industrie technik Evolution FH-xxSH1 series User manual

07/12/2017 Version 1.0.13 EN
ROOM CONTROLLER
EVOLUTION
SERIES FH-xxSH1
USER MANUAL

2/142 AB Industrietechnik srl – Via Julius Durst, 70 – 39042 BRESSANONE (BZ) Italy – Tel: [phone] – [e-mail] – www.industrietechnik.it
1. Technical data ..............................................................................................................................................6
2. Code selection..............................................................................................................................................6
3. Display, keypad and icons ..........................................................................................................................7
4. General description .....................................................................................................................................8
• Contact communication:......................................................................................................................................................................8
• Modbus communication: .....................................................................................................................................................................8
 &RQ¿JXUDWLRQVWDEOH ..................................................................................................................................16
• MASTER controller or SLAVE_Y controller:......................................................................................................................................16
• SLAVE_X controller...........................................................................................................................................................................16
»Control with one sensor/zone: .....................................................................................................................................................16
• SLAVE_X controller...........................................................................................................................................................................17
»Control with one sensor/zone, zone 1 has several thermal actuators that are controlled in order:.............................................17
• SLAVE_X controller...........................................................................................................................................................................17
»Control with one sensor/zone, zones 1 and 2 have 2 thermal actuators that are controlled in order:.........................................17
»&RQ¿JXUDEOHGLJLWDORXWSXWVHWXS ................................................................................................................................................17
 &RQ¿JXUDWLRQRITXLFNDFFHVVSDUDPHWHUV .............................................................................................19
• .H\SDGORFN.......................................................................................................................................................................................19
• Switch on and off...............................................................................................................................................................................19
»Global commands:.......................................................................................................................................................................19
»Local commands:.........................................................................................................................................................................20
»Switch off command from the MASTER controller to the SLAVE controllers:..............................................................................20
• 6HWSRLQWDQGVHWSRLQWRIIVHWFRQ¿JXUDWLRQ .........................................................................................................................................21
• )DQRSHUDWLQJPRGH ..........................................................................................................................................................................21
 '$7(DQG7,0(VHWWLQJ0RGHO)+[[&6+ ...........................................................................................30
 7,0(56/276RSHUDWLRQDQGFRQ¿JXUDWLRQ0RGHO)+[[&6+..........................................................31
 7,0(56/276GXSOLFDWLRQ0RGHO)+[[&6+ ......................................................................................34
• 7LPHUVORWVGXSOLFDWLRQIURPRQHGD\WRDQRWKHURID]RQH...............................................................................................................34
• 7LPHUVORWVGXSOLFDWLRQRID]RQH......................................................................................................................................................35
 3DUDPHWHUIDFWRU\VHWWLQJVOHYHOSDVVZRUG........................................................................................36
 &RQ¿JXUDWLRQRILQVWDOOHUSDUDPHWHUVOHYHOSDVVZRUG......................................................................40
 'LJLWDODQGDQDORJXHLQSXWVORJLF.............................................................................................................46
• 'LJLWDOLQSXWV',DQG',..................................................................................................................................................................46
• $QDORJXHLQSXWV.................................................................................................................................................................................47
 &RQWUROVHQVRUV .......................................................................................................................................51
 &RQWUROZLWKÀRRUWHPSHUDWXUHFRQWURO ....................................................................................................52
• 0LQLPXPÀRRUWHPSHUDWXUHFRQWURO...................................................................................................................................................52
• 0D[LPXPÀRRUWHPSHUDWXUHFRQWURO..................................................................................................................................................52
 6HDVRQRSHUDWLQJVHWSRLQW(&2120<, +2/,'$<PRGH .....................................................................53
16. Zone display or alternate zones on the display:.....................................................................................55
 6XSSO\OLPLWVIXQFWLRQ................................................................................................................................56
• /RZHUOLPLWLQFRROLQJPRGH..............................................................................................................................................................56
• 8SSHUKHDWLQJOLPLW ............................................................................................................................................................................56
 &RQWUROZLWKFRPSHQVDWHGVHWSRLQW .........................................................................................................57
• :LQWHUFRPSHQVDWLRQFXUYH..............................................................................................................................................................57
• 6XPPHUFRPSHQVDWLRQFXUYH...........................................................................................................................................................57
 'HZVHWSRLQWFRQWUROGXULQJWKHVXPPHUVHDVRQ...................................................................................58
 'HZSRLQWIXQFWLRQLQFRROLQJPRGH ........................................................................................................59
TABLE OF CONTENT

3/142
AB Industrietechnik srl – Via Julius Durst, 70 – 39042 BRESSANONE (BZ) Italy – Tel: [phone] – [e-mail] – www.industrietechnik.it
 $QWLFRQGHQVDWLRQIXQFWLRQ ......................................................................................................................59
 'LUW\¿OWHU ....................................................................................................................................................60
 6XPPHUWLPHFKDQJH..................................................................................................................................60
 $,VHQVRUXVHGDV9LQSXW .............................................................................................................61
 )RUFHGRXWSXWVYLD0RGEXV ......................................................................................................................62
 $ODUPV .........................................................................................................................................................63
• Alarms table ......................................................................................................................................................................................63
• 7DEOHRIDODUPVIDXOW\WHPSHUDWXUHVHQVRUV....................................................................................................................................64
• 'HZSRLQWDODUP ...............................................................................................................................................................................64
• Condensation alarm:.........................................................................................................................................................................64
• &RQGHQVDWLRQULVNRQVODYHDODUP ...................................................................................................................................................65
• General alarm:...................................................................................................................................................................................65
• Limits exceeded alarms:....................................................................................................................................................................65
• +LJKÀRRUWHPSHUDWXUHDODUP............................................................................................................................................................65
• Faulty control sensor alarm:..............................................................................................................................................................65
 $ODUPVSDJH................................................................................................................................................67
 5HVWRULQJGHIDXOWSDUDPHWHUV ...................................................................................................................68
 9DOYHRXWSXW................................................................................................................................................69
• )L[HGSRLQWSLSH+($7,1*FRQWUROM02 ....................................................................................................................................69
• )L[HGSRLQWSLSH&22/,1*FRQWUROM01  ...................................................................................................................................70
• SLSHFRPSHQVDWHGVHWSRLQWFRQWUROM02  ...................................................................................................................................71
 'HKXPLGL¿HU ...............................................................................................................................................73
 &LUFXODWRU ...................................................................................................................................................74
 &ROXPQSXPS .............................................................................................................................................74
 7KHUPDODFWXDWRU .......................................................................................................................................75
• &RQWUROVZLWKRQHVHQVRUSHU]RQH...................................................................................................................................................75
»&RQ¿JXUDWLRQVIURPWRWKHUPDODFWXDWRULQKHDWLQJPRGH...............................................................................................75
»&RQ¿JXUDWLRQVIURPWRWKHUPDODFWXDWRULQFRROLQJPRGH ...............................................................................................76
»&RQ¿JXUDWLRQVWKHUPDODFWXDWRULQKHDWLQJPRGH............................................................76
»&RQ¿JXUDWLRQVWKHUPDODFWXDWRULQFRROLQJPRGH ............................................................76
»&RQ¿JXUDWLRQVWKHUPDODFWXDWRULQKHDWLQJPRGH ................................................................................................77
»&RQ¿JXUDWLRQVWKHUPDODFWXDWRULQFRROLQJPRGH.................................................................................................77
»&RQ¿JXUDWLRQWKHUPDODFWXDWRULQKHDWLQJPRGH..................................................................................................................77
»&RQ¿JXUDWLRQVIURPWKHUPDODFWXDWRULQFRROLQJPRGH ........................................................................................................78
• &RQWUROVZLWKDVLQJOHVHQVRUZLWKVHYHUDOWKHUPDODFWXDWRUVIRUDVLQJOH]RQH ...............................................................................78
»&RQ¿JXUDWLRQVWKHUPDODFWXDWRUVLQKHDWLQJPRGH.............................................................................................78
»&RQ¿JXUDWLRQVWKHUPDODFWXDWRUVLQFRROLQJPRGH..............................................................................................79
»&RQ¿JXUDWLRQVWKHUPDODFWXDWRUVLQKHDWLQJPRGH .........................................................................................79
»&RQ¿JXUDWLRQVWKHUPDODFWXDWRUVLQFRROLQJPRGH..........................................................................................80
»&RQ¿JXUDWLRQWKHUPDODFWXDWRUVLQKHDWLQJPRGH ..................................................................................................81
»&RQ¿JXUDWLRQWKHUPDODFWXDWRUVLQFRROLQJPRGH...................................................................................................82
• &RQWUROVZLWKWKHUPDODFWXDWRUVSHU]RQHWZRFRQWUROVHQVRUVDUHUHTXLUHG...............................................................................83
»&RQ¿JXUDWLRQWKHUPDODFWXDWRUVLQKHDWLQJPRGH ..................................................................................................83
»&RQ¿JXUDWLRQWKHUPDODFWXDWRUVLQFRROLQJPRGH...................................................................................................84
 &RQWUROUHTXHVWLQGLFDWLRQ ........................................................................................................................85
 )DQ&RLO .......................................................................................................................................................87
• 7KHVSHHGIDQFRLODFWLYDWLRQORJLFFRQ¿JXUDWLRQVLQKHDWLQJPRGH .................................................................87
• 7KHVSHHGIDQFRLODFWLYDWLRQORJLFFRQ¿JXUDWLRQVLQFRROLQJPRGH..................................................................88
• 7KHVSHHGIDQFRLODFWLYDWLRQORJLFFRQ¿JXUDWLRQVLQKHDWLQJPRGH...............................................................................89
• 7KHVLQJOHVSHHGIDQFRLODFWLYDWLRQORJLFFRQ¿JXUDWLRQVLQFRROLQJPRGH.......................................................................90
• 7KHVSHHGIDQFRLODFWLYDWLRQORJLFFRQ¿JXUDWLRQVLQKHDWLQJPRGH.......................................................................................91
• 7KHVSHHGIDQFRLODFWLYDWLRQORJLFFRQ¿JXUDWLRQLQFRROLQJPRGH .........................................................................................93
• 7KH(&IDQFRLODFWLYDWLRQORJLFFRQ¿JXUDWLRQVLQKHDWLQJPRGH.......................................................................95
• 7KH(&IDQFRLODFWLYDWLRQORJLFFRQ¿JXUDWLRQVLQFRROLQJPRGH .......................................................................98
• )DQFRLOGHDFWLYDWLRQORJLF ...............................................................................................................................................................100
 'HVWUDWL¿FDWLRQF\FOH ...............................................................................................................................101

4/142 AB Industrietechnik srl – Via Julius Durst, 70 – 39042 BRESSANONE (BZ) Italy – Tel: [phone] – [e-mail] – www.industrietechnik.it
 'LUW\¿OWHU ..................................................................................................................................................101
 86%FRQQHFWLRQ .......................................................................................................................................102
 -XPSHUFRQ¿JXUDWLRQ ..............................................................................................................................102
 0RGEXVIRU)+[0[6+PRGHOV...........................................................................................................103
• 5HVWRUDWLRQRIGHIDXOWSDUDPHWHUVYLD02'%86.............................................................................................................................124
• &ORFNVHWWLQJIURP02'%86...........................................................................................................................................................124
• 02'%86FRPPXQLFDWLRQVDODUP....................................................................................................................................................124
• 02'%86FRQQHFWLRQGLDJUDP ........................................................................................................................................................125
41. Electrical connections.............................................................................................................................126
• &RQ¿JXUDWLRQRUPRGHO)+[[6+.....................................................................................................................................126
• &RQ¿JXUDWLRQRUPRGHO)+[[6+......................................................................................................................................126
• &RQ¿JXUDWLRQDQGPRGHO)+[[6+...................................................................................................................................127
• &RQ¿JXUDWLRQDQGPRGHO)+[[6+..................................................................................................................................127
• &RQ¿JXUDWLRQPRGHO)+[[6+.............................................................................................................................................128
• &RQ¿JXUDWLRQPRGHO)+[[6+.............................................................................................................................................128
• &RQ¿JXUDWLRQPRGHO)+[[6+.............................................................................................................................................129
• &RQ¿JXUDWLRQPRGHO)+[[6+.............................................................................................................................................129
• &RQ¿JXUDWLRQPRGHO)+[[6+.............................................................................................................................................130
• &RQ¿JXUDWLRQPRGHO)+[[6+...........................................................................................................................................130
• &RQ¿JXUDWLRQPRGHO)+[[6+ ...........................................................................................................................................131
• &RQ¿JXUDWLRQPRGHO)+[[6+...........................................................................................................................................131
• &RQ¿JXUDWLRQPRGHO)+[[6+...........................................................................................................................................132
• &RQ¿JXUDWLRQPRGHO)+[[6+...........................................................................................................................................132
• &RQ¿JXUDWLRQPRGHO)+[[6+...........................................................................................................................................133
• &RQ¿JXUDWLRQPRGHO)+[[6+...........................................................................................................................................134
• &RQ¿JXUDWLRQPRGHO)+[[6+...........................................................................................................................................134
• &RQ¿JXUDWLRQPRGHO)+[[6+...........................................................................................................................................135
• &RQ¿JXUDWLRQPRGHO)+[[6+...........................................................................................................................................135
• &RQ¿JXUDWLRQPRGHO)+[[6+...........................................................................................................................................136
• &RQ¿JXUDWLRQPRGHO)+[[6+...........................................................................................................................................136
• &RQ¿JXUDWLRQPRGHO)+[[6+...........................................................................................................................................137
 7HUPLQDOEORFNVFRQQHFWLRQ....................................................................................................................138
 'LPHQVLRQV...............................................................................................................................................139
 0RXQWLQJLQVWUXFWLRQV .............................................................................................................................139

5/142
AB Industrietechnik srl – Via Julius Durst, 70 – 39042 BRESSANONE (BZ) Italy – Tel: [phone] – [e-mail] – www.industrietechnik.it

6/142 AB Industrietechnik srl – Via Julius Durst, 70 – 39042 BRESSANONE (BZ) Italy – Tel: [phone] – [e-mail] – www.industrietechnik.it
FH room controller
1. Technical data
Power supply: 110...230 Vca ±10%, 50/60 Hz
Power consumption: max 1.3 W
Operating temperature: 0...50°C
Display: Backlit LCD display
Inputs: 2 potential-free contacts
2 or 3 NTC 10k sensors
      86%IRUSDUDPHWHUFRQ¿JXUDWLRQDQGVRIWZDUHXSGDWHV
Outputs: 1 analogue output 0...10 V (RL> 10K) depending on the model
5 SPST 250 VAC, 3A relays (AC1) depending on the model
N.B: the total current output obtained adding each current output must
be lower than 7A (AC1).
Communication: Master or slave RTU modbus
Temperature reading range: -15...90°C
Humidity reading range: 10...90% r.h., non-condensing
Dimensions: 128 x 80 x 55.5 mm
,QVWDOODWLRQ    PRGXOHÀXVKPRXQWHGER[
Protection class: IP30, class 2
EU compliance standard: EN 60730-1, EN 61000-6-3, EN 61000-6-1
2. Code selection
Room controller:
FH -x MxSH1
Model:
3 digital outputs + 1 analogue output + 3 analogue inputs
5 digital outputs + 0 analogue outputs + 3 analogue inputs 2
4
Communication:
Modbus M
Clock:
Without clock
With clock S
C
Internal sensor:
Temperature + humidity H

7/142
AB Industrietechnik srl – Via Julius Durst, 70 – 39042 BRESSANONE (BZ) Italy – Tel: [phone] – [e-mail] – www.industrietechnik.it
3. Display, keypad and icons
ESC
M
O
D
E
Display A
Display B
On/Off
ÀDVKLQJ Timer extension on
continuously displayed Clock setting
Economy function on
General alarm
Communications alarm
Parameters menu
Operating season
'LUW\¿OWHUDODUP
ÀDVKLQJ Floor temperature too high while cooling
continuously displayed Cooling on
ÀDVKLQJ Condensation alarm
continuously displayed 'HKXPLGL¿FDWLRQRQ
ÀDVKLQJ Floor temperature too high while heating
continuously displayed Heating on
Holiday function
Fan speed
Display C
Time zone number with status
Keypad
2Q2IIQDYLJDWLRQDQGFRQ¿UPNH\V
Change setpoint, navigation and modify value keys
ESC Speed type and ESC function in navigation keys
M
O
D
E
Manual season or occupation change key or operating mode
(see ³02'(EXWWRQIXQFWLRQ´SDJH22)

8/142 AB Industrietechnik srl – Via Julius Durst, 70 – 39042 BRESSANONE (BZ) Italy – Tel: [phone] – [e-mail] – www.industrietechnik.it
4. General description
The controller is used to manage a radiant panel heating or cooling system.
,WPD\EHFRQ¿JXUHGWREHXVHGDV0$67(5RU6/$9(FRQWUROOHU
The MASTER controller receives the information from the SLAVE controllers. The communication between the MASTER
controller and the SLAVE controllers may be performed in 2 ways: contact communication, communication through Modbus
RTU protocol.
• Contact communication:
the MASTER controller receives on its digital inputs the information from the digital contacts. The information is:
UHJXODWLRQUHTXHVWDQGFRQGHQVDWLRQDODUP7KH¿UVWLQIRUPDWLRQZLOODFWLYDWHWKHSDUWVXVHGIRUWKHJHQHUDWLRQRIWKH
GHOLYHU\ÀXLGDWWKHUHTXHVWHGWHPSHUDWXUH7KHVHFRQGLQIRUPDWLRQZLOOLQWHUUXSWWKHÀRZGHOLYHU\DVORQJDVWKHUHLVDQ
abnormal condition.
This information may reach the MASTER controller from the SLAVE controllers or from the contact of the electrothermal
thermal actuators of the plant..
• Modbus communication:
The FH controller may be equipped with a RS485 based communication system with Modbus RTU protocol. This feature
allows the transmission of digital data between the two types of functions. The MASTER controller will cyclicly query all
SLAVE controllers connected to it through the bus, to check if there is any current temperature request; in this case,
RWKHULQIRUPDWLRQVXFKDVDODUPVGHKXPLGL¿FDWLRQUHTXHVWHWFPD\DOVRWUDYHORQWKH0RGEXVOLQH:HFDOOWKLVW\SHRI
connection horizontal type Modbus, since it is likely that this type of application follows an equipment layout on the same
level of the building.
For example: One (primary) level controller and “n” area controllers (SLAVE_X).
The Modbus communication also offers the possibility to use the controllers with a system that we call vertical, also in
relation to the building view. In this case, the interconnected controllers are various level controllers suitable for produc-
ing the water for the radiant panels (SLAVE_Y). The advantage of connecting various level appliances through Modbus
allows all controllers, from different levels, to know the value of a single external sensor. In the same way, the various
level controllers send to the central controller (in this primary case) a request to start the system, avoiding in this way the
connection of more electrical connections between the level and thermal generating unit.
The MASTER controller can manage up to 31 SLAVE controllers. The network must be composed of controllers with pro-
gressive addresses, starting from 1. In the event of a communication problem between the master and a slave node, the
PDVWHULQGLFDWHVRQWKHSDJHRIWKHDODUPVWKH¿UVWQRGHZLWKZKLFKFRPPXQLFDWLRQLVQRWVXFFHVVIXOHJLIWKHPDVWHU
is not properly communicating with the slave controller with address 5, the master indicates the message “CE05” in the
alarm page)
The functions of the FH controller are divided into 2 categories:
ÀXLGFRQWURODQGDUHDFRQWURO
7KHÀXLGFRQWUROFRQWUROOHUPD\FRQWURO
- the column pump
- an area circulator
- a control valve
DGHKXPLGL¿HU
The area control controller manages various areas (up to 4) and can control:
- 1 to 4 ON/OFF thermal actuators
- one ON/OFF 3-speed or EC fan, depending on the equipment model
DGHKXPLGL¿HU
- one ON/OFF valve

9/142
AB Industrietechnik srl – Via Julius Durst, 70 – 39042 BRESSANONE (BZ) Italy – Tel: [phone] – [e-mail] – www.industrietechnik.it
Broadcast writing from MASTER to SLAVE
5HJLVWHUV 'HVFULSWLRQ
MASTER_WR_ON_OFF the MASTER controller ON/OFF sent depending on the I90 parameter
(see paragraph ³6ZLWFKRIIFRPPDQGIURPWKH0$67(5FRQWUROOHUWRWKH6/$9(FRQWUROOHUV´SDJH20)
MASTER_WR_EXT_TEMP Value of the external temperature sensor connected to the MASTER controller
MASTER_WR_SEASON Operational season set on the MASTER controller
MASTER_WR_SUPPLY_T Value of the delivery temperature on the MASTER controller
MASTER_WR_ALARM_DEWPOINT Alarm for temperature control lower than dew temperature + I45 on the MASTER controller
(see paragraph ³'HZSRLQWIXQFWLRQLQFRROLQJPRGH´SDJH59)
MASTER_WR_ALARM_CONDENS Indication of condensation alarm from external contact (M04=4 or M06=4) connected to the MASTER controller
MASTER_WR_ALARM_GEN Indication of general alarm from external contact (M04=6 or M06=6) connected to the MASTER controller
MASTER_WR_ALARM_LIM Indication of limit alarm on the MASTER controller, if the limit function is enabled
(see paragraph ³6XSSO\OLPLWVIXQFWLRQ´SDJH56)
MASTER_WR_ALARM_TEMP_CT Indication of high temperature from external contact (M04=7 or M06=7) connected to the MASTER controller
MASTER_WR_AUTHORIZATION Validity key of the broadcast data.
Register value = 32478 if the sent data is valid
Register value 32478 if the sent data is not valid
Data sent by the MASTER controller prevail over the local settings performed on the SLAVE controllers.
SLAVE FROM MASTER register reading
5HJLVWHUV 'HVFULSWLRQ
MASTER_RD_REG_ACTIVATION Fluid control request (request for column pump, circulator activation and valve control)
MASTER_RD_DEHUM_REQUEST 'HKXPLGL¿FDWLRQDFWLYDWLRQUHTXHVW
MASTER_RD_DEWPOINT_SLAVE Dew temperature value + I45 of the slave controller
MASTER_RD_ALARM_DEWPOINT Alarm for temperature lower than dew temperature + I45 on the SLAVE controller
MASTER_RD_ALARM_CONDENS
Indication of condensation alarm from external contact (M04=4 or M06=4) connected to the SLAVE controller
Sequence of messages sent or received by the MASTER controller:
Time (seconds) Messages on the Modbus network
0
ĻMASTER reading of the SLAVE 1 controller registries
1
ĻMASTER reading of the SLAVE 2 controller registries
2
ĻMASTER reading of the SLAVE 3 controller registries
n (*)
ĻMASTER reading of the SLAVE n (I85) controller registries
n + 1 Broadcast writing from the MASTER controller to all SLAVE controllers
(*) Number n depends on the number of available slaves. To optimize the Modbus communication, set the parameter I85=n.
,IDWOHDVWRQH6/$9(FRQWUROOHUUHTXLUHVÀXLGFRQWUROWKH0$67(5FRQWUROOHUDFWLYDWHVWKHFROXPQSXPSWKHFLUFXODWRUDQG
controls the valve.
,IDWOHDVWRQH6/$9(FRQWUROOHUVHQGVWKHGHKXPLGL¿FDWLRQDFWLYDWLRQUHTXHVWWKH0$67(5FRQWUROOHUDFWLYDWHVWKHGHKXPLGL-
¿HULIWKLVLVDYDLODEOHLQWKHFRQ¿JXUDWLRQRIWKH0$67(5FRQWUROOHU
,I DW OHDVW RQH 6/$9(B; FRQWUROOHU LQGLFDWHV WKH GHZ RU FRQGHQVH SRLQW WKH ÀXLG FRQWURO LV QR ORQJHU SHUIRUPHG RQ WKH
0$67(5FRQWUROOHUFROXPQSXPSFLUFXODWRUDQGYDOYHDUHGLVDEOHGWKHGHKXPLGL¿HULIDQ\LVHQDEOHG6HHSDUDJUDSK“26.
$ODUPV´SDJH63.
If the communication between the MASTER controller and the SLAVE controller is interrupted, after 120 seconds, the SLAVE
FRQWUROOHUGLVSOD\VWKHÀDVKLQJLFRQ and continues controlling based on its local settings.
Note: The MASTER controller is also able to manage a system without a slave controller composed of a pump, control valve,
WKHUPDODFWXDWRUDQGDQ\GHKXPLGL¿HUWRFRQWURODVLQJOHDUHD
The next pages contain system examples.

10/142 AB Industrietechnik srl – Via Julius Durst, 70 – 39042 BRESSANONE (BZ) Italy – Tel: [phone] – [e-mail] – www.industrietechnik.it
Vertical Modbus network between the MASTER controller and the SLAVE_Y controllers
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 1 ZONE 2 ZONE 3 ZONE 4
SLAVE Y SLAVE X SLAVE X
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 1 ZONE 2 ZONE 3 ZONE 4
SLAVE Y SLAVE X SLAVE X
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 1 ZONE 2 ZONE 3 ZONE 4
SLAVE Y SLAVE X SLAVE X
MASTER
MODBUS MODBUS MODBUS
The SLAVE_X controllers send the regulation request to the SLAVE_Y controller, through contact. The activation contact may
EHWKHRQHIURPWKHHOHFWURWKHUPDODFWXDWRURUWKHRQHIURPWKH6/$9(B;FRQWUROOHURQO\IRUFHUWDLQFRQ¿JXUDWLRQV
Key:
remote season change,
external temperature sensor, temperature sensor,
hot/cold water generator, column pump,
valve, circulator, ÀRRUK\GUDXOLFFLUFXLW
thermal actuator, thermal actuator with limit switch contact.

11/142
AB Industrietechnik srl – Via Julius Durst, 70 – 39042 BRESSANONE (BZ) Italy – Tel: [phone] – [e-mail] – www.industrietechnik.it
Vertical Modbus network between the MASTER controller and the SLAVE_Y controllers
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 1 ZONE 2 ZONE 3 ZONE 4
SLAVE Y SLAVE X SLAVE X
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 1 ZONE 2 ZONE 3 ZONE 4
SLAVE Y SLAVE X SLAVE X
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 1 ZONE 2 ZONE 3 ZONE 4
SLAVE Y SLAVE X SLAVE X
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 1 ZONE 2 ZONE 3 ZONE 4
MASTER SLAVE X SLAVE X
MODBUS MODBUS MODBUS
Certain SLAVE_X controllers send the regulation request to the SLAVE_Y through the contact, others to the MASTER
controller. The activation contact may be the one from the electrothermal actuator or the one from the SLAVE_X controller
RQO\IRUFHUWDLQFRQ¿JXUDWLRQV
Key:
remote season change,
external temperature sensor, temperature sensor,
hot/cold water generator, column pump,
valve, circulator, ÀRRUK\GUDXOLFFLUFXLW
thermal actuator, thermal actuator with limit switch contact.

12/142 AB Industrietechnik srl – Via Julius Durst, 70 – 39042 BRESSANONE (BZ) Italy – Tel: [phone] – [e-mail] – www.industrietechnik.it
Horizontal Modbus network between the MASTER controller and the SLAVE_X controllers
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 1 ZONE 2 ZONE 3 ZONE 4
MASTER SLAVE X SLAVE X
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 1 ZONE 2 ZONE 3 ZONE 4
MASTER SLAVE X SLAVE X
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 1 ZONE 2 ZONE 3 ZONE 4
MASTER SLAVE X SLAVE X
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 1 ZONE 2 ZONE 3 ZONE 4
MASTER SLAVE X SLAVE X
MODBUS
MODBUS
MODBUS
MODBUS
Each MASTER controller is independent from other MASTER controllers and is connected through Modbus to SLAVE_X
controllers.
The column pump is controlled by all MASTER controllers.
Each MASTER controller will have an external sensor, if necessary.
Key:
remote season change,
external temperature sensor, temperature sensor,
hot/cold water generator, column pump,
valve, circulator, ÀRRUK\GUDXOLFFLUFXLW
thermal actuator, thermal actuator with limit switch contact.

13/142
AB Industrietechnik srl – Via Julius Durst, 70 – 39042 BRESSANONE (BZ) Italy – Tel: [phone] – [e-mail] – www.industrietechnik.it
Single Modbus network between the MASTER controller and the SLAVE_X controllers
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 1 ZONE 2 ZONE 3 ZONE 4
SLAVE SLAVE
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 1 ZONE 2 ZONE 3 ZONE 4
SLAVE SLAVE
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 1 ZONE 2 ZONE 3 ZONE 4
SLAVE SLAVE
MASTER
MODBUS
MODBUS
MODBUS
MODBUS
MODBUS
The MASTER controller is connected through Modbus to the SLAVE_X controllers.
The column pump is controlled by the MASTER controller.
Key:
remote season change,
external temperature sensor, temperature sensor,
hot/cold water generator, column pump,
valve, circulator, ÀRRUK\GUDXOLFFLUFXLW
thermal actuator, thermal actuator with limit switch contact.

14/142 AB Industrietechnik srl – Via Julius Durst, 70 – 39042 BRESSANONE (BZ) Italy – Tel: [phone] – [e-mail] – www.industrietechnik.it
Network without Modbus
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 1 ZONE 2 ZONE 3 ZONE 4
SLAVE SLAVE
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 1 ZONE 2 ZONE 3 ZONE 4
SLAVE SLAVE
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 1 ZONE 2 ZONE 3 ZONE 4
SLAVE SLAVE
MASTER
The MASTER controller receives certain information only through the digital inputs
Key:
remote season change,
external temperature sensor, temperature sensor,
hot/cold water generator, column pump,
valve, circulator, ÀRRUK\GUDXOLFFLUFXLW
thermal actuator, thermal actuator with limit switch contact.

15/142
AB Industrietechnik srl – Via Julius Durst, 70 – 39042 BRESSANONE (BZ) Italy – Tel: [phone] – [e-mail] – www.industrietechnik.it
MASTER controller without slave for single area control
ZONE 1
MASTER
The MASTER controller controls a single area (vds ³&RQ¿JXUDWLRQVWDEOH´SDJH16)
Key:
external temperature sensor, temperature sensor,
valve, pump, ÀRRUK\GUDXOLFFLUFXLW
remote season change, thermal actuator.
SLAVE controller without master for single area control, fan-coil + valve
ZONE 1
SLAVE X

16/142 AB Industrietechnik srl – Via Julius Durst, 70 – 39042 BRESSANONE (BZ) Italy – Tel: [phone] – [e-mail] – www.industrietechnik.it
5. &RQ¿JXUDWLRQVWDEOH
• MASTER controller or SLAVE_Y controller:
&RQ¿JXUDWLRQ Controller type Column pump Thermal actuator
zone 2 'HKXPLGL¿HU ON/OFF
Valve
0..10 V
zone1
Valve
ON/OFF Output FRQ¿JXUDEOH
- 4 FH-2 or FH-4 DO1
(M15 = 12) DO2 (M16 = 7) --
DO3
(M17 = 10) DO5 (Note 2)
- 3 FH-2 DO1
(M15 = 12) DO2 (M16 = 7) -AO1 (M20 = 1) DO3 (Note 2)
- 2 FH-4 DO1
(M15 = 12) DO2 (M16 = 7) DO3 (M17 = 5) -DO4 (M18 = 10) DO5 (Note 2)
-1 FH-2 DO1
(M15 = 12) DO2 (M16 = 7) DO3 (M17 = 5) AO1 (M20 = 1) --
&RQ¿JXUDWLRQ Controller type Column pump Circulator 'HKXPLGL¿HU
ON/OFF Valve 0..10 V Valve ON/OFF Output FRQ¿JXUDEOH
0 1RWH FH-2 or FH-4 ------
1FH-2
DO1
(M15 = 12) DO2 (M16 = 11) DO3 (M17 = 5) AO1 (M20 = 1) --
2FH-4
DO1
(M15 = 12) DO2 (M16 = 11) DO3 (M17 = 5) -DO4 (M18 = 10) DO5 (Note 2)
3FH-2
DO1
(M15 = 12) DO2 (M16 = 11) -AO1 (M20 = 1) DO3 (Note 2)
4 FH-2 or FH-4 DO1
(M15 = 12) DO2 (M16 = 11) --
DO3
(M17 = 10) DO5 (Note 2)
1RWHIRUWKHFRQ¿JXUDWLRQDOORXWSXWVDUHGLVDEOHGDQGWKHGLJLWDODQGDQDORJXHLQSXWVDUHVHWWRGHIDXOWYDOXHV
• SLAVE_X controller
Control with one sensor/zone:
&RQ¿JXUDWLRQ Type
controller
Thermal
actuator
zone 1
Thermal
actuator
zone 2
Thermal
actuator
zone 3
Thermal
actuator
zone 4
Fan
zone 1 Fan zone 2 'HKXPLGL¿HU ON/OFF Output FRQ¿JXUDEOH
5FH-2 or
FH-4 DO1 (M15 = 6) --- - - DO2 (M16 = 5) DO5 (Note 2)
6FH-2 or
FH-4 DO1 (M15 = 6) DO2 (M16 = 7) -- - - DO3 (M17 = 5) DO5 (Note 2)
7FH-4
DO1
(M15 = 6) DO2 (M16 = 7) DO3 (M17 = 8) -- - DO4 (M18 = 5) DO5 (Note 2)
8FH-4
DO1
(M15 = 6) DO2 (M16 = 7) DO3 (M17 = 8) DO4 (M18 = 9) --DO5 (M19 = 5) -
9FH-2 or
FH-4 DO1 (M15 = 6) ---
ON/OFF
DO2
(M16 = 3) -DO3
(M17 = 5) DO5 (Note 2)
10 FH-4 DO1
(M15 = 6) DO2 (M16 = 7) --
ON/OFF
DO3
(M17 = 3)
ON/OFF
DO4
(M18 = 4)
DO5
(M19 = 5) -
11 FH-4 DO1
(M15 = 6) DO2 (M16 = 7) DO3 (M17 = 8) -ON/OFF
DO4
(M18 = 3) -DO5
(M19 = 5) -
12 FH-4 DO1
(M15 = 6) ---
3 speeds
DO2, DO3,
DO4
(M16 = 0, M17
= 1, M18 = 2)
-DO5
(M19 = 5) -
13 FH-2 DO1
(M15 = 6) ---
0..10 V
AO1
(M20 = 0) -DO5
(M19 = 5 / 10) DO3 (Note 2)
14 FH-2 DO1
(M15 = 6) DO2 (M16 = 7) --
0..10 V
AO1
(M20 = 0) -DO2
(M16 = 5 / 10) -
15 FH-2 DO1
(M15 = 6) DO2 (M16 = 7) DO3 (M17 = 8) -0..10 V
AO1
(M20 = 0) -- -

17/142
AB Industrietechnik srl – Via Julius Durst, 70 – 39042 BRESSANONE (BZ) Italy – Tel: [phone] – [e-mail] – www.industrietechnik.it
• SLAVE_X controller
Control with one sensor/zone, zone 1 has several thermal actuators that are controlled in order:
&RQ¿JXUDWLRQ Controller
type
Thermal
actuator 1
zone 1
Thermal
actuator 2
zone 1
Thermal
actuator 3
zone 1
Thermal
actuator 4
zone 1 Fan 1 zone 1 Fan 2 zone 1 'HKXPLGL¿HU
ON/OFF &RQ¿JXUDEOH output
16 FH-2 or
FH-4 DO1 (M15 = 6) DO2 (M16 = 7) -- - - DO3 (M17 = 5) DO5 (Note 2)
17 FH-4 DO1
(M15 = 6) DO2 (M16 = 7) DO3 (M17 = 8) -- - DO4 (M18 = 5) DO5 (Note 2)
18 FH-4 DO1
(M15 = 6) DO2 (M16 = 7) DO3 (M17 = 8) DO4 (M18 = 9) --DO5 (M19 = 5) -
19 FH-4 DO1
(M15 = 6) DO2 (M16 = 7) --
ON/OFF
DO3
(M17 = 3)
ON/OFF
DO4
(M18 = 4)
DO5
(M19 = 5) -
20 FH-4 DO1
(M15 = 6) DO2 (M16 = 7) DO3 (M17 = 8) -ON/OFF
DO4
(M18 = 3) -DO5
(M19 = 5) -
21 FH-2 DO1
(M15 = 6) DO2 (M16 = 7) --
0..10 V
AO1
(M20 = 0) -DO3
(M17 = 5) -
22 FH-2 DO1
(M15 = 6) DO2 (M16 = 7) DO3
(M17 = 8) -0..10 V
AO1
(M20 = 0) -- -
• SLAVE_X controller
Control with one sensor/zone, zones 1 and 2 have 2 thermal actuators that are controlled in order:
&RQ¿JXUDWLRQ Controller
type
Thermal
actuator 1
zone 1
Thermal
actuator 2
zone 1
Thermal
actuator 3
zone 2
Thermal
actuator 4
zone 2 Fan zone 1 Fan zone 2 'HKXPLGL¿HU
ON/OFF &RQ¿JXUDEOH output
23 FH-4 DO1
(M15 = 6) DO2 (M16 = 7) DO3 (M17 = 8) DO4 (M18 = 9) --DO5 (M19 = 5) -
Key:
- = not selected
DO1 = Digital output 1
DO2 = Digital output 2
DO3 = Digital output 3
DO4 = Digital output 4
DO5 = Digital output 5
AO1 = Analogue output 1
1RWHVHHWKHH[SODQDWLRQVLQSDUDJUDSK³FRQ¿JXUDEOHGLJLWDORXWSXWVHWXS´EHORZ
&RQ¿JXUDEOHGLJLWDORXWSXWVHWXS
&RQ¿JXUDWLRQVDQGUHODWHGWRWKH)+FRQWUROOHUVKDYHWKH'2RXWSXWFRQ¿JXUDEOHVXFKDVWKHLQGLFDWLRQ
for exceeded condensation or dew point (M19=13), control request (M19=14), season change (M19=15) or no function
(M19=16).
&RQ¿JXUDWLRQVUHODWHGWRWKH)+FRQWUROOHUVKDYHWKH'2RXWSXWFRQ¿JXUDEOHVXFKDVWKHLQGLFDWLRQ
for exceeded condensation or dew point (M19=13), control request (M19=14) or no function (M19=16).
&RQ¿JXUDWLRQVDQGUHODWHGWRWKH)+FRQWUROOHUVKDYHWKH'2RXWSXWFRQ¿JXUDEOHVXFKDV WKHLQGLFDWLRQIRU
exceeded condensation or dew point (M17=13), control request (M17=14), season change (M17=15) or no function
(M17=16).
&RQ¿JXUDWLRQUHODWHGWRWKH)+FRQWUROOHUVKDYHWKH'2RXWSXWFRQ¿JXUDEOHVXFKDVGHKXPLGL¿HUM19=5 and
M23=0) or on/off valve (M19=10 and M23=1).
&RQ¿JXUDWLRQVUHODWHGWRWKH)+FRQWUROOHUVKDYHWKH'2RXWSXWFRQ¿JXUDEOHVXFKDVGHKXPLGL¿HUM16=5 and
M23=0) or on/off valve (M16=10 and M23 DQG'2RXWSXWFRQ¿JXUDEOHVXFKDVWKHLQGLFDWLRQIRUH[FHHGHGFRQGHQVD-
tion or dew point (M17=13), control request (M17=14) or no function (M17=16).
7KHGHKXPLGL¿HUGRHVQRWEHORQJWRDQ\]RQH

18/142 AB Industrietechnik srl – Via Julius Durst, 70 – 39042 BRESSANONE (BZ) Italy – Tel: [phone] – [e-mail] – www.industrietechnik.it

19/142
AB Industrietechnik srl – Via Julius Durst, 70 – 39042 BRESSANONE (BZ) Italy – Tel: [phone] – [e-mail] – www.industrietechnik.it
6. &RQ¿JXUDWLRQRITXLFNDFFHVVSDUDPHWHUV
The controller provides the following functions with a simple press of a button:
• Switch on and off
• &RQ¿JXUDWLRQRIWKHVHWSRLQWRUVHWSRLQWRIIVHW
• Fan operating mode
• MODE button functionality
The MODE button can be assigned one quick access function and other normal access functions, depending on parameter
I74 (see ³02'(EXWWRQIXQFWLRQ´SDJH22)
I74=0: season change (if it is local, for 2-pipe systems)
I74=1: zone 1 timer extension
I74=2: zone 2 timer extension
I74=3: zone 3 timer extension
I74=4: zone 4 timer extension
I74=5: operating mode (without clock, using time slots, holiday)
• Keypad lock
To lock the keypad, press buttons ESC
M
O
D
E
at the same time; the display shows LK for one second.
When any button is pressed, it is no longer possible to access the parameters and the display shows LK.
To unlock the keypad, press the buttons ESC
M
O
D
E
again; the display shows NLK for one second.
• Switch on and off
Distinction can be made between two types of switch on/off commands:
- global command
- local command for one zone
The global command switches off all equipment and may be performed in 3 ways:
- manually using the button,
- from an external contact,
- from the Modbus (solely for the SLAVE controller with Modbus)
The local command switches off only one zone and may be performed in two ways:
- manually by accessing parameters OC1 for zone 1, OC2 for zone 2, OC3 for zone 3, OC4 for zone 4
- automatically from the clock, programming the time slots of the 4 zones (if I78=1)
Global commands:
Switching on/off from an external contact has maximum priority. If the external contact is in OFF position, the equip-
ment cannot be manually restarted or by Modbus or by time slots.
7RXVHWKHH[WHUQDOFRQWDFWDVDZD\RIVZLWFKLQJRQRURIIWKHDSSOLDQFHFRQ¿JXUHDGLJLWDOLQSXWDV³5HPRWH2Q2II´
(M04=1 or M06=1).
Example for digital input 1 (M04=1):
Unit ON= (M05=0)
Unit OFF= (M05=0)
Unit ON= (M05=1)
Unit OFF= (M05=1).
,IWKHH[WHUQDOFRQWDFWLVRQ21SRVLWLRQRULWLVQRWFRQ¿JXUHGZLWK³5HPRWH2Q2II´IXQFWLRQDOLW\DSSOLDQFHFDQEH
switched on or off by pressing button (until ON or OFF is displayed) or through Modbus (through the ON_OFF_VIA_
MODBUS register (see ³0RGEXVIRU)+[0[6+PRGHOV´SDJH103).
The manual global switch on/off has the same priority as the one through Modbus. This means that if the appliance is
globally off in manual mode, it can be restarted through Modbus or viceversa.

20/142 AB Industrietechnik srl – Via Julius Durst, 70 – 39042 BRESSANONE (BZ) Italy – Tel: [phone] – [e-mail] – www.industrietechnik.it
Local commands:
7RXVHWKHVZLWFKLQJRQRIIE\WLPHVORWVFRQ¿JXUHSDUDPHWHUI78=1 and set the switch on time slots (see “8. TIMER
6/276RSHUDWLRQDQGFRQ¿JXUDWLRQ0RGHO)+[[&6+´SDJH31).
To manually switch off zone 1, set parameter OC1 to OFF1.
To manually switch off zone 2, set parameter OC2 to OFF2.
To manually switch off zone 3, set parameter OC3 to OFF3.
To manually switch off zone 4, set parameter OC4 to OFF4.
To switch off a zone via Modbus, write in the relevant register (see ³0RGEXVIRU)+[0[6+PRGHOV´SDJH103).
To switch off area 1, write value 2 in the register MANUAL_OCCUPANCY_ZONE_1.
To switch off area 2, write value 2 in the register MANUAL_OCCUPANCY_ZONE_2.
To switch off area 3, write value 2 in the register MANUAL_OCCUPANCY_ZONE_3.
To switch off area 4, write value 2 in the register MANUAL_OCCUPANCY_ZONE_4.
Switch off command from the MASTER controller to the SLAVE controllers:
7KH0$67(5FRQWUROOHUPD\EHVZLWFKHGRIIWKURXJKH[WHUQDOFRQWDFWLIRQHRIWKHGLJLWDOLQSXWVLVFRQ¿JXUHGDV³5H-
mote On/Off” (M04=1 or M06=1), manually (by pressing button or setting parameter OC1 to OFF1) or using time slots.
Depending on the values of parameter I90, switching off the MASTER controller may cause the horizontal controllers
to switch off.
I90 ON/OFF sent by the MASTER controller
0 ON/OFF not sent
1 ON/OFF from an external contact
2 Manual ON/OFF
3 Manual ON/OFF or from an external contact
4 ON/OFF from the time slots
5 ON/OFF from an external contact and from the time slots
6 Manual ON/OFF and from the time slots
7 Manual ON/OFF, from an external contact and from the time slots
Note: SLAVE_Y controllers are never switched off by the MASTER controller.
If the appliance is switched off, the display shows the mode in which it was switched off.
OFF
MA MA = global manual switch off using button .
OFF
reM reM = switched off using remote contact.
OFF
MOD MOD = switched off by Modbus.
OFF
tiMb tiMb =switched off using time slots (if I78=1).This mask is shown only on the MASTER controller.
If one zone is switched off, icon will be lit on display for the displayed switched off zone.
If the appliance is switched off globally, all outputs are disabled.
If one zone is switched off, only the outputs related to that area are disabled.
