Intermatic PG2500 User manual

CAUTION: Turn off power to the electric service or panel and to equipment to be protected
before installing any Surge Protection Device. All wiring should be done by a qualified
electrician and comply with the National Electric Code and local electric codes.
INSTALLATION
1. Test and verify system voltage to assure proper model selection of Surge Protection Device (SPD).
Refer to the wiring configurations and voltages on page 2 and 3 for additional information.
2. Turn Power OFF.
3. Remove the knockout from the power bus, load center or equipment panel that will position the SPD
for the shortest wire lead distance. Note that the shorter the lead length between the SPD and the
connection point, the better the protection.
4. Open the hinged cover on the PanelGuard unit by unscrewing the locking bolts in the cover.
5. Select and remove the appropriate knockout on the PanelGuard cabinet.
6. Connect the mounting plates to the back of the PanelGuard cabinet using the connectors provided.
7. Mount the PanelGuard cabinet to a rigid surface. If the mounting position prevents direct connection
to the load center or equipment panel, conduit must be used to comply with the national Electric
Code.
8. Twist or ty-wrap all lead wires to eliminate space or gaps between them. Route the wire leads from
the PanelGuard cabinet to the power panel.
9. Cut each wire lead to the proper length. DO NOT coil extra wire length.
10. Connect the GREEN wire lead to the system ground.
11. Connect the WHITE wire lead (when included) to the system neutral bus. When installing at a main
panel, the neutral bus may be the same as the ground bus.
12. Connect each phase wire, BLACK or RED, to the power bus. All models have internal line fusing.
Select a method of connection that complies with local electric code and the National Electric Code.
Make sure that the phase wires have the correct voltage level between them. Note that for the 240
volt High Leg Delta, the wire lead for the High Leg is colored RED, and must be connected to the
phase that measures approximately 208 volts to neutral and to ground. Failure to comply with this
instruction will result in failure of the SPD and void the warranty.
13. If remote monitoring is used, remove the ½” knockout and connect wire leads to the terminal strip
located in the monitoring section of the PanelGuard cabinet. Be sure to comply with local and
national wiring codes for the voltage of the monitoring circuit. Refer to the wiring diagram on page 3.
14. Check all connections for proper tightness or torque. Observe the suggested torque values published
by the manufacturer when circuit breakers or separate disconnect devices are used.
15. Close and secure the hinged cover using the locking bolts provided with the cover.
16. Turn Power ON.
17. Make sure that each Protection Status indicator on the PanelGuard is ON. If not, turn power off and
recheck each installation step listed above.
18. Make sure that the Alarm Warning indicator on the PanelGuard is OFF. If not, turn power off and
recheck each installation step listed above.
19. Toggle the Alarm Switch to the ‘TEST’ position. Verify that the audible alarm sounds and the alarm
relay changes state. Return the switch to the ‘NORMAL’ position.
20. Toggle the Alarm Switch to the ‘SILENCE’ position. Verify that the audible alarm sounds and the
alarm relay changes state. Return the switch to the ‘NORMAL’ position.
21. For troubleshooting assistance, call Intermatic at 800-391-4555.
INSTALLATION INSTRUCTIONS

WIRING CONFIGURATIONS
120 VAC Single Phase
Transformer
Secondary
Use of Circuit Breakers is optional
L1
G
N
Load Center
or equipment
Black
White
Green
PanelGuard
120/240 VAC Single (Split) Phase
L1
G
N
Load Center
or equipment
Black
White
Green
Black
L2
Transformer
Secondary PanelGuard
Use of Circuit Breakers is optional
120/208 VAC Three Phase WYE
L1
G
N
Load Center
or equipment
Black
White
Green
Black
L2
Black
L3
Transformer
Secondary
PanelGuard
Use of Circuit Breakers is optional
120/240 VAC Three Phase Delta High Leg Delta
L1
G
N
Black
White
Green
Red
L2
Black
L3
Transformer
Secondary
Load Center
or equipment
PanelGuard
Use of Circuit Breakers is optional
VOLTAGE CONFIGURATION CONFIRMATION
MODE VOLTAGE
Line to Neutral 120
Line to Ground 120
VOLTAGE CONFIGURATION CONFIRMATION
MODE VOLTAGE
Line to Line 240
Line to Neutral 120
Line to Ground 120
VOLTAGE CONFIGURATION CONFIRMATION
MODE VOLTAGE
Line to Line 208
Line to Neutral 120
Line to Ground 120
VOLTAGE CONFIGURATION CONFIRMATION
MODE VOLTAGE
Line to Line 240
Line to Neutral 120
High Leg to Neutral 208
Line to Ground 120
High Leg to Ground 208
277/480 VAC Three Phase WYE

L1
G
N
Black
White
Green
Black
L2
Black
L3
Transformer
Secondary Load Center
or equipment
PanelGuard
Use of Circuit Breakers is optional
480 VAC Three Phase DELTA
L1
G
Black
Green
L2
Black
L3
Black
Transformer
Secondary Load Center
or equipment
PanelGuard
Use of Circuit Breakers is optional
Alarm relay for remote monitoring
PanelGuard
AC lead connections
Common - Brown
Normally Open - orange
Normally Closed - Violet
Alarm relay connections
VOLTAGE CONFIGURATION CONFIRMATION
MODE VOLTAGE
Line to Line 480
Line to Neutral 277
Line to Ground 277
VOLTAGE CONFIGURATION CONFIRMATION
MODE VOLTAGE
Line to Line 480
Line to Ground 480
Alarm Switch functions
NORMAL POSITION:Audible alarm is silent and alarm relay is energized for proper operation. If
protection is lost or reduced, the audible will sound and the alarm relay will change state.
TEST POSITION:Audible alarm will sound and the alarm relay will change state.
SILENCE POSITION:Audible alarm is silenced and alarm relay is not energized during alarm conditions.
When protection is restored, the audible will sound and the alarm relay will energize to change state.
Brown - c
Violet – n/c
Orange – n/o
Alarm condition – relay not energized
Brown - c
Violet – n/c
Orange – n/o
Normal operating condition – relay energized

TEN YEAR LIMITED PRODUCT WARRANTY
For
PanelGuardTM2500 SURGE PROTECTION DEVICES
(1) What Is Covered By This Limited Warranty
Repair or Replacement of Product
Intermatic Incorporated ("Intermatic") warrants to the original purchaser only, the Intermatic PanelGuard 2500 Series Surge
Protection Device shall be free from defects in material or workmanship for a period of ten years from date of purchase. If the
purchaser discovers a defect in material or workmanship, the purchaser must promptly submit a warranty claim. Upon a
determination by Intermatic that the Product is defective, Intermatic shall correct any defect in material or workmanship by, at
Intermatic’s option, either repairing or replacing the Defective Product. Any repair, including both parts and labor, shall be at
Intermatic’s expense. The foregoing remedies are the purchaser’s exclusive remedies for a breach of warranty.
For purposes of this Limited Warranty, a Power Transient shall mean over-voltage resulting from momentary voltage spikes or
surges on an AC power line of magnitude that the Product, according to its specifications, is designed to stop before such spikes
or surges affect the stated equipment.
The Product must be installed in the appropriate application in complete accordance with the installation instructions. All building
wiring and other connections to the Product must conform to all applicable national, state and local electrical codes; the Product
must not be opened, modified, exposed to extreme heat or cold, submerged or subjected to abnormal use or service. All
products must be used in accordance with the instructions provided with the Product and the purchaser shall be solely
responsible for selecting a Product model with specifications appropriate for the equipment to be protected. Intermatic shall
determine, in its sole discretion, whether any Product returned by a purchaser has been used in accordance with its instructions,
is an appropriate model for the purchaser's use thereof, and whether the Product is defective.
(2) What Is Not Covered By This Warranty
Intermatic does not warrant (a) defects in the Product or damage to any equipment caused by the failure to properly install the
Product, (b) damage caused by use of the Product for purposes other than those for which it was designed, (c) damage caused
by disaster such as fire, flood and wind, (d) damage caused by unauthorized attachments or modification of the Product, (e)
damage to the Product occurring during shipment, or (f) electrical disturbances exceeding published product specifications, (h)
damage to the Product caused by any other abuse or misuse by the purchaser.
(3) Disclaimer of Warranty
THE FOREGOING WARRANTIES ARE IN LIEU OF ALL OTHER EXPRESSED WARRANTIES. TO THE EXTENT ALLOWED
BY LAW, ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED
IN DURATION TO THE DURATION OF THIS LIMITED WARRANTY.
(4) Limitation of Remedies
In no case shall Intermatic be liable for any special, incidental, or consequential damages based upon breach of warranty, breach
of contract, negligence, strict tort, or any other legal theory. Such excluded damages include, but are not limited to, damage to
software, loss of data, loss of profits, loss of savings or revenue, loss of use of the Product or any associated equipment, cost of
capital, cost of any substitute equipment, facilities or services, downtime, the claims of third parties including customers, damage
to property and personal injury. Some states do not allow limits on warranties or on remedies for breach in certain transactions.
In such states, the limits in this paragraph and in paragraph (3) may not apply.
(5) Time Limit for Bringing Suit
No action arising out of any claimed breach of warranty may be brought more than one year after the cause of action has
accrued.
(6) No Other Warranties
Unless modified in a writing signed by both parties, this agreement is understood to be the complete and exclusive agreement
between the parties, superseding all prior agreements, oral or written, and all other communications between the parties relating
to the subject matter of this agreement. No employee of Intermatic or any other party is authorized to make any warranty in
additional to those made in this agreement.
INTERMATIC INCORPORATED
SPRING GROVE ILLINOIS
815-675-2321 Fax: [phone]
http://www.intermatic.com
158EG10xxx PDF 11.02
