Insta 907 User manual

MNL90000Rev.I 05.19.15
OPERATIONANDMAINTENANCEMANUAL
MODEL907

FORUSEBYQUALIFIEDPERSONNELONLY
WARNING
In case of power cord damage, do not
attempt to repair or replace the power cord.
Contact the manufacturer or the local
distributor.
WARNING
For protection against fire and electric shock,
replace with same type and rating fuse. Fuse
rated max. 1 amp 120V.
WARNING
Hot Surface. Avoid contact.
CAUTION
During normal operation, the base of the
machine needs to be installed or placed
above the wall socket.
CAUTION
The recommended input pressure shall not
exceed 100 psi. The operating pressure is
from 30-100psi.
CAUTION
The operation may be terminated by
pressing the DISENGAGE switch.
CAUTION
The machine is to be operated by one
person only.
CAUTION
To reduce the risk of electric shock and
injury to persons, disconnect from power
supply before servicing and /or cleaning.
Safety Summary
Power Off
Power On
Hot Surface
Risk of Electrical Shock
Protective Earth Terminal
Ground
Wet Conditions
Start Action
Caution - Warning
Disengage
International Symbols
1

FORUSEBYQUALIFIEDPERSONNELONLY
Congratulations!
Your selection of the Insta heat seal machine is a sound business decision. Insta equipment is
the result of the highest quality engineering and time-tested design. Your new machine
combined with Insta’s reputation of innovation in the heat-sealing field, ensures the continuing
capability of delivering the best decorated substrates possible.
This manual describes installation, operation, and maintenance procedures for your 907 series
machine, as well as easy to use instructions for on-the-spot maintenance.
Your machine will have a long trouble-free life. Read this manual and keep it with your
machine. It's your key to proper operation and lasting service.
General Description
The 907 is a dual station shuttle press for high speed label application. This pneumatic heat
press machine is air-operated to prevent operator fatigue and is equipped with 2 independent
lower platens, with an upper heated platen that swings between the two, for optimal efficiency
The 907 has been strategically designed to generate & evenly distribute tremendous pressure
throughout the entire platen. And, its cast-in tubular heating element heats the metal from
within, to produce consistent and long lasting heat. A successful heat transfer application
requires 3 key elements to work in tandem– time, temperature & pressure. The 907 has
mastered those elements and gets the job done every time.
Our heat press machines serve as a method of product identification and provide customers
with a means of branding their textile-based products through the application of tagless labels,
logos, decorative front and back graphics and over-sized prints.
Limited Machine Warranty
Insta warrants this heat seal machine, when operated under normal conditions, to be free from
manufacturing defects in material and workmanship for a period of one year on parts (lifetime
on the upper heating element) and 90 days on labor from the invoice date.
This warranty will be effective only when Insta authorizes the original purchaser to return the
product to the factory in Cerritos, California freight prepaid, and only when the product upon
examination has proven to be defective.
2

FORUSEBYQUALIFIEDPERSONNELONLY
This warranty does not apply to any machine that has been subjected to misuse, negligence or
accident.
Insta shall not be liable for the injury, loss or damage, direct or consequential, arising out of the
use or the inability to use the product.
No claim of any kind shall be greater in amount than the sale price of the product or part to
which claim is made.
This is the sole warranty given by the company, it is in lieu of any other warranties, expressed
or implied, in law or in fact, including the warranties of merchantability and fitness for a
particular use, and is accepted as such by the purchaser in taking delivery of this product.
3

FORUSEBYQUALIFIEDPERSONNELONLY
IP54=IP
1st Digit5
2nd Digit4
1st
Digit Protection from solid objects 2nd Digit Protection from moisture
0 Non protected 0 Non protected
1Objects greater
than 50mm 1 Dripping water
2Objects greater
than 12mm 2Dripping water
when tilted up to 15
deg.
3Objects greater
than 2.5mm 3 Spraying water
4Objects greater
than 1mm 4 Splashing water
5 Dust protected 5 Water jets
6 Dust tight 6 Heavy seas
-- --- 7 .15m – 1m
immersion
-- --- 8 1m + submersion
Degree of Protection
IP (Ingress Protection) rating according to IEC
60529.
NOTE
IEC 60529 does not specify sealing
effectiveness against the following:
mechanical damage of the equipment;
the risk of explosion; certain types of
liquid conditions, e.g. those that are
produced by condensation; corrosive
vapours; funus; vermin
Installation
DOMESTIC – 907
Use a separate 15 amp AC
circuit. Only industrial extension
cords with proper wire size should
be used: size 18/3 wire for
distances up to 25 feet, and size
16/3 for distances up to 50 feet.
INTERNATIONAL – 907
Use a designated 16-amp AC
circuit. Only industrial extension
cords with proper wire size (2.5
sq. mm) shall be used.
IMPORTANT
The appliance must be plugged
into a proper receptacle of the
proper size and rating. Equally
important the line voltage must be
able to accommodate this
appliance as well as other
appliances operating on this
circuit.
Specifications
Voltage 120 Volts AC 50/60 Hertz
Model 907 1000 Watts 8.3 Amps
Voltage 230 Volts AC 50/60 Hertz
Model 907 920 Watts 4.0 Amps
Model 907
MachineWeight61 Pounds (27.7 KG)
4

FORUSEBYQUALIFIEDPERSONNELONLY
Operation
1. Push ON/OFF switch to ON position.
2. Set desired temperature (See Controller
Operation).
3. Allow the machine to warm up until the selected
temperature is reached.
4. Set the desired pressure by adjusting the air
pressure regulator.
5. Select the desired timing cycle (See Controller
Operation).
6. Place the substrate on lower platen, smoothing
out all wrinkles.
7. Position transfer or lettering on substrate.
8. Swing the upper arm into position directly over
the lower platen.
9. Depress and hold both start buttons, one on
each side of the machine, simultaneously until
the lower platen contacts the upper platen. The
start buttons must be held until the upper
and lower platens make contact. At this point
the machine operation is fully automatic. The
platens seal the transfer to the substrate and
then release automatically at the end of the
selected timing cycle.
10. Swing away the upper platen to the opposite
side and remove substrate.
11. The DISENGAGE button may be pushed at
anytime deactivate the machine.
SAFETY DELAY FEATURE
For operator safety the machine
shall not operate unless the upper
platen has fully reached the left
hand position. An additional delay
has been incorporated in machines
running software 2.29 (see point 9).
Solid State Controller
This controller has three (4) control features:
1. Temperature - Temperature may be set from
125 - 450°F (52-232°C).
2. Time - Time may be set from 1 second to 10
minutes.
3. Counter – Cycle counter counts the number of
applications from 1 to 9999 (see additional Notes
– Counter).
4. Presets ‐Five (5) presets that can be
programmed by the user. Each preset will retain
a temperature and time setting, i.e. Program #1
could be set for 325°F and 10 seconds while
Program #2 could be set for 375°F and 15
seconds. Once the five presets have been
programmed, the user need only press the PGM
button several times until the desired program is
selected. The lit LED above the PGM button
indicates the selected program. Note: there is
also a sixth setting that is indicated by no lit
LED's.
NOTE
Another substrate may be prepared
on the unused platen during the
sealing operation of the used
platen.
5

FORUSEBYQUALIFIEDPERSONNELONLY
Controller Operation
1. Select the desired preset program by pressing
the PGM button until the LED above the PGM
button indicates the desired setting.
2. If a setting other than the programmed presets
are desired, press the PGM button until none
of the LED's above the PGM button are lit.
3. Changing the Temperature
•Press the MODE button until
temperature is displayed.
•Press and hold SET button in while
pressing the UP (↑) or DOWN (↓)
arrow buttons to the desired
temperature setting.
4. Changing the Time
•Press the MODE button until timer is
displayed.
•Press and hold SET button in while
pressing the UP (↑) or DOWN (↓)
arrow buttons to the desired timer
setting.
NOTE
For operator safety the machine is
designed not to operate unless the
upper arm is directly over one of the
lower platens.
NOTE
When the machine is operating with
none of the LED’s lit, i.e. no presets,
the time and temperature will be saved
even if the power is turned off. The
presets will also be saved when the
power is turned off.
NOTE
The DISENGAGE switch (located in
the center of the instrument panel)
may be pushed at any time to
deactivate the machine.
6
Setting the Presets
1. Push and hold both the MODE and PGM
buttons for 3-5 seconds until one of the
programs LED's starts to blink. This is the
programming mode.
2. A blinking LED above the PGM button
indicates which preset is active.
3. Select a program (1,2,3,4,or 5) by pressing
the PGM button.
4. Setting Temperature
•Press the MODE button until
temperature is displayed.
•Press and hold SET button in while
pressing the UP (↑) or DOWN (↓) arrow
buttons to the desired temperature
setting.
5. Setting Time
•Press the MODE button until time is
displayed.
•Press and hold SET button in while
pressing the UP (↑) or DOWN (↓) arrow
buttons to the desired timer setting.
6. Repeat steps 3-5 until all five (5) presets
have the desired preset (temperature/time
cycle).
NOTE
If a Fahrenheit/Celsius change is
desired, see Additional Notes –
Temperature.

FORUSEBYQUALIFIEDPERSONNELONLY
NOTE
When in the normal mode, none of
the five program LED's will be
blinking and the user cannot change
the time and temperature for any of
the five presets.
NOTE
When the machine is operating with
none of the five program LED’s lit, i.e.
no presets, the time and temperature
WILL BE SAVED even if the power is
turned off. The presets will also be
saved when the power is turned off.
7. Push and hold both the MODE and PGM
buttons for 3-5 seconds until a single beep
is heard to exit the programming mode.
7
Timer
•The controller has a count down timer, which
automatically disengages (opens) the machine
at the completion of the application.
•Timer display is minutes:seconds. Range is
00:00 to 10:00, Colons (:) flash while timer is
running.
Counter
The controller has a built in cycle counter.
•Press MODE button until the counter is
displayed.
•Counter display range is 0000 to 9999.
•To reset the cycle counter, display the counter
reading, then push and hold UP (↑) and DOWN
(↓) arrow buttons for 3 seconds until the counter
resets to zero (0000) on the display.
NOTE
The DISENGAGE switch (located in
the center of the instrument panel)
may be pushed at any time to
deactivate the machine. The cycle
will stop immediately, and the timer
will reset.
Additional Notes

FORUSEBYQUALIFIEDPERSONNELONLY
Preventive Maintenance
Suggestions
The Avery Denninson heat seal machines are
relatively maintenance free. For long, trouble-free
life, the following preventive maintenance should be
followed:
1. Do not heat seal items such as buttons, pins,
snaps, or zippers that tend to cut the silicone
rubber pad or scratch the Teflon heat platen.
2. Periodically clean the Teflon-coated heat platen
with a non-abrasive piece of cloth. Stubborn
stains may be cleaned, when platen is cool,
with mineral spirits.
3. When the heat platen is hot and not in use, keep
in open position (away from the silicone rubber
pad).
4. To prevent soiling of substrate, periodic wiping of
the entire exterior machine, including platens,
with a clean rag is recommended. If necessary,
use mineral spirits for cleaning a cold machine.
Since mineral spirits are flammable, use
precautions and keep away from sparks, flame,
or hot heat platen.
5. The machine requires periodic lubrication with a
high-temperature, non-melting grease
(MPPL023). Lubricate the post and heat platen’s
pivot pin depending upon usage. (Once every
month if used continuously.)
6. Turn off air pressure when machine is not being
used.
NOTE
Wipe off any excess oil or grease.
8
WARNING
Power cord replacement
should be from the
manufacturer only (because it
requires a specially prepared
cord).
With the above items you should be able to
accomplish most repairs.
Replacement of Parts
Refer to the 3D explosive view and the bill of
materials at the end of this manual.
NOTE
Machines are shipped with a standard
air fitting. EUROPEAN models
include a MPPF086 quick
disconnect air fitting.
Micro Switch Adjustment
1. Disconnect power supply; remove the top panel
of the instrument housing.
2. Swing upper platen into working position until
stop is reached.
3. The micro switch must be adjusted to JUST
CLOSE, as upper platen swings to this position.
4. To change micro switch setting, loosen the
screw on slotted end of micro switch. Move in
desired direction to bring switch to JUST
CLOSED condition (listen for an audible click
from micro switch) and re tighten screw.
Airborne Noise Emission
Sound pressure level at operator station does not
exceed 70 dB(A).
General Maintenance
It is recommended that you have the following
items available:
A.Regular screw driver
B.Phillips head screw driver
C.Small adjustable wrench
D.Needle nose pliers with insulated handle
E.Set of Allen wrenches
F.Grease gun
G.Special high temperature grease MPPL023

FORUSEBYQUALIFIEDPERSONNELONLY
Model 907
The Sleep Mode / Automatic Shut Off is designed to save
electrical consumption when the user is not engaged in the
usage of machines for a pre-determined period of time
defined by the user.
During activation, any disturbances such as the key press
or heat press cycle will reset the machine and reset the
timers for both Sleep Mode and Automatic Shut Off.
When the Automatic Shut Off is set to OFF and the Sleep
Mode is activated, any disturbances to the machine will
disengage the Sleep Mode.
When the Sleep Mode is set to OFF, the timer for Automatic
Shut Off will activate and resets after every key press or
heat press cycle.
•Sleep Time
(Level 1 – Menu 1)
•Set Back Temperature
(Level 1 – Menu 2)
•Automatic Shut Off Time
(Level 1 – Menu 3)
•Temperature Conversion
(Level 1 – Menu 4)
•User Offset
(Level 1 – Menu 5)
Sleep Time
1. Display the COUNTER . Enter the Factory Mode
by pressing and holding together SET then MODE
for 3 to 5 seconds.
2. Press and hold together SET then UP or DOWN
Arrow to set Sleep Mode Time.
1 ._XX ; XX = Minutes from OFF to 99
Set Back Temperature
3. Press MODE.
4. Press and hold together SET + UP or DOWN Arrow
to set Set Back Temperature.
2._XXX ; XXX = Temp. from 225F to 300F
+
+or
+or
Sleep Time, Set Back
Temperature, Automatic Shut
Off, Temperature Conversion,
and User Offset
9

FORUSEBYQUALIFIEDPERSONNELONLY
Automatic Shut Off
5. Press MODE.
6. Press and hold together SET + UP or DOWN
Arrow to set Auto Shut Off Time.
3._XX ; XX = Minutes from OFF to 99
Temperature Conversion
7. Press MODE.
8. Press and hold together SET + UP or DOWN
Arrow to set Fahrenheit or Celsius.
4._X ; X = F or C
+or
+or
User Offset
9. Press MODE.
10. Press and hold together SET + UP or DOWN Arrow
to set the Offset.
5._XX ; XX = Offset Number
Exit
11. Press and hold together SET then MODE for 3 to 5
seconds at any time to Exit.
+or
+
10

FORUSEBYQUALIFIEDPERSONNELONLY
Safety and Danger Zone Diagram
Hot Surface.
Avoid contact
with Upper Platen
and Aluminum
Casing
Keep hands clear
Disengage
Do not handle the
machinery with
wet hands
Machinery should
be operated
under a secure
flat surface
11

FORUSEBYQUALIFIEDPERSONNELONLY
12
907WiringDiagram0412

FORUSEBYQUALIFIEDPERSONNELONLY
13

MODEL MODEL
907 907
NO PART NAME 120V AC 230V AC
1 AIR SOLENOID VALVE ASS'Y MPPA903 MPPA903
2 NIPPLE, CYLINDER MHN14412 MHN14412
3 AIR CYLINDER ASS'Y MPPA413 MPPA413
4 SCREW, COMPRESSION SPRING 1/4-20 X 3/4 MHSB142034 MHSB142034
5 WASHER, SPRING MHWC716 MHWC716
6 SPRING, COMPRESSION MPSS884 MPSS884
7 SCREW, MICRO SWITCH 4-40 X 1/2 MHSR44012 MHSR44012
8 SCREW, MICRO SWITCH 4-40 X 3/4 MHSR44034 MHSR44034
9 MICRO SWITCH (ARM) MPPS044 MPPS044
10 SCREW, MICRO SWITCH 8-32 X3/8 MHSP83238 MHSP83238
11 PLATE, MICRO SWITCH MOUNTING MH700213 MH700213
12 INSULATOR, MICRO SWITCH MH700214 MH700214
13 BRACKET, MICRO SWITCH MPSM90018 MPSM90018
14 SCREW, MICRO SWITCH BRACKET 10-24 X3/8 MHSP102438 MHSP102438
15 SCREW, STOP BRACKET 1/4-20 X1/2 MHSH142012 MHSH142012
16 BRACKET, STOP MPSM90010 MPSM90010
17 ARM ASS'Y MPSA90021 MPSA90021
18 SCREW, 8-32 X3/8 MHSP83238 MHSP83238
19 WASHER MHWSAE8 MHWSAE8
20 CLAMP, CABLE MHCC516 MHCC516
21 WIRE HARNESS MPPW931 MPPW932
22 WASHER MHWSAE8 MHWSAE8
23 SCREW, 8-32 X3/8 MHSP83238 MHSP83238
24 TERMINAL BLOCK MPST6994 MPST6994
25 LABEL, CONTROL OVERLAY, 907 MPPL015 MPPL015
26 DIGITAL CONTROLLER MPPT752 MPPT752
27 MOUNT, AIR REGULATOR FILTER MPSM90009 MPSM90009
28 AIR PRESSURE/FILTER REGULATOR ASS'Y MPPA900 MPPA900
29 SCREW, AIR FILTER 1/4-20 X1/2 MHSH142012 MHSH142012
30 AIR GAUGE ASS'Y MPPA025 MPPA025
31 NUT, JAM CLEVIS MHJN21 MHJN21
32 BUSHING, GUIDE POST MPSB070 MPSB070
33 NUT, HEX MHNH832 MHNH832
34 WASHER MHWSAE8 MHWSAE8
35 CLAMP, CABLE MHCC516 MHCC516
36 BRACKET, WIRE STABILIZER MPSM90019 MPSM90019
37 SCREW, 8-32 X1/2 MHSP83212 MHSP83212
38 BRACKET, ELECTRICAL SUPPORT MPSM90024 MPSM90024
39 BASE ASS'Y MPSB90711 MPSB90711
40 SCREW, SOCKET 5/16-18 X3/4 MHH5161834 MHH5161834
41 GUIDE POST ASS'Y MPSG90008 MPSG90008
42 CAM, MICRO SWITCH MPSC90020 MPSC90020
43 SCREW, PAN HD 6-32 X 1/4 MHSP63214 MHSP63214
44 SCREW, SOCKET HD 5/16-18 X3/4 MHH5161834 MHH5161834
45 COLLAR, POST MPSC90023 MPSC90023
46 PANEL, TOP COVER (SHEETMETAL) MPSM90004 MPSM90004
47 PANEL, FRONT (SHEET METAL) MPSM90703 MPSM90703
48 DISENGAGE SWITCH ASS'Y MPPS713 MPPS713
50 STARTSWITCH ASS'Y MPPS703 MPPS703
51 POWER SWITCH (ON/OFF) ASS'Y MPPS060 MPPS060
52 PANEL, WRAP AROUND (SHEET METAL) MPSM90701 MPSM90701
53 SCREW, 10-24 X3/8 MHSP102438 MHSP102438
54 SCREW, 6-32 X1/4 MHP63214ST MHP63214ST
MODEL 907 1112

55 HANDLE MPSH900 MPSH900
56 SCREW, 8-32 X 1/2 MHSP83212 MHSP83212
57 PLATE, BOTTOM (SHEET METAL) MPSM90002 MPSM90002
58 SCREW, TRANSFORMER MHSP83238 MHSP83238
59 SPACER CYLINDER MPS90049 MPS90049
64 TRANSFORMER MPT90319 MPT90319
65 WASHER MHWSAE8 MHWSAE8
66 NUT, TRANSFORMER MHNH832 MHNH832
67 AIR HOSE MPPA005 MPPA005
68 POWER CORD (USA MODEL) MPPW161 MPPW162
68A POWER CORD (EUROPEAN MODEL) N/A MPPW202
68B POWER CORD (GREAT BRITAIN) N/A MPPW203
69 NUT, HEX JAM MHNHJ114 MHNHJ114
70 COLLAR, PISTON SHAFT MPSB900 MPSB900
71 SCREW, SET 1/4-20 X 3/8 MHST142038 MHST142038
72 AIR FITTING INLET MPPF085 MPPF085
73 RELAY, SOLID STATE MPSR2450 MPSR2450
76 SCREW, FUSE MHSF44038 MHSF44038
77 FUSE F1 (1 AMP 250V) MPPF701R MPPF701R
78 FUSE HOLDER ASSEMBLY MPPF708 MPPF708
79 NUT, FUSE MHNH440 MHNH440
80 SCREW, LOWER PLATEN TUBE MHSH142012 MHSH142012
81 LOWER PLATEN SUPPORT TUBE MPSP477 MPSP477
82 SOCKET, LOWER PLATEN MPSP499 MPSP499
83 KNOB, LOWER PLATEN MH4210H MH4210H
84 SCREW, SOCKET ATTACHMENT MHSB142012 MHSB142012
111 SILICONE RUBBER PAD MPPP026 MPPP026
113 SENSOR, RTD (2000 OHM) MPPS210 MPPS210
116 PIN, UPPER PLATEN MPPR38112 MPPR38112
118 INSULATION FIBERGLASS MPSP249 MPSP249
120 SCREW, SHROUD (4 SET) MHSB381612 MHSB381612
121 HEAT SHROUD MPS90143 MPS90143
127 GROUND WIRING WITH SCREW MPW90140 MPW90140
A1 CLEVIS ASS'Y MPSC919 MPSC919
A2 UPPER PLATEN ASS'Y MPP9071A MPP9072A
A3 LOWER PLATEN ASS'Y MPSP475 MPSP475
MODEL 907 1112

FORUSEBYQUALIFIEDPERSONNELONLY
Notes:
16

FORUSEBYQUALIFIEDPERSONNELONLY
17

FORUSEBYQUALIFIEDPERSONNELONLY

FORUSEBYQUALIFIEDPERSONNELONLY
