TVE-DEC12 IP Video Decoder Quick
Start Guide
Figure 1: Front panel
LED indicator Description
1.
P
ower Power LED
2.
Link
Network connection LED
3.
Tx/Rx
Data
transmitting/receiving
status LED
4.
HDMI
HDMI output
5.
VGA
VGA output
6.
Audio out
RCA Audio output
7.
Video out
BNC decoding output
Figure 2: Back panel
Name
Description
1.
Line out Audio output, 3.5mm
connector.
2.
Line in Audio input, 3.5mm
connector.
3
. RS-232 Connect to an RS-232
device, such as a computer.
4
. Ethernet Connect the
10M/100M/1000Mbps self-
adaptive UTP Ethernet port
to a network.
5.
RS-485 Connect to RS-485 serial
port.
6.
Alarm
Input/Output
Not applicable.
7.
DC 12V Connect a 12 V power
supply via a PSU.
8.
GND Connect to ground.

2 P/N 1073628-EN • REV A • ISS 08APR19
Figure 3: TVE Video Wall web page
Name Description
1.
Video Wall webpage Set up how you want the video wall to appear. Lets you select which device
is displayed on which monitor. Drag and drop devices from the device tree to
a monitor.
Note: Video images cannot be seen on the decoder web page.
2.
Video Wall Configuration
webpage
Define the monitor resolution and layout (number of rows and columns) on
the wall.
3.
Configuration webpage Configure the general settings of the decoder. See “Configuration” on page
4.
4.
Device tree List of devices connected to the decoder by their IP address or URL.
5.
MonitorsThe decoder can be used with HDMI, VGA and BNC monitors
simultaneously. Up to three monitors can be used.
6.
Scene list Create a list of stored pre-defined layouts with their streams so that they can
be quickly called up when needed.
7.
Multiview Select the desired multiview.
8
. Shortcut toolbar Save the scenes.
Stop decoding for all streams.
Refresh the screen.
The Send to Back button lets you switch the positions of overlapping
video tiles.

P/N 1073628-EN • REV A • ISS 08APR19 3
Package contents
The TruVision TVE H.264 IP video decoderis
shipped with the following items:
•TVE-DEC12 decoder
•Power adaptor
•Power cable
•Quick start guide
Note: The Quick Start Guide and User
manual are available on our web sites:
Americas: www.interlogix.com
EMEA: www.firesecurityproducts.com
The manuals are available in several
languages.
Australia/New Zealand: www.utcfs.com.au
Activate the admin password
When you first start up the unit, the Activation
window appears. You must define a high-
security admin password before you can
access the unit. There is no default password
provided.
A message will appear on-screen when the
unit has been activated.
Figure 4: Password activation window
User Name: It is always
“admin”. It cannot be
changed.
The bar showing
password strength
Enter the new admin password and confirm it.
Tips on creating a strong password:
A valid password range must be
between 8 and 16 characters. You can
use a combination of numbers, lower
and upper case letters, and special
characters: _ - , * & @ / $? Space. The
password must contain characters from
at least two of these groups.
The password is case-sensitive so use a
mixture of upper and lower case letters.
The password must have between 8 and
16 characters.
Do not use personal information or
common words as a password.
Note: If you should forget your admin
password, please contact Technical Support
to reactivate the unit with a new password.
Network settings
Use TruVision Device Manager to find and
configure the IP address and other
parameters of the device. This tool
automatically identifies TruVision devices that
support “auto-discovery” anywhere on the
network,even in different subnets.
To use the TruVision Device Manager:
1. Download the tool from our website.
2. Double-click the shortcut icon to open
the tool. Click Device Manager to begin
the discovery process. The list of
TruVision devices located on your
network appears.
Note: The TruVision Device Manager
can only detect devices that are on the
same LAN. The tool cannot detect
devices placed on a VLAN.
3. Change the device settings as required.
Click Xon the top right corner when
completed.

4 P/N 1073628-EN • REV A • ISS 08APR19
Before you start
Before accessing the browser, you need to
configure the network settings of the decoder.
Connect the decoder to the LAN, and connect
a computer to the same LAN as the decoder.
The decoder’s factory default user name is
admin. The decoder’s factory default IP
address is 192.168.1.70.
Accessing the web browser
The on-screen display menus are available in
English and 10 other languages.
To access the web browser:
1. Open the web browser and select your
language.
2. Enter the IP address of the decoder (for
example, http://192.168.1.70). Press the
Enter key on the computer. The system
displays the login window.
3. Enter the user name (default: admin) and
password to log into the system. The
decoder’s main page appears, which is
Video Wall by default (see Figure 3).
Configuration
Log in and go to the Configuration menu to
configure the general settings of the decoder.
It has four branches:
System
System settings
System Information: Displays the decoder
version.
Time Settings
RS-232: RS-232 communication port
parameters.
RS-485: RS-485 communication port
parameters.
Maintenance
Restart the decoder
Restore the decoder
Import and export files
Upgrade the system firmware
User Management
Create extra users and assign user rights.
Network
Configure the network parameters, such as IP
address, DDNS and HTTPS settings.
Decoding Configuration
Stream configuration: Set up so the decoder
can automatically switch between main stream
and substream.
Transparent Channel: Define how to transfer
data between the encoder and decoder.
Synchronous Output Settings: Synchronize all
video outputs of the decoder.
Display Options: Define what appears on the
monitor screen when decoding stops.
Security Control
Enable/disable SSH, HTTPS, network
discovery,and the webpage time out.
