Inter-m RM-02 Guide

RM-02 I 3
RM-02
Dynamic Remote Microphone

2I RM-02
TheRM-02isanidealremotepagingmicrophonewithpush-to-
talkcontrol.Itfeaturesaunidirectionaldynamicmicrophonewith
agooseneck.Themicrophonehasafrequencyrangeof50Hzto
10kHzwithanimpedanceof600ohmsandasensitivityof-52db.
Thestandisofheavydiecast-zincconstructiontoprovidestability
andminimizenoisecausedbytheoperatortouchingthestand.
FEATURES
POLAR PATTERN & FREQUENCY RESPONSES
OVERVIEW
RM-02
Unidirectional Moving Coil Dynamic Microphone
Heavy die-casting zine construction base
MIC ON/OFF Switch
Frequency response 50Hz ~ 10kHz
Sensitivity -52dB±3dB (0dB=1V/Pa at 1KHz)
Impedance 600Ω
Constitution and Accessory
Stand(RM-02), Microphone(MC-02)
240
o
27
0
o
300
o
330
o
0
o
30
o
60
o
90
o
120
o
150
o
180
o
210
o
-90
-80
-70
-60
-50
-40
10
k20k
2k 5k500200100
20 50
1k

RM-02 I 3
NAME OF GOOSE NECK ASS’Y
NAME OF STAND ASS’Y
󱂧
󱂧
󱂨
󱂨
󱂩
󱂩
󱂪
󱂪
󱂫
󱂫
󱂬
󱂭
󱂧 WIND SCREEN
󱂨 UNIT
This unit which range is from 50Hz to 10kHz can make
sound.
󱂩 UNIT BASE
This base settles unit, and made of aluminium ware to
protect goose neck not to be lower.
󱂪 GOOSE NECK
This goose neck can adjust the direct of unit without
moving stand.
󱂫 CONNECTOR HOLDER
This case is in order to connect stand to connector.
󱂬 WRENCH BOLT
This screw solidifies mounting between goose neck
and connector holder.
󱂭 3P CONNECTOR
This screw solidifies mounting between goose neck
and connector holder.
󱂧 RUBBER FOOT
This rubber foot of stand avoid sliding on the glass or
table.
󱂨 STAND
This stand made of heavy Zn diecasting which can minimize
touch noise.
󱂩 STAND COVER
󱂫 RECEPTACLE
Input signal through 3p connector of goose neck
becomes sound at this part of stand ass’y.
󱂬 TALK SWITCH
After press talk switch, the microphone does work and
press again is off.

2I RM-02
SPECIFICATIONS
RM-02
TYPE Unidirectional
POLAR PATTERN Moving Coil Dynamic
SENSITIVITY -52dB±3dB (0dB=1V/Pa at 1KHz)
FREQUENCY RESPONSE 50Hz ~ 10kHz
MAX SPL Over 130dB
IMPEDANCE 600Ω ±30%
WEIGHT (SET) 1.6kg / 3.5lb
DIMENSIONS(SET)
BASE 99(W) x 50(H) x 148(D)mm
3.9(W) x 2(H) x 5.8(D)in
MIC 26.5(W) x 440(H) x 26.5(D)mm
1(W) x 17.3(H) x 1(D)in
Inter-M Corp. (IMK)
719, Dobong-ro, Dobong-gu, Seoul, Korea
Overseas Sales Team
Tel_ [phone]~7 Fax_ [phone] E-mail_ [e-mail] www.inter-m.com
※Design and specication are subject to be changed for the improvement of product quality without pre notice. 2015. 7. V1
