IntelliSense DT-7435 EU DUAL TEC Setup guide

TBL TBL T T NO EOLCV-NC V+
132
TEST
50%
100%
75%
25%
¶ Select the mounting location.
¹ Wire the unit.
¸ Mount the unit.
ºa Walk-test the sensor.
Mounting Location Guidelines
 2.3 m mounting height
 Avoid direct or reflected sunlight
 Aim sensor away from windows or heating/
cooling devices
 Sensor must have a clear line-of-sight to
protected area
See Special Instructions for pet applications
 Use a small screwdriver to unfasten the housing
latch. Gently pull apart the housings.
 ush outward on the CB latch and lift the CB
out of the housing.
 Slide the wire through the wire channel and wire
access in the back housing.
 Mount the back housing flat against a wall or in a
corner.
 Replace the CB.
 Connect wires as shown using 0.3 - 1.0 mm2
wire size. Observe proper polarity.
 Apply power to the unit. Initialization is complete
when the LED stops flashing slowly.
 Adjust the microwave range to minimum setting
(25%) by turning the range adjustment counterclock-
wise using a small screwdriver.
 Replace the front housing.
 Begin walking through the detection area.
- The LED will turn red, indicating an alarm detection.
 Increase the microwave range as necessary.
 Repeat the items in step 5a until proper detection
range is obtained.
ºb Optional: Walk-test using Zone Finder.
 Use a screwdriver to short the test pads.
 During the Zone Finder walk-test mode, the LED
turns:
- green for IR detection;
- yellow for microwave detection.
 Adjust the microwave range as necessary.
 Zone finder mode times out after ten minutes.
Corner
Mount
Wire Channel
Wall Mount
75%
100%
25%
50%
T-7435 EU UAL TEC® Motion Sensor Installation Instructions
Use the Zone Finder mode to identify the IR and/
or microwave pattern. In Zone Finder mode the red
LED is disabled.
· Separate the sensor housings and
remove the printed circuit board (PCB).
T-7435
Remove look-down
mask for non-pet
applications

PRO UCT SPECIFICATIONS
Range:
11 m x 11 m
Alarm relay:
Energized Form A
125 mA, 25 VDC, 20 Ohm series resistor
Tamper:
NC, 50 mA, 24 VDC
Power requirements:
7.5 - 16 VDC
25 mA typical, 30 mA maximum, 12 VDC
AC Ripple: 3 V peak-to-peak at nominal 12 VDC
Microwave frequencies:
24.125 GHz
PIR white light immunity:
6,500 Lux typical
Fluorescent light filter:
50 Hz
RFI immunity:
30 V/m,10 MHz - 1000 MHz
Operating temperature:
-10o to +55o C (14o to +131o F)
5 - 95% relative humidity (non-condensing)
Self test intervals:
Microwave Supervision Every 5 seconds
IR self-test Once every hour
Temp. Comp. Every 30 seconds
PIR fields of view:
Standard Wide Angle Lens
22 long range edges
12 intermediate edges
6 lower edges
* 4 look-down edges
Dimensions:
11.9 cm H x 7.1 cm W x 4.2 cm D
Sensitivity:
Standard 3 - 4 steps
Harsh 4 - 5 steps
© 2001 IntelliSense®  IntelliSense and DUAL TEC are registered trademarks of Honeywell, Inc.
All other trademarks are the properties of their respective owners. All rights reserved.
5-051-661-00 Rev A
LE IN ICATORS
IP SWITCH SETTINGS (SW1)
Factory default settings are shown in grey.
ETECTION PATTERNS
T-7435 EU UAL TEC® Motion Sensor Product Information
TROUBLE SHOOTING
Problem: Red LED is flashing rapidly.
Explanation: The sensor is in one of three conditions:
Microwave supervision failure: The sensor continues operating using IR
as the only detection method. When detection occurs on the IR channel,
the alarm relay will latch open until the Microwave trouble is removed.
IR self-test failure: Alarm relay does not actuate.
Temperature compensation failure: When alarm occurs, the alarm relay
will latch open until the trouble is cleared.
Solution: ower down the sensor or enter zone finder mode which will
perform self-test. If the trouble does not clear, replace the sensor.
ower Up
Slow
Blink
OFF
OFF
DT 7435 EU Top View
Wide Angle Lens
11 m
SPECIAL INSTRUCTIONS FOR INSTALLATIONS CONTAINING PETS
To take full advantage of the pet immunity the following guidelines should be
followed:
 Mount the center of the detector 2.3 m high.
 Ensure that the look-down mask is in place (see Step 2).
 Mount where animals cannot come within 1.8 m of the detector by
climbing on furniture, boxes or other objects.
 Do not aim the detector at stairways that can be climbed by animals.
Notes:
This sensor will provide immunity to false alarms for an individual animal or a
group of animals whose total weight is equal to or less than 45 kilograms.
DT 7435EU
Side View
Wide Angle Lens
* Look-down fingers are enabled
only when the look-down mask is
removed (see Step 2).
LE
Red
Yellow
Green
Normal
ON
Alarm
ON
Microwave
ON
IR
Trouble
Fast
Blink
OFF
OFF
Zone Finder
OFF
ON
Microwave
ON
IR
OPERATION
Switch
1
2
OFF
Harsh Sensitivity
LED Disabled
ON
Standard Sensitivity
LED Enabled
