Intergraph Rack-Mount Workstation/Server User guide

Rack-Mount Workstation/Server
System Reference
November 1997
DHAF02430

Warranties and Liabilities
The information and the software discussed in this document are subject to change without notice and should not
be considered commitments by Intergraph Corporation. Intergraph Corporation assumes no responsibility for any
errors in this document.
The software discussed in this document is furnished under a license and may be used or copied only in accordance
with the terms of the license. No responsibility is assumed by Intergraph for the use or reliability of software on
equipment that is not supplied by Intergraph or its affiliated companies.
All warranties given by Intergraph Corporation about equipment or software are set forth in your purchase
contract, and nothing stated in, or implied by, this document or its contents shall be considered or deemed a
modification or amendment of such warranties.
Copyright
1997, Intergraph Corporation including this documentation, and any software and its file formats and audio-
visual displays described herein; all rights reserved; may only be used pursuant to the applicable software license
agreement; contains confidential and proprietary information of Intergraph and/or other third parties which is
protected by copyright, trade secret and trademark law and may not be provided or otherwise made available
without prior written authorization.
Restricted Rights Legend
Use, duplication, or disclosure by the United States Government is subject to restrictions as set forth in subdivision
(c)(1)(ii) of the rights in technical data and computer software clause at DFARS 252.227-7013.
Unpublished rights reserved under the copyright laws of the United States.
Intergraph Corporation, Huntsville AL 35894-0001
Trademarks
Intergraphand the Intergraph logo are registered trademarks, and StudioZ, RenderRAX, and InterServe are
trademarks, of Intergraph Corporation.
Other brands and product names are trademarks of their respective owners.

FCC/DOC Compliance
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy. If the equipment is not installed and used in accordance with the instruction manual, it
may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will
be required to correct the interference at his own expense.
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in
the Radio Interference Regulations of the Canadian Department of Communications.
Warnings
To reduce the risk of electrical shock, do not attempt to open the equipment unless instructed. Do not use a tool for
purposes other than instructed.
There is a danger of explosion if the battery is incorrectly replaced. Replace the battery only with the same or
equivalent type as recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s
instructions.
Notes
Read all operating instructions before using this device. Keep these instructions for future reference. Follow all
warnings on the device or in the operating instructions.

v
Contents
Introduction.....................................................................................................................................ix
Document Conventions.....................................................................................................................ix
Additional System Information .........................................................................................................ix
1 Accessing the System....................................................................................................................1
Tools..................................................................................................................................................1
Opening the Base Unit .......................................................................................................................1
Protecting Against Electrostatic Discharge .........................................................................................2
Removing the Face Plate....................................................................................................................2
Attaching the Face Plate.....................................................................................................................2
Closing the Base Unit.........................................................................................................................2
2 Servicing the System ....................................................................................................................3
Peripheral Drives ...............................................................................................................................4
Floppy Disk Drive................................................................................................................4
CD-ROM Drive....................................................................................................................6
Vertical Bay Disk Drives......................................................................................................8
Internal Bay Disk Drives ....................................................................................................11
Power Supply...................................................................................................................................12
Riser Card........................................................................................................................................13
P6 Bus Termination Card.................................................................................................................15
Processor Module for MSMT353 and MSMT359.............................................................................15
Processor Module for MSMT378......................................................................................................15
System Board...................................................................................................................................16
Fans.................................................................................................................................................17
Power Supply Fan...............................................................................................................17
System Fans.......................................................................................................................18
Internal Bay Fan.................................................................................................................18
Vertical Bay Fan.................................................................................................................18
Speaker............................................................................................................................................19
Lithium (CMOS/Clock) Battery .......................................................................................................19
AC Line Filter..................................................................................................................................21
Keyswitch and LEDs........................................................................................................................21
3 Upgrading the System................................................................................................................23
Adding Memory...............................................................................................................................23
Adding Processors to MSMT353 or MSMT359................................................................................24
Single to Dual Upgrade ......................................................................................................24
Dual to Quad Upgrade........................................................................................................25
Adding Processors to MSMT378......................................................................................................26
Single to Dual Upgrade ......................................................................................................26
Pentium Pro to Pentium II Upgrade ....................................................................................26
Adding Option Boards .....................................................................................................................28
Installing an Option Board .................................................................................................28
Assigning System Resources...............................................................................................29
Adding Internal SCSI Drives ...........................................................................................................31

vi
Adding External SCSI Drives ..........................................................................................................34
SCSI Cable Guidelines.......................................................................................................35
Connecting the Drive..........................................................................................................35
Disabling Sync Negotiation................................................................................................35
4 System Hardware Overview and Specifications........................................................................37
Functional Diagram .........................................................................................................................37
System Board Combinations.............................................................................................................38
System Board Feature Summary.......................................................................................................38
System Boards Component Specification..........................................................................................39
Riser Card Features..........................................................................................................................39
System Model Number.....................................................................................................................40
Specifications...................................................................................................................................41
Optional Hardware...........................................................................................................................42
5 System Board MSMT353 and MSMT359 ..................................................................................43
Connectors.......................................................................................................................................43
Jumpers..............................................................................................................................44
Cable Routing and Pinouts .................................................................................................46
Sound Controller..............................................................................................................................49
Address Resources for MSMT353 and MSMT359............................................................................50
DMA Channels ..................................................................................................................50
Input/Output Addresses ......................................................................................................50
Memory Address Map........................................................................................................50
PCI to ISA Bus Interrupt Mapping .....................................................................................51
PCI Bus Configuration Space .............................................................................................51
ISA Bus..............................................................................................................................52
6 System Board MSMT378............................................................................................................53
Connectors.......................................................................................................................................53
Jumpers..............................................................................................................................54
Cable Routing and Pinouts .................................................................................................55
Sound Controller..............................................................................................................................58
Address Resources...........................................................................................................................59
DMA Channels ..................................................................................................................59
Input/Output Addresses ......................................................................................................59
Memory Address Map........................................................................................................59
PCI to ISA Bus Interrupt Mapping .....................................................................................60
ISA Bus..............................................................................................................................60
7 External Port Pinouts..................................................................................................................61
MIDI/Game .....................................................................................................................................62
Parallel ............................................................................................................................................62
SCSI................................................................................................................................................63
Serial (COM)...................................................................................................................................63
Ethernet 10/100 Base-TX.................................................................................................................64
Mouse and Keyboard........................................................................................................................64
Universal Serial Bus (for MSMT378 system board)............................................................................65
Video (for MSMT353 or MSMT359 system board)..........................................................................65
VGA In (for MSMT353 or MSMT359 system board).......................................................................66
Video Out (for MSMT378 system board)..........................................................................................67
VGA In (for MSMT378 system board).............................................................................................67

vii
8 Riser Card MSMT463.................................................................................................................69
Expansion Slots ...............................................................................................................................69
Internal SCSI Controller ..................................................................................................................69
SCSI Connector ...............................................................................................................................70
Power Connector..............................................................................................................................70
Graphics Option Card Slot Assignments ..........................................................................................70
9 Peripherals ..................................................................................................................................73
SCSI CD-ROM Drive (CDSK178)...................................................................................................74
Disk Drives......................................................................................................................................74
CDSK111 (1 GB)...............................................................................................................75
CDSK094 (2 GB)...............................................................................................................76
CDSK098 (4 GB)...............................................................................................................76
CDSK123, CDSK164, CDSK165, CDSK166, CDSK167 (4 GB)........................................77
Floppy Disk Drive (CDSK146).........................................................................................................77
Combo Drive (MESAM86)..............................................................................................................78
EIDE CD-ROM Drive (CDSK177) ..................................................................................................79
10 Power Supply and Fans............................................................................................................81
Power Supply (MPWS145)...............................................................................................................81
DC Output Specifications...................................................................................................81
Cable Connectors ...............................................................................................................82
P1 Pinout............................................................................................................................82
P2 - P7 Pinout ....................................................................................................................83
P9 Pinout............................................................................................................................83
P10 Pinout..........................................................................................................................83
System Fans.....................................................................................................................................83
Power Supply Fan (MCBLZ52 or CFAN1170)...................................................................83
System Fans (MCBLY690).................................................................................................83
Vertical Bay Disk Drive Fan (MCBLY690)........................................................................84
Internal Bay Disk Drive Fan (MCBLY690) ........................................................................84
Index...............................................................................................................................................85

viii

ix
Introduction
This System Reference provides the information necessary to service the following systems:
u TDZ-425 RAX and TDZ-612 RAX workstations
u StudioZ RenderRAX
u InterServe 615R and 625R servers
Document Conventions
Bold Commands, words, or characters that you key in literally.
Italic Variable values that you supply, or cross-references.
Monospace Output displayed on the screen.
SMALL CAPS Key names on the keyboard, such as D, ALT or F3. Names of files and
directories. You can type filenames and directory names in the dialog boxes
or the command line in lowercase unless directed otherwise.
CTRL+DPress a key while simultaneously pressing another key; for example, press
CTRL and D simultaneously.
Additional System Information
A System Setup is shipped with each system, and provides detailed information about:
u Configuring the operating system and associated system software
u Using the system
u Using the AMIBIOS Setup program
u Installing system software
A System Introduction is delivered with the system, and provides information about:
u Intergraph Support
u System hardware features
u Available hardware option

x

1
1 Accessing the System
This chapter lists hand tools and describes servicing restrictions, opening the base unit, avoiding
electrostatic discharge, removing and attaching the face plate, and closing the base unit.
This system features a telescoping chassis that provides increased serviceability and access to internal
components. The telescoping section, to which the system board is mounted, is secured by five screws
and slides out from the rear.
NOTE “Right side” and “left side” are as seen from the front of the base unit.
CAUTION Follow all warnings and cautions in servicing instructions. Personal injury and damage to equipment
can occur if documented procedures are not followed.
CAUTION Use an antistatic wrist strap for all servicing procedures to avoid the possibility of electrostatic
discharge.
Tools
You will need the following tools to service the system:
u Antistatic wrist strap
u Quarter-inch nutdriver
u No. 1 and No. 2 Phillips screwdrivers
u Three-sixteenth-inch nutdriver
u Five-sixteenth-inch or 8 mm nutdriver
u Small single-slot screwdriver
Opening the Base Unit
CAUTION Shut the system down and turn the system power off. Use caution to avoid injury when removing
covers and other hardware.
CAUTION If the system is installed in a free-standing rack, ensure front and side stabilizers are fully extended.
To open the base unit:
1. Remove the screws that secure the face plate to the rack.
2. Slide the system out of the rack until it locks in the extended position.
3. Remove the following eight screws that secure the cover to the chassis: One at right and left top
corners of face plate; two at top, back of cover; and two at right and left sides, back of cover.
4. Slide the cover back about an inch, then lift the cover off.
5. Attach grounding clip from antistatic wrist strap to bare metal.

2
Protecting Against Electrostatic Discharge
Sensitive components inside the base unit can be damaged by static electricity. To protect against this
possibility, take the following precautions when working with the system’s internal components.
u Touch the bare metal of the base unit to ensure it and your body are at the same electric potential.
u Handle all printed circuit boards as little as possible and by the edges only. Leave new parts in
their protective packaging until you install them.
u Use a disposable or reusable antistatic wrist strap when servicing or upgrading the system. Once
a disposable wrist strap is used, it cannot be used again. A reusable antistatic wrist strap can be
attached to any bare metal part of the base unit. The metal conductor bead in the elastic sleeve of
reusable antistatic straps must contact bare skin.
Removing the Face Plate
To remove the face plate:
1. Remove the cover.
2. Remove one lower screw on each side of system front that secures handle to the base unit.
3. Remove the six screws that secure face plate to the base unit.
4. Pull the face plate toward you to remove it. Note how the bottom lip of the face plate attaches to
the cutout in front of the power supply.
Attaching the Face Plate
To attach the face plate:
1. Push the face plate onto the base unit. Ensure that the top part of the lip at bottom slides over the
cutout in front of the power supply.
2. Adjust the face plate as needed to ensure all components are flush.
3. Secure the face plate to the base unit.
4. Close the cover.
Closing the Base Unit
CAUTION After servicing the system, always replace the covers that were removed. The covers ensure the
system maintains proper air flow, so internal components do not overheat and fail. The covers also
ensure that electromagnetic interference (EMI) emissions remain below the standard requirements.
To close the base unit:
1. Remove the antistatic wrist strap from the base unit.
2. Replace the cover.
3. Slide the base unit into the rack.
4. Secure the base unit with screws at each corner of the face plate.

3
2 Servicing the System
This chapter describes how to replace the standard parts within the system.
NOTE Refer to Chapter 1 for details on opening the system and protecting against electrostatic discharge.
CAUTION Follow all warnings and cautions in servicing instructions. Personal injury and damage to equipment
can occur if documented procedures are not followed.
CAUTION Use an antistatic wrist strap for all servicing procedures to avoid the possibility of electrostatic
discharge.
The following shows the location of major parts in the system. Unit with MSMT353 system board is
shown.
Internal Drive Bay
Disk Drive Fan
Riser Card Brace
Riser Card
System Board
Processor Module
or P6 Bus
Termination Card
(MSMT353 or
MSMT359 onl
y)
Memory
PCI Card Guide
Power Supply
Floppy Drive
Horizontal Drive Bay
Vertical Drive Bay

4
Peripheral Drives
Floppy Disk Drive
To replace the floppy disk drive:
1. Disconnect the power cable and floppy cable from the drive as shown in the following figure.
Note the position of the red stripe on the floppy cable.
2. Remove the two screws securing the drive bracket to the power supply.
Floppy Cable
Power Cabl
e
Screw
(
One each side
)

5
3. Remove the four screws securing the bracket to the drive as shown in the following figure.
4. Attach the new drive to the bracket and attach it to the power supply. Connect the power cable
and floppy cable. Ensure the red stripe on the floppy cable is oriented correctly.
5. Close the base unit.
Screws (Two
each side)

6
CD-ROM Drive
Depending on system options, the CD-ROM drive may be a SCSI drive or an EIDE drive. Refer to
Chapter 9, “Peripherals,” for details.
To replace the CD-ROM drive:
1. Disconnect the power cable, data cable, and audio cable from the CD-ROM drive as shown in the
following figure. Note the position of the stripe on the data cable.
2. Remove the screws securing the horizontal bay to the base unit.
Horizontal Bay
Data Cable
Audio
Cable
Power Cable
Screw
Screw

7
3. Remove the four screws securing the drive to the drive bay as shown in the following figure.
4. Set the SCSI ID on a new SCSI drive to the same ID as the old drive. On a new EIDE drive, set
the mode select header to “master.” Refer to Chapter 9, “Peripherals,” for details.
5. Attach the new drive to the horizontal bay and attach it to the base unit. Connect the power
cable, data cable, and audio cable. Ensure the stripe on the data cable is oriented correctly.
6. Close the base unit.
Screws (Two
each side)

8
Vertical Bay Disk Drives
If Kingston removable disk modules are installed in the system, refer to the Kingston documentation
for disk drive or module replacement instructions.
To replace drives in the vertical bay:
1. Remove the disk drive fan by removing the screw at the top of the vertical bay and disconnecting
the fan power cable from the inline connector.
2. Disconnect the power cable and SCSI cable from the disk drive.
Fan Power Cable
In-line Connecto
r
Fan
Screw

9
3. Remove the screws securing the disk drive at the top of the vertical bay as shown in the following
figure.
4. Pull out the black disk drive tray through the front of the system. The disk drive is attached to
the tray.
Screws

10
5. Remove the slot filler by removing screws as shown in the following figure; then remove the four
screws securing the disk drive to the tray.
6. Set the SCSI ID on the new disk drive to the same SCSI ID as on the old disk drive.
7. Attach the new disk drive to the tray and slide it into the vertical bay.
8. Secure the drive to the bay.
9. Connect the SCSI cable and power cable to the disk drive.
10. Replace the disk drive fan and connect the fan power cable.
11. Close the base unit.
Drive Tray
Slot Filler
Screws
Screws (Two
each side)
