Intermatic IG1200RC3 User manual

Model IG1200RC3
Type 1 or Type 2 Surge Protective Device
INSTALLATION INSTRUCTIONS
Risk of Electric Shock
WARNING
• Thoroughlyreadinstructionsbeforeinstallingunit.
 • InstallationandServicetobeperformedbya 
  qualiedlicensedelectrician.
 • Intendedforindoororoutdooruse.
Type 1 installation:
Atypicalinstallationofatype1SPDwillbeconnectedbetweenthesecondaryoftheservicetransformerandthe
linesideoftheservicepanel.ThisinstallationisintendedtobeinstalledwithoutovercurrentprotectiontotheSPD.
 1. Determinelocation:
  • Ensureconductorlengthsareasshortandstraightaspossible
   forbestperformance.Donotcoilexcesswire.TheSPD
   functionsbestifallbendsinwiresarerounded,ideallytoa4”
   radius.Hard90degreebendwillreduceefciency.
   Cutallleadstothecorrectlength.Donotcoilexcessleads.
  • Installappropriateweatherproofttingsiftheunitistobe
   mountedoutside.
2. Ensureallmountingandconnectionsarecorrectandsecure.
  OnceenergizedthegreenindicatorLEDwillbeONandvisible
  throughthecoveroftheSPD.
Type 2 installation:
Atypicalinstallationofatype2SPDwillbeconnectedtotheloadside
oftheservicepanelandisintendedtobeinstalledwithovercurrent
protectiontotheSPD.
 1. Determininglocation:
• Ensureconductorlengthsareasshortandstraightaspossible
   forbestperformance.Donotcoilexcesswire.TheSPD
   functionsbestifallbendsinwiresarerounded,ideallytoa
   4”radius.Hard90degreebendwillreduceefciency.Cutall
   leadstothecorrectlength.Donotcoilexcessleads.
  • Installappropriateweatherproofttingsiftheunitistobe
   mountedoutside.
  • IG1240FMP33isalsoavailableforushmountapplications.
 2. ConnectthewhitewirefromtheSPDtotheneutralbusbarin
  thepanelasshown.
  • Connectionmayalsobemadetotheneutral/groundbusbarif
   paneldoesnothaveaseparategroundbusbar.
 3. Connectthetwoblackwirestoacircuitbreakerasshownin
  gure2.ForbestperformancefromSPDthemaximum
  recommendedcircuitbreakersizeof240V,20A,2-poleshould
  beused.
 4. Ensureallmountingandelectricalconnectionsarecorrectand
  securelyfastened.OnceenergizedthegreenindicatorLEDwill
  beONandvisiblethroughthecoveroftheSPD.
Maintenance:
¡ACVoltageSPD:
 • PeriodicallycheckSPDtoensuregreenindicatorLEDisON.
  IfgreenLEDisOFFprotectionhasdiminishedandtheSPD
  shouldbereplacedimmediately.
• Allwiringmustcomplywithallstateandlocal
 electricalcodesincludingtheNationalElectrical
 Codeand/orCanadianElectricalCode.
• Suitableforuseonacircuitcapableofdelivering
 notmorethan50,000rmssymmetricalamperes.
• Thisunitcontainsnoserviceableparts.
• Thisproductdoesnotprotectagainstdirect
 lightningstrikes.
IMPORTANT SAFETY INSTRUCTIONS • SAVE THESE INSTRUCTIONS
MainBreaker
2-Pole,20Acircuit
breakershown
A=Black(Line)
B=Black(Line)
C=Neutral(White)
Type2Installation
120 VAC Two wire single phase with
separate ground.
Found at connections for individual pieces of
equipment such as pumps and single phase motors.
NOTE: Both Black wires connect to Line.
Line
Neutral
Ground 0 v
120 v
120 v
WHITE
BLACK
BLACK
120/240 VAC Three wire with
separate ground.
Found in Main Disconnect Switches, Main
Distribution panels, Load Centers Sub panels
and equipment locations.
Line
Line
Neutral
Ground
120 v
120 v
240 v
120 v
BLACK
WHITE
BLACK
120/240 VAC Three wire with
grounded neutral.
Found at Service entrances and Meter Cans.
Line
Line
Grounded/
Neutral
120 v
120 v
240 v
WHITE
BLACK
BLACK
Type1Installation

158--01145
THREE YEAR LIMITED PRODUCT and
CONNECTED EQUIPMENT WARRANTY for
INTERMATIC SURGE PROTECTIVE DEVICES
(1) What is Covered By This Limited Warranty
(A) Replacement of Product
Intermatic Incorporated (“Intermatic”) warrants to the original purchaser only, Intermatic IG1200RC3 Surge Protective Devices (each a “Product”) shall be free from defects in
material or workmanship for a period of three years (36 months) from date of purchase or 39 months from date of manufacture. If the purchaser discovers a defect in material
or workmanship, the purchaser must promptly submit a warranty claim. Upon a determination by Intermatic that the Product is defective, Intermatic, shall correct any defect in
material or workmanship by replacing the Defective Product. Any repair, including both parts and labor, shall be at Intermatic’s expense. The foregoing remedy is the purchaser’s
exclusive remedy for a breach of warranty.
The product must be installed in the appropriate application in complete accordance with the installation instructions. All building wiring and other connections to the Product
must conform to all applicable national, state, and local electrical codes; the Product must not be opened, modified, exposed to extreme heat or cold, submerged or subjected
to abnormal use or service. All products must be used in accordance with the instructions provided with the Product and the purchaser shall be solely responsible for selecting a
Product model with specifications appropriate for the equipment to be protected. Intermatic shall determine, in its sole discretion, whether any Product returned by a purchaser
has been used in accordance with its instructions, is an appropriate model for the purchaser’s use thereof, and whether the Product is defective.
(B) Repair or Reimbursement for Damage to Properly Connected Equipment
In addition to the above described Product warranty, Intermatic warrants to the original purchaser of the Product for a period of three years from the date of purchase, the fol-
lowing: In the event that any major household connected electrical equipment (as defined below) is damaged (the “Damaged Equipment”) as a direct result of the failure of a
Product to protect the Damaged Equipment from Power Transients (as hereinafter defined) and all other conditions are satisfied, Intermatic’s option, either repair the Damaged
Equipment or reimburse the purchaser of the defective product. The limit of Intermatic’s liability under this warranty shall be the Fair Market Value (as hereinafter defined) of
the Damaged Equipment or the deductible amount of the original purchaser’s homeowners insurance policy, whichever is less. In no event shall Intermatic incur repair costs or
reimburse the purchaser for an amount in excess of $7,500.
As used herein, “major household connected electrical equipment” shall mean major household appliances and electronic devices, including refrigerators, freezers, air
conditioners, stoves and ovens, microwave ovens, clothes washers and/or dryers, dishwashers, audio and stereo equipment or components, video equipment, televisions and
computers. Major household connected electrical equipment that normally requires an additional connection such as phone/modem connection, antenna or cable connection
or other temporary or permanent connection must be properly connected to an Intermatic listed Surge Protection Device that incorporated surge protection for both AC (power)
and all other input connections. The Fair Market Value of the Damaged Equipment shall be the current value of the equipment specified in the most recent version of the Orion
Blue Book (printed or on-line edition) by Orion Research Corporation, or a comparable publication.
Promptly upon discovering any Damaged Equipment, the purchaser must submit a claim pursuant to the claim procedure provided below. In no event may a purchaser initiate
a claim later than (30) days after the Protected Equipment is damaged. In order to receive the Connected Equipment protection provided in this Section, all of the following
conditions must be satisfied with respect to the use of the Product: (a) the Product must be properly installed; (b) all building wiring and other connections to the Product and
the Damaged Equipment must conform to all applicable federal, state and local electrical codes; (c) no ground wires or ground connections in addition to the AC power source
can be used in connection with the Product or the Damaged Equipment; (d) Equipment with additional wiring or data/cable connections (as defined above) must be properly
connected to a Listed Surge Protection Device (as noted above); and (e) the Product(s) and Protected Equipment must not be opened, modified, exposed to extreme heat or cold,
submerged or subjected to abnormal use or service.
For purposes of this Limited Warranty, a Power Transient shall mean over-voltage resulting from momentary voltage spikes or surges on an AC power line of magnitude that the
Product, according to its specifications, is designed to stop before such spikes or surges affect downstream equipment.
(2) What is Not Covered By This Warranty
Intermatic does not warrant (a) defects in the Product or damage to any equipment caused by the failure to properly install the Product, (b) damage caused by use of the
Product for purposes other than those for which it was designed, (c) damage caused by disaster such as fire, flood and wind, (d) damage caused by unauthorized attachments or
modification of the Product, (e) damage to the Product occurring during the shipment, or (f) electrical disturbances exceeding published product specifications, (g) damage to the
Product caused by any other abuse or misuse by the purchaser, (h) damage due to direct or vicinity lightning strikes, this warranty applies to residential and commercial applica-
tions. This device is not intended to provide protection during Utility voltage swells or loss of neutral conditions which are by definition not transient events and are not covered
by this warranty.
(3) Disclaimer of Warranty
THE FOREGOING WARRANTIES ARE IN LIEU OF ALL OTHER EXPRESSED WARRANTIES. TO THE EXTENT ALLOWED BY LAW, ANY IMPLIED WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED IN DURATION OF THIS LIMITED WARRANTY.
(4) Limitation of Remedies
IN NO CASE SHALL INTERMATIC BE LIABLE FOR ANY SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES BASED UPON BREACH OF WARRANTY, BREACH OF CONTRACT, NEG-
LIGENCE, STRICT TORT, OR ANY OTHER LEGAL THEORY. SUCH EXCLUDED DAMAGES INCLUDE, BUT ARE NOT LIMITED TO, DAMAGE TO SOFTWARE, LOSS OF DATA, LOSS OF PROFITS,
LOSS OF SAVINGS OR REVENUE, LOSS OF USE OF THE PRODUCT OR ANY ASSOCIATED EQUIPMENT, COST OF CAPITAL, COST OF ANY SUBSTITUTE EQUIPMENT, FACILITIES OR
SERVICES, DOWNTIME, THE CLAIMS OF THIRD PARTIES INCLUDING CUSTOMERS, DAMAGE TO PROPERTY AND PERSONAL INJURY. SOME STATES DO NOT ALLOW LIMITS ON WAR-
RANTIES OR ON REMEDIES FOR BREACH IN CERTAIN TRANSACTIONS, IN SUCH STATES, THE LIMITS IN THIS PARAGRAPH AND IN PARAGRAPH (3) MAY NOT APPLY.
(5) Time Limit for Bringing Suit
No action arising out of any claimed breach of warranty may be brought more than one year after the cause of action has occurred.
(6) No Other Warranties
Unless modified in writing signed by both parties, this agreement is understood to be the complete and exclusive agreement between the parties, superseding all prior agree-
ments, oral or written, and all other communications between the parties relating to the subject matter of this agreement. No employee of Intermatic or any other party is autho-
rized to make any warranty in addition to those made in this agreement. This warranty is made by: Intermatic Incorporated/After Sales Service, 7777 Winn Rd., Spring Grove, IL.
60081-9698/815-675-7000 http://www.intermatic.com
(7) Claim Procedure
In order to submit a claim for warranty service the original purchaser must:
(A) Contact the Intermatic Insurance Claims Center at 1-800-270-7227 before having the damaged equipment repaired.
(B) Request that an Incident Claim Report be written regarding the damage including descriptions and model identification (if available) of the equipment that was damaged.
Record the Warranty Claim Number for future reference.
(C) File a claim for the damaged equipment with your homeowners (or renter’s) insurance company.
(D) Send the INTERMATIC SURGE PROTECTIVE DEVICE to the Intermatic Warranty Coordinator at the address listed below. All returned devices must be plainly marked with the
Intermatic Warranty Claim Number.
(E) Send all of the following information in a single packet to the Intermatic Warranty Coordinator at the address listed below.
(1) Claimant’s name, address and telephone number.
(2) Original dated sales receipt for the Intermatic Surge Protection Device.
(3) Original report for repair work.
(4) The damage report
(5) A copy of the claim report by the homeowners (renter’s) insurance company or a copy of the policy showing the deductible amount exceeds the cost of the repair.
(F) Address all communications and products returns to:
IntermaticWarrantyCoordinator
7777WinnRoad
SpringGrove,Illinois60081-9698
Attn:SurgeClaimProcessor
 Product&InstallationInformation
  Purchasedate:
  Installationdate:
  Installedby:
  Pointofinstallation:
  Breakerratingsifapplicable:
