InMotion SCV V3 User manual

INSTRUCTIONS MANUAL
INMOTION SCV V3
INMOTION SCV V3
27

1. Overview
1.1. About This Manual
For your safety, please read this Manual carefully before you ride an INMOTION unicycle. Please also watch the instruction
video carefully in order to get the correct instruction for riding the INMOTION unicycle.
To help you to better enjoy riding the INMOTION unicycle, read and understand all the safety warnings and instructions listed in
this Manual.
This Manual is applicable to the unicycle series produced by Shenzhen INMOTION Technology Co., Ltd.
Should you have any questions, or should there be any information that you cannot obtain from this Manual, please feel free to
contact the INMOTION headquarters in your country.
1.2. Documents and Materials
You can access and download all the Help materials, including the Manual in .pdf format, the Safety Instruction Video, and the
app for mobile devices from the official website of INMOTION Technology Co., Ltd.: www.imscv.com.
1.3. Conventions
The following conventions are used throughout this manual:
Warns you about actions that may result in personal injury.
Cautions you about actions that may result in operational issues or
physical damage to the INMOTION SCV.
Identifies important points, helpful hints, special circumstances, or
alternative methods.
28

2. Safety Instruction of the Product
INMOTION unicycle is a product that is equipped with front and rear automatic self-balancing functions, and left and right
manual balancing, which combine fun and balance. To avoid risks of danger, follow the instructions of this Manual. Physical
harm or death may be caused due to falling, losing control, or collision should you not follow the instructions of this Manual.
Please read this Manual carefully, watch the safety videos, and follow the instructions below in order to avoid risk and potential
harm:Please wear helmet and other protection garments when riding the INMOTION unicycle;
● DonotridetheINMOTIONUnicycleonslopesslantingmorethan20degrees,anddonotspeeduporsuddenlyhalt;
● Be careful hen the road surface is slippery and hen there isobstacles;
● Do not ride the INMOTION unicycle on grasslands or gravel road;
● Do not ride the INMOTION unicycle on treading ater deeper than170cm;
● Do not ride the INMOTION unicycle do nstairs orupstairs;
● Do not ride the INMOTION unicycle on automotiveroads;
● Do not soak the INMOTION unicycle in ater;
● Do not ride the INMOTION unicycle at a speed higher than 20km/h(12mph);
● If the pedals tilt up ards, do not continue to accelerate and reduce speed immediately;
● Do not sit on the handle of the unicycle;
● Assistance is recommended for all beginners ith special attention to individuals younger than 18 or older than45;
● Ensure the battery is full and the tire is inflated in the normal condition;
● Pleasespeedupslo lyanddonotridetoofastbeforegettingfamiliar ithridingtheunicycle;
● Due to the unique features of lit hi um battery, customers should charge the battery atleastoncea month. If damage is
done due to irregular maintenance of the battery, it is not included in the scope of the manufacturer’s warranty.
29

.
3. GeneralIntroduction
INMOTION unicycle is a high-tech human transporter and entertainment vehicle that combines fashion, fun and usefulness all-in-
one. It employs dynamic balancing, and uses its interior gyroscope and acceleration transducer to detect any change of the
unicycle. With a servo-control system to adjust itself by accurately controlling the motor, it keeps the system balanced. The user
may control the unicycle to move forward, speed up, slow down, or brake by leaning forward and backward, and keep balance
side-to-side by twisting his or her body.
INMOTION unicycle is equipped with pull-up handle, smart shifting light, swiping switches, swiping charging switch and high
definition Bluetooth speaker. It is safe, easy to carry, and a solution for short-distance transportation.
3.1. Product SerialNumber
The product serial number, a 16-digit sequence of characters with a one-dimension barcode, is the only identification of the
product for quality tracking, post-sale services, insurance claim, and loss confirmation. Please keep the serial number on hand.
You can obtain the product serial number from the following places: the external packaging of the product, the warranty card of
the product, and the main body of INMOTION unicycle (it is on the angular area of the upper surface of the unicycle when the
handle is pulledup).
3.1.1. Packing List/BoxCheck
The INMOTION unicycle package includes the following components. Please check when opening the box and consult the
reseller in case of missing components.
The main body of the unicycle, adapter, product manual, warranty card, and Approved Certificate for Product.
30

3.1. Components
Do not disassemble or modify INMOTION unicycle without permission, otherwise, it may result in irrepairable damages and
harm to humanbody.
31

3.2. ProductParameters
Item Specification Note
Item Type INMOTIONSCVV3 ①This speed is measured under the condition of 75kg of
weight.
②The maximum mileage is measured under the condition
of 25℃ and 75 Kg of payload on flat road. The mileage
may vary under different conditions of riding habits,
temperature, road condition, and payloads. Mileage may
also vary due to different types and batteries.
③The waterproof and dust resistance level is IP 55,
which means the unicycle functions well when treading
water no deeper than 170mm.
Maximum Cruising Speed 18 Km/h
(11.2 mph) ①
Maximum Mileage 20~25 Km
(12.5-15.5 miles) ②
Maximum Climbing Angle 18°
Net Weight 13.3~13.8Kg
(29.3 lbs.-30.4 lbs.)
Payload Weight 120Kg (
265 lbs.)
Whole Product Size 420*515*178 mm
Battery 72V 2Ah Lithium Batter
Charge Requirement AC220V 50~60Hz
Charging Time About 1.5 hours
Tires 14inch Inflatable Tire
Best Riding Temperature -10~40℃ (14-104°F)
Waterproof Level IP55
③
32

3.3. Product Size Plan
33

4. Product Functions
4.1. Interactive Panel
The interactive panel is the LED display interface that indicates the working condition of the unicycle on the main body.
Icon Description Icon Description
Light Icon: indicates the light is on
Fault Icon, indicates that something is
wrong and Unicycle must be reset
Bluetooth Connection, constant light on
indicates Bluetooth connection and ready
for use with smart phone app.
Icon for Bluetooth speaker, constant
light on indicates Bluetooth connection
and ready to stream music
Power Icon: please swipe finger indirection indicated by the arrows
Battery display, 6 bars, simultaneous display on both sides, flashing icon indicates need for charging
34

4.2. Light
There are LED lights on the front and the rear of the
unicycle, which are used for lighting and warning. As
there is no absolute sense of direction for INMOTION
unicycle, the unicycle switches the front and rear light
automatically according to the direction the vehicle is
moving in order to make sure the front is the front
headlight, and the rear is the red warning light.
To power on, slowly swipe your finger from the
right to the left on the interactive panel (shown as the picture in the right), and the icon for light on the panel will be on and both
lights will illuminate. Try to push the unicycle or ride on it, and the front light will automatically change to the front headlight,
and the rear light will be switched to red warning light. The user can control the front light to be permanently on, or to shut off the
front and rear lights through the smart phone app on a mobile device.
4.3. Data Bluetooth and Music Bluetooth
The INMOTION unicycle is equipped with data Bluetooth 4.0 BLE plug and an interface for music Bluetooth 3.0. The user can
use the former to connect the Bluetooth loudspeaker on the unicycle, or use the latter to communicate with the app on a mobile
device.
When the unicycle is powered on, turn on the Bluetooth of your mobile device, search and connect with the Bluetooth module of
the unicycle, and when the Music Bluetooth icon is on (shown in the figure above), you can enjoy the music on your
35

mobile device by playing it on the unicycle’s built-in speaker.
The preset name of the INMOTION unicycle V3 music Bluetooth is: V3-XXXXXXXXAudio, among which, XXXXXXXX is a
random value. You can connect directly when the name of the device shows up.
The preset name of the INMOTION unicycle Bluetooth 4.0 BLE is: V3-XXXXXXXX, among which, XXXXXXXX is the same
as the music Bluetooth. The initial Bluetooth password is 000000. Only by entering the right Bluetooth password can you pair up
with and use your app on a mobile device to
control INMOTION unicycle.(Modification of the
Bluetooth password is controlled by user permission.
Only validated user can change the password of the
unicycle. )
After passing the validation for users, click and enter
the interface of “Condition of the Vehicle” on the
mobile device app, choose “Change Password” to set
the password for Bluetooth.
4.4. Voice Prompt
There are two interior loudspeakers on INMOTION unicycles that can give prompts in different working modes and conditions.
Initially, the language for voice prompts is in English, which can be changed and redefined by using the mobile device app
according to different events and conditions. You can also use the app to change the content and language of the voice prompts, or
switch them off. Please refer to the help document on the app for more information. The initial events of the voice prompts are
listed as follows:
36

Description Content of Language Description Content of Language
Power-on Sound-dongdongdong Sleep Sound- wu
Lock Sound-budong Unlock Sound- bugu
Battery Low Low battery Sound- Low battery Charging Sound-budong
Charging
Completed
Sound- waterdrop Overload, Please
Get Off
Sound- Overload ，please get off
Light Sound-budong Light Off Sound- bugu
Please Slow
Down
Sound- bibi Power Off Sound- dadada
Please Send for
Repair
Sound-Please repair Locked, Please Do
Not Move It
Sound- wongwong, Please don't move
Data Bluetooth
Connected
Sound- budong Data Bluetooth
Disconnected
Sound- bugu
Music Bluetooth
Connected
Sound- budong Music Bluetooth
Disconnected
Sound- bugu
Please be Careful Sound- Be careful
37

4.5. Pull-up Handle and Energy-Saving Mode
The function of the energy-saving mode can be used when people do not feel like riding, or when the condition is not suitable for
riding (such as steep slopes, slippery roads, sand, bumpy roads and crowded environments). In the energy-saving mode, the
system will provide a low-power assisted force
According to the users pulling force.
Press the button on the top of the INMOTION unicycle
and pull up the handle, just like pulling out the handle of
a suitcase. This is the unique design of the INMOTION
unicycle for unsuitable environment. When the handle is
pulled up and the unicycle is pushed forward, the
unicycle will switch automatically to energy-saving
mode.
The unique pull-up handle design and the energy-saving
mode of the INMOTION unicycle will make it easy to
have the INMOTION unicycle in all scenarios whether
riding or pushing the unicycle.
4.6. App for Mobile Devices
The mobile device app is a specially-designed app for INMOTION unicycle users. It controls the unicycle, connects users with
their INMOTION friends, publishes user experiences, and allows users to participate in INMOTION activities and buy
38

INMOTION accessories. The name for the app is INMOTION.
You can download the app from our official website or relevant App Stores (IOS system: Apple App Store; Android System:
Google Play)
The following functions are achieved by the app:
● Basic control of the unicycle settings: po er on, po er off, lock, unlock.
● Unicycle status display: display of speed, mileage, and battery status.
● Unicycle configuration setting: set the sound volume, protection speed, and sensitivity of the pedals.
● Sensitivity of the pedals: Different user experiences provided by adjusting the sensitivity of the pedals.
● Music customization: customize the voice tips of the unicycle.
● Fault inspection: assess and evaluate the health status of the INMOTION unicycle.
● Post-sale services: by using the app, customers can easily communicate ith our service personnel for any post-sale
problems.
● Hard are upgrades: to detect any ne ly released hard are for the unicycle and to upgrade the unicycle online.
My way: check the new route of the unicycle by using GPS.
For more detailed introduction of the app, please refer to the app itself, the help document, or download the instruction of the latest
app from the INMOTION official website.
The INMOTION unicycle connects with mobile devices via Bluetooth 4.0 BLE which is applicable to Android 4.3 or later
versions, iPhone 4sandabove,iOS 7.0 and other new version of the system.
39

5. Riding the INMOTION Unicycle
5.1. Preparation
The INMOTION unicycle is a high-tech instrument for human transportation. In order to avoid bodily harm, ensure that you
understand instructions completely before riding the INMOTION unicycle. The following is a guide for beginners, especially first
time users of the INMOTION unicycle, on how to correctly ride the unicycle. There are some important safety instructions that
must be read before using the unicycle for the first time.
● Please check if all the components of the INMOTION unicycle are fixed in place and ithout any damage before riding
it;
● Please continuously charge INMOTION unicycle for at least 1.5 hours before riding it.
● Please find an indoor or outdoor flat area of no smaller than 4m x 4m (13ft x 13ft) to practice.
● Pleasemakesureyoukno thesurroundingenvironmentvery ell,andensurethereisnointerferencefromcars
pedestrians, pets, bicycles, cracks, bumps or any other obstacles.
● Please ask a ell-trained assistant to be by your side during practice. This assistant should be familiar ith all the
instructions and riding methods for the INMOTION unicycles in this Manual.
● Please do not ride the unicycle on smooth and slippery ground.
● Please ear comfortable clothes or sporting clothes and flat shoes hen riding the INMOTION unicycle. Please arm
up and keep your body flexible hen riding the unicycle.
● Please ear a helmet and necessary protection gear to avoid injury.
40

5.2. Power on
Put your finger on the power icon of the touch panel. As a lighting arrow shows up and keeps rolling, slowly swipe the panel in
the direction of the arrow and make sure your finger is touching the panel as you turn on the unicycle. The interactive panel is
shown below. The unicycle cannot be switched on when the battery is too low. There will be a voice prompt of “Low Battery”.
5.3. Sleep and Power Off
When the unicycle is on, put your finger on the power icon of the interactive panel. As the running arrow shows, swipe your
finger along with the arrow direction until you hear the voice “sleep”, which indicates the unicycle is in the sleep mode. There
will also be a blinking light on the interactive panel (shown below). After 30 minutes in sleep mode, the unicycle will power off
automatically and there will be no sign on the panel. If you need to power off immediately, please press the end of the arrow for
more than five seconds to power off. If the battery is below 10%, the movement to switch the unicycle into sleep mode will
directly power off the unicycle.
41

5.4. Steps for Beginners
● Turn on the unicycle and use one hand to hold the unicycle. Make sure the unicycle stays vertical to the
ground.
● Open the pedals on both sides, and position both legs next to the pedals in parallel position on both
sides of the unicycle. Put your left foot or right foot (depending on personal preference) on one side of the
pedal, and make sure you step on the center of the pedal.
● Keep your upper body upright ith your eyes looking straight ahead, just like you are standing on flat
ground. Slo ly shift your center of gravity over the opposite pedal, and lift your foot from the ground to that
pedal.Findyourbalanceuntilyoucanstandononefootonthepedal ithyourlegsuprightforashorttime.
● Relax your calves and use both feet to stand on the pedals in order to keep your balance during riding. Some minimal
momentum ill help you keep your balance hile learning to ride the
unicycle.
● It is very common that you might lose your balance momentarily
and fall to the side. Therefore, please ask a friend to hold you to get used to
the unicycle or use the all or railings to keep your balance during practice.
● After you familiarize yourself ith ho to keep your balance on
the unicycle, you can adjust the center of gravity (by leaning) or control your
feet
If the touch button malfunctions, or if it cannot be shut down in an emergency, please tilt your unicycle twice within three
seconds until you hear the sound “Be Careful” as the unicycle shuts down automatically.
42

to change the direction when you move forward (as shown in the diagram).
5.5. Charge
Plug the adapter into the rectangular socket on the unicycle (as
shown in the picture). This socket can be found by sliding the
socket cover in the direction the arrow shows. Push in when it is
switched to the very end. A red indicator light and sound effect
notifies you that the charging plug is in the correct position.
When the light turns from red to blue, it means the battery is
fully charged.
5.6. Reset
If the system encounters an error, please use the reset button to shut down the unicycle. Switch the reset button to the right as shown
below.
43

5.7. Over-speed Protection
In order to avoid dangerous speeds, The INMOTION unicycle has a maximum speed. When the speed surpasses the maximum
limit of 18km/h (11mph), the pedals will tilt up by 3-4° to allow the user to maintain the current speed. It is very difficult for the
user to use self-weight to speed up on this basis. If the user tries to speed up over 20km/h, the unicycle will respond with an
opposite force to protect the user from going over-speed. The pedals will return to the normal angle when the speed gets back to
normal.
When the battery is low, the unicycle will slow down from 18km/h (11mph) to 5km/h (3mph), which shifts to energy-saving
mode. As the battery charge decreases, the speed continues to reduce. The system will automatically shut down once it detects a
speed close to 0km/h for more than 10 seconds if the user does not turn it off.
5.8. Tilt and FallProtection
When the unicycles tilt to the side by more than 45°, it will detect the abnormality, play the “Be careful” warning signal, and shut
off the automatic balancing mode in order to avoid harm to human bodies by the high-speed rotating wheel. All that needs to be
done is to either power off or restart, or to hold the unicycle upright, which activates the automatic balancing mode.
5.9. Over-discharging Protection
The INMOTION unicycle integrates an over-discharging protection system that cuts off the power to protect the battery when the
unicycle is in sleep or in power-off mode, or when the battery is too low. A unicycle in the over-discharging protection mode will
leave this mode when plugged in to a power outlet. After charging for 30 minutes, should the unicycle not turn on, please contact
the authorized resellers or the INMOTION service department.
44

6. Maintenance
6.1. Storage
Improper storage of the INMOTION unicycle may result in the short battery life and other risks. Please store the INMOTION
unicycle in a dry and moderate temperature indoor environment. If you do not use the INMOTION unicycle at least once a
month charge monthly for best battery care.
6.2. Inflation and Replacement of the Interior and ExteriorTires
Please ensure that the air pressure stays the same in both tires and that they remain at 3.5 Bar (50 PSI) If you get a flat tire or
are in need of new tires, please contact an INMOTION authorized distributors or the INMOTION service department.
6.3. Adjustment of the Pedals
Loose pedals may result in fall or injury. For best results, ensure that pedals are not loose. If the pedals are loose, please
use an M8 allen driver to tighten. Before each use, please check all the components of the unicycle before using it. Please
use an M8 allen driver to tighten the set screws on the shaft.
6.4. Cleaning
● Before cleaning, please make sure the product is turned off and unplugged, and the charging plug is closed. Be carful
not to let ater get in the charging plug or the USB plug during cleaning.
● Please use ater or soapy ater ith a soft cloth to ipe clean the shell of the unicycle. Please do not use a high-
pressure ater gun to clean the unicycle.
● TheINMOTIONunicycleisresistantto atersplashesanddustandhasanIP55certification.
45

7. Contact and legal information
7.1. Response to the problems
Please contact us if you or someone around you has any trouble or suggestion during the INMOTION electric scooter use. We
will thoughtfully listen your opinion and we will serve you with enthusiasm.
7.2. Contact us
INMOTION IBERIA
Tel: [phone]
email: [e-mail]
7.3. Local laws fulfillment
INMOTION electric scooter works as a portable intelligent transporting tool, but it’s not a substitute of nowadays modern
transport tools in any case. Is completely restricted to drive the INMOTION electric scooter in public highways. In some
countries, INMOTION electric scooters are also forbidden on public roads. Ask to the local authorities the specific reasons and
condition of your place. You can contact with us or with the authorized dealers of INMOTIONIBERIA.
46
