Infinova V6822-T0 Series User manual

V6822-T0 Series
HD 1MP and 2MP Vandal Resistant Low Light
IP Minidome Camera
User Manual

Notice
Copyright Statement
This manual may not be reproduced in any form or by any means to create any
derivative such as translation, transformation, or adaptation without the prior
written permission of Infinova.
Infinova reserves the right to change this manual and the specifications without
prior notice. The most recent product specifications and user documentation for
all Infinova products are available on our web site www.infinova.com.
Trademarks
Infinova
® is a trademark of Infinova.
All other trademarks that may appear belong to their respective proprietors.
FCC Warning
The V6822-T0 series HD megapixel low light IP minidome cameras comply
with the FCC rules.
Operation is subject to the following two conditions:
This device will not cause harmful interference.
This device must accept any interference received, including interference
that may cause undesired operations.
The V6822-T0 series HD megapixel low light IP minidome cameras have been
tested and found to comply with the limits for a Class A digital device, pursuant
to the FCC rules. With these rules and regulations being obeyed to maintain the
good working condition of device, the operation is not supposed to be affected
by the external interruptions under certain circumstances. This device is
electromagnetic, so all the installation and application processing along the
device has to follow strictly to the manual, or it may hamper the
telecommunication around. Meanwhile, there is no guarantee that interference
will not occur in a certain particular installation situation.

Read this manual carefully before installation. This manual
should be saved for future use.
Important Safety Instructions and Warnings:
Electronic devices must be kept away from water, fire or high magnetic
radiation.
Clean with a dry cloth.
Provide adequate ventilation.
Unplug the power supply when the device is not to be used for an extended
period of time.
Only use components and parts recommended by manufacturer.
Position power source and related wires to assure to be kept away from
ground and entrance.
Refer to qualified personnel for all service matters.
Save product packaging to ensure availability of proper shipping containers
for future transportation.
Indicate that the un-insulated components within the product may carry a
voltage harmful to humans.
Indicate operations that should be conducted in strict compliance with
instructions and guidelines contained in this manual.
Warning: To avoid risk of fire and electric shock, keep the product away
from rain and moisture!

CONTENTS
Chapter I System Introduction .................................................................. 1
1.1 Product Description................................................................................. 1
1.2 Product Features ...................................................................................... 1
1.3 System Requirement ............................................................................... 2
1.4 Product Model ......................................................................................... 3
1.5 Specifications .......................................................................................... 3
1.6 Precautions .............................................................................................. 5
Chapter II Installation Instruction............................................................ 7
Chapter III IE Browser Settings...............................................................11
3.1 Equipment Connection...........................................................................11
3.2 Software Installation ..............................................................................11
Chapter IV Basic Function Operation.................................................... 14
4.1 Browsing Videos ................................................................................... 14
4.2 System ................................................................................................... 17
4.3 Network Settings ................................................................................... 22
4.4 Camera Settings..................................................................................... 30
4.5 Audio & Video Settings......................................................................... 36
4.6 Alarm Settings ....................................................................................... 45
4.7 Record Management ............................................................................. 47
4.8 Account Settings.................................................................................... 51
4.9 System Log............................................................................................ 53
Appendix I Magnetic Ring Filter Instruction......................................... 55
Appendix II Questions & Solutions......................................................... 56
Appendix III Cable Diameter Calculation and Lightning & Surge
Protection.................................................................................................... 57

1
CHAPTER I SYSTEM INTRODUCTION
1.1 Product Description
Infinova’s V6822-T0series HD megapixel IP minidome camera features
miniature structure. Utilizing 1/3" progressive scan CMOS sensor, built-in
3.0-9.0mm vari-focal lens and H.264 High profile/ M-JPEG video compression
formats, this series can output real-time image with resolution up to
30fps@1920×1080 or 30fps@1280×720.
V6822-T0series supports three simultaneous video streams, bi-directional
audio in the G.711 compression format, and IR-Cut Removable (ICR) filter for
day/night switching; also, it supports motion detection functions, which are able
to link with alarm to store and snapshoot images. Privacy mask can protect
certain private area from being seen by operator. Power over Ethernet (PoE)
greatly simplifies transmission cable.
V6822-T0series minidome camera is suitable for financial institutions,
telecommunications, governments, schools, airports, factories, hotels, museums,
city streets and other high-resolution surveillance applications.
1.2 Product Features
Infinova’s V6822-T0series camera has the following features and functions:
1/3" progressive scan CMOS sensor
IR-Cut Removable (ICR) Filter for Day/Night switching
Supports WDR function
Sensitivity: 0.01 lux
Onvif Profile S
High-resolution image signal output: up to 1920×1080, with 1280×1024,
1280×960, 1280×720, 1024×768 and 800×600 optional (for V6822-T02
series)
High-resolution image signal output: up to 1280×720, with 1024×768 and
800×600 optional (for V6822-T00 series)

2
Low band width for high quality images
High frame rate transmission: up to 30fps
Three Simultaneous Video Streams: Dual H.264 High profile & Scalable
M-JPEG
Smooth dynamic video
Bi-directional audio, G.711
Support storage with TF card
Supports active video tampering
Supports motion detection, up to four areas
Supports privacy mask, up to four masks
Local recording
2 alarm inputs, 1 relay output
Supports multiple ways to handle alarms, such as sending an email, FTP
upload, audible alarm and relay output
Supports simultaneous multi-user access and parameters configuration via
Web Server
Compatible with Infinova’s V2216 digital video surveillance software, easy
to integrated with other video surveillance software
Provides standard SDK, easily incorporated with the digital surveillance
system of other brands
Provides analog video debugging interface
Utilizes vandal resistant minidome bubble for all-day protection
Able to adjust Panning, Tilting and Rotating angles
1.3 System Requirement
Minimum PC Requirements:
CPU: Intel Pentium 4, 2.4 GHz or above
RAM: 512 MB or above
Network Port: 100M Ethernet port
Operating System: Microsoft Windows 7, Microsoft Windows XP
IE Browser Version: Microsoft Internet Explorer 6.0 or above

3
1.4 Product Model
This manual is for the following models:
V6822-T0220SF HD Megapixel IP minidome camera, Vandal-resistant,
3-axis, Day/night, 1/3 inch CMOS sensor,
H.264/M-JPEG, 2.0 Mpx, PoE/12VDC/24VAC,
Surface mount, 3.0-9.0mm vari-focal lens
V6822-T0020SF HD Megapixel IP minidome camera, Vandal-resistant,
3-axis, Day/night, 1/3 inch CMOS sensor,
H.264/M-JPEG, 1.0 Mpx, PoE/12VDC/24VAC,
Surface mount, 3.0-9.0mm vari-focal lens
1.5 Specifications
Model V6822-T0 series
Image Sensor 1/3" low light progressive scan CMOS
Dynamic Range 72.4dB
Lens F1.2, f=3.0-9.0mm
Camera Angle Adjustment X (Panning): 0°~340°; Y (Tilting): 0°~80°;
Z (Rotating): 0°~340°
Day/Night Functionality ICR
Sensitivity
V6822-T00: Color mode: 0.01 lux @ F1.2 (30IRE,
AGC ON); B/W mode: 0.001 lux @ F1.2 (30IRE, AGC
ON)
V6822-T02: Color mode: 0.05 lux @ F1.2 (30IRE,
AGC ON); B/W mode: 0.01 lux @ F1.2 (30IRE, AGC
ON)
Exposure Scene mode, Manual mode, Shutter priority mode
Shutter Auto/Manual (1/25s~1/8000s)
White Balance Auto/Manual/Incandescent light/Cool white fluorescent
light/Sun light/Cloudy/Natrium light
AGC Auto/Manual
FNR 3D

4
Video Compression H.264 High profile/M-JPEG
Maximum Resolution 1920×10[email protected]/M-JPEG (for V6822-T02 series);
1280×72[email protected]/M-JPEG (for V6822-T00 series)
Optional Resolution
Major stream:
1920×1080, 1280×1024, 1280×960, 1280×720,
1024×768, 800×600 (for V6822-T02 series),
1280×720, 1024×768, 800×600 (for V6822-T00
series);
Minor stream: 720×576, 720×480, 640×480, 352×288,
352×240
Maximum Frame Rate 30fps
Data Rate Variable bit rate;
Constant bit rate: 256Kbps~10Mbps
Audio
Audio Compression: G.711-u;
1 input (Linear level, Resistance: 1000 Ohm),
1 output (Linear level, Resistance: 600 Ohm)
Network Delay ≤250ms
Motion Detection Up to 4 areas
Privacy Mask Up to 4 masks
Local Recording Available
Upgrade Online Available
Password Protection Available
Network Port 1 RJ45 10/100M self-adaptive Ethernet port
Applicable Protocols
IPv4, IPv6, TCP, UDP, IGMP, DHCP, FTP, SNMP (V3),
SMTP, NTP, RTP, RTSP, RTCP, HTTP, HTTPS, TSL,
SSL, 802.1X, QoS, PPPoE, DNS, ARP, ICMP, UPNP,
DDNS, Profile S
Alarm 2 alarm inputs, 1 relay output
Power Supply 12VDC/24VAC/PoE (IEEE 802.3af Class 2)
Power Consumption <4W
Operating Temperature 14°F ~ 122°F (-10°C ~ 50°C)
Storage Temperature -4°F ~ 140°F (-20°C ~ 60°C)

5
Operating Humidity 0~90% RH (non-condensing)
Unit Dimensions (H×Ø) 4.07"×5.20" (103.3mm×132mm)
Unit Weight 1.76lbs. (0.80kg)
Shipping Weight 2.31lbs. (1.05kg)
1.6 Precautions
1. Do not drop the camera or subject it to strong knock.
2. Do not point the camera lens toward the sun or other strong light.
3. Do not install the camera in environment with temperature beyond the
acceptable range (from -10°C to 50°C).
4. Never let liquid of any kind flow into this unit.
5. Do not directly touch the CMOS element. If it is necessary to clean the
element, use a soft cloth moistened with alcohol to wipe off the dust.
6. If any abnormality occurs, make sure to unplug the unit and contact your
local dealer.
7. This camera features AGC circuit, so when the camera is applied under
low illumination, sensitivity will enhance automatically, making images
look rough, which is normal.
8. Under the default setting, the lens has been adjusted till the object in a
1.5m-distance becomes clear. The lens can be readjusted as per the actual
surveillance scenes.
9. Lens Adjusting:
a. Loosen the zoom tightening knob and the focus tightening knob.
b. Slowly rotate the zoom ring to adjust the focal length.
c. After a zoom operation, slowly rotate the focus ring to obtain the
sharpest image on the monitor.
d. If there are still blurred images, loosen the locking screw with an Allen
wrench to adjust the back focal length and repeat the above
procedures.
e. Tighten the zoom tightening knob, the focus tightening knob and the

6
locking screw.
10.The camera power supply can be 12VDC/24VAC or PoE. Be sure of the +/-
terminal correct when the camera is connected with 12VDC power supply.
24VAC power supply must be isolated power.
11.Firstly perform network settings after login. Gateway IP address should be
set to the IP address of the gateway that the device connects to.
12.The IP address of the device should not conflict with other IP address; or
else no video will be available.

7
CHAPTER II INSTALLATION INSTRUCTION
Step 1: Prepare mounting holes
According to the figures below to drill mounting holes and cable hole at the
desired position.
Figure 2-1 Base
(Unit: mm)
Figure 2-2
Step 2: Install upper housing
Loosen the three mum-head screws in bubble flange and take off the bubble.
For ease of installation, upper housing and dome bubble are connected with a
safety rope.

8
Install the upper housing to the desired position with three M4×25 conical
tapping screws and then arranged the cables.
Figure 2-3
There are Audio, Power, Alarm In, Relay Out and Network ports in the upper
module. (See Figure 2-4 for location.)
Figure 2-4
V6822-T0series cameras support bi-directional audio, providing with 1-ch
audio input and 1-ch audio output. They also support 2-ch alarm inputs and
1-ch relay output. In addition to 12VDC/24VAC power supply, they can work
on power over Ethernet (PoE). As shown in the figure above, G indicates audio
or alarm ground.
Step 3: Adjust viewing angle
Check whether the cables are properly and firmly connected before powering
on. Remember to visit the device about 70 seconds after power-on. At the
moment, loosen the knurled thumb screws to adjust the camera angle according
to your surveillance need. Then fasten the screws. The camera features X, Y, Z

9
3-axis adjustment. It allows 0°~340° panning adjustment, 0°~80° tilting
adjustment and 0°~340° rotating adjustment.
Figure 2-5
Step 4: Install dome bubble
Install the bubble flange to upper housing. Align the screw holes of the two
parts. Rotate the bubble to make the gap of the shielding cover align with the
lens. Then pre-tighten the three M4 screws. Rotate the bubble slightly to make
the lens lie in the middle of the gap (See Figure 2-7). Then, fasten the three M4
screws.
With all the procedures finished, user should further confirm whether each part
of the device is properly and firmly connected.
Figure 2-6

10
Figure 2-7
Dimensions (Unit: inch, in the parentheses is mm)
Figure 2-8

11
CHAPTER III IE BROWSER SETTINGS
When view the video, the user need to adjust the IE browser of the monitor or
other video devices, and set proper system function based on the following
instructions:
Support IE browser version: Internet Explorer 6.0 or above;
Must install InfiPlayerAX control and equip with Directx 9.0c.
3.1 Equipment Connection
V6822-T0series IP minidome camera can be directly connected to a computer,
or connected to a network.
Note: Check whether the connection is tight or not before power-on.
3.2 Software Installation
The installation procedures of V6822-T0series camera image software are
listed as follows:
(1) Login
First, start IE browser and enter IP address. Enter user name and password in
the pop-up login interface.
The default IP address is http://192.168.1.100; the default subnet mask is
255.255.255.0 and the default gateway IP address is 192.168.1.254. For normal
access, correctly set local IP parameters before system login.
Do log in the system with the default super user for the first time to run the
software. The default Super User is admin (password: admin).
(2) Install and run Control
There are two ways to install control.
Method 1:
The prompt message as below will come out in live view window after a

12
successful login. Click the link to run, or store the exe file, then run it.
Figure 3-1
If the installation fails, check whether there is video viewed through other IE
window or page. You should close the video or the IE window directly.
If it successes, click refresh, you can view the live video.
Method 2:
The prompt message as below will come out in the page after a successful
login. Right click “Add-on Disabled” and select “Run Add-on”.
Figure 3-2
Then the prompt of security warning will pop up to remind the user to install
InfiPlayerAX control. Click “Install”.
Figure 3-3
After InfiPlayerAX control is installed, you can view the live video. If it pops
up reboot prompt, please cancel reboot. Then close all the IE window and
install InfiPlayerAX control once again. The live video will display as below:

13
Figure 3-4
Note:
If InfiPlayerAX control installation falls, the live video won’t display. Then,
you should change the IE security level.
1. Click “Tool” in the menu bar, and then select “Internet Options” from the
drop-down menu.
2. Select “Security” in the pop-up Internet options, as shown in the following
figure:
3. Click “Internet” icon, then click “Custom Level” to pop up the following
interface:
4. Select “Enable” or “Prompt” in the options of “Download unsigned
ActiveX controls”.
5. Select “Privacy” in the Internet options and uncheck the checkbox of
“Block pop-ups”. Refresh the webpage and set up the ActiveX control as
per the prompts and then live view interface appears normally.
By now, the preparation for image viewing with IE browser comes to an end.

14
CHAPTER IV BASIC FUNCTION OPERATION
This chapter mainly introduces the settings and operation of V6822-T0series.
4.1 Live View
Start IE browser after the server is powered on for about 75 seconds, and then
enter IP address, such as http://192.168.1.100 (default), in the address field.
Note: The default subnet mask is 255.255.255.0 and the default gateway IP
address is 192.168.1.254. For normal access, please correctly set local IP
parameters before system login.
The login interface is displayed as shown in figure below in English operating
system.
Figure 4-1 User Login
Do login the system with the default super user for the first time to run the
software. The system default Super User is admin (password: admin). Input the
correct user ID and password and then press “OK” button to login the system.
After login is successful, the following interface will display:

15
Figure 4-2 Live View
V6822-T0series IP minidome camera supports H.264 and M-JPEG video
compression formats. After successful login, it enters H.264 major stream live
video interface. Users can also select H.264 minor stream or MJPEG from the
dropdown list of stream type. In the H.264 major or minor stream type, users
can do recording, snap shootting, and audio in/out settings. Over browsing
videos, users can also select a proper video scale.
Click the button to snapshoot and to enter the storage path. Default:
C:\InfiPlayerAX\Picture.
V6822-T0 series supports local recording. Click the recording button to start
recording; when the button changes to , click it to stop recording. During local
recording, “REC”appears on the video screen. Click the button to enter the
recording storage path. Default: C:\InfiPlayerAX\ Video.

16
Users can set the snapshootting and recording storage path in the audio and video
settings interface.
Indicate audio input/output disabled. Click the buttons to enable audio
input/output and then the buttons will be shown as .
Indicate that the motion detection and privacy mask functions are
disabled. Click the buttons to enable them and then the buttons will be shown
as .
Note: only when motion detection or privacy mask is enabled, you can set the
corresponding function in Audio & Video Settings, refer to Section 4.5.3 or
4.5.4 for details.
Note: the login web page language should be set to the same as that of PC’s
operating system.
Click the option tab “Settings”to enter the system setting interface.
Figure 4-3 Settings Interface
