INFOSEC Mod5T User manual

1 INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –03 17 AA59 201 24
USER MANUAL
Three phases Modular UPS Solutions:
20 kVA to 120 kVA HV models
with 20 kVA Power Modules

2 INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –03 17 AA 59 201 24
Table of Contents
1. Safety ...............................................................................................................................3
1.1 Important Safety Instructions.....................................................................................3
1.2 CE conformity............................................................................................................3
1.3 Installation information ..............................................................................................4
1.4 Maintenance .............................................................................................................4
1.5 Recycling the used battery .........................................................................................4
2. Installation ........................................................................................................................5
2.1 Initial Inspection .......................................................................................................5
2.2 Installation Environment ............................................................................................5
2.3 Unpacking.................................................................................................................6
2.4 Moving the Cabinet....................................................................................................8
2.5 Types of UPS Cabinet.................................................................................................9
2.6 Exterior................................................................................................................... 10
2.7 Internal Mechanisms................................................................................................ 14
2.8 Control Panel........................................................................................................... 17
2.9 Introduction of Modules ........................................................................................... 19
2.10 Power Cable .......................................................................................................... 24
2.11 Wiring................................................................................................................... 25
2.12 Power Module Installation ...................................................................................... 27
3. Operation Mode and UPS Operation............................................................................ 29
3.1 Block diagram of UPS .............................................................................................. 29
3.2 Operation Mode....................................................................................................... 30
3.3 UPS Operation......................................................................................................... 34
4. Control Panel and Display Description................................................................................ 44
4.1 Introduction ............................................................................................................ 44
4.2 Screen Description................................................................................................... 45
4.3 Alarm List ............................................................................................................... 69
4.4 History Record......................................................................................................... 71
5. Interface and Communication ........................................................................................... 73
5.1 Dry Contact Port...................................................................................................... 73
5.2 Extra Comm. Slot .................................................................................................... 75
5.3 Local Communication Ports –RS232 & USB............................................................... 75
5.4 SNMP Slot ............................................................................................................... 75
6. Troubleshooting ............................................................................................................... 76
7. Service ............................................................................................................................ 79
7.1 Replacement Procedures Of Power Module................................................................ 79
7.2 Replacement Procedures Of STS Module ................................................................... 79
7.4 Replacement Procedures Of Air Filter ........................................................................ 80
8. Specifications .................................................................................................................. 81
9.1 Input and Output Wiring .......................................................................................... 82
9.2. Parallel Board Setting and Power Module ................................................................. 83
9.3 Parallel Function Setting........................................................................................... 84
9.4Parallel Cable Connection.......................................................................................... 85
9.5Parallel System Turn-on Procedure ............................................................................ 85

3
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –03 17 AA59 201 24
1. Safety
1.1 Important Safety Instructions
This UPS contains LETHAL VOLTAGES. All repairs and service must be performed by AUTHORIZED
SERVICE PERSONNEL ONLY. There are NO USER SERVICEABLE PARTS inside the UPS.
WARNING:
The UPS designed for commercial and industrial purpose, it is forbidden to apply for any life
sustainment and support.
The UPS system contains its own energy source. The output terminals may carry live voltage
even when UPS is disconnected to an AC source.
To reduce the risk of fire or electrical shock, UPS installation has to be in a controlled room
where temperature and humidity are monitored. Ambient temperature must not exceed 40°C.
The system is only for indoor use.
Ensure all power is disconnected before installation or service.
Service and maintenance should be performed by qualified personnel only.
1.2 CE conformity
WARNING: This is a product for commercial and industrial application in the second
environment - installation restrictions or additional measures may be needed to prevent
disturbances.
This logo means that the 220V/230V/240V HV product answers to the EMC and LVD
standards (regarding to the regulation associated with the electric equipment voltage and
the electromagnetic fields).
This is a category C3 UPS product. This category includes UPS with an output current exceeding 16
A and intended for use in the second environment. Such UPS are suitable for use in commercial or
industrial installations having a minimum boundary of 30 m from other buildings classified as first
environment (HV versions only).
WARNING:
An UPS belongs to the electronic and electrical equipment category. At the end of its
useful life it must be disposed of separately and in an appropriate manner.
This symbol is also affixed to the batteries supplied with this device, which means they
too have to be taken to the appropriate place at the end of their useful life.
Contact your local recycling or hazardous waste centre for information on proper disposal
of the used battery.
Before working on this circuit
-Isolate Uninterruptible Power System (UPS)
-Then check for Hazardous Voltage between
all terminals including the protective earth.
Risk of Voltage Backfeed
The isolation device must be able to carry the UPS input current.

4
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –03 17 AA59 201 24
1.3 Installation information
WARNING:
Installation must be performed by qualified personnel only.
The cabinets must be installed on a level floor suitable for computer or electronic equipment.
The UPS cabinet is heavy. If unloading instructions are not closely followed, cabinet may
cause serious injury.
Do not tilt the cabinets more than 10 degree.
Before applying electrical power to the UPS, make sure the Ground conductor is properly
installed.
Installation and Wiring must be performed in accordance with the local electrical laws and
regulations.
The disconnection device should be chosen based on the input current and should break line
and neutral conductors - four poles for three phases.
1.4 Maintenance
WARNING:
Only qualified service personnel should perform the battery installation.
The following PRECAUTIONS should be observed
(1.) Remove watches, rings, or other metal objects.
(2.) Use tools with insulated handles.
(3.) Wear rubber gloves and boots.
(4.) Do not lay tools or metal parts on top of batteries or battery cabinets.
(5.) Disconnect the charging source prior to connecting or disconnecting terminal.
(6.) Check if the battery is inadvertently grounded. If it is, remove the source of grounding.
Contacting with any part of a grounded might result in electrical shock. The likelihood of
such shock can be prevented if such grounds are removed during installation and
maintenance.
UPS is designed to supply power even when disconnected from the utility power. After
disconnect the utility and DC power, authorized service personnel should attempt internal
access to the UPS.
Do not disconnect the batteries while the UPS is in Battery mode.
Disconnect the charging source prior to connecting or disconnecting terminals.
Batteries can result in a risk of electrical shock or burn from high short circuit current.
When replacing batteries, use the same number of sealed, lead-acid batteries.
Do not open or mutilate the battery. Release electrolyte is harmful to the skin and eyes, and
may be toxic.
1.5 Recycling the used battery
WARNING:
Do not dispose of the battery in a fire. Battery may explode. Proper disposal of battery is
required. Refer to your local codes for disposal requirements.
Do not open or mutilate the battery. Released electrolyte is harmful to the skin and eyes. It
may be toxic.
Do not discard the UPS or the UPS batteries in the trash. This product contains sealed,
lead-acid batteries and must be disposed properly. For more information, contact your local
recycling/reuse or hazardous waste center.
Do not discard waste electrical or electronic equipment (WEEE) in the trash. For proper
disposal, contact your local recycling/reuse or hazardous waste center.

5
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –03 17 AA59 201 24
2. Installation
2.1 Initial Inspection
1. Visually examine if there is any damage inside and outside of packages in the process of the
transportation. If any damage, report it to the carrier immediately.
2. Verify the product label and confirm the consistency of the equipment
3. If the equipment needs to be returned, carefully repack the equipment by using the originally
packing material that came with.
2.2 Installation Environment
1. The UPS is designed for indoor use only and should be located in a clean environment with
adequate ventilation to keep the environmental parameters within the required specification.
2. Make sure that transportation routes (e.g. corridor, door gate, elevator, etc.) and installation
area can accommodate and bear the weight of the UPS, the external battery cabinet and
handling equipment.
3. The UPS uses forced convection cooling by internal fans. Cooling air enters the module
through ventilation grills located at the front of the cabinet and exhausted through grills
located in the rear part of the cabinet. Please do not block the ventilation holes.
4. Ensure that the installation area is spacious for maintenance and ventilation.
5. Keep the temperature of installation area around 30°C and humidity within 90%. The highest
operating altitude is 1000 meters above sea level.
6. If necessary, install a system of room extractor fans to avoid formation of room temperature.
Air filters are necessary if the UPS is operated in a dusty environment.
7. It is recommended that you parallel the external battery cabinets to the UPS. The following
instructions of clearances are suggested:
Keep a clearance of 100cm from the top of the UPS for maintenance, wiring and
ventilation.
Keep a clearance of 100cm from the back of the UPS and the external battery cabinets for
ventilation.
Keep a clearance of 150cm from the front of the UPS and the external battery cabinets
for maintenance and ventilation.
8. For safety concerns, we suggest that you shall:
Equip with CO2 or dry powder fire extinguishers near the installation area.
Install the UPS in an area where the walls, floors and ceilings were constructed by
fireproof materials.
9. Do not allow unauthorized personnel to enter the installation area. Assign specific personnel
to keep the UPS key.

6
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –03 17 AA59 201 24
2.3 Unpacking
Before installation, please inspect the unit. Make sure that nothing inside the package is damaged.
Please keep the original package in a safe place for future use. S versions means without
batteries space.
HV version
Voltage
3 x 380V + N
3 x 400V + N
3 x 415V + N
1. Use a forklift to move the product to installed area. Refer to Figure 2-1. Please make sure the
bearing capacity of forklift is sufficient.
2. Please follow the orders in Figure 2-2 to remove carton and foams.
Figure 2-1
Figure 2-2

7
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –03 17 AA59 201 24
3. Put a ramp in the front of the cabinet and insert small wood into groove. Then, remove two
side panels. Refer to Figure 2-3.
Figure 2-3
4. Remove 4 fixing cabinet plates and loosen leveling feet by rotating them counterclockwise.
Then, move the cabinet from the pallet. Refer to Figure 2-4.
5. To fix the cabinet in position, simply rotate leveling feet clockwise. Refer to Figure 2-5.
Figure 2-4
Figure 2-5

8
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –03 17 AA59 201 24
2.4 Moving the Cabinet
The UPS is fixed on the pallet with 4 fixing cabinet plates. When removing it, pay attention to
the movement of the casters to avoid accidents.
The cabinet can be pushed forward or backward only. Pushing it sideward is not allowed.
When pushing the cabinet, pay attention not to overturn it as the gravity center is high.
1. If you need to move the UPS over a long distance, please use appropriate equipment like a
forklift. Do not use the UPS casters to move over a long distance.
2. After the UPS has been removed from the pallet to ground, we suggest that at least three
people move the UPS to the installation area. One person holds a lateral side of the UPS with
hands, another holds the other lateral side of the UPS with hands, and the other person pushes
the UPS either from the front side or from the back side to the installation area and avoid
tipping the UPS.
3. The casters are designed to move on level ground. Do not move the UPS on an uneven surface.
This might cause damage to the casters. Toppling the UPS could also damage the unit.
4. Ensure that the weight of UPS is within the designated bearing capacity of any handling
equipment.
5. At the bottom of the UPS, the four casters help you to move the UPS to a designated area.
Before you move the UPS, please turn the four leveling feet counterclockwise to raise them off
the ground. This protects the leveling feet from damage when moving the UPS. Refer to Figure
2-6.
Figure 2-6

9
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –03 17 AA59 201 24
2.5 Types of UPS Cabinet
For HV version, there are 2 models of UPS cabinets. There is no battery compartments for all these
models. The battery has to be connected externally (S versions).
Please consider the external battery space and wiring gauge for installation.
Mod5T 80/20 S HV
Mod5T 120/20 S HV
Cabinet Height
30U
Switch Unit
1
1
STS
1
1
Max. Power Module
4
6
Power max.
80 kVA
120 kVA

10
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –03 17 AA59 201 24
2.6 Exterior
In the front of the UPS, there are control interface (LCD Panel) and door lock.
The side panels are lockable. The casters at the bottom of the UPS cabinet can be used to move
over short distances. There are four leveling feet to fix and stabilize the UPS cabinet on the ground.
Refer to Figure 2-7.
Inside the cabinet, there are Breakers, STS Module and Power Module slots.
All wiring terminal blocks are located in the back of cabinet when rear door is opened.
Figure 2-7 Exterior

11
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –03 17 AA59 201 24
2.6.1 Mechanical Data
Dimensions
UPS cabinet
Width
Depth
Height
30U
600mm
1100m
1475mm
42U
600mm
1100m
2010mm
Figure 2-8 Dimensions

12
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –03 17 AA59 201 24
2.6.2 Front View
Unlock and open the front door and you will see the Main Breaker (Q1), Maintenance Breaker (Q2),
Output Breaker (Q3), STS Module and Power Module.
Mod5T 120/20 S HV
1. Switch Unit
2. STS Module
3. Power Module
Figure 2-9 Front View

13
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –03 17 AA59 201 24
2.6.3 Rear View
Unlock and open the rear door and you will see the rear panel of UPS.
Mod5T HV S 30U
Figure 2-10 Rear View

14
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –03 17 AA59 201 24
2.7 Internal Mechanisms
2.7.1 Breakers
After opening the front door, you can see there are three breakers, Main Breaker (Q1),
Maintenance Breaker (Q2) and Output Breaker (Q3).
Figure 2-11 Front Breakers

15
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –03 17 AA59 201 24
2.7.2 Wiring Terminal Blocks
Open the UPS’s back doors and you will see the wiring terminal block. For UPS cabinet wiring,
please refer to Figure 2-13.
No.
Item
Function
Description

Output Block
Connects the critical loads
Includes R, S, T and Neutral
terminals.

Bypass Input Block
Connects bypass AC source
Includes R, S, T and Neutral
terminals.

Main Input Block
Connects main AC source
Includes R, S, T and Neutral
terminals.

For UPS Grounding
For UPS grounding
Includes one grounding terminal.

Battery Input Block
Connects an external battery
cabinet
Includes
Positive (+), Negative (-) and
Neutral (N) terminals.
Figure 2-13 Mod5T 80/20 S HV (30U) Terminal Blocks






16
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –03 17 AA59 201 24
Figure 2-14 Mod5T 120/20 S HV (30U) Terminal Blocks






17
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –03 17 AA59 201 24
2.8 Control Panel
2.8.1 LCD Display
Through the graphic LCD display, the user can easily understand the operation mode of UPS. In
addition, the measurement, parameters, versions of firmware and warnings can be browsed in the
friendly interface. For detailed information, please refer to Charter 4.
Figure 2-16 Control Panel
2.8.2 LED Indicators
LED
Color
Status
Definition
INPUT
Green
On
Input source is normal.
Flashing
Input source is abnormal (out of limit).
Off
No input source
BYPASS
Yellow
On
Load on Bypass.
Flashing
Input source is abnormal (out of limit).
Off
Bypass not operating.
INVERTER
Green
On
Load on inverters.
Off
Inverters not operating.
BATTERY
Red
On
Load on Battery.
Flashing
Low battery
Off
Battery converter is normal and battery is charging.
ALARM
Red
On
UPS fault.
Flashing
UPS alarm.
Off
Normal.

18
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –03 17 AA59 201 24
2.8.3 Function Keys
Control Key
Description
Esc
When it is in Main screen, you can enter menu by pressing ESC
key.
Return to previous screen, when screen is not in Main screen.
Return to previous value in the same row, so you can change it.
For example, when changing 4-digit password, press “Esc” to
allow cursor back to previous digit.
(Up) (Left)
Key for menu page navigation or digit modification.
(Down) (Right)
Key for menu page navigation or digit modification.
Enter
Confirmation of commands, or cursor displacement.
Home
Return to Main screen.
Power On/Off
Turn on UPS or Turn off UPS.

19
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –03 17 AA59 201 24
2.9 Introduction of Modules
The design of STS Module and Power Module make maintenance and replacement quick and easy.
The modular and hot-swappable design of Power Module makes it a highly cost-effective solution
to meet your power requirement. The number of Power Modules installed in the UPS can be based
on the initial needs. Once the power requirement increases, you can easily install more Power
Modules without interrupting the operation of the system.
Figure 2-17 Front View of Module

20
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line –Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - [e-mail] –03 17 AA59 201 24
2.9.1 STS Module
The STS Module is installed before leaving factory. It provides the bypass power when UPS is in
Bypass Mode.
In addition to offering bypass power, it includes some communication interfaces. For detailed
information, please refer to Charter 5.
No.
Item
Description

Extra Comm. Slot
This slot can insert an optional card, Extra Comm. card which can
enhance the communication capability of UPS system. It can
provide another SNMP slot and some dry contact ports.

LCD Port
This port connects to Control Panel with a factory installed cable.

RS232 port
Local communication interface.

USB port
Local communication interface.

SNMP Slot
This slot can work with optional cards, SNMP, AS400 or Modbus
card.

Dry contact ports
CN1 ~ CN8. For detailed information, please refer to Chapter 5.
Figure 2-18 STS Module
