USER MANUAL –EN
IN 11117 Massage Chair inSPORTline Marvyn

2
CONTENTS
SAFETY AND MAINTENANCE............................................................................................................... 3
PARTS DESCRIPTION........................................................................................................................... 5
FUNCTION.............................................................................................................................................. 5
CONTROL............................................................................................................................................... 6
INSTALLATION..................................................................................................................................... 10
PRODUCT SPECIFICATION................................................................................................................ 12
TERMS AND CONDITIONS OF WARRANTY, WARRANTY CLAIMS................................................. 12
Thank you for purchasing this product. Read the entire manual to operate the device correctly.
Observe all safety precautions. Retain the manual for future reference.
NOTE: Our company reserves the right to change design and specifications without previous warning.
Product colour depends on the model.

3
SAFETY AND MAINTENANCE
IMPORTANT SAFETY PRECAUTIONS
•Keep children away from moving parts.
•Use adequate and properly grounded power source.
•For higher safety, plug the cord out from electric outlet after each use, before cleaning or
maintenance.
•Use it only according to the manual.
•Use only original accessories.
•Use it only indoors.
•Read the manual prior to first use.
•Improper use is strictly forbidden.
•Recommended massage length: 20 mins.
•Never use it, if the leather is damaged or worn.
•Never use it, if covers or another components are damaged or worn.
•Keep the ventilation holes free of dirt. Never use it, if it the ventilation is blocked.
•Never put any item on the chair.
•Don’t sleep in the chair.
•Don’t use it under influence of alcohol or drugs.
•Use it one hour after having a meal.
•Don’t exceed massage intensity to avoid injury.
•Place it on a flat, clean and dry surface and keep safety clearance of at least 0.6 m round the
chair.
•Max. user weight: 100 kg
ENVIRONMENT OF USE
•Avoid extreme temperatures and humidity (don’t use it in a bathroom etc.).
•Don’t use it if environment temperature has abruptly changed.
•Don’t use it in dusty or dirty place.
•Assure sufficient ventilation and free space round the chair.
THE CHAIR IS NOT SUITABLE FOR
•People with osteoporosis
•People with heart complications or for people with electronic implants, such as pacemaker etc.
•People with fiver or increased body temperature
•Pregnant women or for women in period
•People with post-traumatic symptoms
•People with dermal problems
•Users younger than 14 years of age and for people with mental impairment
•People told by a physician to have rest or people who don’t feel well
•People with wet or moist skin (after bath, exercise etc.)

4
•The chair surface is heated. People with higher skin sensitivity must pay especially attention.
SAFETY
•Check proper voltage before start using.
•Never manipulate the cord or cables with wet hands.
•Protect the chair from water to avoid electric shock or product damage.
•Protect wires and don’t modify electric circuit.
•Never use damp cloth to clean electric parts (switch, socket etc.)
•If the power is interrupted, pay attention to avoid an electric shock, when it starts again.
•If the chair doesn’t work properly, stop using and contact service.
•If you don’t feel well, stop using and consult a physician.
MAINTENANCE
•Maintenance must be done only by an expert or professional service. Don’t disassemble it and
don’t modify it.
•Plug it out from the outlet after each use.
•Don’t use it, if the cord, outlet or socket is damaged.
•Before long-time storing roll the cord and store the chair in a dry and clean place.
•Avoid extreme temperatures, fire and heat sources. Protect it from direct sunrays.
•Clean it only with a dry cloth. Never use solvents, petrol or alcohol.
•Due special design, the mechanical parts don’t need any extra maintenance.
•Protect it from sharp items.
•Don’t move it on uneven surface. Before transport, lift it and transport it.
•Don’t use it too long continuously. Make pauses.
TROUBLESHOOTING
•It is normal, you can hear the motor noise during usage.
•If the chair doesn’t work, check power cord connection and the net switch.
•The massage will be automatically stopped after reaching pre-set time. The device switches
off automatically, if it is used for a long time continuously and gets overheated. In this case, let
it get cool for at least 30 mins. before starting it again.

5
PARTS DESCRIPTION
1. Pillow pad
2. Arm airbag assembly
3. Seat cushion
4. Leg frame
5. Foot frame
6. Front cover
7. Back cushion
8. LED colourful indicator
9. Decorating strip
10. Armrest
11. Slide side plate
12. Base
13. Caster
14. Hand controller
15. Chassis cover
16. Movable wheel
17. Power cord
18. Power-cord socket
19. Fuse box
20. Power switch
21. Controller socket
FUNCTION
•The chair features a set of vertically movable massage hands with 4 massage wheels.
•Massage kinds: shiatsu, kneading, tapping, knocking, simultaneous kneading and tapping.
•5 automatic massage modes: comfort, relax, decompress, neck and shoulders, back and
waist.
•Three massage memory functions: M1, M2, M3.
•Manual massage for upper body parts with 5 options: partial, fixed, overall, neck and
shoulders, back and waist. Each mode has adjustable speed in 3 levels. During the fixed
massage, the massage hands can be moved up and down. During tapping, shiatsu or
knocking, the distance between two kneading balls is adjustable in 3 levels: wide, medium,
narrow.
•Air-pressure massage: 3 adjustable modes: full-body air massage, arms (8 airbags), feet (20
airbags) –adjustable intensity in 3 levels.
•Back heating function –carbon fibres.

6
•LED indictor on the side rest.
•Extendable calf rest according to user height.
•Technology „forward-sliding recline“ – back-rest recline for space saving
•Maximally smooth back-rest and seat reclining to horizontal line (Zero Gravity).
•Calf and back rests can be reclined together and automatic return to initial position.
CONTROL
CONTROLLER (PICTURE ONLY FOR ILLUSTRATION):
1. SWITCHING ON THE POWER SUPPLY
Power cord plugging-in
Power switch location (ON/OFF)
2. MASSAGE START
•Push the power button to start massage.
•Wait until detection of shoulders and massage points will be finished.

7
•Adjust position of massage hands using keys UP and DOWN. The shoulder position is
adjustable in 10 grades. Massage will be started automatically within 10 seconds after position
adjustment.
Button
Description
Display
Move the massage balls upward
Move the massage balls downward
•To start the massage, you can also use one of memory buttons M1, M2 or M3 –you can start
massage mode that has been saved in memory from last sored massage.
Function
Button
Memory buttons
for massage
selection
•Automatic massage mode description:
Function
Button
Description
Display
Automatic
massage
Deep massage of acupressure points (relax for painful
area).
Auto F1
Relax for muscles and bones
Auto F2
Optimizing blood circulation
Auto F3
Neck and shoulder massage
Auto F4
Back and waist massage
Auto F5

8
•Upper body
Function
Button
Adjusting of massage balls
Display
Massage kind
Speed, width
Speed
Speed, width
Speed
Speed, width
Speed
3 levels
Width
3 levels
Function
Button
Description
Display
Back-rest
adjustment
Fixed position massage
Local massage (small area)
Global massage
Neck and shoulder massage
Back and waist massage
Adjusting of acupressure point /
target massage areas
Move massage
balls upward
Move massage
balls downward
•Air massage
Function
Button
Description
Display
Full air
For arms, legs and footrest

9
Arm
Arm massage
Leg
Leg and feet
Intensity
3 adjustable levels
•Other available functions
Function
Button
Description
Display
Heating
Heating of the back (long-wave infrared radiation). The chair
will be fully heated within 3 mins. after function activation.
Rise-up
button
Press it and the backrest goes up slowly and the calf rest
goes down. Release it to stop. After reaching the top, a
sound alarm will be given.
Lie-down
button
Press it and the backrest goes down slowly and the calf rest
goes up. Release it to stop. After reaching the bottom, a
sound alarm will be given.
Auto lie-
down mode
Automatic switching among modes (3 modes in all).
3. Switching off / Massage stop
•Push the Power button to stop the massage (back and calf rest comes back to the initial
position) or it pre-set time has expired (in this case the rests don’t return automatically). After a
massage, the actual setting can be stored in computer memory.
•Massage mode storage: After massage stop, the word “Memory” will be displayed. It means,
the user can push keys M1, M2 or M3 before switching off to save actual setting.
•The massage hands and rests return initial position if the Power key is pushed again or within
10 seconds from massage end.
Function
Button
Display
Save
setting
•Switch off the chair after massage finish.

10
Switch location (ON/OFF)
Power cord plugging-out
INSTALLATION
NOTE:
•If the chair is adjusted for lying massage with calf rests in horizontal position, don’t press on
the calf rests with your entire body weight.
4. Installation of linkage pole of calf rests
•Open the package box (Fig. 1), turn it on via controller and set in position according to Fig. 2.
Fig. 1
Fig. 2
•Take off the linkage pole from the seat inside, align at the hole and insert the pin (Fig. 3).
•Fig. 4: Successful installation.
Fig. 3
Fig. 4
