Intex CS3110 User manual

133
PO
(133PO) SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2020
English
English
OWNER’S MANUAL
Saltwater System
Model CS3110
IMPORTANT
SAFETY RULES
Read, understand, and follow
all instructions carefully before
installing and using this product.
Don’t forget to try these other fine Intex products: Pools, Pool
Accessories, Inflatable Pools and In-Home Toys, Airbeds and
Boats available at fine retailers or visit our website listed below.
Due to a policy of continuous product improvement, Intex
reserves the right to change specifications and appearance,
which may result in updates to the instruction manual without
notice.
IMPORTANT!
DO NOT RETURN PRODUCT TO STORE
To purchase parts and accessories or to obtain non-technical assistance, Visit
www.intexcorp.com
For technical assistance and missing parts call us toll-free (for U.S. and Canadian Residents):
1-800-234-6839
Monday through Friday, 8:30am to 5:00pm Pacific Time 133-*PO-R1-2107
For illustrative purposes only.

(133PO) SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2020
133
PO
SAVE THESE INSTRUCTIONS
English
Page 2
Warnings.................................................................................3
Parts References....................................................................4
Product Specifications..........................................................4
Setup Instructions..................................................................5
Salt & Pool Water Volumes...................................................6
Intex Pools Salt Table............................................................7
Intex Pools Cyanuric Acid Table..........................................8
Intex Pools Operating Time Table........................................9
Non-Intex Pools Salt Table....................................................10
Non-Intex Pools Cyanuric Acid Table..................................10
Non-Intex Pools Operating Time Table................................10
Operating Instructions...........................................................11-12
LED Code Chart......................................................................13
Maintenance............................................................................14-15
Long Term Storage................................................................15
Pool Maintenance and Chemical Definitions.......................16
Troubleshooting Guide..........................................................17-18
Limited Warranty....................................................................19
TABLE OF CONTENTS

(133PO) SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2020
133
PO
SAVE THESE INSTRUCTIONS
English
Page 3
WARNING
•For Outdoor use only.
•Not to energize or operate the unit if the cell housing is damaged or improperly assembled.
•To reduce the risk of injury, do not permit children to use this product. Always supervise
children and those with disabilities.
•Children must stay away from this product and all electrical cords.
•Assembly and disassembly by adults only.
•Risk of electric shock. Connect only to a grounding type receptacle, this product is provided
with a ground-fault circuit interrupter. If replacement of the plug or cord is needed, use only
identical replacement parts.
•Always unplug this product from the electrical outlet before removing, cleaning, servicing or
making any adjustment to the product.
•The unit is provided with a ground-fault circuit interrupter (GFCI). To test the GFCI, push the
test button. The GFCI should interrupt power. Push the reset button, power should be restored.
If the GFCI fails to operate in this manner. The GFCI is defective. If the GFCI interrupts power
to the pump without the test button being pushed, a ground current is flowing, indicating the
possibility of an electric shock. Do not use this pump. Disconnect the pump and have the
problem corrected by a qualified service representative before using.
•Do not bury the electrical cord. Locate the cord where it will not be damaged by lawn mowers,
hedge trimmers and other equipment.
•To reduce the risk of electric shock, the supply cord cannot be replaced. If the cord is
damaged, the appliance should be replaced immediately.
•To reduce the risk of electric shock, do not use extension cords, timers, plug adaptors or
converter plugs to connect unit to electric supply; provide a properly located outlet.
•Do not attempt to plug in or unplug this product while standing in water or when your hands
are wet.
•Do not use an appliance leakage current interrupter (ALCI) in place of a GFCI since the ALCI
will not protect people.
•Position this product away from the pool, so as to prevent children from climbing on it and
accessing the pool.
•Make sure the electrical parameters indicated on the product correspond to the local mains
voltage before you connect the unit.
•This product is intended to be used only for the purposes described in the manual!
FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN PROPERTY DAMAGE,
ELECTRIC SHOCK, ENTANGLEMENT OR OTHER SERIOUS INJURY OR DEATH.
IMPORTANT SAFETY RULES
Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product.
READ AND FOLLOW ALL INSTRUCTIONS
For portable Above-Ground-Pools only
This product is for use with storable pools only. Do not use with permanently-installed pools. A
storable pool is constructed so that it is capable of being readily disassembled for storage and
reassembled to its original integrity. A permanently-installed pool is constructed in or on the
ground or in a building such that it cannot be readily disassembled for storage.
To reduce the risk of electric shock the pool must be installed no closer than 6 feet (1.8 m) from
any electrical outlet. Do not place portable appliances closer than 5 feet (1.5 m) from the pool.
These product warnings, instructions and safety rules provided with the product represent some common
risks of water recreation devices and do not cover all instances of risk and danger. Please use common
sense and good judgement when enjoying any water activity.
CAUTION

(133PO) SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2020
133
PO
SAVE THESE INSTRUCTIONS
English
Page 4
PARTS REFERENCE
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
When ordering parts, be sure to quote the model number and part numbers.
REF. NO. DESCRIPTION QTY. SPARE PART NO.
1CONTROL STATION 1 12943
2CONNECTOR HOSE 1 11873
3HOSE CLAMP 2 11489
4CELL HOUSING O-RING 2 12947
5CELL HOUSING 1 12945
6TITANIUM ELECTRODE O-RING 1 11585
7TITANIUM ELECTRODE 1 12946
8ELECTROLYTIC CELL NUT 1 11582
9TEST STRIPS 1 19635
PRODUCT SPECIFICATIONS
53
1
6
8
7
2
4
9
Inlet (Connector Hose
to Filter Pump)
Outlet (Hose Returning
Water to Pool)
Model: CS3110
Power: 110 - 120 Volt AC
Amperage: 0.5 A
Wattage: 30 W
Ideal Salt Level: 3000 ppm (parts per million)
Maximum Chlorine Output/hour:4 grams/hour
Filter pump minimum and
maximum flow rate:
300 gallons/hour (1136 liters/hour) /
1000 gallons/hour (3785 liters/hour)
Limited Warranty: see “Limited Warranty”
For pools and filter pumps with 1-¼” (32mm) hose connection fittings.

(133PO) SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2020
133
PO
SAVE THESE INSTRUCTIONS
English
Page 5
SETUP INSTRUCTIONS
1. Assemble the above-ground-pool (AGP) and its filter pump according to their installation
instructions.
2. Take the Saltwater System and its accessories out of the packaging.
3. Place the Saltwater System in line after the filter pump.
4. Connect the connector hose (2) to the Saltwater System inlet with a hose clamp (3).
5. Go directly to step 6 if your pool is empty. If your above-ground-pool is filled with water,
unscrew the strainer grids from the strainer connectors and insert the black hat-like plugs
into the connectors, before installing the saltwater pool system.
6. Disconnect the water return hose from the filter pump connection and connect it to the
Saltwater System outlet.
7. Connect the connector hose (2) to the filter pump outlet connection with a hose clamp (3).
Tighten securely.
8. Remove the black hat-like plugs that prevent water from flowing out of the pool. Now,
return the strainer grids to the strainer connectors.
IMPORTANT
• TheSaltwaterSystemrequiresaseparatefilterpump[300~1000gph(1136~
3785 lph)] to drive the water and function properly.
• TheSaltwaterSystemmustbeinstalledasthelastpieceofpoolequipmentinthe
water return line to the pool as displayed below. This location extends the life of
the titanium plates.
• Removeanylargedebrisandparticlessuchasleaves,sand,insectsandbugs
from the pool water first.
Please visit www.intexdevelopment.com/support/videos for the latest
instructional video on the installation and operation of this product.
FILTER
PUMP
ID 1-1/4” (32mm)
PUMP HOSE
ID 1-1/4” (32mm)
PUMP HOSE
SALTWATER
SYSTEM
SWIMMING POOL
WATER TO
POOL
WATER FROM
POOL
2
ID 1-1/4” (32mm)
CONNECTOR HOSE
3

(133PO) SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2020
133
PO
SAVE THESE INSTRUCTIONS
English
Page 6
SALT & POOL WATER VOLUMES
• Whichkindofsalttouse:
Use only Sodium Chloride Salts
Use only sodium chloride (NaCl) salt that is at least 99.8% pure. It is also acceptable to use
water conditioning salt pellets (the compressed forms of evaporated salt). However, it will take a
longer time for them to dissolve.
Do not use iodized or yellow (yellow prussiate of soda) colored salt.
Salt is added to the pool water and the electrolytic cell uses the salt to create chlorine. The purer
the salt the better the performance of the electrolytic cell.
• OptimumSaltLevels
The ideal salt level in the pool water is between 2500-3500 ppm (parts per million). The optimal
level is 3000 ppm.
A too low salt level will reduce the efficiency of the Saltwater System and result in low chlorine
production. A high salt level may generate a salty taste to the pool water (this may occur at a
salt level above 3500-4000ppm). Too high a salt level may damage the power supply and cause
corrosion to the pool metal fixtures and accessories. The Salt Table page of this manual, shows
the correct dosage of salt needed. The salt in the pool is constantly recycled. The loss of salt is
due only to pool water being physically removed from the pool. Salt is not lost due to evaporation.
• AddingSalt
1. Switch the filter pump on to start the water circulation.
2. Keep the Saltwater System turned off.
3. Determine the amount of salt to be added (see “Salt Table”).
4. Evenly spread the proper amount of salt around the inside perimeter of the pool.
5. Avoid clogging the filter. Do not add salt through the skimmer.
6. Brush the pool bottom to speed up the dissolving process. Do not allow salt to pile up on the
bottom of the pool. Run the filter pump 24 consecutive hours to thoroughly dissolve the salt.
7. After 24 hours and if all the salt is dissolved, turn on the Saltwater System, press button,
code “00” flashing and set the saltwater pool system to desired operating time (see “Operating
Time Table”).
• RemovingSalt
If too much salt has been added, the unit will beep and display “Code 92” (see “Alarm Codes”).
You will need to lower the salt concentration. The only way to do so, is to partially drain the pool
and refill it with fresh water. Drain and refill approximately 20% of the pool’s water until the “Code
92” disappears.
• PoolVolumeCalculation
Rectangular
Length x Width x Average Depth x 7.5 Length x Width x Average Depth
Circular
Length x Width x Average Depth x 5.9 Length x Width x Average Depth x 0.79
Oval
Length x Width x Average Depth x 6.0 Length x Width x Average Depth x 0.80
Types of Pool Gallons
(pool size in feet)
Cubic Meters
(pool size in meters)

(133PO) SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2020
133
PO
SAVE THESE INSTRUCTIONS
English
Page 7
INTEX POOLS SALT TABLE
This table shows the amount of salt needed to achieve and maintain the optimal 3000 ppm salt level.
Pool Size
Water Capacity (Calculated at
90% for Frame Pool and 80%
for Easy Set & Oval Pool)
Salt Needed for
Startup
3.0g/L (3000ppm)
Salt Needed when
Low Salt Detected
(CODE “91”)
(Gals) (Liters) (Lbs) (Kgs) (Lbs) (Kgs)
INTEX ABOVE GROUND POOLS (AGP’s)
EASY SET®
POOL
244cmx61cm (8’x24”) 513 1942 13 6 5 2
244cmx76cm (8'x30") 639 2419 16 7 5 2
305cmx61cm (10’x24”) 813 3077 20 9 7 3
305cmx76cm (10'x30") 1018 3853 25 12 9 4
366cmx76cm (12'x30") 1485 5621 37 17 13 6
396cmx84cm (13'x33") 1926 7290 48 22 17 8
457cmx84cm (15'x33") 2587 9792 65 29 21 10
457cmx107cm (15'x42") 3284 12430 82 37 27 12
457cmx122cm (15'x48") 3736 14141 94 42 31 14
METAL
FRAME
POOL
244cmx51cm (8’x20”) 483 1828 13 6 5 2
305cmx76cm (10'x30") 1185 4485 30 13 9 4
366cmx76cm (12'x30") 1718 6503 43 20 15 7
457cmx122cm (15'x48") 4440 16805 111 50 37 17
PRISM
FRAMETM
POOL
305cmx76cm (10'x30") 1185 4485 30 13 10 5
366cmx76cm (12'x30") 1718 6503 43 20 15 7
366cmx99cm (12'x39") 2270 8592 57 26 19 9
427cmx107cm (14'x42") 3357 12706 84 38 28 13
457cmx107cm (15'x42") 3861 14614 97 44 32 15
457cmx122cm (15'x48") 4440 16805 111 50 37 17
PRISM
FRAMETM
RECT. POOL
300cmx175cmx80cm
(9'10"x5'9"x31½") 935 3539 23 11 7 3
400cmx200cmx100cm
(13'1½"x6'6¾"x39½") 1806 6836 45 21 15 7
400cmx200cmx122cm
(13’1½”x6’6¾”x48”) 2224 8418 56 25 17 8
488cmx244cmx107cm
(16'x8'x42") 2873 10874 72 33 24 11
SMALL RECT.
FRAME POOL
220cmx150cmx60cm
(7'2⅝"x4'11"x23⅝") 439 1662 11 5 3 1
260cmx160cmx65cm
(8'6½"x5'3"x25⅝") 603 2282 16 7 5 2
300cmx200cmx75cm
(9'10"x6'6¾"x29½") 1013 3834 25 12 9 4
450cmx220cmx84cm
(14'9¼"x7'2⅝"x33") 1883 7127 48 22 17 8

(133PO) SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2020
133
PO
SAVE THESE INSTRUCTIONS
English
Page 8
INTEX POOLS CYANURIC ACID TABLE
Pool Size
Water Capacity (Calculated at
90% for Frame Pool and 80%
for Easy Set & Oval Pool)
Cyanuric Acid Needed
for Startup
0.01g/L (10ppm)
(Gals) (Liters) (oz) (g)
INTEX ABOVE GROUND POOLS (AGP’s)
EASY SET®
POOL
244cmx61cm (8’x24”) 513 1942 0.7 19
244cmx76cm (8'x30") 639 2419 0.9 25
305cmx61cm (10’x24”) 813 3077 1.1 31
305cmx76cm (10'x30") 1018 3853 1.4 39
366cmx76cm (12'x30") 1485 5621 2.0 56
396cmx84cm (13'x33") 1926 7290 2.6 73
457cmx84cm (15'x33") 2587 9792 3.5 98
457cmx107cm (15'x42") 3284 12430 4.4 124
457cmx122cm (15'x48") 3736 14141 5.0 141
METAL
FRAME
POOL
244cmx51cm (8’x20”) 483 1828 0.7 19.0
305cmx76cm (10'x30") 1185 4485 1.6 45
366cmx76cm (12'x30") 1718 6503 2.3 65
457cmx122cm (15'x48") 4440 16805 5.9 168
PRISM
FRAMETM
POOL
305cmx76cm (10'x30") 1185 4485 1.6 45
366cmx76cm (12'x30") 1718 6503 2.3 65
366cmx99cm (12'x39") 2270 8592 3.0 86
427cmx107cm (14'x42") 3357 12706 4.5 127
457cmx107cm (15'x42") 3861 14614 5.2 146
457cmx122cm (15'x48") 4440 16805 5.9 168
PRISM
FRAMETM
RECT. POOL
300cmx175cmx80cm
(9'10"x5'9"x31½") 935 3539 1.3 35
400cmx200cmx100cm
(13'1½"x6'6¾"x39½") 1806 6836 2.4 68
400cmx200cmx122cm
(13’1½”x6’6¾”x48”) 2224 8418 2.9 84
488cmx244cmx107cm
(16'x8'x42") 2873 10874 3.8 109
SMALL RECT.
FRAME POOL
220cmx150cmx60cm
(7'2⅝"x4'11"x23⅝") 439 1662 0.6 17
260cmx160cmx65cm
(8'6½"x5'3"x25⅝") 603 2282 0.8 23
300cmx200cmx75cm
(9'10"x6'6¾"x29½") 1013 3834 1.4 39
450cmx220cmx84cm
(14'9¼"x7'2⅝"x33") 1883 7127 2.5 71
Cyanuric acid is a chemical that reduces the loss of chlorine in water due to ultraviolet rays. To maintain the pool water clear
and clean, and to maximize the performance of the device, add cyanuric acid to the pool. We recommend that the cyanuric acid
level be maintained at approximately 0.35% of the salt, i.e. 100 Lbs (45 Kgs) salt x0.35% = 0.35 Lbs (0.16 Kgs) cyanuric acid.
If the pool water is dirty, filthy or grimy, DO NOT add chlorine stabilizer (cyanuric acid) as this will slowdown the sanitation
time of the device. Under this condition you must BOOST your pool water, refer to BOOST cycle steps. Once the pool water
has been restored to clear and clean conditions you may add cyanuric acid.

(133PO) SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2020
133
PO
SAVE THESE INSTRUCTIONS
English
Page 9
INTEX POOLS OPERATING TIME TABLE (WITH CYANURIC ACID)
IMPORTANT
Thefilterpumprunningtimeshouldbe1hourlongerthantherequiredoperatingtimeoftheSaltwaterSystem.
Pool Size
Water Capacity (Calculated at
90% for Frame Pool and 80%
for Easy Set & Oval Pool)
Operating Time (hours)
at different ambient/air
temperatures
Intex Filter
pump
Operating
Time
(hours)
(Gals) (Liters)
10 - 19°C
(50 - 66°F)
20 - 28°C
(68 - 82°F)
29 - 36°C
(84 - 97°F)
INTEX ABOVE GROUND POOLS (AGP’s)
EASY SET®
POOL
244cmx61cm (8’x24”) 513 1942 1 1 1 2
244cmx76cm (8'x30") 639 2419 1 1 1 2
305cmx61cm (10’x24”) 813 3077 1 2 2 3
305cmx76cm (10'x30") 1018 3853 2 2 2 3
366cmx76cm (12'x30") 1485 5621 3 3 3 4
396cmx84cm (13'x33") 1926 7290 3 4 4 5
457cmx84cm (15'x33") 2587 9792 5 5 5 6
457cmx107cm (15'x42") 3284 12430 6 6 7 8
457cmx122cm (15'x48") 3736 14141 7 7 7 8
METAL
FRAME
POOL
244cmx51cm (8’x20”) 483 1828 1 1 1 2
305cmx76cm (10'x30") 1185 4485 2 2 2 3
366cmx76cm (12'x30") 1718 6503 3 3 4 5
457cmx122cm (15'x48") 4440 16805 8 8 8 9
PRISM
FRAMETM
POOL
305cmx76cm (10'x30") 1185 4485 2 2 2 3
366cmx76cm (12'x30") 1718 6503 3 3 4 5
366cmx99cm (12'x39") 2270 8592 4 4 5 6
427cmx107cm (14'x42") 3357 12706 6 6 7 8
457cmx107cm (15'x42") 3861 14614 7 7 8 9
457cmx122cm (15'x48") 4440 16805 8 8 8 9
PRISM
FRAMETM
RECT. POOL
300cmx175cmx80cm
(9'10"x5'9"x31½") 935 3539 1 2 2 3
400cmx200cmx100cm
(13'1½"x6'6¾"x39½") 1806 6836 3 3 4 5
400cmx200cmx122cm
(13’1½”x6’6¾”x48”) 2224 8418 4 4 5 6
488cmx244cmx107cm
(16'x8'x42") 2873 10874 5 5 6 7
SMALL RECT.
FRAME POOL
220cmx150cmx60cm
(7'2⅝"x4'11"x23⅝") 439 1662 1 1 1 2
260cmx160cmx65cm
(8'6½"x5'3"x25⅝") 603 2282 1 1 1 2
300cmx200cmx75cm
(9'10"x6'6¾"x29½") 1013 3834 2 2 2 3
450cmx220cmx84cm
(14'9¼"x7'2⅝"x33") 1883 7127 4 4 4 5

(133PO) SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2020
133
PO
SAVE THESE INSTRUCTIONS
English
Page 10
SALT TABLE FOR COMMON NON-INTEX POOLS
Water Capacity Salt Needed for Startup
Salt Needed when
Low Salt Detected
(CODE “91”)
(Gals) (Liters) (Lbs) (Kgs) (Lbs) (Kgs)
1000 3785 25 11 8 4
1500 5678 38 17 13 6
2000 7570 50 23 17 8
2500 9463 63 28 21 9
3000 11355 75 34 25 11
3500 13248 88 40 29 13
4000 15140 100 45 33 15
4500 17033 113 51 38 17
Salt Needed for Startup
(Lbs)
Salt Needed for Startup
(Kgs)
Salt Needed when
Low Salt Detected (Lbs)
Salt Needed when
Low Salt Detected (Kgs)
Water Capacity (Gals) x 0.025
Water Capacity (Liters) x 0.003 Water Capacity (Gals) x 0.0067 Water Capacity (Liters) x 0.0008
OPERATING TIME TABLE FOR COMMON NON-INTEX POOLS (WITH CYANURIC ACID)
CYANURIC ACID TABLE FOR COMMON NON-INTEX POOLS
Water Capacity Cyanuric Acid Needed for Startup
0.01g/L (10ppm)
(Gals) (Liters) (oz) (g)
1000 3785 1.3 38
1500 5678 2.0 57
2000 7570 2.7 76
2500 9463 3.4 95
3000 11355 4.0 114
3500 13248 4.7 133
4000 15140 5.4 151
4500 17033 6.0 170
SALT CALCULATION FORMULA FOR ALL POOLS
Water Capacity Operating Time (hours) at different ambient/air temperatures Recommend Filter
pump Operating
Time (hours)
(Gals) (Liters) 10 - 19°C (50 - 66°F) 20 - 28°C (68 - 82°F) 29 - 36°C (84 - 97°F)
1000 3785 2 2 2 3
1500 5678 3 3 3 4
2000 7570 4 4 4 5
2500 9463 5 5 5 6
3000 11355 5 6 6 7
3500 13248 6 7 7 8
4000 15140 7 8 8 9
4500 17033 8 8 8 9

(133PO) SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2020
133
PO
SAVE THESE INSTRUCTIONS
English
Page 11
OPERATION INSTRUCTIONS
1. Turn on the filter pump.
2. Start up the unit:
Plug the power cord into the electrical outlet and test the household
socket GFCI (circuit breaker). Press button. Flashing code “00”
appears on the electronic control station’s LED, indicating that the unit
is ready to be programmed.
3. Set operating hours for Saltwater system:
With code “00” flashing, press button to set
the desired operating hours. See the “Operating
Time Table” for the required operating hours
related to each pool size. Pressing will
increase the time from 01 to 12 hours maximum.
If you have selected too many hours keep
pressing to repeat the cycle. The built-in
timer will now activate your Saltwater System, at
the same time each day, for the number of hours you have set.
NOTE: The Saltwater System will not operate if the filter pump is not operating. Make
sure to program your filter pump (or start it manually) for operation beginning 5 minutes
before the saltwater system and finishing 15 minutes after the saltwater system.
4. Lock keypad controls:
With the desired hour value showing, press button. A green
“WORKING” indicator on the control panel will light up within a few
seconds to indicate that the saltwater system has started chlorine
production, the LED will display the remaining chlorinator hours until
it’s finished. Locking the control buttons into this setting prevents
unauthorized changing of the operating cycle.
NOTE: If you forget to lock the keypad controls, the system will
automatically lock it and start working 10 seconds later.
5. Readjust operating time if necessary:
The operating hours can be re-adjusted if necessary. Press button
and the current programmed time will flash. Repeat steps 3 to 4.
6. Stand-by/power saving mode:
•When the cycle ends, the green “SLEEP” indicator on the control
panel lights up and the LED display flashes “93”. The system is now
in Stand-By mode. After a while, it shuts down and sets itself in a
Power Saving mode. The system will automatically turn itself back
on in 24 hours, starting its daily cycle of chlorine production.
•The “SLEEP” indicator stays on, while the system is in the Power
Saving mode. The LED display however, goes blank after 5 minutes.
Press any button ( or ) to view the last LED code.
(01 to 12 hours max per cycle)

(133PO) SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2020
133
PO
SAVE THESE INSTRUCTIONS
English
Page 12
OPERATION INSTRUCTIONS (continued)
Set BOOST operating hours:
1. Press button to unlock the keypad. With LED flashing, press
button to set the desired operating hours. Total of 4 settings:
36 hours, 48 hours, 60 hours and 00 (OFF). Keep pressing
button to repeat the cycle.
2. With the desired hour value showing, press button to lock the
keypad controls. The BOOST indicator will light up when activated.
The system is now starting more chlorine sanitizer production. After the boost procedure
has been completed, the system will automatically switch to the normal working mode.
The LED display will show the remaining BOOST hours first until it’s finished and then
the remaining programmed saltwater system hours.
NOTE: If you forget to lock the keypad controls, the system will automatically lock it and
start working 10 seconds later.
3. To cancel the boost cycle, press button to unlock the keypad, then press button
and reset the hour to “00”.
Set electrode Self-Clean cycle time:
The default self-clean cycle time is 14 hours. To adjust the self-clean
cycle time:
1. Press button to unlock the keypad and the LED display is
flashing. Depending on your pool water calcium hardness level,
press button to select the self-clean cycle time as below.
Total of 3 settings: 14 hours, 10 hours and 06 hours.
NOTE: The life of the cell varies depending on water conditions, pool usage and
operating time of the device. Select 14 hours cycle time to maximize the life of the
electrolytic cell if the calcium hardness level is up to 150 ppm. Manual routine cleaning
and maintenance will further lengthen the life of the electrolytic cell.
2. With the desired self-clean hours showing, press button to lock the keypad controls
and the LED display will return to the normal operating time. The system will reverse the
polarity of the electrode (7) every time according to the selected hours.
NOTE: If you forget to lock the keypad controls, the system will automatically lock it and
start working 10 seconds later.
Calcium Hardness Self-clean cycle time
0 - 150 ppm Reverse polarity every 14 hours
150 - 250 ppm Reverse polarity every 10 hours
250 - 350 ppm Reverse polarity every 06 hours

(133PO) SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2020
133
PO
SAVE THESE INSTRUCTIONS
English
Page 13
LED CODE CHART
IMPORTANT
When Code “90” alarm is shown, ensure the timer of the filter pump is set
one (1) hour longer than the Saltwater System.
If the filter pump does not have a built-in timer, the filter pump needs to
be turned on/off manually every day.
LED Reading Definitions
00 Stand-By Mode (Start-up)
01 Minimum Operating Hour (1 hour remaining)
02 Operating Hours (2 hours remaining)
03 Operating Hours (3 hours remaining)
04 Operating Hours (4 hours remaining)
05 Operating Hours (5 hours remaining)
06 Operating Hours (6 hours remaining)
07 Operating Hours (7 hours remaining)
08 Operating Hours (8 hours remaining)
09 Operating Hours (9 hours remaining)
10 Operating Hours (10 hours remaining)
11 Operating Hours (11 hours remaining)
12 Maximum Operating Hours (12 hours remaining)
36 Boost Mode (36 hours remaining)
48 Boost Mode (48 hours remaining)
60 Boost Mode (60 hours remaining)
90 Alarm Code (Low Pump Flow / No Flow)
91 Alarm Code (Low Salt Level)
92 Alarm Code (High Salt Level)
93 Stand-By Mode (Operating Process finished)
“BLANK” No Power or “Power Saving Mode” waiting to start next
Saltwater System cycle.

(133PO) SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2020
133
PO
SAVE THESE INSTRUCTIONS
English
Page 14
MAINTENANCE
IMPORTANT
Unplug the power cord before cleaning your system. Also insert the black hat-like
plugs in the strainer opening to prevent water spillage. After completing all
maintenance tasks, you must plug the power cord back in and remove the plugs.
Titanium Electrode Cleaning
The titanium electrode has a self cleaning function incorporated into the electronic control’s
programming. In most cases this self cleaning action will keep the electrode working at
optimum efficiency. If the pool water is hard (high mineral content) the electrode may require
periodic manual cleaning. To maintain maximum performance, we recommend that you open
and visually inspect the titanium electrode (7) monthly.
The following steps provide instructions on how to clean your cell.
Inspection and cleaning:
1. Switch off the unit, unplug the power cord from the electrical socket.
2. To prevent water from flowing out of the pool, unscrew the strainer grids from the strainer
connectors and insert the hat-like plugs into the strainer connectors.
3. Disconnect the 2 hoses from the Saltwater System (seedrawings1~3).
4. Unscrew the titanium electrode plug collar, disconnect the plug from the titanium electrode
(7) (see drawing 4).
5. Unscrew the cell nut, remove the titanium electrode from the cell housing (see drawing 5).
6. Place the titanium electrode in a container and pour kitchen grade vinegar into the
container until the titanium electrode is immersed. Soak for 1 hour and then flush with a
high-pressure garden hose (see drawing 6).
7. Reverse steps 3, 4, 5 and 6 to reconnect the electrolytic cell.
1
654
2 3

(133PO) SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2020
133
PO
SAVE THESE INSTRUCTIONS
English
Page 15
MAINTENANCE (continued)
The Test Strips can test the “Free Chlorine”, “pH”, “Calcium Hardness” and “Total Alkalinity”
levels at the same time. We recommend that you test the water chemistry weekly, and maintain
the chlorine concentration at 1.0-3.0 ppm.
Directions and Use
1. Dip the entire strip into the water and remove immediately.
2. Hold the strip level for 15 seconds. Do not shake excess water from the strip.
3. Now compare the strip pad to the color chart on the packaging label. If necessary, adjust the
chemical level in the pool water. It is very important, to use the proper technique when
testing the water's chemical level. Read and follow the written strip instructions carefully.
1. Disconnect the power cord from the electrical outlet.
2. After the pool is completely empty, disconnect the Saltwater System from the hoses by
reversing the installation instructions.
3. Air-dry the unit before you store it. This might be a good time to visually inspect and clean
the electrolytic cell.
4. Store the unit and accessories in a dry place. The temperature should be controlled, between
32 degrees Fahrenheit (0 degrees Celsius) and 97 degrees Fahrenheit (36 degrees Celsius).
5. The original package can be used for storage.
INTEX®TEST STRIPS (PACkED WITH THE PRODUCT)
LONG TERM STORAGE

(133PO) SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2020
133
PO
SAVE THESE INSTRUCTIONS
English
Page 16
POOL MAINTENANCE & CHEMICAL DEFINITIONS
Free Chlorine - Is the chlorine residual present in pool water.
Combined Chlorine - Is formed by the reaction of free chlorine with ammonia wastes.
Result if too high - Sharp chlorinous odor, eye irritation.
pH
- A value that indicates how acidic or basic a solution is.
Result if too low - Corroded metals, eye & skin irritation, destruction
of total alkalinity.
Result if too high - Scale formation, cloudy water, shorter filter runs,
eye & skin irritation, poor chlorine efficiency.
Total Alkalinity - Indicates the degree of the water's resistance to change in pH. It
determines the speed and ease of pH change, so always adjust total
alkalinity before adjusting the pH level.
Result if too low - Corroded metals, eye & skin irritation. Low
alkalinity will cause the pH to be unstable. Any
chemical added to the water will have an affect on
pH.
Result if too high - Scale formation, cloudy water, eye & skin irritation,
poor chlorine efficiency.
Calcium Hardness - Refers to the amount of calcium and magnesium dissolved in the
water.
Result if too high - Eye & skin irritation, difficulty balancing water and
poor chlorine efficiency. Scale will form and will
cause the water to become cloudy.
Stabilizer - Stabilizers extend the life of chlorine in swimming pools.
(Cyanuric Acid)
• Donotaddpoolchemicalsdirectlytotheskimmer.Thismaydamagethecell.
•Maintainingasaltandsanitizerlevelabovetherecommendedrangecancontributetothe
corrosion of the pool equipment.
• Checktheexpirydateofthetestkitasthetestresultsmaybeinaccurateifthekitisused
after that date.
• If,duetoheavypoolusage,itisrequiredtoincreasethesanitizerlevel,thenuseachemical
based on Trichloro-s-triazinetrione or sodium dichloro-s-triazinetrione dihydrate.
Preferred Water Chemistry Reading
Minimum Ideal Maximum
Free Chlorine 0 1.0 - 3.0 ppm 5.0 ppm
Combined Chlorine 0 0 ppm 0.2 ppm
pH 7.2 7.4 - 7.6 7.8
Total Alkalinity 40 ppm 80 ppm 120 ppm
Calcium Hardness 50 ppm 100 - 250 ppm 350 ppm
Stabilizer (Cyanuric Acid) 10 ppm 10 - 30 ppm 30 ppm

(133PO) SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2020
133
PO
SAVE THESE INSTRUCTIONS
English
Page 17
TROUBLESHOOTING GUIDE
INSUFFICIENT
CHLORINE
WHITE FLAKES IN
THE WATER
NO LED DISPLAY
• Insufficient operating hours of
the Saltwater System.
• The salt level in the pool water
is less than 2000ppm. This is
insufficient.
• Chlorine loss due to intense
sunlight exposure.
• The bather load has increased.
• Clogged or dirty electrolytic cell.
• HighUVlevelexposure.
• Excessive calcium hardness is
present in the pool water.
•No power supply.
• HouseholdsocketGFCIhasnot
reseted.
• Apowerfusehasblown.
• LED failure.
• Increase the daily Saltwater System
operating time. See “Operating Instructions”.
• Check the salt level with the Test Kit. Adjust
as needed. See “Salt & Pool Water Volumes”.
•Use a pool cover when the pool is not
in use and/or when the unit is operating.
•Increase the daily Saltwater System
operating time. See “Operating Instructions”.
•Remove the cell for inspection, clean it if
necessary. See “Maintenance”.
•Cover the pool with a pool cover for 2 days
with the device running and then test the
water using the test strips.
•If the pool is clean and clear, add stabilizer
to the water and then test the water with the
device running.
•Drain about 20 to 25% of the pool water
and add fresh water to decrease the
calcium hardness. Inspect the electrolytic
cell for scale buildup. Clean the electrolytic
cell if necessary.
• Find out the switch and turn on.
•Reset the household socket GFCI.
•Contact Intex Service Center.
•Contact Intex Service Center.
PROBLEM CAUSE SOLUTION
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
WARNING: Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.

(133PO) SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2020
133
PO
SAVE THESE INSTRUCTIONS
English
Page 18
TROUBLESHOOTING GUIDE (continued)
IMPORTANT
If you continue to experience difficulty, please contact our Consumer Service Department for
assistance. See separate “Authorized Service Centers” sheet.
1. Filter pump not attached to system
and/or switch on.
2. Circulation line is blocked.
3. Incorrect inlet and outlet hose direction.
4. Scale on flow sensor pins inside the
titanium electrode.
5. Electrode cord is loose.
6. Inner timer conflict between
filter pump and saltwater system.
1. Dirt or scale on titanium plates.
2. Low salt level / No salt.
3. Electrolytic cell cord is loose.
4. Possible electrolytic cell failure.
1. High salt level.
2. Water temperature > 35ºC.
3. Titanium electrode failure.
• Ensure a filter pump with the correct flow
rate is attached and operating. See "Setup
Instruction".
• Remove the black hat-like plugs from the pool
strainer connectors.
• Clear your filter cartridge and cell from debris
and dirt. See “Maintenance”.
• Release all trapped air in the circulation line.
See the filter pump manual.
• Check the direction of the inlet and the outlet
hose. Reverse the hoses if necessary. See “Set
Up Instructions”.
• Clean the titanium electrode. See
“Maintenance” section.
•Plug the cord into the electrode and tighten the
plug collar firmly.
•Reset both timers on the filter pump and
saltwater system. See “Operating Instructions”.
•Remove the electrolytic cell for inspection.
Clean it if necessary. See “Maintenance”.
•Add salt. See “Salt & Pool Water Volumes”.
•Ensure that the cell cord is plugged firmly into
the cell housing receptacle.
•Contact Intex Service Center. Replace the cell
if needed.
•Partially drain the pool and refill it with fresh
water. See “Salt & Pool Water Volumes”.
•Contact Intex Service Center.
•Contact Intex Service Center.
LED PANEL
CODE PROBLEM SOLUTION
LED Panel Code Flash & Alarm On (NOTE: Always turn off the power before cleaning and servicing).

(133PO) SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 07/17/2020
133
PO
SAVE THESE INSTRUCTIONS
English
Page 19
Your Krystal Clear Saltwater System®has been manufactured using the highest
quality materials and workmanship. All Intex products have been inspected and
found free of defects prior to leaving the factory. This Limited Warranty applies only
to the Krystal Clear Saltwater System® and accessories listed below.
The provisions of this Limited Warranty apply only to the original purchaser and is
not transferable. This Limited Warranty is valid for the period noted below from the
date of the initial retail purchase. Keep your original sales receipt with this manual,
as proof of purchase will be required and must accompany warranty claims or the
Limited Warranty is invalid.
Krystal Clear Saltwater System®Warranty – 2 Years
Titanium electrode Warranty – 1 Year
Hoses & Fittings Warranty – 180 days
If a manufacturing defect is found within the periods noted above, please contact the
appropriate Intex Service Center listed in the separate “Authorized Service Centers”
sheet. The Service Center will determine the validity of the claim. If the Service
Center directs you to return the product, please carefully package the product and
send with shipping and insurance prepaid to the Service Center. Upon receipt of the
returned product, the Intex Service Center will inspect the item and determine the
validity of the claim. If the provisions of this warranty cover the item, the item will be
repaired or replaced at no charge.
Any and all disputes regarding the provisions of this Limited Warranty shall be
brought before an informal dispute settlement board and unless and until the
provisions of these paragraphs are carried forth, no civil action may be instituted.
The methods and procedures of this settlement board shall be subject to the rules
and regulations set forth by the Federal Trade Commission (F.T.C.). IMPLIED
WARRANTIES ARE LIMITED TO THE TERMS OF THIS WARRANTY AND IN
NO EVENT SHALL INTEX, THEIR AUTHORIZED AGENTS OR EMPLOYEES
BE LIABLE TO THE BUYER OR ANY OTHER PARTY FOR DIRECT OR
CONSEQUENTIAL DAMAGES OR LIABILITIES. Some states, or jurisdictions do
not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you.
This Limited Warranty does not apply if the products are subject to negligence,
abnormal use or operation, accident, improper operation, improper voltage or current
contrary to operating instructions, or to damage by circumstances beyond Intex’s
control, including but not limited to, ordinary wear and tear and damage caused by
exposure to fire, flood, freezing, rain, or other external environmental forces. This
Limited Warranty applies only to those parts and components sold by Intex. The
Limited Warranty does not cover unauthorized alterations, repairs or disassembly by
anyone other than Intex Service Center personnel.
DO NOT GO BACK TO THE PLACE OF PURCHASE FOR RETURN OR
REPLACEMENT. IF YOU ARE MISSING PARTS OR NEED ASSISTANCE,
PLEASE CALL US TOLL-FREE (FOR U.S. AND CANADIAN RESIDENTS):
1-800-234-6839 OR VISIT OUR WEBSITE: WWW.INTEXCORP.COM.
Proof of Purchase must accompany all returns or the warranty claim will be invalid.
LIMITED WARRANTY
