Intex Krystal Clear 8110 User manual

101
CD
(101CD) MODEL 8110 KRYSTAL CLEAR™ DELUXE SALTWATER SYSTEM (SALT IN POOL) ENGLISH 7.5” X 10.5” PANTONE 295U 12/06/2007
OOWWNNEERR’’SSMMAANNUUAALL
Krystal Clear™ Deluxe
Saltwater System (salt
in pool)
Model 8110
IMPORTANT
SAFETY RULES
Read, Understand, and Follow all
Instructions Carefully before
Installing and using this Product.
IIMMPPOORRTTAANNTT!!
DO NOT RETURN PRODUCT TO STORE
To purchase parts and accessories or to obtain non-technical assistance,
Visit www.intexcorp.com
For technical assistance and missing parts call us toll-free (for U.S. and Canadian Residents):
1-800-234-6839
Monday through Friday, 8:30am to 5:00pm Pacific Time
To find out more about additonal Intex products, please visit our website.
For illustrative purposes only.
101CD-R1-08--
2015-6332
2016-02-09

101
CD
SAVE THESE INSTRUCTIONS Page 2
(101CD) MODEL 8110 KRYSTAL CLEAR™ DELUXE SALTWATER SYSTEM (SALT IN POOL) ENGLISH 7.5” X 10.5” PANTONE 295U 12/06/2007
TTAABBLLEEOOFFCCOONNTTEENNTTSS
Warnings............................................................................... 3-4
Parts List & Reference......................................................... 5-7
Product Information & Specifications................................ 8
Set Up Instructions.............................................................. 9-13
Salt and Pool Water Volumes.............................................. 14
Intex Pools Salt Table........................................................... 15
Intex Pools Operating Time Table....................................... 16
Non-Intex Pools Salt Table................................................... 17
Non-Intex Pools Operating Time Table............................... 17
Operating Instructions......................................................... 18-19
Alarm Codes.......................................................................... 20
LED Code Chart.................................................................... 21
Maintenance.......................................................................... 22-24
Long Term Storage............................................................... 24
INTEX 3-Way Test Strips...................................................... 24
Pool Maintenance and Chemical Definitions..................... 25
Troubleshooting Guide........................................................ 26-27
General Aquatic Safety........................................................ 28
Limited Warranty.................................................................. 29
Pool Safety Sign................................................................... 30
Intex Service Center Locations........................................... 31

101
CD
SAVE THESE INSTRUCTIONS Page 3
(101CD) MODEL 8110 KRYSTAL CLEAR™ DELUXE SALTWATER SYSTEM (SALT IN POOL) ENGLISH 7.5” X 10.5” PANTONE 295U 12/06/2007
SSAAFFEETTYYRRUULLEESS
This product is for use with storable pools only. Do not use with
permanently-installed pools. A storable pool is constructed so that it is capable of
being readily disassembled for storage and reassembled to its original integrity. A
permanently-installed pool is constructed in or on the ground or in a building such
that it cannot be readily disassembled for storage.
CAUTION
WARNING
•To reduce the risk of injury, do not permit children to use this product. Always
supervise children and those with disabilities.
•Risk of electric shock. Connect this product only to a grounding type receptacle
protected by a ground-fault circuit interrupter (GFCI). Contact a qualified electrician
if you cannot verify that the receptacle is protected by a GFCI.
•Do not bury electrical cord. Locate cord where it will not be damaged by lawn
mowers, hedge trimmers, and other equipment.
•To reduce the risk of electric shock, the supply cord cannot be replaced. If the cord
is damaged, the appliance should be replaced immediately.
•To reduce the risk of electric shock, do not use extension cords, timers, plug
adaptors or converter plugs to connect unit to electric supply; provide a properly
located outlet.
•Assembly and disassembly by adults only.
•Do not attempt to plug in or unplug this product while standing in water or when
your hands are wet.
•Do not use an appliance leakage current interrupter (ALCI) in place of a GFCI
since the ALCI will not protect people.
• Position this product away from pool to prevent a child from climbing on product to
access the pool.
•Children must stay away from this product and all electrical cords.
•Do not operate this product when pool is occupied.
•Always unplug this product from the electrical outlet before removing, cleaning,
servicing or making any adjustment to the product.
• This product is intended to be used only for the purposes described in the manual!
FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN
PROPERTY DAMAGE, ELECTRIC SHOCK, ENTANGLEMENT OR
OTHER SERIOUS INJURY OR DEATH.
These product warnings, instructions and safety rules provided with the product represent
some common risks of water recreation devices and do not cover all instances of risk and
danger. Please use common sense and good judgement when enjoying any water activity.
Follow all aspects of the local and National Electrical Code(s) when installing the Krystal
Clear™ Deluxe Saltwater System (salt in pool) Model 8110.
IMPORTANT SAFETY RULES
Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product.
READ AND FOLLOW ALL INSTRUCTIONS
For Portable, Above-The-Ground Pools Only

101
CD
SAVE THESE INSTRUCTIONS Page 4
(101CD) MODEL 8110 KRYSTAL CLEAR™ DELUXE SALTWATER SYSTEM (SALT IN POOL) ENGLISH 7.5” X 10.5” PANTONE 295U 12/06/2007
KRYSTAL CLEAR™ DELUXE SALTWATER SYSTEM
(SALT IN POOL) MODEL 8110
110 – 120 V~, 60 Hz, 2.5 A
THERMALLY PROTECTED
WEATHERPROOF ENCLOSURE
CSA ENCLOSURE 3
DOUBLE INSULATED AND GROUNDED
FOR USE WITH SWIMMING POOLS ONLY.
CAUTION
FOR CONTINUED PROTECTION AGAINST POSSIBLE ELECTRIC SHOCK,
USE ONLY IDENTICAL REPLACEMENT PARTS WHEN SERVICING.
IMPORTANT
READ THE LABEL AND OWNER’S MANUAL BEFORE USING.
KRYSTAL CLEAR™ DELUXE SALTWATER SYSTEM
(SALT IN POOL) MODEL 8110
CONTROLS BACTERIA AND ALGAE in Storable Swimming pool Waters.
Domestic.
A Maximum of 55,000 L (14,530 gal) of water can be treated with one Krystal Clear™ Deluxe
Saltwater System (salt in pool) Model 8110 unit.
Maximum output of hypochlorous acid equivalent to 0.225 kg (0.495 lb) of free available
chlorine per day.
For swimming pools, a minimum of 1 ppm of free available chlorine must be maintained.
READ THE LABEL AND OPERATING MANUAL BEFORE USING.
KEEP OUT OF REACH OF CHILDREN.
REGISTRATION NO. 28190 PEST CONTROL PRODUCTS ACT.
Registrant: Intex Trading (Hong Kong) Ltd., th floor Dah Sing Financial Center, 108
Gloucester Road, Wanchai, Hong Kong
Canadian Agent: The Canadian Group, 430 Signet Drive Suite A, Toronto, Ontario M9L2T6,
Canada 1-800-234-6839 WARNING
Operating Krystal Clear™ Deluxe Saltwater System (salt in pool) Model 8110
without water flow through the cell can cause a build up of flammable gases
which can result in FIRE OR EXPLOSION.
WARNING
RISK OF ELECTRIC SHOCK.
CONNECT ONLY TO GROUNDING TYPE RECEPTACLE PROTECTED BY A CLASS
A GROUND FAULT CIRCUIT INTERRUPTER (GFCI).
LED DEFINITIONS
88 Start-up
90 Low Water Flow / No Flow
91 Low Salt Level
92 High Salt Level
93 Operating Process Finished

101
CD
SAVE THESE INSTRUCTIONS Page 5
(101CD) MODEL 8110 KRYSTAL CLEAR™ DELUXE SALTWATER SYSTEM (SALT IN POOL) ENGLISH 7.5” X 10.5” PANTONE 295U 12/06/2007
PPAARRTTSSLLIISSTT
PARTS LIST
NOTE: Drawings for illustration purpose only. May not reflect actual product. Not to scale.
123
* Optional
* Optional
456
789
10 11 12

101
CD
SAVE THESE INSTRUCTIONS Page 6
(101CD) MODEL 8110 KRYSTAL CLEAR™ DELUXE SALTWATER SYSTEM (SALT IN POOL) ENGLISH 7.5” X 10.5” PANTONE 295U 12/06/2007
PPAARRTTSSRREEFFEERREENNCCEE
PARTS REFERENCE
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
1
2
3
97
5
456 810 11 12
NOTE: Drawings for illustration purpose only. May not reflect actual product. Not to
scale.
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for Class B
digital device, pursuant to part 15 of the FCC Rules.These limits are designed to
provide reasonable protection against harmful interference in a residential
installation.This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.

101
CD
SAVE THESE INSTRUCTIONS Page 7
(101CD) MODEL 8110 KRYSTAL CLEAR™ DELUXE SALTWATER SYSTEM (SALT IN POOL) ENGLISH 7.5” X 10.5” PANTONE 295U 12/06/2007
PPAARRTTSSRREEFFEERREENNCCEE
PARTS REFERENCE (continued)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
REF. NO.
DESCRIPTION QTY. SPARE PART
NO.
COMMON
FOR
CONNECTION
TO FILTER
PUMPS WITH
32MM (1-1/4")
HOSE SIZE
1 ADAPTOR A WITH THREADED COLLAR (OPTIONAL) 110849
2O-RING A 110712
3SCREW 410713
4ELECTROLYTIC CELL (WITH TITANIUM
PLATES) (O-RING A INCLUDED) 110888
5O-RING B 210715
6FLOW SENSOR CONDUIT (O-RING B &
O-RING C INCLUDED) 110887
7FLOW SENSOR 111143
8O-RING C 110717
9SHORT SCREW 210881
10 SCREEN FITTING WITH THREADED COLLAR
(O-RING B INCLUDED) 110719
11 CONNECTOR HOSE WITH THREADED FITTINGS 110720
12 THREADED ADAPTOR B (OPTIONAL) 110722

101
CD
SAVE THESE INSTRUCTIONS Page 8
(101CD) MODEL 8110 KRYSTAL CLEAR™ DELUXE SALTWATER SYSTEM (SALT IN POOL) ENGLISH 7.5” X 10.5” PANTONE 295U 12/06/2007
PPRROODDUUCCTTIINNFFOORRMMAATTIIOONN//SSPPEECCSS
Common salt (sodium chloride) is made up of two elements, sodium and
chloride. During the installation of your Saltwater System, a measured quantity of
salt is dissolved in the pool water to make it slightly salty.This pool water is passed
through the Saltwater System’s electrolytic cell to produce chlorine which is
dissolved instantly in the water.The chlorine instantly starts to destroy bacteria,
algae and oxidizes other organic materials.
HOW THE CHLORINE IS GENERATED
Hose Returning
Water to Pool
Hose from
Filter Pump
Electrolytic Cell
(with Titanium Plates)
Flow Sensor
Cell Housing
Receptacle
Electrolytic Cell
Line Cord
Power Cord
Electronic
Control Station
Key Saltwater System Parts:
• Power Supply
The power supply converts AC electrical current to a low voltage DC current.
This is required by the cell to perform the electrolysis that creates chlorine.
• Electrolytic Cell (with Titanium Plates)
The electrolytic cell contains bipolar titanium electrodes which perform the
electrolysis and produce liquid chlorine when energized with DC electricity.
Chlorine is generated when pool water containing salt passes through the cell.
The chlorine production can be varied by changing the number of hours the
Saltwater System is operating each day.The Saltwater System has a built-in self
cleaning cycle that operates every twenty hours without interrupting chlorine
production.
• Flow Sensor
The flow sensor protects the electrolytic cell and ensures there is adequate
water flowing through the cell.When the water flow drops below minimum flow
rate, the electrolytic cell will automatically shut down to protect the titanium
plates. A safety buzzer will sound and the LED display panel will show a signal
code (see “LED Code Chart”) indicating the problem.
• Electronic Control Station
The electronic control station contains an LED display panel and a set of
pushbuttons to program the Saltwater System operating hours. It also monitors
the different parameters such as salt level, water flow and the electrolytic cell
activity. If any deviation from the norm occurs then a buzzer will sound and
the LED display panel will show a signal code (see “LED Code Chart”) indicating
the problem.
PRODUCT SPECIFICATIONS
Power: 110 - 120 Volt AC
Amperage: 2.5 A
Wattage: 250W
Ideal Salt Level: 3000 ppm (parts per million)
Maximum Chlorine Output/hour: 24 grams/hour
Minimum Flow Rate: 700 ~ 4000 gallons/hour (2650 - 15140 liters/hour)
Limited Warranty: 2 Years (see “Limited Warranty”)
Power Supply

101
CD
SAVE THESE INSTRUCTIONS Page 9
(101CD) MODEL 8110 KRYSTAL CLEAR™ DELUXE SALTWATER SYSTEM (SALT IN POOL) ENGLISH 7.5” X 10.5” PANTONE 295U 12/06/2007
SSEETT--UUPPIINNSSTTRRUUCCTTIIOONNSS
SET-UP INSTRUCTION
32mm (1-1/4”)
HOSE
32mm (1-1/4”)
HOSE
WATER TO
POOL
SWIMMING POOL
SALTWATER SYSTEM
WATER
FROM POOL
FILTER
PUMP
1
11
12
12
11
1. Assemble the above-ground-pool (AGP) and its filter pump per installation
instructions.
2. Remove the Saltwater System and it’s accessories from the packaging.
3. Place the Saltwater System in line after the filter pump.
4. Connect the connector hose (11) to the Saltwater System inlet.
For connection to filter pumps with 32mm (1-1/4”) hose size:
Drawing #1
IMPORTANT
The Saltwater System must be installed as the last piece of pool
equipment in the water return line to the pool as displayed in Drawing #1.
This location extends the life of the titanium plates.

101
CD
SAVE THESE INSTRUCTIONS Page 10
(101CD) MODEL 8110 KRYSTAL CLEAR™ DELUXE SALTWATER SYSTEM (SALT IN POOL) ENGLISH 7.5” X 10.5” PANTONE 295U 12/06/2007
SSEETT--UUPPIINNSSTTRRUUCCTTIIOONNSS
SET-UP INSTRUCTION (continued)
1. If your above-ground-pool is filled up with water, unscrew the strainer grids
from the strainer connectors and insert the black hat-like plugs into the strainer
connectors before saltwater pool system installation. Go to step 2 directly if
your pool is empty.
2. Connect the adaptor A (1) to the electrolytic cell (4) outlet as shown in Drawing
#1.Tighten securely.
3. Disconnect the water return (to the pool) hose from the filter pump connection,
and connect it to the adaptor A (1) on the Saltwater System with a hose clamp.
(see Drawing #1)
4. Connect adaptor B (12) to the connector hose (11).Tighten securely. (see
Drawing #1)
5. Connect adaptor B (12) to filter pump outlet connection (lower connection).
Tighten securely.
6. Return strainer grids to strainer connectors inside pool after removing black
hat-like plugs that prevented water from flowing out of the pool.
11 12
11
12
14
Filter
Pump

101
CD
SAVE THESE INSTRUCTIONS Page 11
(101CD) MODEL 8110 KRYSTAL CLEAR™ DELUXE SALTWATER SYSTEM (SALT IN POOL) ENGLISH 7.5” X 10.5” PANTONE 295U 12/06/2007
SSEETT--UUPPIINNSSTTRRUUCCTTIIOONNSS
SET-UP INSTRUCTION (continued)
For connection to filter pumps with 38mm (1-1/2”) hose size:
(Do not use adapter A (1) or B (12))
Drawing #2
11
FILTER
PUMP
38mm (1-1/2”) HOSE 38mm (1-1/2”) HOSE
SALTWATER
SYSTEM
SWIMMING POOL
WATER TO
POOL
PLUNGER
VALVE
WATER FROM
POOL
1. If your above-ground-pool is filled with water, close the plunger valves before
Saltwater System installation. Go to step 2 directly if your pool is empty.
2. Disconnect the water return (to the pool) hose from the filter pump connection,
and connect it to the Saltwater System outlet.
3. Connect the connector hose (11) to the filter pump outlet connection.
4. Open plunger valves to allow water to flow.

101
CD
SAVE THESE INSTRUCTIONS Page 12
(101CD) MODEL 8110 KRYSTAL CLEAR™ DELUXE SALTWATER SYSTEM (SALT IN POOL) ENGLISH 7.5” X 10.5” PANTONE 295U 12/06/2007
SSEETT--UUPPIINNSSTTRRUUCCTTIIOONNSS
SET-UP INSTRUCTION (continued)
For connection to other filter pump (with different type of thread or no
thread):
Saltwater System can also adapt to other filter pumps for those with different thread
or without thread on the connection.
• Connect to 32mm (1-1/4”) filter pump outlet connection:
1. Connect adaptor B (12) to the connector hose (11).Tighten securely.
2. Connect adaptor B (12) to filter pump outlet connection.Tighten securely.
•Connect to 38mm (1-1/2”) filter pump outlet connection:
1. Connect the connector hose (11) to the filter pump outlet connection with a
large hose clamp.Tighten securely.
11 12
32mm (1-1/4”)
CONNECTION
SALTWATER SYSTEM
FILTER PUMP
11 LARGE HOSE
CLAMP
FILTER PUMP
38mm (1-1/2”)
CONNECTION
SALTWATER SYSTEM

101
CD
SAVE THESE INSTRUCTIONS Page 13
(101CD) MODEL 8110 KRYSTAL CLEAR™ DELUXE SALTWATER SYSTEM (SALT IN POOL) ENGLISH 7.5” X 10.5” PANTONE 295U 12/06/2007
SSEETT--UUPPIINNSSTTRRUUCCTTIIOONNSS
SET-UP INSTRUCTION (continued)
•Connect to 32mm (1-1/4”) hose:
1. Connect the adaptor A (1) to the electrolytic cell (4) outlet.Tighten securely.
2. Connect the water return (to the pool) hose to the adaptor A (1) on the
Saltwater System with a hose clamp.
•Connect to 38mm (1-1/2”) hose:
1. Connect the adaptor A (1) to the electrolytic cell (4) outlet.Tighten securely.
2. Connect the water return (to the pool) hose to the adaptor A (1) on the
Saltwater System with a large hose clamp.
1
HOSE CLAMP
32mm (1-1/4”)
HOSE SALTWATER SYSTEM
1
LARGE HOSE CLAMP
38mm (1-1/2”)
HOSE SALTWATER SYSTEM

101
CD
SAVE THESE INSTRUCTIONS Page 14
(101CD) MODEL 8110 KRYSTAL CLEAR™ DELUXE SALTWATER SYSTEM (SALT IN POOL) ENGLISH 7.5” X 10.5” PANTONE 295U 12/06/2007
SSAALLTT&&PPOOOOLLWWAATTEERRVVOOLLUUMMEESS
SALT & POOL WATER VOLUMES
Use only Sodium Chloride Salts
Use only sodium chloride (NaCl) salt that is at least 99.8% pure. It is also
acceptable to use water conditioning salt pellets (the compressed forms of
evaporated salt), but it will take longer time for them to dissolve. Do not use
iodized or yellow (yellow prussiate of soda) colored salt. Salt is added to the
pool water and the electrolytic cell uses this salt to create chlorine, the purer the
salt the better the performance of the electrolytic cell.
Optimum Salt Levels
The ideal salt level in the pool water is between 2500-3500 ppm (parts per million)
with 3000 ppm being optimal.
A too low salt level will reduce the efficiency of the Saltwater System and result in
low chlorine production. A high salt level may begin to generate a salty taste to your
pool water (this may occur at a salt level above 3500-4000 ppm).Too high of a salt
level may damage the power supply and cause corrosion to pool metal fixtures and
accessories.The following “salt table” shows the quantity of salt to use.The salt in
the pool is constantly recycled. Salt loss is due only to pool water physically
removed from the pool. Salt is not lost due to evaporation.
How to Add or Remove Salt
Adding Salt
1. Depress the ON button on the filter pump switch to circulate pool water.
2. Keep the Saltwater System “OFF”.
3. Determine the amount of salt to be added (see “Salt Table”).
4. Evenly spread the proper amount of salt around the inside perimeter of the
pool.
5. To avoid clogging the filter, do not add salt through the skimmer.
6. Brush the pool bottom to speed up the dissolving process. Do not allow salt to
pile up on the bottom of the pool. Run the filter pump 24 consecutive hours to
thoroughly dissolve the salt.
7. After 24 hours and if all the salt is dissolved, turn on the Saltwater System and
set the saltwater pool system to desired operating time (see “Operating Time
Table”).
Removing Salt
If too much salt has been added, the unit will beep and display “code 92” (see
“Alarm Codes”).You need to lower the salt concentration.The only way to lower the
salt concentration is to partially drain the pool and refill with fresh water. Drain and
refill approximately 20% of the pool’s water until the “Code 92” disappears.
Pool Volume Calculation
Rectangular Length x Width x Average Depth x 7.5 Length x Width x Average Depth
Circular Length x Width x Average Depth x 5.9 Length x Width x Average Depth x 0.79
Oval Length x Width x Average Depth x 6.0 Length x Width x Average Depth x 0.80
Types of Pool Gallons
(pool size in feet) Cubic Meters
(pool size in meters)

101
CD
SAVE THESE INSTRUCTIONS Page 15
(101CD) MODEL 8110 KRYSTAL CLEAR™ DELUXE SALTWATER SYSTEM (SALT IN POOL) ENGLISH 7.5” X 10.5” PANTONE 295U 12/06/2007
INTEX POOLS SALT TABLE
This table shows how much salt to use to achieve the desired 3000 ppm salt level and how much
will be needed to maintain this level if it drops below this desired level.
Pool Size
Water Capacity ( Calculated at
90% for Frame Pool and 80%
for Easy Set & Oval Pool)
Salt Needed for
Startup
3.0g/L (3000 ppm)
Salt Needed when
Low Salt Detected
(CODE “91”)
(Gals) (Liters) (Lbs) (Kgs) (Lbs) (Kgs)
INTEX ABOVE GROUND POOLS (AGP’s)
EASY SET®
POOL
CIRCULAR
METAL
FRAME POOL
ULTRA FRAME
POOL
SEQUOIA SPIRIT™
POOL SET
OVAL FRAME
POOL
RECT. ULTRA
FRAME POOL
457cm x 91cm (15' x 36")
457cm x 107cm (15' x 42")
457cm x 122cm (15' x 48")
488cm x 107cm (16' x 42")
488cm x 122cm (16' x 48")
549cm x 107cm (18' x 42")
549cm x 122cm (18' x 48")
549cm x 132cm (18' x 52")
457cm x 91cm (15' x 36")
457cm x 107cm (15' x 42")
457cm x 122cm (15' x 48")
488cm x 122cm (16' x 48")
488cm x 132cm (16' x 52")
549cm x 122cm (18' x 48")
549cm x 132cm (18' x 52")
732cm x 122cm (24' x 48")
732cm x 132cm (24' x 52")
488cm x 122cm (16' x 48")
549cm x 132cm (18' x 52")
508cm x 124cm (16'8" x 49")
549cm x 135cm (18'8" x 53")
549cm x 305cm x 107cm (18' x 10' x 42")
610cm x 366cm x 122cm (20' x 12' x 48")
732cm x 366cm x 122cm (24' x 12' x 48")
853cm x 366cm x 122cm (28' x 12' x 48")
549cm x 274cm x 132cm (18' x 9' x 52")
732cm x 366cm x 132cm (24' x 12' x 52")
975cm x 488cm x 132cm (32' x 16' x 52")
2822 10681 65 30 20 10
3284 12430 80 35 20 10
3736 14141 95 45 20 10
3754 14209 95 45 20 10
4273 16173 110 50 30 15
4786 18115 120 55 30 15
5455 20647 135 60 30 15
5894 22309 150 65 40 20
3282 12422 80 35 20 10
3861 14614 100 45 20 10
4440 16805 110 50 30 15
5061 19156 125 55 30 15
5501 20821 135 60 30 15
6423 24311 160 75 40 20
6981 26423 175 80 40 20
11483 43462 290 130 75 35
12481 47241 310 140 85 40
5061 19156 125 55 30 15
6981 26423 175 80 40 20
5061 19156 125 55 30 15
6981 26423 175 80 40 20
2885 10920 75 35 20 10
4393 16628 110 50 30 15
5407 20465 132 60 35 15
6420 24300 150 70 40 20
4545 17203 115 50 30 15
8403 31805 210 95 60 30
14364 54368 365 165 95 45

101
CD
SAVE THESE INSTRUCTIONS Page 16
(101CD) MODEL 8110 KRYSTAL CLEAR™ DELUXE SALTWATER SYSTEM (SALT IN POOL) ENGLISH 7.5” X 10.5” PANTONE 295U 12/06/2007
INTEX POOLS OPERATING TIME TABLE
This table shows the operating time required for normal use of the Saltwater System with AGP’s.
Pool Size
Water Capacity ( Calculated at
90% for Frame Pool and 80%
for Easy Set & Oval Pool)
Operating Time (hours)
at different ambient/air
temperatures
(Gals) (Liters)
10 - 19°C
(50 - 66°F) 20 - 28°C
(68 - 82°F) 29 - 36°C (84 - 97°F) 37- 42°C (99 - 108°F)
INTEX ABOVE GROUND POOLS (AGP’s)
EASY SET®
POOL
CIRCULAR
METAL
FRAME POOL
ULTRA FRAME
POOL
SEQUOIA SPIRIT™
POOL SET
OVAL FRAME
POOL
RECT. ULTRA
FRAME POOL
457cm x 91cm (15' x 36")
457cm x 107cm (15' x 42")
457cm x 122cm (15' x 48")
488cm x 107cm (16' x 42")
488cm x 122cm (16' x 48")
549cm x 107cm (18' x 42")
549cm x 122cm (18' x 48")
549cm x 132cm (18' x 52")
457cm x 91cm (15' x 36")
457cm x 107cm (15' x 42")
457cm x 122cm (15' x 48")
488cm x 122cm (16' x 48")
488cm x 132cm (16' x 52")
549cm x 122cm (18' x 48")
549cm x 132cm (18' x 52")
732cm x 122cm (24' x 48")
732cm x 132cm (24' x 52")
488cm x 122cm (16' x 48")
549cm x 132cm (18' x 52")
508cm x 124cm (16'8" x 49")
549cm x 135cm (18'8" x 53")
549cm x 305cm x 107cm (18' x 10' x 42")
610cm x 366cm x 122cm (20' x 12' x 48")
610cm x 366cm x 132cm (20' x 12' x 52")
732cm x 366cm x 122cm (24' x 12' x 48")
732cm x 366cm x 132cm (24' x 12' x 52")
853cm x 366cm x 122cm (28' x 12' x 48")
853cm x 366cm x 132cm (28' x 12' x 52")
975cm x 366cm x 122cm (32' x 12' x 48")
1,219cm x 366cm x 122cm (40' x 12' x 48")
549cm x 274cm x 132cm (18' x 9' x 52")
732cm x 366cm x 122cm (24' x 12' x 48")
732cm x 366cm x 132cm (24' x 12' x 52")
975cm x 488cm x 132cm (32' x 16' x 52")
2822
3284
3736
3754
4273
4786
5455
5894
3282
3861
4440
5061
5501
6423
6981
11483
12481
5061
6981
5061
6981
2885
4393
4738
5407
5832
6420
6925
7434
9461
4545
7757
8403
14364
10681
12430
14141
14209
16173
18115
20647
22309
12422
14614
16805
19156
20821
24311
26423
43462
47241
19156
26423
19156
26423
10920
16628
17935
20465
22073
24300
26211
28137
35809
17203
29359
31805
54368
1
1
2
2
2
3
3
3
1
2
3
3
3
4
4
7
8
3
4
3
4
1
2
3
3
3
4
4
5
6
3
5
5
9
3
3
3
3
3
4
4
5
3
3
3
4
4
5
5
9
10
4
5
4
5
3
4
4
4
5
5
5
6
8
4
6
6
11
3
3
3
3
3
5
5
6
3
3
3
5
5
6
6
10
11
5
6
5
6
3
5
5
5
6
6
6
7
9
5
7
7
12
3
3
3
3
4
6
6
7
3
3
4
6
6
7
7
11
12
6
7
6
7
3
6
6
6
7
7
7
8
10
6
8
8
12

101
CD
SAVE THESE INSTRUCTIONS Page 17
(101CD) MODEL 8110 KRYSTAL CLEAR™ DELUXE SALTWATER SYSTEM (SALT IN POOL) ENGLISH 7.5” X 10.5” PANTONE 295U 12/06/2007
NON INTEX POOLS SALT TABLE
NON INTEX POOLS OPERATING TIME TABLE
SALT CALCULATION FOR POOLS
Water Capacity ( Calculated at 90% for
Frame Pool and 80% for Easy Set &
Oval Pool)
Salt Needed for Startup Salt Needed when Low Salt Detected
(CODE “91”)
(Gals) (Liters) (Lbs) (Kgs) (Lbs) (Kgs)
2000 7500 50 20 10 5
4000 15000 100 45 25 10
6000 22500 150 65 40 20
8000 30000 200 90 55 25
10000 37500 250 110 70 30
12000 45500 300 135 80 35
14000 53000 350 160 95 45
Water Capacity Operating Time (hours)
at different ambient/air temperatures
(Gals) (Liters) 10 - 19°C
(50 - 66°F) 20 - 28°C
(68 - 82°F) 29 - 36°C (84 - 97°F) 37 - 42°C (99 - 108°F)
2000
4000
6000
8000
10000
12000
14000
7500
15000
22500
30000
37500
45500
53000
2
3
5
6
8
10
11
2
3
6
7
9
11
12
3
3
7
8
10
12
12
Salt Needed for Startup
(Lbs) Salt Needed for Startup (Kgs) Salt Needed when Low Salt Detected (Lbs) Salt Needed when Low Salt Detected (Kgs)
Water Capacity (Gals) x
0.025 Water Capacity (Liters) x 0.003 Water Capacity (Gals) x 0.0067 Water Capacity (Liters) x 0.0008
1
2
4
5
6
9
10

101
CD
SAVE THESE INSTRUCTIONS Page 18
(101CD) MODEL 8110 KRYSTAL CLEAR™ DELUXE SALTWATER SYSTEM (SALT IN POOL) ENGLISH 7.5” X 10.5” PANTONE 295U 12/06/2007
OPERATION INSTRUCTIONS
OOPPEERRAATTIINNGGIINNSSTTRRUUCCTTIIOONNSS
After the salt is dissolved, but before starting the Saltwater System be sure
that:
•The entire filtering and chlorinating system is connected to a grounding type
receptacle protected by a ground-fault circuit interrupter (GFCI).
•The filter pump operates several minutes before starting the Saltwater System
(This removes air pockets and debris in the water hoses).
•No air is trapped in any of the hoses (Follow the Filter Pump Owner’s manual
to release any trapped air).
1. Plug the power cord into the electrical outlet. Switch on the
unit. Code “88” appears on the electronic control station’s
LED indicating the unit is in a Stand-By Mode, this is normal.
2. Unlock keypad controls:
Press and hold button for 2 seconds until you hear a
short “beep”, then press and hold button for another 2
seconds until you hear the second short “beep”, LED flashes
“00”.This procedure unlocks the keypad control buttons.
3. Set Saltwater System operating hours:
Increase the scheduled number of hours of
operation by pressing button, or reduce
by pressing button. See “Operating Time
Table” for pool size and required operating
hours. Press button to select hours
required, press if too many hours were
selected.The built-in timer will now operate
for the number of hours selected at the
same time each day.
NOTE: The Saltwater System will not operate if the filter pump is not operating.
4. Re-lock keypad controls:
With the proper hour value showing, press and hold button
for 2 seconds until you hear a long “beep”, then press
and hold button for another 2 seconds until you hear the
second long “beep”. A green LED light on the control panel will
light up within a few minutes, which indicates the saltwater
system starting chlorine production.With locking the control
buttons into this setting you will have prevented unauthorized
changing of the operating cycle.
NOTE: If you forget to Re-lock the keypad controls, the salt system will
automatically lock the keypad controls and start working 1 minute later.
(1 to 12 hours max per cycle)

101
CD
SAVE THESE INSTRUCTIONS Page 19
(101CD) MODEL 8110 KRYSTAL CLEAR™ DELUXE SALTWATER SYSTEM (SALT IN POOL) ENGLISH 7.5” X 10.5” PANTONE 295U 12/06/2007
OPERATION INSTRUCTIONS (continued)
OOPPEERRAATTIINNGGIINNSSTTRRUUCCTTIIOONNSS
5. Operating hours can be re-adjusted if necessary. Follow steps 2 thru 4.
6. The scheduled operating hours displayed on the LED readout will decrease to
zero as the unit operates.The LED shows “hours remaining” in the daily
operating cycle.
7. The green LED light on the control panel will disappear when
the cycle has ended.The system will go into a “Stand-By
Mode” with the LED flashing “93”.The system automatically
goes into a “Power Saving Mode” and will automatically turn
itself back on in 24 hours to continue its daily chlorine
production.
8. The LED will be become blank after 1 hour indicating the
Saltwater System is dormant (Power Saving Mode) waiting for
the next startup cycle to begin. Press any button ( or )
to view the last LED code.
SPECIAL NOTES
•Always use a test strip to test the chlorine level before entering or using the
pool. If the chlorine level is too high, wait until the chlorine level drops
below 3 ppm before using the pool or operating the Saltwater System
again.
• IMPORTANT: Never use the pool if chlorine level is more than 3 ppm. Do
not operate Saltwater System while the pool is in use or occupied.
•If a power outage occurs or the power cord is unplugged then the Saltwater
System operating hours will have to be reset.
Heavy pool usage, and higher temperatures may require higher chlorine output to
maintain proper free available chlorine residuals.
WARNING

101
CD
SAVE THESE INSTRUCTIONS Page 20
(101CD) MODEL 8110 KRYSTAL CLEAR™ DELUXE SALTWATER SYSTEM (SALT IN POOL) ENGLISH 7.5” X 10.5” PANTONE 295U 12/06/2007
ALARM CODES
No chlorine production will occur if “Low Water Flow”, “Low Salt Level” or “High Salt
Level” are detected. If any of these conditions occur then the Saltwater System will
sound an alarm that indicates chlorine production has stopped. A buzzer will sound
and a Code (see below) will keep flashing on the LED for 1 hour.The buzzer and
flashing light will end after one hour and the Saltwater System will go to Power
Saving Mode. If this occurs then press any button ( or ) to view the code of
the original problem so that it can be corrected.
Turn off the power of the unit and follow the solutions below to solve the problem.
Turn on the unit again by following the “Operating Instructions”.
AALLAARRMMSS
Code Cause Remedy Flashing Buzzer
1.Circulation line
blocked.
2.Incorrect inlet and
outlet hose
direction.
3.Scale on the flow
sensor.
4.Flow sensor cord
is loose.
5.Flow sensor failure.
1.Dirt or scale on
titanium plates.
2.Low salt level / No
salt.
3.Possible electrolytic
cell failure.
1.High salt level.
• Ensure the plunger valves are
opened (if any).
• Ensure your filter cartridge, cell
are clear from debris and dirt. See
“Maintenance”.
• Release all trapped air in the
circulation line. See Filter Pump
Manual.
• Check for the direction of water
inlet and water outlet hose. Reverse
the hoses if necessary. See “Set
Up Instructions”.
• Ensure the flow sensor (especially
the hinge) is clean. See
“Maintenance”.
• Check for flow sensor loose or not
connected properly. Plug the flow
sensor firmly into the flow sensor
receptacle.
• Contact Intex Service Center for
replacement.
• Remove the electrolytic cell for
inspection and clean it if necessary.
See “Maintenance”.
• Add salt. See “Salt & Pool Water
Volumes”.
• Contact Intex Service Center.
Replace the cell if needed.
• Partially drain the pool and refill
with fresh water. See “Salt & Pool
Water Volumes”.
Low
Water
Flow or
No Flow
Low Salt
Level
High Salt
Level
Yes
Yes
Yes
Yes
Yes
Yes
•The expected life expectancy of the electrolytic cell is 3,000 hours under normal
use conditions.
•When replacing the cell, only use replacement cells having a label that clearly
states that it is a replacement cell for the Krystal Clear™ Deluxe Saltwater
System (salt in pool) Model 8110.
