Intelix DIGI-HD60-WP-S HDMI Ultra HD 4K Decora HDBaseT Wall Plate Transmitter, PoH

DIGI-HD60-WP-S Installation Guide
Important notice:
• Do not attempt to disassemble or alter the extender housing. There are no user-serviceable parts inside
the unit. Doing so will void your warranty.
• To minimize the possibility of equipment damage from electrostatic discharge (ESD), all source and
destination equipment must be powered o during installation.
• Do not connect the extender to a telecommunication outlet wired to unrelated equipment. Doing so may
damage the unit or any connected equipment. Ensure all connected twisted pair cabling is straight-through
(point-to-point).
• Allow proper ventilation to reduce the risk of thermal failure.

The Intelix DIGI-HD60-WP-S extends HDMI over a single twisted pair cable by incorporating HDBaseT
technology. The DIGI-HD60-WP-S supports HDCP Encrypted Content & DDC/EDID Transmission.
DIGI-HD60-WP-S transmits Ultra HD (4K2K), HDTV Video Resolutions up to 720p/1080i/1080p@60Hz
and WUXGA (1920X1200 @60Hz) at distances of 60m (196ft). Diagnostic LED ensure hassle-free and
robust installations. Power design allows the units to be powered at the RX end, and pass power
upstream to the wall plate.
The DIGI-HD60 series extenders are compatible with all Intelix HDBaseT product oerings and any
product that meets the HDBaseT specications.
Instructions
The following instructions describe the installation process for a point-to-point installation. The
procedure is similar for compatible HDBaseT components. In the event a compatible HDBaseT product
cannot provide power over the HDBaseT cable connection, the DIGI-HD60-WP-S product will require a
local power supply.
1. Verify all components included with the extender set are present before installation.
2. Turn o power and disconnect the audio/video equipment by following the manufacturer’s
instructions.
3. Connect shielded Category 5e or greater twisted pair cable with RJ45 connectors between the
transmitter (DIGI-HD60-WP-S) and the receiver (DIGI-HD60-R). TIA/EIA-568B straight-through wiring
connections must be used with all HDBaseT extenders.
4. Connect an HDMI cable between the display and the receiver (DIGI-HD60-R).
5. Connect an HDMI cable between the source and the transmitter (DIGI-HD60-WP-S).
6. Connect the power supply to the compatible receiver.
7. Power on attached audio/video devices.
Diagnostic LED:
The DIGI-HD60-WP-S provides one LED to indicate the current operating status and to assist
troubleshooting an installation.
Link: Solid red when powered up. Blinking red/amber when HDBT is connected without video
signal. Solid amber when video connection is established.

TIA/EIA-568B
Orange/White
Orange
Green/White
Blue
Blue/White
Green
Brown/White
Brown
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
1 8
Twisted Pair Wiring
Use TIA/EIA-568B wiring for Category
6 connection between send and
receive units.
Troubleshooting Tips
Symptom Possible Soluons
• Power indicator is off. • Ensure that active power is connected.
• If power is provided by another HDBase-T device, verify
twisted pair cable is securely connected to the HDBT port
on back of wall plate.
• Power indicator is on, but link
indicator is off.
• Verify CAT5e or greater twisted pair cable is being utilized
and terminated with 568B crimp pattern.
• Test with another twisted pair cable.
• Power and link indicator
are on, but no video signal is
present.
• Verify the source is powered on.
• Test with another HDMI cable. Verify the HDMI cable
between the source and the transmitter is less than or
equal to 5 meters in length.
• Test with another HDMI source.
• Ensure twisted pair cable connections between
transmitter and receiver are securely fastened.
• Turn the power off, then back on to reset the link.

rev 151030
11675 Ridgeline Drive
Colorado Springs, Colorado 80921
1-800-530-8998
[e-mail]
Technical Specicaons
Input/Output Connecons
HDMI One (1) HDMI Type A Receptacle
Twisted Pair One (1) 8P8C port (Shielded RJ45)
Supported Audio and Video
Maximum Video Compability at 60 m Deep Color 36/30/24 Bit at 1080p
Maximum Video Compability at 35 m Deep Color 48 Bit at 1080p, 3D, and 4k x 2k (UHD) up to 30 Hz:
RGB, YCbCr 4:4:4, YCbCr 4:2:2; up to 60 Hz: YCbCr 4:2:0
Video Compliance HDMI, HDCP 2.2, and CEC (Consumer Electronics Control)
Embedded Audio Up to PCM 8 channel, Dolby Digital TrueHD, and DTS-HD Master
Audio
HDBaseT Signal Characteriscs
Maximum Distance 60 m
Cable Requirements Solid core shielded Category 5e, Category 6 or greater with TIA/
EIA-568B crimp paern
Bandwidth 10.2 Gbps
Chassis and Environmental
Enclosure Painted steel
Dimensions 45.72mm x 20.82mm x 104.14mm (1.80 in. x 0.82 in. x 4.10 in.)
Shipping Weight 0.22 kg (0.49 lbs.)
Operang Temperature (Environment) 0° to +40° C (+32° to +104° F)
Operang Temperature (Chassis) 0° to +55° C (+32° to +131° F)
Operang Humidity (Environment) 20% to 90%, Non-condensing
Storage Temperature (Environment) -10° to +60° C (+14° to +140° F)
Storage Humidity (Environment) 20% to 90%, Non-condensing
Power, ESD, and Regulatory
Maximum Power Consumpon 24VDC @ 0.5 Amps (Max.)
ESD Protecon 15kV
Regulatory CE, RoHS, FCC
Other
Standard Warranty 2 years
Diagnosc Indicators Link LED
Included Accessories Installaon Guide
Distances and picture quality may be aected by cable grade, cable quality, source and desnaon equipment, RF
and electrical interference, and cable patches.
