InMotion P2 Series User manual

INMDTIDN



(NMO

3.1.
3.2.
3.3.
About this Manual
Related Document and Date
Relevant Agreement
4. Product Overview
4.1.
4.2.
4.3.
4.4.
4.5.
Serial Number
P2/P2F Dimension Figure
P2/P2F Specifications
Product Parameters
Assemble P2/P2F
3
4
4
4
4
4
5
6
7
8
CONTENTS
1
3
1. Product Introduction
2. Safe Driving Precautions
3. Overview 4
.....................................................................................................................................................................................................
..............................................................................................................................................................................................
..........................................................................................................................................................................................................................
...............................................................................................................................................................................................................
...........................................................................................................................................................................................
..........................................................................................................................................................................................................
.............................................................................................................................................................................................................
....................................................................................................................................................................................................................
..................................................................................................................................................................................................
........................................................................................................................................................................................................
............................................................................................................................................................................................................
..............................................................................................................................................................................................................
5.Product Instructions
5.1.
5.2.
5.3.
Riding Modes
Bicycle Learning Mode
Bike Code Parameters
9
9
9
9
.............................................................................................................................................................................................................
....................................................................................................................................................................................................................
..................................................................................................................................................................................................
........................................................................................................................................................................................................
6.APP ..................................................................................................................................................................................................................................... 10

2
8.1.
8.2.
8.3.
8.4.
8.5.
16
16
17
17
17
9.1.
9.2.
9.3.
19
23
9.18
11.1.
11.2.
11.3.
25
27
28
10.24
11
25
8.
..................................................................................................................................................................................................................... 16
...............................................................................................................................................................................................................................
..............................................................................................................................................................................................................................
...........................................................................................................................................................................................................................
...................................................................................................................................................................
..........................................................................................................................................................................................................
...............................................................................................................................................................................................................
...................................................................................................................................................................................................................
22
Maintenance
Storage
Cleaning
Treatment
Inflation & Exchange Inner and Outer Tires
Brake Maintenance
Legal Statement
Use Statement
Personal Information Statement
Intellectual Property Statement
Product Certification
Product Warranty
The Warranty Periods of Different Parts
Service Policies for Repair
Product Warranty Card
......................................................................................................................................................................................
.........................................................................................................................................................................................
......................................................................................................................................................................................................
...........................................................................................................................................................................................................
..........................................................................................................................................................................
...............................................................................................................................................................................................
......................................................................................................................................................................................................
7.1.
7.2.
7.3.
7.4.
7.5.
12
13
13
14
15
.................................................................................................................................................................................................
..................................................................................................................................................................................................
...........................................................................................................................................................................................
................................................................................................................................................................................................
..................................................................................................................................................................................................
7.Safety Tips for P2 / P2F
Charging Method
Safety Tips for Charging
Riding INMOTION E-bike P2
Precautions before Riding
Safe Driving Precautions
................................................................................................................................................................................................................ 12

1. Product Introduction
This manual is applicable to INMOTION P2/P2F manufactured by Shenzhen INMOTION Technologies Co.,Ltd.
2. Safe Driving Precautions
The following components and parts shall be included when leaving the factory.Please check after unpacking. If there are any missing
components and parts, please contact the dealer or after-sale service department
Warning
Use of unauthorized parts and components or incorrectly installed parts and components may result in damage to P2/P2F or even
personal injury. In order to ensure quality and safety, all parts of P2/P2F will be subject to the approval of INMOTION Technologies
Co., Ltd. and assured to be correctly mounted to P2/P2F.
Please do not try to ride on a P2/P2F that is not correctly, effectively and completely installed.
Do not disassemble, refit P2/P2F without permission, or it will cause irreparable damage of P2/P2F and may result in personal injury. 3

4
3.Overview
3.1 About this Manual
For your safety, please read over this manual before riding.
Knowing all the listed safety warnings and precautions will help you for a better riding.
This manual is applicable for INMOTION E-bike P2-series products manufactured by INMOTION TECHNOLOGIES CO., LTD.
Any questions or any information you cannot get from this manual, please immediately contact INMOTION local official Distributor/
Dealer or INMOTION after-sales service department.
3.2 Related document and data
The PDF Manual, precautions for battery pack, APP as well as the Help document can be downloaded from the official website of
INMOTION TECHNOLOGIES CO., LTD., it's www.inmotionworld.com
3.3 Relevant agreement
The following instructions are applicable for this Manual. Please pay more attention to the related Warning, Notes and Prompts
4 Product Overview
INMOTION E-bike P2/P2F is a kind of compact, effective and economic personal transporter. The fashionable and light structure
design, as well as the lithium-ion power battery (high configuration) will provide you with joyful riding experience.
4.1 Serial NO.
Serial No.(SN) is the only TAG of this product, which is used for quality tracking and after-sales services etc. of the product. Please well
record and keep the Serial No that can be obtained from the followings: external packing, warranty card, E-bike body(on the side of
the controller box).

5
4.2 P2/P2F Dimension Figure

6
4.3 P2/P2F Parameter
Model P2 P2F ①
The maximum speed is measured at the
temperature of 77℉(25℃), the payload of
70kg(154.32lbs), fully charged and the flat
pavement. The factory default speed is
20km/h, the max speed could be adjusted
via INMOTION APP.
②
The range is measured at the
temperature of 77℉(25℃), the speed of
20km/h(12.43mph), the payload of
70kg(154.32lbs) and on the flat pavement.
The factors like environment temperature,
road surface condition, payload etc. will
affect the range
③
Charging time varies with the ambient
temperature and the battery capacity that
may change in the course of time.
Max. Speed ① 30km/h
Ranges (without pedal assist) ② 30km 80-100km
Ranges (with pedal assist) ② 60-70km 160-180km
Max Slope 12°
Net Weight 17kg 19.9kg
Maximum Payload 120kg
Expanded Size 1020*480*1050 mm
Battery Specification
36V 7.6Ah 36V 22.4Ah
Input (Charger) AC 100V~240V 50/60Hz
Charging Time ③ ~6.5 h ~13.5 h
Tire 12 inches Pneumatic Tires
Brake Type Double Disc Brakes
Working Temperature -10~40℃
Motor Power 350W
USB Interface 5V 1A
IP Ratings IP54

7
4.4. Product Parameters

8
4.5. Assemble P2/P2F
Step 1 : Hold well the direction bar as the picture shows, and lock the folding handle as the picture shows. （See picture①②）
Step 2 : Install the foot lever on the E-bike as the picture shows (Note: Screw tightly)
Step 3 : Move the head of the direction bar as the picture shows, and then well adjust the cross handle (to the comfortable point you need)
Step 4 : Try to fasten the folding wrench
step 1 step 3
step 2
step 4step 5

5.Product Instructions
The IMMOTION P2 series electric bikes provide three riding modes which can be switched by the rider as needed by a mobile
APP connected to the bike.
.1Riding Modes
1. Eco mode: Power assistance and throttle start is relatively soft. Only when the bike speed reaches 5km/h, the throttle can start.
The maximum speed of riding is limited to 18km/h. Under same conditions, pure power or power assistance range in the eco
mode is even larger.
2. Common mode: Power assistance and throttle start is slightly strong. When the bike speed is 0km/h, the throttle can also start.
The maximum speed of riding is limited to 20km/h.
3. Extreme speed mode: Power assistance and throttle start is stronger. This mode ensures the maximum performance of the
motor under the premise of riding safety. The maximum speed of riding is up to 25km/h. Note that under same conditions, the
extreme speed mode will reduce the range of the bike.
5.2 Bicycle Learning Mode
When the bicycle learning mode is selected using the IMMOTION APP, the power assistance function is turned off, and the speed
is limited to 7 km.
5.3 Bike Code
Each IMMOTION P2 electric bike has a unique code which is labeled on the frame in front of the taillight. The frame also has a
unique code that is engraved on the bottom bracket of the frame.
9

unique serial number
unique frame Code
10
6.APP
This APP is specially designed for users by INMOTION based on the manufactured products, which can realize such functions as
controlling the vehicle, making friends, releasing INMOTION articles, taking part in INMOTION activities, buying INMOTION accessories
etc. The APP name is INMOTION SCV on the APP Store and Android smart phone.
You can get this APP from our website or corresponding APP Store.
Through this APP, you can realize the following functions:

· E-bike control: Lock, unlock, auto cruise.
· E-bike body status display: It can display the speed, mileage, electric quantity etc.
· Parameter setting: Max. speed.
· Failure detection: It can realize the evaluation and detection to the status of INMOTION E-bike.
· After-sales service: We can arrange our workers for you to deal with the after-sales services.
· For more detailed functions of this APP, please download the product manual of the latest APP with reference to the prompts and
Help document. We regularly promote new functions on the APP.
11
Prompt

12
7. Safety Tips for P2 / P2F
7.1 Charging Method
Step 1: The charge port is on the tail of the battery, see picture 1
Step 2: Inset the charging port of the charger to the connecting charge port of the battery (please make sure
the charge port is dry).
Step 3: When the charger indicator turns red, it is charging; when it turns green, it is fully charged. After fully
charged, please stop charging, as long-term charge will affect the service life of the battery.
Step 4: After charging, please cover the charging port in case water in.

7.2 Safety Tips for Charging
Please charge at least 5 hours before first use.
· In order to maximum extend the battery life, please charge it every one month or two days after riding it. Please charge it
under proper temperature and environment.
· Not charging timely may cause battery damage. As time goes by, battery capacity will gradually run out, and eventually
lead to battery over-discharge.
· Please use the battery, charger and cable provided by original manufacturer, to avoid dangers caused by battery overcharged.
· Please ensure correct connection of the charger and the cable, as well as enough ventilation environment.
· Please use it under dry condition. It is NOT allowed to make the charger or cable connect with water, as it may result in
electric shock. Please do not tough with wet hands. If there is any failure during charging, please immediately pull up the power plug.
· Please guarantee to pull it up from the plug, not from the cable.
· Please do not make the charger or cable contact sharp or high temperature articles.
· Please regularly make sight check to the charger and its cable.
· If there is obvious damage of the charger or cable, in order to avoid further damage, please do not use the charger any more,
and contact for exchange.
· Please do not personally repair the battery, charger or cable. Any questions, please contact us.
7.3 Ride INMOTION E-bike P2
INMOTION E-bike is a kind of technological travel tool. Riding without better understanding of the operation specification will result
in unpredictable injury. The following instructions are explained in details on how to correctly ride the INMOTION E-bike for green
hands, especially those who ride it for the first time, and list all precautions during the riding. Please carefully read it and
ride INMOTION E-bike as required.
INMOTION E-bike is suitable for people over 14 years of age.
owner of the INMOTION SCV has the authority of Bluetooth password modification. The user can only modify the password of this unicycle
after the authentication of the unicycle owner.)
After the user enters the unicycle owner authentication, click to enter the "Unicycle Status”interface of the INMOTION APP. Select the
option of "Password Modification" to modify the Bluetooth password.
13

14
7.4 Precautions before riding
When riding or parking INMOTION E-bike, it will cause loss and affect the using performance of the product. Therefore, before riding,
please pay attention to the following notes:
· Please check if all parts of the E-bike are well installed without damage.
· Please check if the brake is well.
· Please check if the folding mechanism is locked.
· Please check if there is enough power.
· Please check if the tire is well.
· Please check if the handle is fixed. Once loose, please screw it down.
· You need to find an open and flat place with the square of at least 4m * 20m to practice riding, indoor and outdoor are OK.
· You need to have a deep understanding to the surrounding riding condition, in order to ensure not to be disturbed by the cars,
pedestrians, pets, bikes or other obstacles.
· You need a skilled assistant who is familiar to ride INMOTION E-bike and knows about all precautions and riding methods in this manual.
· Please do not test on smooth and wet ground.
· Please wear a helmet or other protectors to avoid possible injury.
Prompt

15
cars, pedestrians,
7.5 Safe Driving Precautions
INMOTION E-bike is a personal transpertation with certain speed, which has been strictly inspected on the technology and manufacture.
Please use it according to the safety warnings in this manual, otherwise, it may bring risks. Any time or places, it may hurt you or even
cause death due to the reasons such as falling, loss of control, collision etc., including that you do not ride INMOTION E-bike according
to the manual. Therefore, in order to reduce risks and avoid injury, you MUST carefully read this manual, and obey the following
precautions:
· When riding, please wear helmet and protectors.
· Please do not climb slope over 12°, and do not sharply speed up or slow down on the slope.
· Be cautious to the obstacles and wet and smooth road, do not ride on grass or pebble road.
· Please do not ride in water over 30mm.
· DO NOT ride up and down the stairs.
· DO NOT ride in motorway.
· DO NOT soak in water.
· INMOTION E-bike belongs to single-use vehicle, please DO NOT ride by several people.
· Beginners at the age of 14-18 years or older than 45 years of age, please practice under someone's help.
· Before using, please confirm if the power is full, and if the tire is in normal inflation.
· Before familiar to the E-bike, please DO NOT ride with higher speed, instead please ride slowly.
· As for the special property of lithium battery, users should charge it at least one time one month. It is not within the warranty range if
the battery is damaged due to irregular maintenance.
· INMOTION E-bike is only used as daily transport tool, therefore, please DO NOT use it in extreme sports or other dangerous riding
methods.

16
8 Maintenance
8.1 Storage
·Please keep the E-bike out of direct sun (even it is in trunk of your car), because after some time, the temperature of the after carriage
and battery will reach 50℃, which will decrease the function and shorten the lifespan.
· Please do not place INMOTION E-bike in moisture condition.
· It will automatically discharge when the INMOTION E-bike is not in use. The battery power should be checked at least every 3 month,
and should be timely charged until it is full. Please do not keep it for long time, as it will cause invocatableloss (such as deep discharge of
the battery) due to the battery without power.
· In winter, the battery will lose power faster due to the low temperature.
· Unreasonable storage will lead to the life loss of the battery in the E-bike or other risks, therefore, please keep the INMOTION E-bike
indoor in a dry place with proper humiture. If the INMOTION E-bike is not used for long time, please fully charge it and charge it at least
one time every month.
· Please fully charge the E-bike if you do not use it for long time.
8.2 Cleaning
Before cleaning, please make sure the E-bike powers off, pull up the cable, and close the charging port. When cleaning, please notice not
to make water in the port.
· lease use soapy water or clean water to wipe the shell of INMOTION E-bike with soft cloth. Please DO NOT use high pressure water gun
to wash it.
·The IP Ratings of INMOTION E-bike is IP54, namely, it is spilling and dust proof. Therefore, please do not soak the INMOTION E-bike in
water, as it will lead to permanent damage.

17
8.3 Treatment
Please do not treat the battery and power device as general wastes. You have made great contribution to the environmental protection
undertaking through riding INMOTION E-bike, so in order to further avoid unnecessary pollution:
· When scrap is required, please deal with your E-bike and all related components (battery) through the authorized treatment facilities.
· Please obey the latest user guide. Any questions, please consult our dealers or contact INMOTION after-sales department.
8.4Inflation & Exchange Inner and Outer Tires
Once there is insufficient air pressure, please timely inflate. Factory default tire pressure of INMOTION P2 Series E-bike is 2.8 Bar.
If the tire needs to be replaced due to tire burst or other reasons, please contact INMOTION authorized agencies or INMOTION after-sales
department (Also you can repair it in a bicycle maintenance shop).
8.5 Brake Maintenance
①Insert the elbow to the brake, and fix it on the screw of the frame. According to the: direction of Left Loose and Right Tight, please
lightly turn left to make the brake a little loose.

18
②Then clench the brake with one of your hands, in order to make the rear brake close to the brake pad. Keep clenching.
9 Legal Statement
INMOTION P2 series can be considered as a intelligent and portable travel and commuting device. However, it is no replacement of the
current existing means of transportation. When you use INMOTION P2 series as a means of transportation for short-distance travel, there
might exist conditions causing injuries such as decline, crash, etc. and other risks. You have the responsibility and obligation to carefully
read and learn the user manual for INMOTION P2 series and user guide; be familiar with how to drive the INMOTION P2 series; and be
fully aware of the warnings and precautions as well as the provisions specified in the following legal statement, so as to reduce (but
cannot totally eliminate) potential risks and to ensure the personal and property safety of yourself and other people.
