Integral LED ILDEA030 User manual

Thank you for purchasing an INTEGRAL LED product. When installed correctly this unit will
provide years of service. For support or warranty information please see integral-led.com.
Important Details – Please read prior to installation
1.Installation must be completed by a qualied electrician in accordance with all recognised local and national
electricalandconstructionregulations.
2.EnsurethatthepowerisOFFduringinstallationandthatpowercannotbeunexpectedlyreconnected.
3.Thelightttingisdesignedtooperatewitha220-240V50Hz/60Hzelectricitysupply.
4.DoNOTusetheluminaireifdamaged
5.Whereapplicable,considerationshouldbetakentoensureallxingsareofsuitablesizefortheluminairetobe
installed.
6.This luminaire is rated at IP54, suitable for residential outdoor areas such as the garden, porch, garage and
driveway.NOTsuitableforwaterimmersion.Wheninstallingtheproductensurethesuppliedgrommetsand
glandsareusedtoprotecttheIPrating.
7.Donotcoverthelightsource.
8.Toavoiddamage,DONOTlift,carryorlettheluminairehangbyanypartofthewiring.
9.ThisproductisClassI–Earthconnectionrequired.
10.Failuretocomplywiththerecommendationsandinstructionsprovidedhereinmaycausedamagetotheluminaire
orpresentariskofinjuryordeath(e.g.shortcircuit,re,burnsorelectricshock).
11.Anymodicationstotheluminaire,incorrectinstallationoruntpositioningmaybedangeroustousersandmay
causethewarrantytobecomevoid.
Installation Instructions
12.EnsurethatthepowerisOFFduringinstallationandthatpowercannotbeunexpectedlyreconnected.
13.FollowthestepsaslaidoutinFigures1to8
14.Use suitable tools and xings to mount the luminaire safely and securely to the surface.  Depending on the
substratealternatexingstotheonessuppliedmayberequired.
15.Avoidanydamagetoanywiring.
16.Oncethelightttingbaseissecurelymounted,connectthemainssupplytotheconnector.Pleasepayattentiontothepolarity.
L=Live(Brown),N=Neutral(Blue),E=Earth(Green/Yellow).TheluminaireisaCLASSIdevice–anEARTHconnectionisMANDATORY.
NEUTRAL = BLUE LIVE = BROWN GREEN/YELLOW = EARTH
INSTALLATION INSTRUCTION
LumiDisc Wall Light
EN
Product Code 6 Digit Code Wattage Lumens Output
ILDEA030 47-89-91 8.4W 350LM

Warranty/Technicalandcontactinformation
areallavailableat www.integral-led.com
Integral LED is a division of Integral Memory plc:
Unit6,IronBridgeClose,IronBridgeBusinessPark,
London,NW100UF,UK
IP54
WASTE ELECTRICAL PRODUCTS SHOULD NOT BE
DISPOSED OF WITH HOUSEHOLD WASTE. PLEASE
RECYCLE WHERE FACILITIES EXIST. CHECK WITH
YOUR LOCAL AUTHORITY FOR RECYCLING ADVICE.
Non-Dimmable
