InFocus IN119HDxa User manual

1English
Setup |
Audio Settings.................................... 44
Setup |
Advanced........................................... 45
Options .............................................. 46
Options | Advanced............................ 48
Options |
Lamp Settings.................................... 49
Options | ........................................... 50
Optional Filter .................................... 50
Settings............................................. 50
Appendices....................................51
Troubleshooting ................................51
Image Problems................................. 51
Other Problems.................................. 53
Remote Control Problems ................. 53
LED Lighting Messages..................... 54
On Screen Messages ........................ 55
Replacing the Lamp..........................56
Installing and Cleaning the Dust Filter.. 58
Compatibility Modes .........................59
Ceiling Mount Installation..................61
Regulation & Safety Notices .............62
FCC Notice ........................................ 62
Declaration of Conformity for
EU countries ...................................... 63
Table of Contents ............................1
Usage Notice...................................2
Safety Information...............................2
Precautions.........................................3
Eye Safety Warnings ..........................6
Introduction......................................7
Package Overview..............................7
Product Overview ...............................8
Main Unit.............................................. 8
Keypad................................................. 9
Input/Output Connections .................. 10
Remote Control.................................. 11
Installation .....................................12
Connecting to the Projector ..............12
Connecting a Computer/Notebook .... 12
Connecting a Video source................ 13
Connect to 3D Video Devices...........14
Using the 3D glasses........................16
Powering On/O the Projector..........17
Powering On the Projector................. 17
Powering O the Projector ................ 18
Warning Indicator............................... 19
Adjusting the Projected Image..........20
Adjusting the Projector’s Height ........ 20
Adjusting the Projector’s Zoom / Focus... 21
Adjusting Projection Image Size ........ 21
User Controls ................................23
Keypad & Remote Control ................23
Keypad............................................... 23
Remote Control.................................. 24
On-screen Display Menus ................30
How to operate .................................. 30
Menu Tree.......................................... 31
Image................................................. 35
Image | Advanced .............................. 37
Display ............................................... 39
Display | 3D ...................................... 41
Setup ................................................. 42
Table of Contents

2
English
Usage Notice
The lightning ash with arrow head within an equilateral triangle is
intended to alert the user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may be of su󰀩cient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH
VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE
CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY.
Class B emissions limits
This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
Important Safety Instruction
1. Do not block any ventilation openings. To ensure reliable operation of the
projector and to protect from over heating, it is recommended to install the
projector in a location that does not block ventilation. As an example, do
not place the projector on a crowded co󰀨ee table, sofa, bed, etc. Do not
put the projector in an enclosure such as a book case or a cabinet that
restricts air ow.
2. Do not use the projector near water or moisture. To reduce the risk of re
and/or electric shock, do not expose the projector to rain or moisture.
3. Do not install near heat sources such as radiators, heaters, stoves or any
other apparatus such as ampliers that emit heat.
4. Clean only with dry cloth.
5. Only use attachments/accessories specied by the manufacturer.
6. Do not use the unit if it has been physically damaged or abused. Physical
damage/abuse would be (but not limited to):
- Unit has been dropped.
- Power supply cord or plug has been damaged.
- Liquid has been spilled on to the projector.
- Projector has been exposed to rain or moisture.
- Something has fallen in the projector or something is loose inside.
Do not attempt to service the unit yourself. Opening or removing covers
may expose you to dangerous voltages or other hazards. Please call
InFocus before you send the unit for repair.
7. Do not let objects or liquids enter the projector. They may touch
dangerous voltage points and short out parts that could result in re or
electric shock.
8. See projector enclosure for safety related markings.
9. The unit should only be repaired by appropriate service personnel.
Safety Information

3English
Usage Notice
Please follow all warnings, precautions and
maintenance as recommended in this user’s guide.
When the lamp
reaches the end
of its life, the
projector will not
turn back on until
the lamp module
has been replaced.
To replace the
lamp, follow the
procedures listed
under “Replacing
the Lamp”
section on pages
56-57.
▀■Warning- Do not look into the projector’s lens when the
lamp is on. The bright light may hurt your eyes.
▀■Warning- To reduce the risk of  re or electric shock, do
not expose this projector to rain or moisture.
▀■Warning- Please do not open or disassemble the
projector as this may cause electric shock.
▀■Warning- When replacing the lamp, please allow the unit
to cool down. Follow instructions as described
on pages 56-57.
▀■Warning- This projector will detect the life of the lamp
itself. Please be sure to change the lamp when
it shows warning messages.
▀■Warning- Reset the “Lamp Reset” function from the on-
screen display “Options|Lamp Settings” menu
after replacing the lamp module (refer to page
49).
▀■Warning- When switching the projector o󰀨 , please ensure
the cooling cycle has been completed before
disconnecting power. Allow 90 seconds for the
projector to cool down.
▀■Warning- When the lamp is approaching to the end of its
life time, the message “Lamp life exceeded.”
will show on the screen. Please contact your
local reseller or service center to change the
lamp as soon as possible.
Precautions

4
English
Usage Notice
Do:
Turn o󰀨 and unplug the power plug from the AC outlet before
cleaning the product.
Use a soft dry cloth with mild detergent to clean the display
housing.
Disconnect the power plug from AC outlet if the product is not
being used for a long period of time.
Do not:
Block the slots and openings on the unit provided for ventilation.
Use abrasive cleaners, waxes or solvents to clean the unit.
Use under the following conditions:
- In extremely hot, cold or humid environments.
`Ensure that the ambient room temperature is within 5°C ~
40°C
`Relative humidity is 10% ~ 85%
- In areas susceptible to excessive dust and dirt.
- Near any appliance generating a strong magnetic eld.
- In direct sunlight.
Viewing 3D projection using the 3D function
IMPORTANT SAFETY INFORMATION. READ THE FOLLOWING
WARNINGS BEFORE YOU OR YOUR CHILD USE THE 3D FUNCTION.
Warning
Children and teenagers may be more susceptible to health issues
associated with viewing in 3D and should be closely supervised
when viewing these images.
Photosensitive Seizure Warning and Other Health Risks
Some viewers may experience an epileptic seizure or stroke when
exposed to certain ashing images or lights contained in certain
Projector pictures or video games. If you su󰀨er from, or have a
family history of epilepsy or strokes, please consult with a medical
specialist before using the 3D function.
Even those without a personal or family history of epilepsy or
stroke may have an undiagnosed condition that can cause
photosensitive epileptic seizures.

5English
Usage Notice
Pregnant women, the elderly, su󰀨erers of serious medical
conditions, those who are sleep deprived or under the inuence of
alcohol should avoid utilizing the unit’s 3D functionality.
If you experience any of the following symptoms, stop viewing
3D pictures immediately and consult a medical specialist: (1)
altered vision; (2) light-headedness; (3) dizziness; (4) involuntary
movements such as eye or muscle twitching; (5) confusion; (6)
nausea; (7) loss of awareness; (8) convulsions; (9) cramps; and/
or (10) disorientation. Children and teenagers may be more
likely than adults to experience these symptoms. Parents should
monitor their children and ask whether they are experiencing
these symptoms.
Watching 3D projection may also cause motion sickness,
perceptual after e󰀨ects, disorientation, eye strain and decreased
postural stability. It is recommended that users take frequent
breaks to lessen the potential of these e󰀨ects. If your eyes
show signs of fatigue or dryness or if you have any of the above
symptoms, immediately discontinue use of this device and do not
resume using it for at least thirty minutes after the symptoms have
subsided.
Watching 3D projection while sitting too close to the screen for
an extended period of time may damage your eyesight. The
ideal viewing distance should be at least three times the screen
height. It is recommended that the viewer’s eyes are level with the
screen.
Watching 3D projection while wearing 3D glasses for an extended
period of time may cause a headache or fatigue. If you experience
a headache, fatigue or dizziness, stop viewing the 3D projection
and rest.
Do not use the 3D glasses for any other purpose than for
watching 3D projection. Wearing the 3D glasses for any other
purpose (as general spectacles, sunglasses, protective goggles,
etc.) may be physically harmful to you and may weaken your
eyesight.
Viewing in 3D projection may cause disorientation for some
viewers. Accordingly, DO NOT place your 3D PROJECTOR near
open stairwells, cables, balconies, or other objects that can be
tripped over, run into, knocked down, broken or fallen over.

6
English
Usage Notice
▀■Avoid staring/facing directly into the projector beam at all
times. Keep your back to the beam as much as possible.
▀■When projector is used in a classroom, adequately supervise
students when they are asked to point out something on the
screen.
▀■In order to minimize the lamp power, use room blinds to
reduce ambient light levels.
Eye Safety Warnings

7English
Introduction
Unpack and inspect the box contents to ensure all parts listed
below are in the box. If something is missing, please contact
InFocus customer service.
Package Overview
Standard Accessories

CD User Manual

Quick Start Card
Projector Power Lead Documentation
VGA
Ent er
Menu Zoom
Remote HDMI Cable

8
English
Introduction
Product Overview
Main Unit
Do not block
projector in/out air
vents.
1. Lens
2. IR Receivers
3. Keypad
4. Input / Output
Connections
5. Power Socket
6. Tilt-Adjustment Feet
7. Speaker
8. Zoom Lever
9. Focus Ring
10. Lamp Cover
11. Ventilation (inlet)
12. Ventilation (outlet)
13. KensingtonTM Lock Port
7
6
9
810 12
11
613
1 32 54

9English
Introduction
Keypad
11
1 3
10
5
1. Source
2. Enter
3. Keystone Correction
4. Re-Sync
5. Menu
6. Help
7. Lamp LED
8. On/Standby LED
9. Power
10. Temperature LED
11. Four Directional Select Keys
6
7
2 4
8 9

10
English
Introduction
Input/Output Connections
AUDIO-OUT 12V OUT Out (5V)
3D SYNC
HDMI 1
HDMI 2
USB
1. 12V Relay Trigger (12V, 250mA, 3.5mm mini jack)
2. 3D Sync Out (5V) connector
3. HDMI 1 connector
4. Security Bar
5. Audio Out connector (3.5mm mini jack)
6. HDMI 2 connector
7. USB-B mini connector (Firmware upgrade)
8. Power Socket
2 31
4 7 86
5
Remote mouse
requires special
remote.

11 English
Introduction
Remote Control
The interface is
subject to model’s
speci cations. 1. Source
2. Re-Sync
3. Video Not Available
4. HDMI
5. 3D
6. Volume +/-
7. Four Directional Select
Keys
8. Menu
9. AV Mute
10. Mute
11. IR LED
12. Power On/O󰀨
13. VGA Not Available
14. Keystone +/- and
Remote Mouse
function
15. Aspect
16. Enter and Enable
Remote Mouse
function
17. Zoom
18. Brightness Mode
VGA
Enter
Menu Zoom
12
13
15
EE
nn
tt
ee
rr
14
7
10
9
8
4
5
3
2
1
11
66
17
16
18
14

12
English
Installation
AUDIO-OUT 12V OUT Out (5V)
3D SYNC
HDMI 1
HDMI 2
USB
MOLEX
5
1
2
Audio output
3D glasses
3 4
6
Connecting a Computer/Notebook
Connecting to the Projector
Due to the
di󰀨 erence in
applications for
each country,
some regions may
have di󰀨 erent
accessories.
(*) Optional
accessory
1.................................................................................................*12V DC plug
2........................................................................................... *3D emitter cable
3....................................................................................................HDMI cable
4.....................................................................................................Power cord
5............................................................................................ *Audio out cable
6.................................................................................................... *USB cable

13 English
Installation
Connecting a Video source
Due to the
di󰀨 erence in
applications for
each country,
some regions may
have di󰀨 erent
accessories.
(*) Optional
accessory
AUDIO-OUT 12V OUT Out (5V)
3D SYNC
HDMI 2
USB HDMI 1
4
1
2
Audio output
3D glasses
3
6
DVD player,
Set-top box,
HDTV receiver
1.................................................................................................*12V DC plug
2........................................................................................... *3D emitter cable
3.....................................................................................................Power cord
4............................................................................................ *Audio out cable
5....................................................................................................HDMI cable
DVD player, Blu-ray player, Set-top box,
HDTV receiver, Games console

14
English
Installation
Connect to 3D Video Devices
The 3D video
source device
must be
powered on
before the 3D
projector.
If input video
is normal 2D,
please press
“3D Format”
and switch to
“Auto”.
If “SBS Mode”
is active, 2D
video content
will not display
correctly.
Once you have connected your devices together with HDMI
cables, as shown in the diagram, you are ready to begin.
Power ON your 3D video source and your 3D projector.
PlayStation®3 Games
yMake sure that you have updated your console to the latest
software version.
yGo to the “Settings menu -> Display settings -> Video output ->
HDMI”. Select “Automatic” and follow the on-screen instructions.
yInsert your 3D game disc. Alternatively you can download games
(and 3D updates) via the PlayStation® network.
yLaunch the game. In the in-game menu, select “Play in 3D”.
Blu-ray 3D™ Player
yMake sure that your player can support 3D Blu-ray™ disc and that
3D output is enabled.
yInsert the 3D Blu-ray™ disc into the player, press “Play”.
3D TV (e.g. SKY 3D, DirecTV)
yContact your TV service provider to enable any 3D channels on
your channel package.
yOnce enabled, switch to the 3D channel.
yYou should see two images side-by-side.
ySwitch to the “SBS Mode” of the 3D projector. The option is
located in the “Display” section of the projector OSD menu.
3D Device (e.g. 3D DV/DC) with 2D 1080i side by side signal
output
yConnect your 3D device and switch to out 3D content with 2D
side-by-side output to 3D Projector.
- You should see two images side-by-side.
ySwitch to the “SBS Mode” of the 3D projector. The option is
located in the “Display” section of the projector OSD menu.
If watching 3D content from an HDMI 1.4a source (e.g. 3D Blu-ray)
your 3D glasses should always be in sync. If watching 3D content
from an HDMI 1.3 source (e.g. 3D broadcast using SBS mode) it may
be necessary to use the projector’s 3D Sync-Invert option to optimize
your 3D experience. The option is located in the “Display ->3D”
section of the projector OSD menu.

15 English
Installation
3D Broadcast 3D Blu-ray™ Disc 3D Console Games
SKY+HD, cable/satellite
box 3D Blu-ray™ Player
PlayStation®3
3D DLP®Link™ Glasses
Full 3D 1080p DLP®Projector
3D RF Glasses 3D Emitter

16
English
Installation
1. To turn ON 3D glasses.
2. Verify that 3D content is being sent to the projector and
signal is compatible with projector specications.
3. Turn on the “3D Mode” (O󰀨/DLP-Link/IR - depending on
which type of glasses you are using) of the 3D projector.
The option is located in the “Display” section of the
projector OSD menu.
4. Turn on 3D glasses and verify image appears in 3D without
eyestrain.
5. If the image does not appear in 3D, please check 3D
device set up correctly to send out 3D image or not. Or
“SBS” mode should be turned on when input signal is 2D
1080i side-by-side. Repeat previous steps 1 ~ 4.
6. It may be necessary to use projector’s “3D Sync. Invert”
option to optimize your 3D experience. The option is
located in the “Display” section of the projector OSD menu.
7. To turn OFF 3D glasses: Press the “Power” button and hold
until the LED switches o󰀨.
8. For more detailed information, please refer to the 3D
glasses user’s guide, or manufacturer's Website.
Using the 3D glasses
For more
detailed
information,
please refer
to 3D glasses
user’s guide.

17 English
Installation
Powering On/O󰀨 the Projector
Turn on the
projector  rst and
then select the
signal sources.
Powering On the Projector
1. Securely connect the power cord and signal cable. When
connected, the On/Standby LED will turn Red.
2. Turn on the lamp by pressing “ ” button either on the top of
the projector or on the remote. The On/Standby LED will now
blink Blue.
The startup screen will display in approximately 10 seconds.
The  rst time you use the projector, you will be asked to
select the preferred language.
3. Turn on and connect the source that you want to display
on the screen (computer, notebook, video player, etc). The
projector will detect the source automatically. If not, push
menu button and go to “Options”.
Make sure that the “Source Lock” has been set to “O󰀨 ”.
If you connect multiple sources at the same time, press the
“SOURCE” button on the Keypad or direct source keys on
the remote control to switch between inputs.
Power
VGA
Enter
Menu Zoom
or

18
English
Installation
Powering O󰀨 the Projector
1. Press the “ ” button on the Keypad or the remote control
to turn o󰀨 the projector. The following message will be
displayed on the screen.
Power o󰀨?
Press power key again.
Press the “ ” button again to conrm otherwise the
message will disappear after 15 seconds. When you
press the “ ” button for the second time, the projector will
display countdown timer and will shut down.
2. The cooling fans continue to operate for about 10 seconds
for cooling cycle and the On/Standby LED will ash Blue.
When the On/Standby LED lights solid Red, the projector
has entered standby mode.
If you wish to turn the projector back on, you must wait
until the projector has completed the cooling cycle and
has entered standby mode. Once in standby mode, simply
press “ ” button to restart the projector.

19 English
Installation
Contact InFocus
if the projector
displays these
symptoms.
Warning Indicator
When the warning indicators (see below) come on,
the projector will automatically shutdown:
 “LAMP” LED indicator is lit Red and if “On/Standby”
indicator ashes Red.
 “TEMP” LED indicator is lit Red and if “On/Standby”
indicator ashes Red. This indicates the projector has
overheated. Under normal conditions, the projector can be
switched back on.
 “TEMP” LED indicator ashes Red and if “On/Standby”
indicator ashes Red.
Unplug the power cord from the projector, wait for 30 seconds
and try again. If the warning indicator lights up again, please
contact your nearest service center for assistance.

20
English
Installation
Adjusting the Projected Image
Adjusting the Projector’s Height
The projector is equipped with elevator feet for adjusting
the image height.
1. Locate the adjustable foot you wish to modify on the
underside of the projector.
2. Rotate the adjustable ring clockwise to raise the projector
or counter clockwise to lower it. Repeat with the remaining
feet as needed.
Tilt-Adjustment Feet
Tilt-Adjustment Ring
