Insportline Adamys IN 11112 User manual

USER MANUAL –EN
IN 11112 Massage Chair inSPORTline Adamys

2
CONTENTS
SAFETY AND MAINTENANCE............................................................................................................... 3
PARTS DESCRIPTION........................................................................................................................... 5
FUNCTION.............................................................................................................................................. 5
CONTROL............................................................................................................................................... 6
INSTALLATION..................................................................................................................................... 11
PRODUCT SPECIFICATION................................................................................................................ 17
TERMS AND CONDITIONS OF WARRANTY, WARRANTY CLAIMS................................................. 17
Thank you for purchasing this product. Read the entire manual to operate the device correctly.
Observe all safety precautions. Retain the manual for future reference.
NOTE: Our company reserves the right to change design and specifications without previous warning.
Product colour depends on the model.

3
SAFETY AND MAINTENANCE
IMPORTANT SAFETY PRECAUTIONS
•Keep children away from moving parts.
•Use adequate and properly grounded power source.
•For higher safety, plug the cord out from electric outlet after each use, before cleaning or
maintenance.
•Use it only according to the manual.
•Use only original accessories.
•Use it only indoors.
•Read the manual prior to first use.
•Improper use is strictly forbidden.
•Recommended massage length: 20 mins.
•Never use it, if the leather is damaged or worn.
•Never use it, if covers or another components are damaged or worn.
•Keep the ventilation holes free of dirt. Never use it, if it the ventilation is blocked.
•Never put any item on the chair.
•Don’t sleep in the chair.
•Don’t use it under influence of alcohol or drugs.
•Use it one hour after having a meal.
•Don’t exceed massage intensity to avoid injury.
•Place it on a flat, clean and dry surface. Keep a safety clearance of at least 0.6 m round this
device.
•Maximum load: 150 kg
ENVIRONMENT OF USE
•Avoid extreme temperatures and humidity (don’t use it in a bathroom etc.).
•Don’t use it if environment temperature has abruptly changed.
•Don’t use it in dusty or dirty place.
•Assure sufficient ventilation and free space round the chair.
THE CHAIR IS NOT SUITABLE FOR
•People with osteoporosis
•People with heart complications or for people with electronic implants, such as pacemaker etc.
•People with fiver or increased body temperature
•Pregnant women or for women in period
•People with post-traumatic symptoms.
•People with dermal problems
•Users younger than 14 years of age and for people with mental impairment
•People told by a physician to have rest or people who don’t feel well
•People with wet or moist skin (after bath, exercise etc.)

4
•The chair surface is heated. People with higher skin sensitivity must pay especially attention.
SAFETY
•Check proper voltage before start using.
•Never manipulate the cord or cables with wet hands.
•Protect the chair from water to avoid electric shock or product damage.
•Protect wires and don’t modify electric circuit.
•Never use damp cloth to clean electric parts (switch, socket etc.)
•If the power is interrupted, pay attention to avoid an electric shock, when it starts again.
•If the chair doesn’t work properly, stop using and contact service.
•If you don’t feel well, stop using and consult a physician.
MAINTENANCE
•Maintenance must be done only by an expert or professional service. Don’t disassemble it and
don’t modify it.
•Plug it out from the outlet after each use.
•Don’t use it, if the cord, outlet or socket is damaged.
•Before long-time storing roll the cord and store the chair in a dry and clean place.
•Avoid extreme temperatures, fire and heat sources. Protect it from direct sunrays.
•Clean it only with a dry cloth. Never use solvents, petrol or alcohol.
•Due special design, the mechanical parts don’t need any extra maintenance.
•Protect it from sharp items.
•Don’t move it on uneven surface. Before transport, lift it and transport it.
•Don’t use it too long continuously. Make pauses.
TROUBLESHOOTING
•It is normal, you can hear the motor noise during usage.
•If the chair doesn’t work, check power cord connection and the net switch.
•The massage will be automatically stopped after reaching pre-set time. The device switches
off automatically, if it is used for a long time continuously and gets overheated. In this case, let
it get cool for at least 30 mins. before starting it again.

5
PARTS DESCRIPTION
1. Padded headrest
2. Loudspeaker
3. Control panel
4. Forearm airbags
5. Seat cushion
6. Phone pocket
7. Calf rests
8. Footrest
9. Armrest
10. Backrest pads
11. Forearm rest
12. Decorative LED lights
13. Rear cover
14. Controller
15. Base frame
16. Power cord
17. Power cord socket
18. Main switch
19. Fuse box
FUNCTION
•This device features 3D massage mechanism with vertical movement and four massage
wheels.
•The shoulder area is equipped with function of automatic detection of massage points for
precise adjustment of moving hands. To assure the best comfort, this system offers automatic
adjustment of distance between massage hands while following the body shape according to
detected massage points.
•Massage functions: comfort massage, relax massage, pain relieve, complete air massage,
middle-body massage.
•Memory for 3 massage modes.
•Manual adjustment of the upper-body massage, adjustable in 3 levels –overall, partial and
point, 6 types of massage: grasping, kneading, tapping, shiatsu, kneading and tapping, 3D
massage. Massage intensity adjustable in 5 speed levels. Massage-hand distance adjustable
in 5 levels.
•Function for massage of upper body (26 airbags), arm massage (4 airbags) –intensity
adjustable in 3 levels.

6
•Lower-body massage: 4 airbags on back area, 5 airbags on buttock, 40 airbags in leg area.
Intensity adjustable in 3 levels.
•MP3 playing function from a cell phone. Loudspeaker in-built.
•Heating of the back area –carbon fibre (infrared radiation)
•Heating of the knee area –carbon fibre (infrared radiation)
•Extendable footrest according to user height.
•Auto-sitting function –after turning off, the massage hands return automatically into initial
position.
•VFD display
•Decorative LED indicator on the forearm rest
CONTROL
NOTE: Picture for illustration purposes only.

7
1. SWITCHING ON
Power cord plugging-in
Main switch location (ON/OFF)
2. MASSAGE START
•Push the red button to activate massage mode. The chair reclines automatically into massage
position.
•Follows automatic detection of shoulder position and massage points.
•After the detection you can hear a signal sound. Now, you can adjust vertical hand position on
your shoulders. The massage starts automatically within 10 seconds after hand adjustment.
Move massage balls up
Move massage balls down
•Select massage method.
•To select a pre-set mode, use keys A, B or C.
Memory keys
•Setting massage length
Recommended massage length: 20 mins. The max. massage length: 40 mins. Set
unit: 5 mins. When exceeding the max. length of 40 mins., the unit will be added
from begin.

8
•Automatic massage
Relax for musculoskeletal system
F1 Auto
Improving blood circulation
F2 Auto
Relieve from ache: deep massage reducing pains
F3 Auto
Overall air pressure massage. Waist buttock,
hands and legs massaged simultaneously.
F4 Auto
Stretching the body core. First the airbags in calf
rests are activated and the backrest goes
downward. The, the calf rests will move up and
down while stretching body core. Also, the
massage mechanism and airbags on the seat are
activated.
F5 Auto
•Manual function
Button
Description
Display
Grasping on shoulders: 1 method, adjustable speed and
intensity
Kneading and tapping: 1 method, adjustable speed and
intensity
Kneading: 1 method, adjustable speed and intensity
Tapping: 2 methods, adjustable speed, width and
intensity
Shiatsu: 2 methods, adjustable speed, width and
intensity
3D: 4 methods: adjustable speed and intensity
Speed adjustment in 5 levels
Massage hand width: adjustable in 5 levels (in tapping
and kneading )
•Air pressure massage
Button
Description
Display
For air pressure massage of arms

9
Intensity adjustment in 3 levels.
Air pressure massage of lower body (lower body parts, back,
waist and calves).
Intensity adjustment in 3 levels.
Calf stretching: active in air pressure massage for lower body and calves.
•Other manual functions
Button
Description
Display
Decreasing massage intensity for upper body
Increasing massage intensity for upper body
Sole roller: adjustable in 3 levels
Heating on back and knees. Fully activated 3 mins after turning
on.
3. Angle of back and calf rest
Button
Description
Display
Auto lay-down mode
Moving calf rest up –it raises while button pushed
Moving calf rest down –it goes down while button pushed
Backrest lifting button –press this button to lift it slowly
Backrest decline button –press this button to recline it slowly

10
Simultaneous backrest lifting and calf rest declining. Hold the button to change position.
Simultaneous backrest declining and calf rest lifting. Hold the button to change position.
4. Other functions
•Music playing from mobile. It features cell phone pocket and system for music playing.
•3D speakers on upper rests allow the best music enjoyment
•Decorative side LED indicator, automatic switching among red, green, blue, blue-green,
purple, yellow and white colour.
Cell phone pocket (audio
screen)
3D speakers
Decorative LED indicator
5. Shut off power / massage finish
•Push the red button to stop massage, all functions and for automatic return of the back and
foot rest to original position. Also, the massage stops after reaching pre-set time (in this case
rests don’t come back automatically to original position).
•After massage finish the message “Memory Set On” appears on display. The user will be
advised to possible storing of massage mode in the system memory via one of keys. A, B or
C. Push the red button again to turn off the device. Massage hands returns to original position.
The chair shuts down automatically with massage hands restoration if there is no activity
within 10 seconds.
•Unplug from socket
Switch ON/OFF
Unplug power cord from socket
