Innotech SPAR-10-25 User manual

© INNOTECH Arbeitsschutz GmbH. Irrtümer, Druckfehler, technische Änderungen vorbehalten! © INNOTECH Arbeitsschutz GmbH. Errors and misprints accepted. We reserve the right to make technical changes.
SPAR-10-25
Instruction manual
DE – ACHTUNG: Die Verwendung des INNOTECH-Produkts ist erst zulässig, nachdem die
Gebrauchsanleitung in der jeweiligen Landessprache vollständig gelesen und verstanden wurde.
DE
EN – ATTENTION: Use of the INNOTECH product is permitted only after the instruction
manual has been read and fully understood in the respective language.
EN
IT – ATTENZIONE: L'utilizzo del prodotto INNOTECH è permesso solo previa lettura e
comprensione dell'intero manuale di istruzioni nella lingua del relativo paese di utilizzo.
IT
FR – ATTENTION : L'utilisation du produit INNOTECH n'est autorisée qu'après avoir
entièrement lu et compris la notice d'utilisation dans la langue du pays concerné.
FR
NL – ATTENTIE: Dit INNOTECH-product mag pas gebruikt worden nadat u de gebrui-
kershandleiding in de taal van het betreffende land gelezen en begrepen hebt.
NL
SV – OBS: Denna INNOTECH-produkt får inte användas förrän bruksanvisningen på
respektive lands språk har lästs igenom och förståtts.
SV
DK – GIV AGT: Du må først bruge et produkt fra Innotech, efter du har læst og forstået
brugsvejledningen i fuldt omfang i dit lands sprog.
DK
ES – ATENCIÓN: Se autorizará el uso de los productos INNOTECH una vez que se hayan
leído y entendido las instrucciones de uso en el idioma del país.
ES
PT – ATENÇÃO: O uso do produto INNOTECH apenas é permitido depois de ter lido e
compreendido na totalidade as instruções de uso na respetiva língua nacional.
PT
PL – UWAGA: Produkty firmy INNOTECH mogą być używane dopiero po dokładnym
zapoznaniu się z całą instrukcją obsługi w ojczystym języku.
PL
TR – DİKKAT: INNOTECH ürününün kullanımına ancak ilgili ülkenin dilinde sunulmuş
olan kullanım kılavuzunun tamamen okunmasından ve anlaşılmasından sonra izin verilir.
TR
SL – POZOR: Uporaba izdelka INNOTECH je dovoljena šele po tem, ko ste navodila pre-
brali v celoti v ustreznem jeziku svoje dežele in jih tudi razumeli.
SL
CZ – POZOR: Práce s výrobkem INNOTECH je povolena teprve po kompletním přečtení a
porozumění návodu k použití v jazyku daného státu.
CZ
SK – POZOR: Produkt INNOTECH môžete používať až po prečítaní a porozumení celého
návodu na použitie pre príslušnú krajinu.
SK
HU – FIGYELEM: Az INNOTECH termékek használata csak azt követően engedélyezett,
hogy saját nyelvén elolvasta és megértette a teljes használati utasítást.
HU
ZH – 注意：只有在仔细阅读并完全理解了当地语言的使用说明后，才能使用 INNOTECH 公司的产品。
ZH

2SPAR-10-25 / 180223 / www.innotech.at
EN
1TABLE OF CONTENTS
[2] DESCRIPTION OF SYMBOLS 3
[3] SAFETY INSTRUCTIONS 4
[4] COMPONENTS/MATERIAL 6
[5] USE 6
[6] INSPECTION 7
[7] WARRANTY 8
[8] APPROVAL 8
[9] SIGNS & MARKINGS 9
[10] DIMENSIONS 10
[11] INSTALLATION INSTRUCTIONS 10
[12] INSTALLATION SUBSTRATE 11
[13] INSTALLATION TOOL 11
[14] INSTALLATION 12
[15] DISPOSAL 13
[16] ACCEPTANCE LOG 14
[17] SAFETY SYSTEM INSTRUCTIONS 15
[18] TEST LOG 16
[19] DEVELOPMENT & SALES 18

3
EN
SPAR-10-25 / 180223 / www.innotech.at
2DESCRIPTION OF SYMBOLS
Additional information/tip
Warning/danger information
For a DIRECTLY threatening hazard which results in
serious physical injury or death.
ücorrect wrong
For a potentially DANGEROUS situation which results in
serious physical injury or death.
For a POTENTIALLY dangerous situation which could result in
slight physical injuries and material damage.
DANGER
WARNING
CAUTION

4SPAR-10-25 / 180223 / www.innotech.at
EN
3SAFETY INSTRUCTIONS
- The restraint system may by tted or used only be persons who:
• are trained in "personal protective equipment" (PPE).
• are in good physical and mental health. Medical conditions such
as cardiovascular problems, intake of medicines, consumption of alcohol
negatively aect the safety of the user.
• are familiar with the locally applicable safety regulations.
- The restraint system may be installed only by specialised experts familiar with
the roof safety system and in compliance with the current state of the art.
- When installing/using the INNOTECH "SPAR-10-25" anchorage device, comply with
the respective accident prevention regulations (e.g. working on roofs).
-A plan must be available that species rescue procedures for all possible
emergencies. Attention! After a fall, an extended period of suspension in the
personal protective equipment can cause severe injuries or even death
(suspension trauma).
- Before starting work, ensure that no objects can fall to the ground from the work
site. The area below the work site (pavement, etc.) must be kept clear.
- Plan, install, and use the anchorage point in such a manner that no fall over the
edge is possible if the personal protective equipment (PPE) is used properly.
See planning documents at www.innotech-safety.eu.
- When accessing the roof safety system, you must document the positions of the
anchorage devices by means of templates (e.g. view of the roof from above).
- No changes may be made to the restraint system.
- If used on sloping roofs, roof avalanches (ice, snow) must be prevented by the
use of suitable devices to hold back snow.
- After a fall and the resulting strain, you must stop using the entire restraint system
and have it (component parts, fastening to the substrate, etc.) checked by
a specialist.
- When installation is complete, these instructions must be stored by the building
owner and made available to the user. Carefully complete the acceptance protocol,
test sheet, and test log.
- Understand and accept the possibilities and restrictions of the protective equipment,
as well as the risks associated with its use.
- Make particularly sure that the restraint system cannot be damaged by sharp edges.
Comply with the following safety instructions and the latest state of the art.
3.1 GENERAL

5
EN
SPAR-10-25 / 180223 / www.innotech.at
3SAFETY INSTRUCTIONS
If uncertainties arise during installation, it is imperative that you contact
the manufacturer.
3.2 SAFE INSTALLATION
3.3 SAFE USE
- All stainless steel bolts must be greased with a suitable lubricant before installation
(provided: Weicon AntiSeize ASW 10000 or equivalent).
- Ensure that stainless steel does not come into contact with swarf or steel tools,
as this can lead to corrosion.
- Document the correct fastening of the restraint system to the building with dowel
logs, and provide photos of each installation situation.
- Only suitable for a single installation!
- The roof covering must be properly sealed in accordance with applicable guidelines.
-The minimum free space necessary under the edge is calculated as follows:
Deformation of the anchorage device under load + manufacturer's specication
for the personal protective equipment used + body height + 1 m safety margin.
-Hazards may arise when combining individual elements of the specied equipment,
since the safe function of one of the elements can be impaired. Follow the specic
instructions for each element.
- Attachment to the INNOTECH "SPAR-10-25" is always made with one carabiner
through the rotating anchorage eye, and this must be used with personal
protective equipment in accordance with EN 361 (safety harness) and EN 363
(fall arrest system).
-ATTENTION! For horizontal use, only lanyards may be used that are suited for this
purpose and have been tested for the respective edges (sharp edges, trapezoidal
corrugated sheeting, steel girders, concrete, etc.).
- Do NOT use restraint systems if wind speeds are higher than normal.
-Children and pregnant women must NOT use the restraint system.
- If you provide the restraint system to external contractors, understanding of these
instruction manual must be conrmed in writing.
- If the equipment is sold to another country, the instruction manual must be provided
in the respective national language.
- Comply with the local lightning protection regulations.

6SPAR-10-25 / 180223 / www.innotech.at
EN
4COMPONENTS/MATERIAL
INNOTECH "SPAR-10-25" was developed as an anchorage point for the personal safety
of 3 people (including 1 person for the provision of rst aid) and it is suitable for the
following fall protection systems in accordance with EN 363:2008:
- Restraint systems
- Fall arrest systems
- Rescue systems
Comply with the manufacturer's instructions for the personal
protective equipment being used.
5INTENDED
USE
DANGER TO LIFE from incorrect use.
- Use INNOTECH "SPAR-10-25" ONLY for personal safety.
-NEVER hang loads from the INNOTECH "SPAR-10-25".
!
DANGER
A
B
CDE
A) Instruction manual
B) Lubricant: Weicon AntiSeize ASW10000
C) Hexagonal nut M16: Stainless steel, quality A2
D) Hexagonal bolt M16 x 45: Stainless steel, quality A2
E) Anchorage eye Stainless steel, quality 1.4301

7
EN
SPAR-10-25 / 180223 / www.innotech.at
6.1 CHECK BEFORE EVERY USE
6INSPECTION
If there is doubt about the safe functioning of the restraint system,
do NOT use it any more, and have it inspected by a specialist
(written documentation). If necessary, replace the product.
DANGER TO LIFE from damage to the INNOTECH "SPAR-10-25".
- INNOTECH "SPAR-10-25" must be in perfect condition.
- Do NOT continue to use INNOTECH "SPAR-10-25" if:
• Damage or wear to its components is obvious.
• Other defects were observed (loose threaded connections, deformation,
corrosion, wear, defective roof sealing).
• Strain has been caused by a fall (exception: provision of rst aid).
• The product identication is illegible.
!
DANGER
Before every use, visually inspect INNOTECH "SPAR-10-25" for obvious defects.
Test the suitability for use of the complete restraint system on the basis of the
acceptance protocol and the test log.
The inspection intervals are found in the test log.
6.2 INSPECT EVERY YEAR
Have INNOTECH "SPAR-10-25" inspected at least once each year by a specialist who
is familiar with the restraint system. The user's safety depends on the eectiveness
and reliability of the equipment.
Shorter intervals between inspections may be required, depending on the intensity
of use, and the environment (e.g. in corrosive atmospheres, etc.).
Document the inspection by the specialist in the test log in the instruction manual, and
keep it with the instruction manual.

8SPAR-10-25 / 180223 / www.innotech.at
EN
7WARRANTY
For normal conditions of use, the guarantee period for manufacturing defects on all parts
is 2 years from the date of purchase. This period is reduced if equipment is used
in corrosive atmospheres.
If there is strain (a fall, weight of snow, etc.) the warranty claim is void for those
components that were designed to absorb energy, or which deform.
For system installation and for components planned and installed
by specialised installation companies under their own responsibility,
INNOTECH assumes neither responsibility nor warranty in the case
of improper use.
8APPROVAL
INNOTECH "SPAR-10-25" was tested and certied as an anchorage device as per
EN 795:2012 TYPE A and CEN/TS16415.
The notified authority participating in the type test:
DEKRA EXAM GmbH, Dinnendahlstr. 9, 44809 Bochum, Germany C0158
The type test was performed in accordance with EN 795:2012

9
EN
SPAR-10-25 / 180223 / www.innotech.at
9SIGNS & MARKINGS
A) Name or logo of the manufacturer/reseller: INNOTECH
B) Type designation: SPAR-10-25
C) Indication that instructions in the manual
must be followed:
D) Maximum number of people who can be secured: 3 (including 1 person for
provision of rst-aid)
E) Year of manufacture and manufacturer's
serial number: JJJJ-....
F) Number of the applicable standard: EN 795:2012 TYPE A
S
P
A
R
-
1
0
-
2
5
7
9
5
:
N
2
E
0
1
.
.
2
.
-
T
.
.
y
-
p
J
J
A
J
J
max.
Z-14.9-732
AB
C
D
EF

10 SPAR-10-25 / 180223 / www.innotech.at
EN
10 DIMENSIONS
55
33
86
81
M 16
26
Beschriftung
[mm]
11 INSTALLATION INSTRUCTIONS
Use INNOTECH "SPAR-10-25" only as a replacement anchorage eye on INNOTECH
post structures (anchorage points), e.g.: on
- INNOTECH "STABIL/STA-10-300"
- INNOTECH "FALZ-15/45", ...
Exception:
INNOTECH "EAP-POINT-11/-12", "EAP-VARIO-15"
Read and follow the instruction manual for the respective INNOTECH product
(check for compatibility).
Use the eyebolt as an anchorage
point for additional PPE to prevent
falls from a height
marking

11
EN
SPAR-10-25 / 180223 / www.innotech.at
2 x
12 INSTALLATION SUBSTRATE
The basic prerequisite for correct technical installation is an INNOTECH anchorage
point tested and tted as per EN 795:1996 or EN 795:2012, and the use of the original
fastener listed in this manual.
DANGER TO LIFE from installation on an unsuitable substrate.
- Install INNOTECH "SPAR-10-25" only onto INNOTECH anchorage points.
- Install INNOTECH "SPAR-10-25" anchorage points onto a static
load-bearing sub-construction.
-In cases of doubt, have the installation substrate examined by a statics
engineer or by the manufacturer.
!
DANGER
13 INSTALLATION TOOL
Read and follow the instruction manual for the respective INNOTECH product
(check for compatibility).
Spanner size = 24

12 SPAR-10-25 / 180223 / www.innotech.at
EN
1.
14 INSTALLATION
2x
2.
DONE!
ü
DANGER TO LIFE from installation which is NOT carried
out correctly.
- Install INNOTECH "SPAR-10-25" correctly as per instruction
manual.
- Refer to the respective instruction manual for the edge
spacings of the INNOTECH anchorage point from the end
of the roof deck.
!
DANGER

13
SPAR-10-25 / 180223 / www.innotech.at
EN
15 DISPOSAL
Do NOT throw the restraint system into domestic waste.
As per national requirements, gather together the used parts, and send
them for environmentally friendly re-use.

14 SPAR-10-25 / 180223 / www.innotech.at
16 COPY TEMPLATE
ACCEPTANCE LOG
ACCEPTANCE LOG
SPAR-10-25
ORDER NUMBER:
PROJECT:
CUSTOMER:Specialist: (
Company address:
CONTRACTOR:Specialist: (
Company address:
INSTALLATION: (ýmark with a cross where applicable)
PRODUCT: Item SPAR-10-25 Year of manufacture/Serial number: ________
Single anchorage point (EAP)
Specialist: (
Company address:
FASTENER & PHOTO DOCUMENTATION
PRODUCT: Item _________ Year of manufacture/Serial number:___________
Type designation of anchorage point (e.g.: INNOTECH "STABIL/STA-10-300", INNOTECH "FALZ-15/45", ...)
Date: Location: Photos:
(storage location)
The installation company which signs conrms the correct workmanship (edge spacings, inspection of the substrate, etc.)
The customer accepts the contractor's services. The instruction manual, documentation of the fastenings, photo documentation, and test sheets have been transferred to the
customer (building owner) and are to be made available to the user. When accessing the restraint system, the building owner must document the positions of the anchorage
devices by means of template (e.g. view of the roof from above).
The expert tter familiar with the safety system conrms that the installation work has been executed properly, in accordance with the state of the art,
and with the manufacturer's manufacturer's instruction manual. The technical safety reliability is conrmed by the installation company.
Handover of: (e.g. Travelling eyebolt, personal protective equipment PPE, self retracting lanyard, storage cabinet etc.)
Item Item Item Item
Name:
Customer Fitter
___________________________________________ _________________________________________________
Date, company stamp, signature Date, company stamp, signature

15
EN
SPAR-10-25 / 180223 / www.innotech.at
17 COPY TEMPLATE
SAFETY SYSTEM INSTRUCTIONS
INSTRUCTION FOR THE EXISTING
SAFETY SYSTEM
The building owner must ax this notice in a conspicuous location near the access
to the system.
This system must be used in accordance with the state of the art and
the instruction manual.
The storage location for the instruction manual, test logs, etc. is:
_______________________________________________________________
• Overview template showing the position of the anchorage device:
Mark non-shatter-proof areas (e.g. skylights and/or light strips)
For the maximum limit values of the anchorage device, refer to the relevant instruction
manual or the type plate of your system.
If there is strain caused by fall, or if in doubt, the anchorage device must be taken out of service immediately and
sent to the manufacturer, or to a specialised workshop for inspection and repair.
The same applies if there is damage to the anchorage equipment.

16 SPAR-10-25 / 180223 / www.innotech.at
EN
18 COPY TEMPLATE
TEST LOG
TEST LOG NO. ____ (Part 1/2)
SPAR-10-25
ORDER NUMBER:
PROJECT:
PRODUCT: Item SPAR-10-25 Year of manufacture/Serial number: __________
(Type designation SINGLE ANCHORAGE POINT)
ANNUAL SYSTEM INSPECTION CARRIED OUT ON:
LATEST DATE FOR ANNUAL SYSTEM INSPECTION:
CUSTOMER: Specialist:(
Company address:
CONTRACTOR: Specialist:(
Company address:
INSPECTION POINTS: Rchecked and in order DEFECTS DETECTED:
(Description of defects/measures)
DOCUMENTATION:
Instruction manuals
Acceptance log/fastener documentation/
Photo documentation
PPE (personal protective equipment against falls from a height):
Inspection in accordance with manufacturer's specications
Expiration date
Annual inspection performed
Not checked (no authorisation)
ROOF SEALING:
No damage
No corrosion

17
EN
SPAR-10-25 / 180223 / www.innotech.at
18 COPY TEMPLATE
TEST LOG
Acceptance result: The restraint system corresponds to the manufacturer's instruction manual
and to the state of the art. Technical safety reliability is conrmed.
Comments: _________________________________________________________
Name: _____________________________ ______________________________
Customer Inspection: Contractor (specialist who is familiar with the
restraint system)
___________________________________________ _____________________________________________
Date, company stamp, signature Date, company stamp, signature
TEST LOG NO. ____ (Part 2/2)
SPAR-10-25
INSPECTION POINTS: Rchecked and in order DEFECTS DETECTED:
(Description of defects/ measures)
VISIBLE PARTS OF THE ANCHORAGE DEVICE:
No deformation
Rotation of anchorage eye
No corrosion
Threaded connections secured
Firmly seated
............

18 SPAR-10-25 / 180223 / www.innotech.at
EN
19 DEVELOPMENT & SALES
INNOTECH Arbeitsschutz GmbH, Laizing 10, 4656 Kirchham/Austria.
www.innotech.at
