INSTEON ON/Off Switch User manual

•
•
•
•
•
•
•
•
...

INSTEON On/Off Switch
On
LED
-
•
•
•
•
0
Status
LED
•
Set Button

Tools Needed for Installation
Phillips Screwdriver
Flathead Screwdriver
Voltage Detector
Wire CutterI Stripper
Disconnect Power
Always disconnect power before
installation.
Contact INSTEON
Support when uncertain about
installation.
1-866-243-8022

0 Basic Installation
Turn off
power
to
your switch at the
electrical service panel.
or
Circuit Breakers Fuse Panel
~
Power is ON
~
Power is OFF

A Remove the old switch and disconnect
V the wires. If your box lacks neutral wires,
stop and contact support.
If·.
Neutral
Wire

Turn on
power
at
the
circuit breaker and
use a voltage
detector
or
multi-meter
to
identify line and load. Line will be
energized.

0 Turn off powerat the circuit breaker. Connect the On/Off Switch wires
to
the identified wires
in
the junction box. Verify that the wire nuts are secure and that no exposed copper wire is visible
except for the bare ground wire.
•
•
•
•
•
• •
•
• •
•
• •
•
• •
•
• •
•
•
• •
• •
•
•
• •
•
• •
•
•
Neutral

Mount the On/Off Switch into the
junction
box with the LED bar on the left
and turn power on
to the switch at the
circuit breaker panel.

Test your On/Off Switch by tapping the
paddle
to turn On and Off.
-
-
-

Linking
to
the Hub
Follow the on-screen instructions to add
your On/Off Switch
to
the INSTEON Hub.
When prompted, press and hold the
On/Off Switch's set button.

Device Control
Turn on, turn off, set schedules and
create scenes for your On/Off Switch
using the INSTEON Hub and App.
On/Off Switch
Protected underU.S. and foreign patents (see www.insteon.com/patents)
©2014 1NSTEON RAW-1292 Rev 03.27.14

This device complies with FCC Rules
and
Industry Canada license-exempt RSS
standard(s). Operation is subject
to
the following
two
conditions:
(1)
this device may
not cause harmful interference, and
(2)
this device
must
accept
any interference,
including interference that
may
cause undesired operation
of
the
device.
CAUTION:
To
reduce the risk
of
overheating and possible
damage
to
other
equipment,
do
not install
to
control a receptacle, a motor-operated appliance, a
fluorescent lighting fixture,
or
a transformer-supplied appliance.
FCC & Industry Canada Compliance Statement
This device complies with FCC Rules and Industry Canada license-exempt RSS
standard(s). Operation is subject
to
the following
two
conditions:
(1)
this device may
not
cause harmful interference, and
(2)
this device
must
accept any interference,
including interference that
may
cause undesired operation
of
the device.
Le present appareil est conforme aux CNR d'lndustrie Canada applicables aux
appareils radio exempts
de
licence. L'exploitation est autorise aux
deux
conditions
suivantes:
(1)
l'appareil ne
doit
pas produire
de
brouillage,
et
(2)
l'utilisateur
de
l'appareil doit accepter
tout
brouillage radiolectrique
subi,
mme
si le brouillage est susceptible
d'en
compromettre le fonctionnement.
Le present appareil est conforme aux CNR d'lndustrie Canada applicables aux
appareils radio exempts
de
licence. L'exploitation
est
autorise aux
deux
conditions
suivantes:
(1)
l'appareil ne
doit
pas produire
de
brouillage,
et
(2)
l'utilisateur
de
l'appareil
doit
accepter
tout
brouillage radiolectrique subi,
mme
si le brouillage est
susceptible
d'en
compromettre le fonctionnement.
Gradateurs commandant une lampe a filament
de
tungstene -afin
de
reduire le
risque
de
surchauffe et
Ia
possibilite
d'endommagement
a d'autres materiels,
ne
pas
installer
pour
commander
une prise, un appareil a moteur, une lampe
flourescente ou
un
appareil alimente
par
un transformateur.
Protected under U.S. and foreign patents
(see
www.insteon.com/patents)
Protege par des brevets americains et etrangers (consultez www.insteon.com/patents)
©2014
INSTEON RAW-1340 Rev 03.13.14
