Intercomp CS750 User manual

Page 1 of 31
CS750
User Manual
Manual # 7005041-E

CS750 User Manual
Rev E, April 2018
Page 2 of 31
Table of Contents
DECLARATION OF CONFORMITY........................................................................................................... 3
INTRODUCTION........................................................................................................................................... 4
SPECIFICATIONS ......................................................................................................................................... 4
Controls ................................................................................................................................................4
Electrical............................................................................................................................................... 4
Performance......................................................................................................................................... 4
Environmental.......................................................................................................................................4
Physical ................................................................................................................................................ 4
Optional Radio...................................................................................................................................... 5
WEIGHTS AND MEASURES........................................................................................................................... 6
OPERATIONS............................................................................................................................................... 7
OPERATING PRACTICES .............................................................................................................................. 7
DISPLAY .....................................................................................................................................................8
CONTROLS ................................................................................................................................................. 8
ON / OFF.............................................................................................................................................. 8
ACCUM / TOTAL..................................................................................................................................8
MODE................................................................................................................................................... 9
ZERO.................................................................................................................................................... 9
Lb/Kg .................................................................................................................................................... 9
TARE.................................................................................................................................................... 9
IR REMOTE CONTROL ............................................................................................................................... 10
KEY TARE (IR remote only)............................................................................................................... 11
PEAK (IR Remote Only).....................................................................................................................11
SETTING THE MODE MENU PARAMETERS...................................................................................................12
MOTION DETECTION SYSTEM .................................................................................................................... 16
SERIAL OUTPUT (OPTIONAL) ................................................................................................................. 17
SCOREBOARD........................................................................................................................................... 18
MAINTENANCE.......................................................................................................................................... 19
CALIBRATION MENU ..................................................................................................................................19
SETTING THE CALIBRATION PARAMETERS ..................................................................................................21
WEIGHT CALIBRATION............................................................................................................................... 23
CALIBRATION (VERIFICATION)....................................................................................................................24
INSPECTION REQUIREMENTS .....................................................................................................................24
POWER/BATTERIES...................................................................................................................................27
LEGAL-FOR-TRADE SEALING ..................................................................................................................... 27
TROUBLESHOOTING................................................................................................................................ 28
PROBLEM TABLE.......................................................................................................................................28
ERROR MESSAGES ...................................................................................................................................29
CALIBRATION MENU SKIP ""...............................................................................................................30
HOW TO CONTACT INTERCOMP............................................................................................................31
This document is the property of Intercomp Co. and contains information
that is confidential and protected under federal and/or state trade secret,
unfair competition and copyright law. Any reproduction, use or disclosure
without written permission from Intercomp Co. is prohibited.

CS750 User Manual
Rev E, April 2018
Page 3 of 31
Declaration of Conformity

We, Intercomp Company
3839 County Road 116
Medina, Minnesota 55340 USA
Declare under sole responsibility that the CS750 to which this declaration relates meets the essential health and
safety requirements and is in conformity with the relevant EC Directives listed below using the relevant section of
the following standards and other normative documents.
2001/95/EC - on general product safety
2009/125/EC - ecodesign requirements for energy-related products (2005/32/EC recast)
(EC) No 278/2009 - no-load condition electric power consumption and average active efficiency of
external power supplies
Directive 2014/30/EU of the European Parliament and of the Council of 26 February 2014 on the
harmonization of the laws of the Member States relating to electromagnetic compatibility (recast) Text with
EEA relevance AKA Electromagnetic Compatibility (EMC) Directive
EN 55011:2016 - Industrial, scientific and medical equipment. Radio-frequency disturbance
characteristics. Limits and methods of measurement
EN 1000-6-1:2007 - Generic standards, Residential, commercial and light industry environment
EN 61000-6-2:2005 - Immunity for industrial environments
EN 61000-6-3:2007 - Emission standard for residential, commercial and light-industrial environments
2006/42/EC - on machinery, and amending Directive 95/16/EC (recast)
EN 45501:2015 - Metrological aspects of non-automatic weighing instruments
2012/19/EU - on waste electrical and electronic equipment (WEEE) (Directive 20/96/EC Recast)
2013/56/EU amending Directive 2006/66/EC on batteries and accumulators
Directive 2014/53/EU of European Parliament and of the Council of 16 April 2014 on the harmonization of
the laws of the Member States relating to the making available on the market of radio equipment and
repealing Directive 1999/5/EC Text with EEA relevance AKA Radio Equipment Directive (RED).
EN 301 489-1 V2.2.0 (2017-03) – Electro-Magnetic Compatibility (EMC) standard for radio equipment and
services; Part 1: Common technical requirements
EN 300 328 V2.1.1 (2016-11) - Wideband transmission systems; Data transmission equipment operating
in the 2.4GHz ISM band
EN 60950-1:2006+A2:2013 - Information technology equipment. Safety. General requirements
This product complies with all safety-relevant provision referring to protection against electrical hazards
and other hazards, such as mechanical hazards, fire hazards, noise and vibration. The safety issues of
this measurement equipment have been evaluated under the self-certification provisions of the relevant
directives.
The related technical construction files are held for inspection in the U.K. at Intercomp Europe Limited.
The CE mark, Red M and WEEE marks must be affixed as required in the directives.
Mark Browne / Quality Manager
June 24, 2014

CS750 User Manual
Rev E, April 2018
Page 4 of 31
Introduction
This manual contains specifications, operating instructions and calibration procedures
for the Intercomp Model CS750 Crane Scale.
Specifications
Controls
General
Zero, lb/kg, Mode, Print, TARE, On, Off
Display
5 1/2 digit, 1 inch liquid crystal display (LCD) with automatic back
lighting.
Electrical
Batteries
4 X D-size alkaline
Battery Life
800 hours (1 month continuous use)
5000 hours in Stand-by mode. Using the backlight will reduce
battery life.
Filtering
Adjustable averaging up to 30 seconds.
Stand-by Mode
Scale goes into standby when shut off using the IR or RFX
remote or after an adjustable time without use or motion.
When in "stand-by" mode, scale can be turned on with the IR
or RFX remote.
Auto-Zero
Satisfies all HB-44 requirements.
Performance
Speed
4 display updates per second
Accuracy
0.1% of reading or 1 display graduation, whichever is
greater.
Calibration Interval
Twelve months recommended
Environmental
Humidity
10 to 95% Non-Condensing
Temperature
Operating: -28 C to +65 C. / -20 F to +150 F
Storage: - 40 C to +75 C. / - 40 F to +170 F
Ingress Protection
IP50
EMI/RFI
Meets Mil Spec 461
Physical
Dimensions
Control Box
4.25" x 5" x 8.5". / 10.8 cm X 12.7 cm x 21.6 cm
Lifting Eye to Hook (Standard)
12" / 30.5 cm
Weight
7.5 lb. / 3.4 kg

CS750 User Manual
Rev E, April 2018
Page 5 of 31
Optional Radio
Radio Frequency
ISM 2.4GHz, 802.15.4
License Requirements
None. Pre-approved US/FCC, CAN/IC, EUR/CE
Range
200' / 60m indoor, 300' / 90m line of sight
WARNING: To satisfy FCC RF exposure requirements for mobile
transmitting devices, a separation distance of 20 cm or more should be
maintained between the antenna of this device and persons during device
operation. To ensure compliance, operations at closer than this distance is
not recommended. The antenna used for this transmitter must not be co-
located in conjunction with any other antenna or transmitter.
!

CS750 User Manual
Rev E, April 2018
Page 6 of 31
Weights and Measures
The CS750 meets or exceeds Class III standards for 3000
division accuracy from 300 lb to 1000 lb. The certification was
completed by the National Type Evaluation Program (NTEP) in
accordance with the National Institute of Standards and Technology
(NIST) Handbook 44. A NTEP Certificate of Conformance Number
97-135A4 was issued under the National Conference of Weights and
Measures.
Optional Equipment
RS232 Serial Data Output / Direct Power (184256)
This option adds a metal circular connector harness to the side of the CS750. The
harness provides RS232 serial data output and direct power connections for the
following cable options:
Direct Power Cable, 100-250VAC (101055)
The Direct Power cable allows the CS750 to use 100-250VAC power instead of
batteries. The coiled power cord is 2ft long retracted and approximately 6ft in length
when extended. Four interchangeable International power plug clips accommodate US,
Europe, UK and China power types.
*Option #184256 is required
RS232/USB Serial Output Cable (101233)
The Serial Output Cable provides communication with a computer or remote display.
The 15 ft. cable provides connection from the CS750 to a 9-pin serial port. A RS232-
USB adapter is included to convert the cable to a USB Type A connection.
*Option #184256 is required
Thermal Printer Cable (101231)
The two-part Thermal Printer Cable system connects the CS750 to Citizen thermal
printers CMP-10 or CMP-20. Cable length is 15 ft.
*Option #184256 is required

CS750 User Manual
Rev E, April 2018
Page 7 of 31
Operations
Operating Practices
Warning: The crane scale must be operated by qualified designated persons, trainees
under the direct supervision of designated persons, maintenance and test personnel
when in performance of their assigned duties or lifting device inspectors.
Warning: Do not exceed the rated load limit of the crane scale.
Warning: The crane scale shall be applied to the load in accordance with the
instruction manual.
Warning: Prior to lifting, ensure that ropes or chains are not kinked and if multiple lines
are used they are not twisted around each other.
Warning: Ensure that the load is correctly distributed for crane scale use.
Warning: Ensure the temperature of the load does not exceed the maximum
temperature limits of the crane scale.
Warning: Ensure that crane scale movement (swing) is minimized when positioning
over a load.
Warning: Avoid any sudden acceleration of deceleration when moving the load.
Warning: Do not allow crane scale or the lifter to come into contact with any obstruction
when moving the load.
Warning: Do not operate crane scale if it is damaged, malfunctioning or missing parts.
Warning: Do not lift people with the crane scale.
Warning: Do not lift suspended loads over people.
Warning: Do not use the crane scale to pull side loads or to slide loads unless
specifically authorized by a qualified person.
Warning: Do not leave suspended loads unattended.
Warning: Do not remove or obscure warning labels.
Warning: Do not operate the crane scale without having read and understood the
operating manual.
Warning: Stay clear of suspended loads.
Warning: Do not lift loads higher than necessary.
Warning: Do not make alterations or modifications to the crane scale.
Warning: Ensure all portions of the human body are kept clear of all device involved
with the rigging during the lift.

CS750 User Manual
Rev E, April 2018
Page 8 of 31
Display
Controls
ON / OFF
Press and hold the power button to apply power to the weighing system electronics.
Hold button until the display responds (approximately 1 second). When power is
applied, the weighing system performs a self-test of the pad and the internal
electronics. When the self-test has been completed, the system begins weighing. If a
problem is detected during self-test, an error message will be displayed. Press the
button to turn the scale off.
NOTE:
When the scale is turned off using the ON/OFF button, it cannot be turned on
with the IR remote or RFX wireless indicator. If the scale is powered up using a
remote, turn off the scale with the IR remote or wireless indicator.
ACCUM / TOTAL
The scale will not accumulate when the weight is negative, zero or if the weight is in
motion (when Motion Detect is enabled). A display message "." with error icon will
be displayed if any of those conditions are present. After a successful accumulation the
scale must return to zero before the next weight can be accumulated. Failure to do so
will generate and display an error message: ".".

CS750 User Manual
Rev E, April 2018
Page 9 of 31
MODE
The Mode button cycles through the scale set-up menu (Mode Menu) when in normal
run mode. When in calibration mode, use the button to toggle through the calibration
menu. Refer the "Mode Menu" and "Calibration Menu" sections for further details.
ZERO
The ZERO button is used to display a zero weight when the scale shows a non-zero
value with no weight on the hook. If ZERO is pressed with weight on the hook, the
weight becomes the zero condition for the scale. This can be useful to cancel the
weight of any weighing fixtures, such as containers, chains or cables. When the weight
is removed, a negative weight shows until the system is zeroed again. If "Motion Detect"
(see Calibration Menu) is enabled, the "ZERO" command will be rejected when a
change in weight is detected. The weight must be allowed to stabilize before the zero
command is accepted.
NOTE:
The scale has a feature called Auto Zero Tracking (AZT) that corrects slight
zero changes during normal operation. If small weights are added slowly, the
scale will zero them off.
Lb/Kg
The Lb/Kg button toggles the weighing system between pound (English) and kilogram
(SI metric) units of measure. The current unit of measure is shown in the top left of the
indicator screen.
TARE
Pressing the TARE button will set the TARE equal to the current gross weight of the
total load suspended on the scale and then switch the display to net weight. The NET
indicator light is located below the indicator screen. The net weight is equal to the gross
weight minus the TARE weight. If TARE is pressed when a TARE is already set, the
display will briefly show the current TARE weight before returning to net weight display.
The TARE weight can only be set if the current gross weight is positive.
Clearing the TARE:
Press both the TARE and ZERO buttons to reset the TARE
to zero and return the scale to the GROSS weighing status.

CS750 User Manual
Rev E, April 2018
Page 10 of 31
IR Remote Control
The following diagram of depicts the primary key functions of the CS750 IR Remote
Control.
Press "POWER" key
to power up the CS750
Press the "CLEAR"
key to clear an entry
Press the "FUNCTION"
key to toggle through the
Menu
The "NORMAL" key turns
off Peak Mode. When in
the Mode Menu, press key
to toggle through menu
Enter numbers using
the Numeric keypad
Turn Peak Mode On
Press "ENTER" to
enter and save a
numerical entry.
Clear Total
Press "KEY TARE" to
enter weight using the
keypad
Clear TARE
Executes "Print" on
demand command

CS750 User Manual
Rev E, April 2018
Page 11 of 31
KEY TARE (IR Remote Only)
Pressing the KEY TARE key on the IR remote will allow the user to enter the TARE
weight using the keypad on the IR remote. After entering the number, press ENTER on
the IR remote to apply the new TARE. Note that the entered TARE weight must match
the grad setting for the scale. For example, if the display graduations are set to "2 lb" on
the scale, a TARE entry of "19 lb" will not accepted. In this case enter either a 18 or 20
lb setting. If an invalid TARE weight is entered the scale will blink "." 3 times and
return to normal weighing without applying the new TARE.
PEAK (IR Remote Only)
Press the PEAK key on the IR remote to enter peak mode. Press NORMAL on the IR
remote to turn peak mode off. When peak mode is enabled, the scale will show the
highest weight that has been applied to the scale since it was turned on or zeroed.
Toggling peak mode will not clear the peak weight. Press ZERO to reset the peak
weight. Peak mode works with gross or net weights and with print tickets. Continuous
print output functions only when in Gross mode.

CS750 User Manual
Rev E, April 2018
Page 12 of 31
Mode Menu
Press the mode button to access the Mode menu. The screen will display "". If
"" is displayed, the calibration button should be pressed to return to normal RUN
mode. RUN mode will allow entry into the Mode Menu when mode is pressed again.
(Enter "5" for the "" entry to bring up Mode Menu.)
It may be necessary to enter a number (up to 5 digits). This is required when the current
number is displayed with a flashing number (right hand digit). The flashing number may
be incremented by pressing the Lb/Kg button or decremented by pressing the ZERO
button. To move one digit to the left, press the TARE button. When the number has
been entered, press the Mode button. Settings are saved each time Mode is pressed to
advance the menu. The scale can then be turned off.
Step
Function
Note
Default

Print
Yes or no

.
Back light
On, off, or Auto


Set Point 1
0 to 19999


Set Point 2
0 to 19999

.
Average rate
1 to 120

.
Average Threshold
1 to 10000


Auto Off
000 = off, 1 to 240


Print Mode
0 = On-demand, 1 = Continuous


Printer Baud rate
1200, 2400, 4800, 9600, 19200,
38400, 57600, or 115200


Scale ID
1-190


Protocol
,,., or 


Radio Enable
Yes or no


Radio Channel
01 to 12

.
Radio Network ID
0 to 65534

.
Radio Encryption Enable
Yes or no


Radio Encryption Button
0 to 65534

.
Restore Radio Defaults
0 or 3

Setting the Mode Menu Parameters
1. Press the mode button to access the Mode menu. The display will show "".
This will allow the user to activate the print function by selecting "" or bypass
printing by selecting "". Press either the zero button or the lb/kg button to
toggle the display. When the desired setting is displayed press the mode button
to continue through the mode menu.

CS750 User Manual
Rev E, April 2018
Page 13 of 31
2. The screen will display ".". Press the Mode button. The flashing display
shows the current setting. Press either the ZERO button or the lb/kg button to
toggle through Auto, on and off. When "Auto" is elected (default), the backlight
will automatically light up when low level light conditions are detected. When the
desired setting is entered, press the MODE button to continue through the mode
menu.
3. The screen will show "". Press the Mode button. The screen will display
the current setting. When the weight displayed is equal to or greater than the set
point, the corresponding icon is shown on the LCD. During normal weighing
mode, the S1 icon on the display will light when the weight is greater than or
equal to set point 1. The flashing digit may be incremented by pressing the Lb/Kg
button or decremented by pressing the ZERO button. To move one digit to the
left, press the TARE button. When the desired number is displayed, press the
mode button to continue through the mode menu.
4. The screen will display "". Press the Mode button. The display shows the
current setting. During normal weighing mode, the S2 icon on the display will
light when the weight is greater than or equal to set point 2. The flashing digit
may be incremented by pressing the Lb/Kg button or decremented by pressing
the ZERO button. To move one digit to the left, press the TARE button. When
the desired number is displayed, press the mode button to continue through the
mode menu.
5. The screen will display ".". Press the Mode button. The screen displays the
current setting. The number indicates the number of readings will be averaged
together before the reading is sent to the display. Higher values will result in a
more stable reading, but take longer to display the final value. The scale updates
at 4Hz, so an Average Rate of "8" equates to 2 seconds of averaging. Enter "1"
to disable the averaging function. The flashing digit may be incremented by
pressing the Lb/Kg button or decremented by pressing the ZERO button. To
move one digit to the left, press the TARE button. When the screen displays the
desired number, press the mode button to continue through the mode menu.
6. The screen will display ".". Press the Mode button. The screen displays the
current Average Threshold setting. This setting enables dynamic averaging,
which can improve the settling time of a large Average Rate. If the scale senses
a large weight change, it will temporarily suspend averaging, jump to the new
weight, and resume averaging. Enter a value of 1-10000 to set the threshold (in
display divisions) at which point the dynamic averaging triggers. Enter "0" to
disable dynamic averaging. The flashing digit may be incremented by pressing
the Lb/Kg button or decremented by pressing the ZERO button. To move one
digit to the left, press the TARE button. When the display shows the desired
number, press the mode button to continue through the mode menu.

CS750 User Manual
Rev E, April 2018
Page 14 of 31
7. The screen will display ".". Press the Mode button. The number shown is
the current setting, displayed in minutes the scale will remain idle before it
automatically powers down into standby mode. When the scale powers down
into standby mode, the scale can be powered back on using the wireless
indicator. Setting the sleep mode to "" will disable the function. The flashing
digit may be incremented by pressing the Lb/Kg button or decremented by
pressing the ZERO button. To move one digit to the left, press the TARE button.
When the screen displays the desired number, press the mode button to
continue through the mode menu.
8. The screen will display "". Press the Mode button. The screen displays the
current setting and enables the scale print modes (0 for on-demand, 1 for
continuous). Refer to the "Serial Output" section for additional print information.
The flashing digit may be incremented by pressing the Lb/Kg button or
decremented by pressing the ZERO button. When the screen displays the
desired number, press the mode button to continue through the mode menu.
9. The screen will display "". Press the Mode button. The flashing number is
the current setting of the printer baud rate. The available baud rates are: 1200,
2400, 4800, 9600, 19200, 38400, 57600 and 115200. Press the ZERO button or
the lb/kg button to toggle the display through the baud rate settings. When the
desired setting is displayed, press the mode button to continue through the mode
menu.
10.Message "" will be displayed. Press the Mode button. A number will be
displayed followed by three dashes. This is the scale number. The flashing digit
may be incremented by pressing the Lb/Kg button or decremented by pressing
the ZERO button. To move one digit to the left, press the TARE button. When
the desired number is displayed, press the Mode button.
11.The screen will display "". Press the Mode button. The flashing message
is the current setting. There are 4 protocol settings for the scale; Standard
(""), Low Power (""), Current Loop (".") and Disable ("").
Select the "Lo Pr" setting for wireless operation with the RFX wireless indicator.
Selecting "" will disable wireless operation. Note: Disabling wireless
operation will extend battery life. Press either the zero button or the lb/kg button
to toggle the display through the different settings. When the desired setting is
displayed, press the mode button to continue through the mode menu.
12.The screen will display "". Press the Mode button. The flashing message
is the current setting for the radio enable function. Select the "" setting for
wireless operation with the RFX wireless indicator. Select “" to disable wireless
operation. Note: Disabling wireless operation will extend increase battery life. If
the "" setting is selected, the scale will skip the remaining radio modes and
return to normal weighing. Press either the zero button or the lb/kg button to
toggle the display. When the desired setting is displayed press the mode button
to continue through the mode menu.

CS750 User Manual
Rev E, April 2018
Page 15 of 31
13.The screen will display "". Press the Mode button. The flashing digit is the
current setting. All scales and indicators in a system must be set to the same
radio channel setting to communicate with each other. The flashing digit may be
incremented by pressing the Lb/Kg button or decremented by pressing the
ZERO button. To move one digit to the left, press the TARE button. When the
desired number is displayed, press the Mode button.
14.The screen will display ".". Press the Mode button. The current setting is
displayed with the right number in flashing mode. All scales and indicators in a
system must be set to the same "Personal Area Network ID" setting to
communicate with each other. The flashing digit may be incremented by pressing
the Lb/Kg button or decremented by pressing the ZERO button. To move one
digit to the left, press the TARE button. When the desired number is displayed,
press the Mode button.
15.The screen will display ".". Press the Mode button. The current setting will
be flashing. This setting is the encryption enable status and will be in either the
on or off mode. Use the Lb/Kg button or the ZERO button to toggle between the
settings. When the desired status is flashing, press the Mode button. If "" was
selected proceed to the next step. If "" was selected skip the next step. The
display will show "" with the right digit in flashing mode. The flashing digit
may be incremented by pressing the Lb/Kg button or decremented by pressing
the ZERO button. To move one digit to the left, press the TARE button. The
number selected will be the encryption key. For security purposes, the encryption
key is not accessible for viewing and will always be displayed as "". All
scales and indicators in a system must be set to the same encryption key setting
to be able to communicate with each other. When the desired number is
selected, press the Mode button. To keep the existing encryption key, enter
"", then press the Mode button to lock the existing key as is.
16. The screen will display ".". Press the Mode button. The screen will display
a flashing "". This setting restores the radio default settings. The flashing digit
may be incremented by pressing the Lb/Kg button or decremented by pressing
the ZERO button. Setting the number to "3" will restore the default radio settings.
No other numbers will have an effect on radio set-up. When the desired number
is flashing, press the Mode button. The scale will return to normal weighing.

CS750 User Manual
Rev E, April 2018
Page 16 of 31
Accum / Total Use
To enable the accumulating total function, press the "ACCUM TOTAL" button when a
load is placed on the scale. The screen will briefly show ".". This message
indicates the first accumulation has been calculated. Each subsequent accumulation
will briefly display ".X". The "X" element of the equation denotes the number of
accumulations that have been calculated during the weighing operation.
Accumulation Errors
The scale will not accumulate when the weight displayed is negative, zero or if motion is
detected on the scale. The message "." with error icon will be displayed if any of
these conditions are present. If motion is detected, the "MOTION" icon will also be
displayed. After a successful accumulation the scale must return to zero before
accumulation of the next weight can initiated. If an accumulation of the next weight is
attempted before allowing the scale to return to zero, the message “.” with error
icon will be displayed.
Motion Detection System
The scale has a motion detection system that can be enabled or disabled using the
"Calibration" menu. Refer to the ", Motion Detect" step of the "Calibration Menu"
section. When the motion detect function is enabled, any load motion detected will
disable the zero, TARE, print and accum functions. When accumulating, the message
"." with the "MOTION" icon will be displayed. When attempting to zero, print, or
TARE the scale, the display will show "" and the "MOTION" icon.

CS750 User Manual
Rev E, April 2018
Page 17 of 31
Serial Output (Optional)
The Serial Output is accessed through the mode menu under the "" option. The
following steps will enable Print On-Demand when "0" is entered.
1. Press the mode button. The display will show "".
2. Press the mode button once more. Toggle the display to "" by pressing the
lb/kg button.
3. Press the mode button once more and the print command will be transmitted.
After the print command is sent the scale will return to normal operations. If
accumulating, all accumulations will be retained.
Or press PRINT on the IR remote.
Print-In-Continuous Mode will be enabled when "1" is entered. The scale transmits one
weight line per second.
Print Output Examples
On-Demand Print Mode
GROSS: 2048 lb (No TARE or accum total)
GROSS: 2048 lb (A TARE is set)
TARE: 500 lb
NET: 1548 lb
GROSS: 2048 lb (Accumulated total and TARE set)
TARE: 500 lb
NET: 1548 lb
ACC.TOT: 3025 lb
ACCUM #01: 2048 lb (Accum total, but no TARE)
ACCUM #02: 2200 lb
ACCUM #03: 2000 lb
ACC.TOT: 6248 lb NOTE: When there is no TARE, each accumulated
weight is included in the printout (limit of ~50 weights)
Continuous Print Mode (weight line sent once per second)
2048 lb
2048 lb
2048 lb

CS750 User Manual
Rev E, April 2018
Page 18 of 31
Scoreboard
The output of the CS750 can be connected to a scoreboard to display continuous, real-
time information.
The signal is transmitted through the Serial I/O connector located on the side of the
unit. The connector has the following pinout:
Signal
Pin
TXD
F
GND
B
The transmitted signal has the following characteristics:
Fixed 8 Data bits, no parity, 1 stop bit.
Baud rate is configurable with the "printer baud rate" setting in the "Mode Menu".
The output swings from -9 VDC to 9 VDC.
The scoreboard output is an externally available signal designed to drive a numeric
overhead display such as the Intercomp LED Display or a computer RS-232 input.
Continuous Print Mode Transmitted Data: xxxxxxx<cr><lf>
Transmitted data is displayed in either NET or GROSS weight, whichever is currently
shown on the Wireless CS750 display. Data is transmitted at a rate of once per a
second. However, the transmission may be delayed when motion is detected.
The xxxxxxx field will vary in size depending on the length of the number. The field may
also contain a decimal point and/or a minus sign.
The connection to a 9-pin PC communication port is referenced in the following table.
WIRELESS CS750
PC 9-Pin
F (TXD)
2 (RXD)
B (GND)
5 (GND)

CS750 User Manual
Rev E, April 2018
Page 19 of 31
Maintenance
Calibration Menu
To initiate calibration, press the Mode button. The screen will display "". If the
message is not displayed, the calibration jumper needs to be set in the "CAL" position
to allow calibration to be initiated.
Step
Function
Note
Default

Skip
000= no skip
002= skip to weight calibration
005= skip to Mode menu

.
Unit Switch Enable
Yes or no


Motion Detect
Yes or no

.
ADC Rate
0 or 1


AZT (auto zero tracking)
1 d, 3 d, .5 d, oFF, or.6 d
.
.
Zero Range
0= off, 1= 1%, 2= 2%, 3= 5%,
4 = 1%

g
Graduation Size
0.02, 0.05, 0.1, 0.2, 0.5, 1, 2, 5, 10, 20,
50,100, 200, 500, 1000



Displays for 1 sec and advances

Capacity
Enter scale capacity


No Weight Applied

First Weight
Enter first weight


First Weight
Load first weight

Second Weight
Enter second weight

Second Weight
Load second weight

Third Weight
Enter third weight

Third Weight
Load third weight

Fourth Weight
Enter fourth weight

Fourth Weight
Load fourth weight
10 Points Available to Enter
3 or more recommended

CS750 User Manual
Rev E, April 2018
Page 20 of 31
Enabling the Calibration Function
On the right side panel, remove the 4 screws that hold the side plate secure. Remove
the side panel and slide the circuit card out to access the calibration jumper. Place the
jumper in the "CAL" position.
Number Entry
The flashing digit may be incremented by pressing the Lb/Kg button or decremented by
pressing the ZERO button. To move one digit to the left, press the TARE button. When
you have finished entering a number, press the Mode button. The settings are saved
once Mode is pressed to advance the menu, and the scale can then be turned off.
Cal jumper
