱓇󺁷󳵿󲍱󱛔󵥌󾙙󾙗󾙒
BPBIO750_manual_다국어 합본_F_210517.indd 1BPBIO750_manual_다국어 합본_F_210517.indd 1 2021-05-21 오전 10:41:132021-05-21 오전 10:41:13

Please note the important information below before reading this manual.
Failure to comply with safety precautions can damage the equipment.
Caution
Se référer aux notes peut aider à améliorer l'utilisation de l'appareil.
Remarque
Reading the notes can help you get the most out of your device.
Note
Le non-respect de ses précautions peut causer des blessures ou des dommages à l'appareil.
Avertissement
Le non-respect de ses précautions peut causer des dommages à l'appareil.
Attention
Failure to observe these precautions can result in personal injury or damage to the equipment.
Warning
在阅读本手册之前，请注意下列重要信息。
󷏕󱒹󸷸󳏂󲰈󱨴󸔽󱺵󱼑󳥸󶀱󸇛󲰬󱸯󲳸󷆻󹂧󱙏󳟾󴠦󱖇
警告
󷏕󱒹󸷸󳏂󲰈󱨴󴪒󳘍󱕥󹰙󱸯󶾨󲳸󷆻󱸉󱙏󳟾󸗜󲙘󳨄󲎟
注意
󳄍󱰣󵥌󳠴󵜝󸈐󵯔󸘒󳻛
参考
BPBIO750_manual_다국어 합본_F_210517.indd 2BPBIO750_manual_다국어 합본_F_210517.indd 2 2021-05-21 오전 10:41:142021-05-21 오전 10:41:14

3
I. BPBIO750 Installation
A. Product Components
B. Operating Environment
C. Installation Instructions
D. Loading and Reloading Printer Paper
 E.ReplacingCu󰀨Cover
F. Setup
G. Connecting to InBody
H. Precautions for Maintenance
II. Blood Pressure Test
A. Preparatory Steps
B. Test Instructions
C. Test Posture
III. Transportation and Storage
A. Transportation Precautions
B. Repacking Instructions
C. Transportation and Storage Environment
IV. FAQ
A. Error Code
B. Regarding the Equipment
C. Regarding the Test
V.Others
A. Exterior and Functions
B. Safety Information
 C.ProductClassication
 D.Specications
E. EMC Information (Declaration)
5
6
6
10
11
13
17
18
19
19
22
23
24
24
25
25
27
29
30
31
32
33
I. BPBIO750电子血压计的安装
 󱖓󱽢󶮐󳟸
 󳲊󱚝󵚦󲖀
 󲰈󷿙󳥸󱵀
 󳡳󱵦󶮄󲰈󷿙󱼑󴁡󳨇
 󷾁󳄁󴁍󳨇
 󸗜󶱭󷗇󱴾
 󸱡󳩺󱖶󱚏󳟸󱬨󱬨󴅌󱗺
 󶯀󳣪
II. 血压测量
 󴬟󹂩󱮆󴪒󳘍󱕥󹰙
 󴬟󹂩󳹂󴩰
 󴬟󹂩󲡵󱱂
III. 运输和储存
 󸱂󸯀󴪒󳘍󱕥󹰙
 󹂧󳸮󱲯󷿙󳥸󱵀
 󸱂󸯀󱷷󱣕󲮨󵚦󲖀
IV. 常见问题解答
 󹚐󸘍󱗰󵸿
 󱩊󱕨󸗜󲙘
 󱩊󱕨󷻲󱶎󴬟󹂩
V. 其他
 󲙻󸇙󱷷󱰖󶾨
 󲰈󱨴󱝵󳓽
 󱖓󱽢󱬨󶛘
 󲘽󳻛
 󸇛󴉓
37
38
38
41
42
44
48
49
50
50
53
54
55
55
56
56
58
60
61
61
62
66
Contents
BPBIO750_manual_다국어 합본_F_210517.indd 3BPBIO750_manual_다국어 합본_F_210517.indd 3 2021-05-21 오전 10:41:142021-05-21 오전 10:41:14

BPBIO750_manual_다국어 합본_F_210517.indd 4BPBIO750_manual_다국어 합본_F_210517.indd 4 2021-05-21 오전 10:41:142021-05-21 오전 10:41:14

User's Manual

BPBIO750
BPBIO750_manual_다국어 합본_F_210517.indd 5BPBIO750_manual_다국어 합본_F_210517.indd 5 2021-05-21 오전 10:41:142021-05-21 오전 10:41:14

6
7
I.BPBIO750 Installation
A. Product Components
The BPBIO750 consists of the following components. Make sure all of the components are present.
*Please check each component for damage prior to installation.
Standard Components
The BPBIO750
Power cable 110V or 220V (AC 250V 10A 1.8m (70.9 in.)) 1 EA
Printer paper 2 EA
User’s manual
Cu󰀨covers2EA;1installed
Optional Components
Desk for the BPBIO750
Chair for the BPBIO750
Print
Start
Stop
Placeyourelbow on the elbow point.
PresstheSTART button.
Donotmove during the measurement.
SYS.
P.R
DIA.
*Pleaseconsultwith your doctor for accurate diagnosis.
Blood Pressure Guidelines
(Age18and O ver)
Stage2 Hypertension
DiastolicBloodPressure
SystolicBloodPressure
Stage1 Hypertension
Prehypertension
Normal
Start
Stop
BPBIO750
User’s Manual
Print
Print
Start
Stop
Placeyourelbow on the elbow point.
PresstheSTART button.
Donotmove during the measurement.
SYS.
P.R
DIA.
*Pleaseconsultwith your doctor for accurate diagnosis.
Blood PressureGuidelines
(Age18and Over)
Stage2 Hypertension
DiastolicBloodPressure
SystolicBloodPressure
Stage1 Hypertension
Prehypertension
Normal
Start
Stop
BPBIO750
User’s Manual
Print
Print
Start
Stop
Placeyourelbow on the elbow point.
PresstheSTART button.
Donotmove during the measurement.
SYS.
P.R
DIA.
*Pleaseconsultwith your doctor for accurate diagnosis.
Blood Pressure Guidelines
(Age18and O ver)
Stage2 Hypertension
DiastolicBloodPressure
SystolicBloodPressure
Stage1 Hypertension
Prehypertension
Normal
Start
Stop
BPBIO750
User’s Manual
Print
1
1
6
7
2
3
4
5
2
3
4
5
6
7
<110V or 220V>
BPBIO750
User’s Manual
BPBIO750_manual_다국어 합본_F_210517.indd 6BPBIO750_manual_다국어 합본_F_210517.indd 6 2021-05-21 오전 10:41:142021-05-21 오전 10:41:14

6
7
C. Installation Instructions
1. Open the BPBIO750 box and remove the packing pads. Remove the protective vinyl on the BPBIO750
and take it out of the box. Remove the packing material.
B. Operating Environment
Please make sure the environment is appropriate for the BPBIO750 installation. This equipment is
designedforindooruse.Ifinstallingtheequipmentoutdoors,thefollowingrequirementsmustbefullled.
Temperature range 10 to 40ºC (50 to 104ºF)
Relative humidity 30 to 75% RH
Atmospheric pressure range 70 to 106 kPa
• Do not carry the equipment by the cuff.
• Keep packing material to store the BPBIO750. Dispose of trash according to local laws and regulations.
• Refer to the figure below when transporting the BPBIO750.
Caution
• Ne transportez pas l’appareil en le tenant par le brassard.
• Conservez l’emballage original de l’appareil BPBIO750 pour le réemballer ultérieurement.
Disposez des déchets selon la réglementation locale en vigueur.
• Référez-vous à l’illustration ci-dessous pour transporter l’appareil BPBIO750.
Attention
Packing material
*Pleaseconsultwith your doctor for accurate diagnosis.
BloodPressure Guidelines
(Age18and Over)
Stage2Hypertension
DiastolicBloodPressure
SystolicBloodPressure
Stage1Hypertension
Prehypertension
Normal
Placeyourelbow on the elbow point.
PresstheSTARTbutton.
Donotmoveduring the measurement.
SYS.
P.R
DIA.
Print
Start
Stop
*Pleaseconsultwith your doctor for accurate diagnosis.
BloodPressure Guidelines
(Age18and Over)
Stage2Hypertension
DiastolicBloodPressure
SystolicBloodPressure
Stage1Hypertension
Prehypertension
Normal
Placeyourelbow on the elbow point.
PresstheSTARTbutton.
Donotmoveduring the measurement.
SYS.
P.R
DIA.
Print
Start
Stop
Packing pads Protective vinyl
BPBIO750_manual_다국어 합본_F_210517.indd 7BPBIO750_manual_다국어 합본_F_210517.indd 7 2021-05-21 오전 10:41:152021-05-21 오전 10:41:15

8
9
2. Place the equipment on a solid table that can withstand the weight of the BPBIO750 (approx. 7.1kg (15.65lb)).
   IfusingtheoptionalBPBIO750desk,alignthedeskxinggroovesonthebottomoftheBPBIO750withthe
groovesonthedeskandsecurethemwiththetwoxingscrews.
3. Connect the provided power cable.
* Plug the power cable into a grounded 3-prong outlet.
• Install the BPBIO750 on a flat, vibration-free surface.
If the device is installed on a surface that is not flat, it may topple during testing or the results may be
inaccurate.
Caution
• Installer le BPBIO750 sur un sol plat et sans vibration.
Si l'équipement est installé sur un sol qui n'est pas plat, il peut glisser pendant un test ou les résultats
peuvent être inexacts.
Attention
Placeyour elbow on the elbow point.
Pressthe START button.
Donot move during the measurement.
SYS.
P.R
DIA.
Fixing screws
Deskxinggrooves Desk grooves
Print
Start
Stop
Placeyourelbow on the elbow point.
PresstheSTARTbutton.
Donotmove during the measurement.
SYS.
P.R
DIA.
*Pleaseconsultwith your doctor for accurate diagnosis.
Blood PressureGuidelines
(Age18and Over)
Stage2Hypertension
DiastolicBloodPressure
SystolicBloodPressure
Stage1Hypertension
Prehypertension
Normal
Start
Stop
BPBIO750
User’s Manual
Print
Start
Stop
Ground
Pin
Plug Type B
Anti-theft
groove
Anti-theft
groove
Ground
Pin
Plug Type F
3-prong outlet Type F
3-prong outlet Type B
BPBIO750_manual_다국어 합본_F_210517.indd 8BPBIO750_manual_다국어 합본_F_210517.indd 8 2021-05-21 오전 10:41:162021-05-21 오전 10:41:16

8
9
• Do not install the equipment where the power cable is difficult to disconnect.
• To avoid electric shock, do not plug or disconnect the power cable with wet hands.
• Always use an outlet designed for the correct power supply (AC100-240 V).
An incorrect power supply may cause fire or equipment malfunction.
• If using a multiple tab, ensure it has a sufficient power capacity or use an extension cable.
• Do not disassemble the equipment arbitrarily. This may cause electric shock or injury, product malfunction,
and/or inaccurate results. Unauthorized disassembly will void the manufacturer’s warranty.
• Do not let the BPBIO750 touch other electronic devices when turned on. This may cause electric shock.
Warning
• N’installez pas l’appareil dans un lieu difficile d’accès.
• Ne branchez pas et ne débranchez pas le câble d’alimentation si vos mains sont mouillées; ce geste comporte
des risques d’électrocution.
• Utilisez toujours une prise reliée à un circuit électrique approprié (CA 100-240V); dans le cas contraire,
un incendie ou un mauvais fonctionnement pourrait se produire.
• Lorsque vous utilisez une prise multiple, assurez-vous qu’elle fournit suffisamment de puissance, ou utilisez
une rallonge électrique.
• Ne démontez pas l’appareil de façon arbitraire; ceci comporte des risques d’électrocution et de blessure,
un mauvais fonctionnement de l’appareil, et des résultatsinexacts. Le cas échéant, la garantie du manufacturier
serait annulée.
• Ne mettez pas l’appareil BPBIO750 en contact avec d’autres appareils électroniques lorsqu’il est en marche,
ceci comporte des risques d’électrocution.
Avertissement
• Plugging the device into an ungrounded outlet may cause malfunction or electric shock and/or inaccurate
results.
Caution
• Branchez l’appareil à une prise de courant n’ayant pas été mise à terre pourrait causer un mauvais
fonctionnement et/ou des résultats inexacts.
Attention
BPBIO750_manual_다국어 합본_F_210517.indd 9BPBIO750_manual_다국어 합본_F_210517.indd 9 2021-05-21 오전 10:41:162021-05-21 오전 10:41:16

10
11
• Do not operate or touch the device while it is calibrating. It may cause errors to future tests.
• Ne manipulez pas l’appareil BPBIO750 et ne le faites pas fonctionner pendant qu’il effectue un test
automatique (env. 10 s); des erreurs et des résultats inexacts pourraient en résulter.
Caution
Attention
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
Irregular signal was detected.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
4. Use the anti-theft groove to prevent theft.
*Theft protection cable is sold separately.
5. Turn the BPBIO750 on by pressing the power switch located on the back of the device.
6. When powered on, the BPBIO750 will automatically calibrate and display the following screen.
Power switch
7. Adjust the volume by turning the volume knob on the rear of the BPBIO750.
BPBIO750_manual_다국어 합본_F_210517.indd 10BPBIO750_manual_다국어 합본_F_210517.indd 10 2021-05-21 오전 10:41:162021-05-21 오전 10:41:16

10
11
D. Loading and Reloading Printer Paper
1. Press the button shown below to open the cover while the BPBIO750 is turned on.
2. Insert the printer paper in the direction as shown below.
After inserting the printer paper, let a certain amount of paper come out of the cover, then close it
to complete the installation.
• The printer will not work if the paper is inserted in the wrong direction.
• Remove all trash from previous printer paper rolls when replacing with the new printer paper.
• L’imprimante ne fonctionnera pas si le papier n’est pas inséré adéquatement.
• Assurez-vous de bien retirer les résidus du papier précédent lorsque vous rechargez le papier
d’impression.
Caution
Attention
• Two rolls of printer paper are provided with the BPBIO750.
• If an additional printer paper roll is needed, it may be purchased separately.
• Deux rouleaux de papiers sont fournis avec le BPBIO750.
• Si du papier supplémentaire est nécessaire, l'utilisateur peut l'acheter séparément comme un article
consommable.
Note
Remarque
PUSH
BPBIO750_manual_다국어 합본_F_210517.indd 11BPBIO750_manual_다국어 합본_F_210517.indd 11 2021-05-21 오전 10:41:172021-05-21 오전 10:41:17

12
13
E.ReplacingCu󰀨Cover
  Thecu󰀨coveroftheBPBIO750shouldbereplacedperiodicallyforsanitarypurposes.Followtheguide
belowtoreplacethecu󰀨cover.
1. Remove the front cover of the BPBIO750 by pushing downward, and loosen the screw with a screwdriver.
Remove the ring on the front of the BPBIO750 by pulling it forward.
  2.Pushintheseamofthecu󰀨coverasshownbelowtoseparatethecu󰀨cover.
  3.Pullthecu󰀨coverasshownbelowtoremoveitfromthedevice.
SYS.
P. R
DIA.
Print
Front cover
SYS.
P. R
DIA.
Front ring
Screw
BPBIO750_manual_다국어 합본_F_210517.indd 12BPBIO750_manual_다국어 합본_F_210517.indd 12 2021-05-21 오전 10:41:172021-05-21 오전 10:41:17

12
13
  4.Placetheseamofthenewcu󰀨coverdownasshownbelow,andalignitwithfrontandrearring.
5. Reattach the front and rear rings to the BPBIO750 and secure them with the screws. Close the front cover of
the BPBIO750.
• The blood pressure reading may be inaccurate if the seam does not face down.
• Les résultats de la pression artérielle pourraient être faussés si la ligne de couture n’est pas placée vers le
bas.
Caution
Attention
• Two cuff covers are included with the BPBIO750. (One is already installed in the equipment.)
• You may purchase additional cuff covers separately.
• Deux housses de brassard sont fournies avec l’appareil BPBIO750, l’une d’elles est préalablement installée
sur l’équipement.
• Au besoin, l’utilisateur peut faire l’achat de nouvelles housses de brassard auprès de son fournisseur.
Note
Remarque
Print
Front cover
Front ring
Screw
BPBIO750_manual_다국어 합본_F_210517.indd 13BPBIO750_manual_다국어 합본_F_210517.indd 13 2021-05-21 오전 10:41:182021-05-21 오전 10:41:18

14
15
F. Setup
Setup consists of time settings, sound settings, Result Sheet printing, pressure unit setting, and communication
settings.
  1. ConguringSetup
1) When the ' ' and 'Print' buttons are pressed and held simultaneously for 2 seconds while on
the home screen, ' ' (Time setting) will blink.
The current setting status will be shown in the Diastolic ( ) column and Pulse (Hour value) column.
2) When the Systolic column is blinking, you can go to the desired setting item.
Press UP / DOWN buttons to move to the other setting items.
* UP/DOWN buttons are located beneath the printer cover of the device.
3) To adjust the setting value, press the button.
The set value can be changed with the UP / DOWN buttons, and the set value of the corresponding item is
displayed in the Pulse column.
4) Press the button to save the setting value. Then, you can go back
to the desired setting item.
   5)Onceyouarenishedadjustingallsettings,pressandholdthePrintbuttonfor2secondstoreturntothe
home screen.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
UP
DOWN
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
BPBIO750_manual_다국어 합본_F_210517.indd 14BPBIO750_manual_다국어 합본_F_210517.indd 14 2021-05-21 오전 10:41:192021-05-21 오전 10:41:19

14
15
2. Setup Example
The following is an example showing how to change the automatic Result Sheet printing option to manual
printing option.
1) While on the home screen, press and hold the and buttons simultaneously time for more
than2seconds.Thecurrentsettingisshownonthe''screen,therstscreenofSetup.
2) Press the 'UP/DOWN' buttons to go to ' ' screen.
In the Pulse column, the current setting value is displayed as ‘ ’.
3) Press the button to enter the corresponding item, and then use the UP / DOWN buttons to
change the current setting value from ‘ ’ to ‘ ’.
4) Press the button to save the setting value, and the display will return to the Setup screen.
   5)CheckthesettingvalueofthePulsecolumntoconrmyourdesiredsetting,thenpressandholdthe
button for 2 seconds to return back to the home screen.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
Place your elbow on the elbow point.
Press the START button.
Do not move during the measurement.
SYS.
P. R
DIA.
BPBIO750_manual_다국어 합본_F_210517.indd 15BPBIO750_manual_다국어 합본_F_210517.indd 15 2021-05-21 오전 10:41:192021-05-21 오전 10:41:19

16
17
3. Detailed description of Setup
   WhenconguringSetup,thefollowingmessageswillbedisplayedintheSystolic,Diastolic,andPulsescreen.
Function
Screen
Description
Systolic Diastolic Pulse
Hour setting Setting hour (0-23)
Minute setting Setting minute (0-59)
Year setting Setting year (2000-2035)
Month setting Setting month (1-12)
Day setting Setting day (1-31)
Sound
Read test instructions and measurement results
Read test instructions only
Read measurement results only
Beep guide
Printing options
Automatic printing of Result Sheet
Manual printing of Result Sheet
Screen timeout
duration
Display the test result value for 5 seconds
Display the test result value for 10 seconds
Display the test result value for 20 seconds
Display the test result value for 30 seconds
Display the test result value for 60 seconds
Display the test result value for 120 seconds
Date output format
YY / MM / DD
MM / DD / YY
DD / MM / YY
Pressure unit mmHg
Communication
InBody
PC
Result
Sheet item
Type of
Result Sheet
3-line automatic output (vertical)
*F13-F18 function not available
3-line automatic output (horizontal)
Additional
result values
Output of Mean arterial pressure /
Pulse pressure / Pressure rate product
Not used
Blood
pressure
graph
Print blood pressure graph
Not used
Test posture
check
Guide output about the elbow placement
Not used
BPBIO750_manual_다국어 합본_F_210517.indd 16BPBIO750_manual_다국어 합본_F_210517.indd 16 2021-05-21 오전 10:41:212021-05-21 오전 10:41:21

16
17
Result
Sheet
item
Blood Pressure
Knowledge
Output of additional blood pressure
information on the Result Sheet
Not used
Pulse Evelope
Pulse Evelope output on the Result Sheet
Not used
Logo
Customized logo on the Result Sheet
Not used
Setting up the Elbow
Sensor
Elbow sensor is functional
Elbow sensor is disabled
Result
Sheet item QR Code
QR code output
Not used
Measurement
mode setting
3 consecutive
measurements
3 consecutive measurements mode
One-time measurement mode
* “QR Code” is registered trademark of DENSO WAVE INCORPORATED.
BPBIO750_manual_다국어 합본_F_210517.indd 17BPBIO750_manual_다국어 합본_F_210517.indd 17 2021-05-21 오전 10:41:222021-05-21 오전 10:41:22

18
19
G. Connecting to InBody
You can connect the BPBIO750 to InBody body composition analyzers to transfer over blood pressure
measurements.
*Only compatible with other InBody products.
*Blood pressure values can be printed on the InBody Result Sheet.
*Serial cable is sold separately.
1. Turno󰀨theBPBIO750.
2. Connect the serial cable to the RS232C (9-pin serial) connection terminal located on the back of the BPBIO750.
Connect the other end of the serial cable to the serial connection terminal on the InBody device.
*RefertotheInBodyuser'smanualtondthelocationoftheserialconnectionterminal.
3. Turn on the BPBIO750.
4. Devices will connect automatically.
Example: InBody770
Blood Pressure Monitor
serial connection terminal
• Refer to the InBody user's manual to print the blood pressure values on the InBody Result Sheet.
Note
• Consultez le manuel du produit d'InBody pour la méthode d'impression des valeurs de la pression artérielle
sur la fiche des résultats d'InBody.
Remarque
BPBIO750_manual_다국어 합본_F_210517.indd 18BPBIO750_manual_다국어 합본_F_210517.indd 18 2021-05-21 오전 10:41:222021-05-21 오전 10:41:22

18
19
Avant d’allumer l’appareil, assurez-vous que :
• l’appareil n’ait pas subi de dommage à la suite d’un impact
• l’appareil n’est pas contaminé
• l’appareil n’est pas mouillé
• le cordon d’alimentation est bien inséré dans la prise murale.
• le cordon d’alimentation n’est pas endommagé
• le cordon d’alimentation ne constitue pas un risque de chute.
Si un message d'erreur (code d'erreur) apparaît pendant l'auto-test, veuillez contacter le revendeur ou le
centre de service à la clientèle.
H. Precautions for Maintenance
Check the following before turning the equipment on.
• Never move the equipment while the power is on.
• Do not let foreign objects like dust and liquid enter the device, as they can cause damage to electrical components.
• Clean the exterior of the equipment gently with a lint-free cloth once a week.
Do not scratch the LED screen while cleaning the equipment.
• Replace the cuff cover when it becomes dirty or worn out.
• Packing material and other waste should be disposed of according to the relevant laws and regulations.
• Make sure the equipment was not damaged from impact.
• Make sure the equipment is not contaminated.
• Make sure the equipment is not wet.
• Make sure the power cord is completely plugged in.
• Make sure the power cord is not damaged.
• Make sure the power cord is not a tripping hazard.
The BPBIO750 calibrates automatically when it is turned on, but it may be necessary for a specialist to
inspect the device once every two years to maintain its performance and safety. If an error message
appears during calibration, please contact product support.
Caution
• Ne déplacez pas l’appareil lorsqu’il fonctionne.
• Ne laissez aucun corps étranger, tel de la poussière ou du liquide s’insérer dansl’appareil;
ces derniers pourraient endommager les composantes électriques.
• Nettoyez l’extérieur de l’appareil avec un chiffon doux et non pelucheux une fois par semaine, veillez
à ne pas gratter l’écran D.E.L. lors du nettoyage de l’appareil.
• Remplacez la housse du brassard lorsque celle-ci devient sale ou trop usée.
• Vous devez disposer des emballages et autres déchets conformément à la réglementation locale en vigueur.
Attention
BPBIO750_manual_다국어 합본_F_210517.indd 19BPBIO750_manual_다국어 합본_F_210517.indd 19 2021-05-21 오전 10:41:222021-05-21 오전 10:41:22

20
21
Blood Pressure Test
A. Preparatory Steps
B. Test Instructions
1. Adjust the height of the chair so that the inserted upper arm and heart are horizontal.
2. Rest for at least 5 minutes prior to taking the test.
*If examinee tests in an agitated state, the results may be inaccurate and read higher than normal.
II.
• Examinee should rest at least 5 to 10 minutes before the test.
•Donotrolluptheexaminee'ssleeve;instead,removethickclothing
• Examinee should sit up straight in the chair.
• Insert the examinee's arm until the elbow is positioned in the elbow groove.
• Adjust the height of the chair so that the inserted upper arm and heart are horizontal.
• Test in a relaxed state.
• Examinee should not talk or move during the test.
• Il est recommandé que l’utilisateur se repose de 5 à 10 minutes avant le test.
• Il n’est pas nécessaire de relever la manche de l’utilisateur, mais ce dernier devrait enlever les
vêtements plus épais.
• L’utilisateur doit s’asseoir bien droit sur la chaise.
• Insérez le bras de l’utilisateur dans le brassard jusqu’à ce que son coude atteigne le point prévu à cet effet.
• Ajustez la hauteur du siège afin que l’avant-bras de l’utilisateur, une fois inséré dans l’appareil,
soit parallèle à son cœur.
• Assurez-vous que l’utilisateur soit détendu pendant le test.
• Assurez-vous que l’utilisateur ne parle pas et ne bouge pas pendant le test.
Caution
Attention
Arm insertion point
BPBIO750_manual_다국어 합본_F_210517.indd 20BPBIO750_manual_다국어 합본_F_210517.indd 20 2021-05-21 오전 10:41:232021-05-21 오전 10:41:23
