OWNER’S MANUAL
Krystal Clear™ Saltwater System
Certified Model Number CS2110
IMPORTANT
SAFETY RULES
Read, understand, and follow
all instructions carefully before
installing and using this product.
Don’t forget to try these other fine Intex products: Pools, Pool
Accessories, Inflatable Pools and In-Home Toys, Airbeds and
Boats available at fine retailers or visit our website listed below.
Due to a policy of continuous product improvement, Intex
reserves the right to change specifications and appearance,
which may result in updates to the instruction manual without
notice.
For illustrative purposes only.
IMPORTANT!
DO NOT RETURN PRODUCT TO STORE
To purchase parts and accessories or to obtain non-technical assistance, Visit
www.intexcorp.com
For technical assistance, missing parts or warranty claims call (for U.S. and Canadian Residents):
1-310-549-8235
Monday through Friday, 8:30am to 5:00pm Pacific Time
130-*PO-R0-2205

(130PO) MINI SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 05/31/2021
130
PO
SAVE THESE INSTRUCTIONS
English
Page 2
Warnings............................................................................... 3
Parts References................................................................... 4
Product Specifications......................................................... 4
Setup Instructions................................................................ 5
Salt & Pool Water Volumes...................................................6
Intex Pools Salt Table........................................................... 7
Intex Pools Cyanuric Acid Table..........................................8
Intex Pools Operating Time Table........................................9
Non-Intex Pools Salt Table................................................... 10
Non-Intex Pools Cyanuric Acid Table................................. 10
Non-Intex Pools Operating Time Table................................10
Operating Instructions......................................................... 11
LED Code Chart.................................................................... 12
Maintenance.......................................................................... 12-13
Long Term Storage............................................................... 13
Pool Maintenance and Chemical Definitions..................... 14
Troubleshooting Guide........................................................ 15-16
Limited Warranty................................................................... 17
TABLE OF CONTENTS

(130PO) MINI SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 05/31/2021
130
PO
SAVE THESE INSTRUCTIONS
English
Page 3
WARNING
• This Saltwater System is designed only to produce sodium hypochlorite. It does not monitor or control
sodium hypochlorite levels in the pool. It is the pool ownerʼs responsibility for monitoring and maintaining
free chlorine levels in the recommended range of 1.0 to 3.0 parts per million (ppm). It is the pool ownerʼs
responsibility to check, on a regular basis, the free chlorine level while the pool pump is running and
adjust the Saltwater System accordingly.
• For Outdoor use only.
• Not to energize or operate the unit if the cell housing is damaged or improperly assembled.
• To reduce the risk of injury, do not permit children to use this product. Always supervise children and
those with disabilities.
• Children must stay away from this product and all electrical cords.
• Assembly and disassembly by adults only.
• Risk of electric shock. Connect only to a grounding type receptacle, this product is provided with
a ground-fault circuit interrupter. If replacement of the plug or cord is needed, use only identical
replacement parts.
• Always unplug this product from the electrical outlet before removing, cleaning, servicing or making any
adjustment to the product.
• The unit is provided with a ground-fault circuit interrupter (GFCI). To test the GFCI, push the test button.
the GFCI should interrupt power. push the reset button, power should be restored. If the GFCI fails
to operate in this manner. the GFCI is defective. If the GFCI interrupts power to the pump without the
test button being pushed, a ground current is flowing, indicating the possibility of an electric shock.
Do not use this pump. Disconnect the pump and have the problem corrected by a qualified service
representative before using.
• Do not bury the electrical cord. Locate the cord where it will not be damaged by lawn mowers, hedge
trimmers and other equipment.
• To reduce the risk of electric shock, the supply cord cannot be replaced. If the cord is damaged, the
appliance should be replaced immediately.
• To reduce the risk of electric shock, do not use extension cords, timers, plug adaptors or converter plugs
to connect unit to electric supply; provide a properly located outlet.
• Do not attempt to plug in or unplug this product while standing in water or when your hands are wet.
• Do not use an appliance leakage current interrupter (ALCI) in place of a GFCI since the ALCI will not
protect people.
• Position this product away from the pool, so as to prevent children from climbing on it and accessing the
pool.
• Make sure the electrical parameters indicated on the product correspond to the local mains voltage
before you connect the unit.
• This product is intended to be used only for the purposes described in the manual!
FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN PROPERTY
DAMAGE, ELECTRIC SHOCK, ENTANGLEMENT OR OTHER SERIOUS INJURY
OR DEATH.
IMPORTANT SAFETY RULES
Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product.
READ AND FOLLOW ALL INSTRUCTIONS
For portable Above-Ground-Pools only
This product is for use with storable pools only. Do not use with permanently-installed pools. A storable
pool is constructed so that it is capable of being readily disassembled for storage and reassembled to its
original integrity. A permanently-installed pool is constructed in or on the ground or in a building such that
it cannot be readily disassembled for storage.
To reduce the risk of electric shock the pool must be installed no closer than 6 feet (1.8 m) from any
electrical outlet. Do not place portable appliances closer than 5 feet (1.5 m) from the pool.
These product warnings, instructions and safety rules provided with the product represent some common risks of
water recreation devices and do not cover all instances of risk and danger. Please use common sense and good
judgement when enjoying any water activity.
CAUTION

(130PO) MINI SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 05/31/2021
130
PO
SAVE THESE INSTRUCTIONS
English
Page 4
PARTS REFERENCE
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
When ordering parts, be sure to quote the model number and part numbers.
REF. NO. DESCRIPTION QTY. SPARE PART NO.
1 CONTROL STATION 1 13091EG
2 CONNECTOR HOSE 1 11873
3 HOSE CLAMP 2 11489
4 CELL HOUSING O-RING 2 12947
5 CELL HOUSING 1 13088
6 TITANIUM ELECTRODE O-RING 1 13094
7 TITANIUM ELECTRODE 1 13093
8 ELECTROLYTIC CELL NUT 1 13095
9 TEST STRIPS 1 19635
53
1
6
8
7
24
9
PRODUCT SPECIFICATIONS
Certifi ed Model Number: CS2110
Power: 110 - 120 Volt AC
Amperage: 0.3 A
Wattage: 20 W
Ideal Salt Level: 3000 ppm (parts per million)
Maximum sodium hypochlorite output/
hour: 2 grams/hour
Filter pump minimum and
maximum flow rate:
300 gallons/hour (1136 liters/hour) /
1000 gallons/hour (3785 liters/hour)
Limited Warranty: see “Limited Warranty”
For pools and filter pumps with 1-¼” (32mm) hose connection fittings.
Outlet (Hose Returning
Water to Pool)
Inlet (Connector Hose
to Filter Pump)

(130PO) MINI SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 05/31/2021
130
PO
SAVE THESE INSTRUCTIONS
English
Page 5
SETUP INSTRUCTIONS
1. Assemble the above-ground-pool (AGP) and its filter pump according to their installation
instructions.
2. Take the Saltwater System and its accessories out of the packaging.
3. Place the Saltwater System in line after the filter pump.
4. Connect the connector hose (2) to the Saltwater System inlet with a hose clamp (3).
5. Go directly to step 6 if your pool is empty. If your above-ground-pool is filled with water,
unscrew the strainer grids from the strainer connectors and insert the black hat-like plugs
into the connectors, before installing the saltwater pool system.
6. Disconnect the water return hose from the filter pump connection and connect it to the
Saltwater System outlet.
7. Connect the connector hose (2) to the filter pump outlet connection with a hose clamp (3).
Tighten securely.
8. Remove the black hat-like plugs that prevent water from flowing out of the pool. Now,
return the strainer grids to the strainer connectors.
IMPORTANT
• The Saltwater System requires a separate filter pump [300~1000 gph
(1136~3785 lph)] to drive the water and function properly.
• The Saltwater System must be installed as the last piece of pool equipment in
the water return line to the pool as displayed below. This location extends the
life of the titanium plates.
• Remove any large debris and particles such as leaves, sand, insects and bugs
from the pool water first.
Please visit www.intexdevelopment.com/support/videos for the latest
instructional video on the installation and operation of this product.
FILTER
PUMP
ID 1-1/4” (32mm)
PUMP HOSE
ID 1-1/4” (32mm)
PUMP HOSE
SALTWATER
SYSTEM
SWIMMING POOL
WATER TO
POOL
WATER FROM
POOL
2
ID 1-1/4” (32mm)
CONNECTOR HOSE
3

(130PO) MINI SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 05/31/2021
130
PO
SAVE THESE INSTRUCTIONS
English
Page 6
SALT & POOL WATER VOLUMES
• Which kind of salt to use:
Use only Sodium Chloride Salts
Use only sodium chloride (NaCl) salt that is at least 99.8% pure. It is also acceptable to use
water conditioning salt pellets (the compressed forms of evaporated salt). However, it will take a
longer time for them to dissolve.
Do not use iodized or yellow (yellow prussiate of soda) colored salt.
Salt is added to the pool water and the electrolytic cell uses the salt to create sodium
hypochlorite. The purer the salt the better the performance of the electrolytic cell.
• Optimum Salt Levels
The ideal salt level in the pool water is between 2500-3500 ppm (parts per million). The optimal
level is 3000 ppm.
A too low salt level will reduce the efficiency of the Saltwater System and result in low sodium
hypochlorite production. A high salt level may generate a salty taste to the pool water (this may
occur at a salt level above 3500-4000ppm). Too high salt level may damage the power supply
and cause corrosion to the pool metal fixtures and accessories. The Salt Table page of this
manual shows the correct dosage of salt needed.
• Adding Salt
1. Switch the filter pump on to start the water circulation.
2. Keep the Saltwater System turned off.
3. Determine the amount of salt to be added (see “Salt Table”).
4. Evenly spread the proper amount of salt around the inside perimeter of the pool.
5. Avoid clogging the filter. Do not add salt through the skimmer.
6. Brush the pool bottom to speed up the dissolving process. Do not allow salt to pile up on the
bottom of the pool. Run the filter pump 24 consecutive hours to thoroughly dissolve the salt.
7. After 24 hours and if all the salt is dissolved, turn on the Saltwater System, press button,
code “00” flashing and set the saltwater pool system to desired operating time (see “Operating
Time Table”).
• Removing Salt
If too much salt has been added, the unit will beep and display “Code 92” (see “Alarm Codes”).
You will need to lower the salt concentration. The only way to do so, is to partially drain the pool
and refill it with fresh water. Drain and refill approximately 20% of the pool’s water until the “Code
92” disappears.
• Pool Volume Calculation
Types of Pool Gallons
(pool size in feet)
Cubic Meters
(pool size in meters)
Rectangular Length x Width x Average Depth x 7.5 Length x Width x Average Depth
Circular Length x Width x Average Depth x 5.9 Length x Width x Average Depth x 0.79
Oval Length x Width x Average Depth x 6.0 Length x Width x Average Depth x 0.80

(130PO) MINI SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 05/31/2021
130
PO
SAVE THESE INSTRUCTIONS
English
Page 7
INTEX POOLS SALT TABLE
This table shows the amount of salt needed to achieve and maintain the optimal 3000 ppm
salt level.
Pool Size
Water Capacity (Calculated at
90% for Frame Pool and 80%
for Easy Set & Oval Pool)
Salt Needed for
Startup
3.0g/L (3000ppm)
Salt Needed when
Low Salt Detected
(CODE “91”)
(Gals) (Liters) (Lbs) (Kgs) (Lbs) (Kgs)
INTEX ABOVE GROUND POOLS (AGP’s)
EASY SET®
POOL
244cmx61cm (8’x24”) 513 1942 13 6 5 2
244cmx76cm (8'x30") 639 2419 16 7 5 2
305cmx61cm (10’x24”) 813 3077 20 9 7 3
305cmx76cm (10'x30") 1018 3853 25 12 9 4
366cmx76cm (12'x30") 1485 5621 37 17 13 6
396cmx84cm (13'x33") 1926 7290 48 22 17 8
METAL
FRAME
POOL
244cmx51cm (8’x20”) 483 1828 13 6 5 2
305cmx76cm (10'x30") 1185 4485 30 13 9 4
366cmx76cm (12'x30") 1718 6503 43 20 15 7
PRISM
FRAMETM POOL
305cmx76cm (10'x30") 1185 4485 30 13 10 5
366cmx76cm (12'x30") 1718 6503 43 20 15 7
PRISM
FRAMETM
RECT. POOL
300cmx175cmx80cm
(9'10"x5'9"x31½") 935 3539 23 11 7 3
400cmx200cmx100cm
(13'1½"x6'6¾"x39½") 1806 6836 45 21 15 7
SMALL RECT.
FRAME POOL
220cmx150cmx60cm
(7'2⅝"x4'11"x23⅝") 439 1662 11 5 3 1
260cmx160cmx65cm
(8'6½"x5'3"x25⅝") 603 2282 16 7 5 2
300cmx200cmx75cm
(9'10"x6'6¾"x29½") 1013 3834 25 12 9 4
450cmx220cmx84cm
(14'9¼"x7'2⅝"x33") 1883 7127 48 22 17 8

(130PO) MINI SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 05/31/2021
130
PO
SAVE THESE INSTRUCTIONS
English
Page 8
INTEX POOLS CYANURIC ACID TABLE
Cyanuric acid is a chemical that reduces the loss of chlorine in water due to ultraviolet
rays. To maintain the pool water clear and clean, and to maximize the performance of
the device, add cyanuric acid to the pool. We recommend that the cyanuric acid level be
maintained at approximately 0.35% of the salt, i.e. 100 Lbs (45 Kgs) salt x 0.35% =
0.35 Lbs (0.16 Kgs) cyanuric acid.
Pool Size
Water Capacity (Calculated at
90% for Frame Pool and 80%
for Easy Set & Oval Pool)
Cyanuric Acid Needed
for Startup
0.01g/L (10ppm)
(Gals) (Liters) (oz) (g)
INTEX ABOVE GROUND POOLS (AGP’s)
EASY SET®
POOL
244cmx61cm (8’x24”) 513 1942 0.7 19
244cmx76cm (8'x30") 639 2419 0.9 25
305cmx61cm (10’x24”) 813 3077 1.1 31
305cmx76cm (10'x30") 1018 3853 1.4 39
366cmx76cm (12'x30") 1485 5621 2.0 56
396cmx84cm (13'x33") 1926 7290 2.6 73
METAL
FRAME
POOL
244cmx51cm (8’x20”) 483 1828 0.7 19
305cmx76cm (10'x30") 1185 4485 1.6 45
366cmx76cm (12'x30") 1718 6503 2.3 65
PRISM
FRAMETM POOL
305cmx76cm (10'x30") 1185 4485 1.6 45
366cmx76cm (12'x30") 1718 6503 2.3 65
PRISM
FRAMETM
RECT. POOL
300cmx175cmx80cm
(9'10"x5'9"x31½") 935 3539 1.3 35
400cmx200cmx100cm
(13'1½"x6'6¾"x39½") 1806 6836 2.4 68
SMALL RECT.
FRAME POOL
220cmx150cmx60cm
(7'2⅝"x4'11"x23⅝") 439 1662 0.6 17
260cmx160cmx65cm
(8'6½"x5'3"x25⅝") 603 2282 0.8 23
300cmx200cmx75cm
(9'10"x6'6¾"x29½") 1013 3834 1.4 39
450cmx220cmx84cm
(14'9¼"x7'2⅝"x33") 1883 7127 2.5 71

(130PO) MINI SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 05/31/2021
130
PO
SAVE THESE INSTRUCTIONS
English
Page 9
INTEX POOLS OPERATING TIME TABLE (WITH CYANURIC ACID)
Pool Size
Water Capacity (Calculated at
90% for Frame Pool and 80%
for Easy Set & Oval Pool)
Operating Time (hours)
at different ambient/air
temperatures
Intex Filter
pump
Operating
Time
(hours)
(Gals) (Liters)
10 - 19°C
(50 - 66°F)
20 - 28°C
(68 - 82°F)
29 - 36°C
(84 - 97°F)
INTEX ABOVE GROUND POOLS (AGP’s)
EASY SET®
POOL
244cmx61cm (8’x24”) 513 1942 2 2 2 3
244cmx76cm (8'x30") 639 2419 2 2 2 3
305cmx61cm (10’x24”) 813 3077 3 3 3 4
305cmx76cm (10'x30") 1018 3853 4 4 4 5
366cmx76cm (12'x30") 1485 5621 5 5 5 6
396cmx84cm (13'x33") 1926 7290 7 7 7 8
METAL
FRAME
POOL
244cmx51cm (8’x20”) 483 1828 2 2 2 3
305cmx76cm (10'x30") 1185 4485 4 4 4 5
366cmx76cm (12'x30") 1718 6503 6 6 6 7
PRISM
FRAMETM POOL
305cmx76cm (10'x30") 1185 4485 4 4 4 5
366cmx76cm (12'x30") 1718 6503 6 6 6 7
PRISM
FRAMETM
RECT. POOL
300cmx175cmx80cm
(9'10"x5'9"x31½") 935 3539 3 3 4 5
400cmx200cmx100cm
(13'1½"x6'6¾"x39½") 1806 6836 6 6 7 8
SMALL RECT.
FRAME POOL
220cmx150cmx60cm
(7'2⅝"x4'11"x23⅝") 439 1662 1 2 2 3
260cmx160cmx65cm
(8'6½"x5'3"x25⅝") 603 2282 2 2 2 3
300cmx200cmx75cm
(9'10"x6'6¾"x29½") 1013 3834 4 4 4 5
450cmx220cmx84cm
(14'9¼"x7'2⅝"x33") 1883 7127 7 7 7 8
IMPORTANT
The filter pump running time should be 1 hour longer than the required operating time of
the Saltwater System.
NOTE: If an Intex fi lter pump has a timer on the GFCI, the maximum run time is 10 hours. The timer
will need to be manually reset in order to extend the operating time.

(130PO) MINI SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 05/31/2021
130
PO
SAVE THESE INSTRUCTIONS
English
Page 10
SALT TABLE FOR COMMON NON-INTEX POOLS
Water Capacity Salt Needed for Startup
Salt Needed when
Low Salt Detected
(CODE “91”)
(Gals) (Liters) (Lbs) (Kgs) (Lbs) (Kgs)
500 1893 13 6 5 2
750 2839 20 9 7 3
1000 3785 25 11 8 4
1250 4731 31 14 11 5
1500 5678 38 17 13 6
1750 6624 44 20 15 7
2000 7570 50 23 17 8
2200 8327 55 25 20 9
Salt Needed for Startup
(Lbs)
Salt Needed for Startup
(Kgs)
Salt Needed when
Low Salt Detected (Lbs)
Salt Needed when
Low Salt Detected (Kgs)
Water Capacity (Gals) x 0.025
Water Capacity (Liters) x 0.003 Water Capacity (Gals) x 0.0067 Water Capacity (Liters) x 0.0008
OPERATING TIME TABLE FOR COMMON NON-INTEX POOLS (WITH CYANURIC ACID)
CYANURIC ACID TABLE FOR COMMON NON-INTEX POOLS
Water Capacity Cyanuric Acid Needed for Startup
0.01g/L (10ppm)
(Gals) (Liters) (oz) (g)
500 1893 0.7 19
750 2839 1 28
1000 3785 1.3 38
1250 4731 1.7 47
1500 5678 2 57
1750 6624 2.3 66
2000 7570 2.7 76
2200 8327 2.9 83
SALT CALCULATION FORMULA FOR ALL POOLS
Water Capacity Operating Time (hours) at different ambient/air temperatures Recommend Filter
pump Operating
Time (hours)
(Gals) (Liters) 10 - 19°C (50 - 66°F) 20 - 28 °C (68 - 82 °F) 29 - 36°C (84 - 97°F)
500 1893 2 2 2 3
750 2839 3 3 3 4
1000 3785 4 4 4 5
1250 4731 4 5 5 6
1500 5678 5 5 6 7
1750 6624 6 6 6 7
2000 7570 7 7 7 8
2200 8327 8 8 8 9

(130PO) MINI SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 05/31/2021
130
PO
SAVE THESE INSTRUCTIONS
English
Page 11
OPERATION INSTRUCTIONS
1. Turn on the filter pump.
2. Start up the unit:
Plug the power cord into the electrical outlet and test the household
socket GFCI (circuit breaker). Press button. Flashing code “00”
appears on the electronic control station’s LED, indicating that the unit
is ready to be programmed.
3. Set operating hours for Saltwater system:
With code “00” flashing, press button to set
the desired operating hours. See the “Operating
Time Table” for the required operating hours
related to each pool size. Pressing will
increase the time from 01 to 12 hours
maximum. If you have selected too many hours
keep pressing to repeat the cycle. The built-in
timer will now activate your Saltwater System, at the same time each day, for the number
of hours you have set.
NOTE: The Saltwater System will not operate if the filter pump is not operating. Make
sure to program your filter pump (or start it manually) for operation beginning 5 minutes
before the saltwater system and finishing 15 minutes after the saltwater system.
4. Lock keypad controls:
With the desired hour value showing, press button. A green
“WORKING” indicator on the control panel will light up within a few
seconds to indicate that the saltwater system has started sodium
hypochlorite production, the LED will display the remaining chlorinator
hours until it’s finished. Locking the control buttons into this setting
prevents unauthorized changing of the operating cycle.
NOTE: If you forget to lock the keypad controls, the system will automatically lock it and
start working 10 seconds later.
5. Readjust operating time if necessary:
The operating hours can be re-adjusted if necessary. Press button and the current
programmed time will flash. Repeat steps 3 to 4.
6. Stand-by/power saving mode:
• When the cycle ends, the green “SLEEP” indicator on the control
panel lights up and the LED display flashes “93”. The system is now
in Stand-By mode. After a while, it shuts down and sets itself in a
Power Saving mode. The system will automatically turn itself back on
in 24 hours, starting its daily cycle of sodium hypochlorite production.
• The “SLEEP” indicator stays on, while the system is in the Power
Saving mode. The LED display however, goes blank after 5 minutes.
Press any button ( or ) to view the last LED code.
(1 to 12 hours max per cycle)

(130PO) MINI SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 05/31/2021
130
PO
SAVE THESE INSTRUCTIONS
English
Page 12
LED CODE CHART
IMPORTANT
When Code “90” alarm is shown, ensure the timer of the filter pump is set
one (1) hour longer than the Saltwater System.
If the filter pump does not have a built-in timer, the filter pump needs to
be turned on/off manually every day.
LED Reading Definitions
00 Stand-By Mode (Start-up)
01 Minimum Operating Hour (1 hour remaining)
02 - 11 Operating Hours (2 - 11 hours remaining)
12 Maximum Operating Hours (12 hours remaining)
90 Alarm Code (Low Pump Flow / No Flow)
91 Alarm Code (Low Salt Level)
92 Alarm Code (High Salt Level)
93 Stand-By Mode (Operating Process finished)
“BLANK” No Power or “Power Saving Mode” waiting to start next
Saltwater System cycle.
MAINTENANCE
IMPORTANT
Unplug the power cord before cleaning your system. Also insert the black hat-like
plugs in the strainer opening to prevent water spillage. After completing all
maintenance tasks, you must plug the power cord back in and remove the plugs.
Titanium Electrode Cleaning
The titanium electrode has a self cleaning function incorporated into the electronic control’s
programming. In most cases this self cleaning action will keep the electrode working at
optimum efficiency. If the pool water is hard (high mineral content) the electrode may require
periodic manual cleaning. To maintain maximum performance, we recommend that you open
and visually inspect the titanium electrode (7) monthly.
The following steps provide instructions on how to clean your cell.
Inspection and cleaning:
1. Switch off the unit, unplug the power cord from the electrical socket.
2. To prevent water from flowing out of the pool, unscrew the strainer grids from the strainer
connectors and insert the hat-like plugs into the strainer connectors.

(130PO) MINI SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 05/31/2021
130
PO
SAVE THESE INSTRUCTIONS
English
Page 13
MAINTENANCE (continued)
3. Disconnect the 2 hoses from the Saltwater System (see drawing 1~3).
4. Unscrew the titanium electrode plug collar, disconnect the plug from the titanium electrode
(7) (see drawing 4).
5. Unscrew the cell nut, remove the titanium electrode from the cell housing (see drawing 5).
6. Place the titanium electrode in a container and pour kitchen grade vinegar into the
container until the titanium electrode is immersed. Soak for 1 hour and then flush with a
high-pressure garden hose (see drawing 6).
7. Reverse steps 3, 4, 5 and 6 to reconnect the electrolytic cell.
The Test Strips can test the “Free Chlorine”, “pH”, “Calcium Hardness” and “Total Alkalinity”
levels at the same time. We recommend that you test the water chemistry weekly, and maintain
the chlorine concentration at 1.0-3.0 ppm.
Directions and Use
1. Dip the entire strip into the water and remove immediately.
2. Hold the strip level for 15 seconds. Do not shake excess water from the strip.
3. Now compare the strip pad to the color chart on the packaging label. If necessary, adjust the
chemical level in the pool water. It is very important, to use the proper technique when
testing the water's chemical level. Read and follow the written strip instructions carefully.
1. Disconnect the power cord from the electrical outlet.
2. After the pool is completely empty, disconnect the Saltwater System from the hoses by
reversing the installation instructions.
3. Air-dry the unit before you store it. This might be a good time to visually inspect and clean
the electrolytic cell.
4. Store the unit and accessories in a dry place. The temperature should be controlled, between
32 degrees Fahrenheit (0 degrees Celsius) and 97 degrees Fahrenheit (36 degrees Celsius).
5. The original package can be used for storage.
INTEX®TEST STRIPS (PACKED WITH THE PRODUCT)
LONG TERM STORAGE
1
4
2
5
3
6

(130PO) MINI SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 05/31/2021
130
PO
SAVE THESE INSTRUCTIONS
English
Page 14
POOL MAINTENANCE & CHEMICAL DEFINITIONS
• Do not add pool chemicals directly to the skimmer. This may damage the cell.
• Maintaining a salt and sanitizer level above the recommended range can contribute to the
corrosion of the pool equipment.
• Check the expiry date of the test kit as the test results may be inaccurate if the kit is used
after that date.
• If, due to heavy pool usage, it is required to increase the sanitizer level, then use a chemical
based on Trichloro-s-triazinetrione or sodium dichloro-s-triazinetrione dihydrate.
Preferred Water Chemistry Reading
Minimum Ideal Maximum
Free Chlorine 0 1.0 - 3.0 ppm 5.0 ppm
Combined Chlorine 0 0 ppm 0.2 ppm
pH 7.2 7.4 - 7.6 7.8
Total Alkalinity 40 ppm 80 ppm 120 ppm
Calcium Hardness 50 ppm 100 - 250 ppm 350 ppm
Stabilizer (Cyanuric Acid) 10 ppm 10 - 30 ppm 30 ppm
Free Chlorine -Is the chlorine residual present in pool water.
Combined Chlorine -Is formed by the reaction of free chlorine with ammonia wastes.
Result if too high - Sharp chlorinous odor, eye irritation.
pH
-A value that indicates how acidic or basic a solution is.
Result if too low - Corroded metals, eye & skin irritation,
destruction of total alkalinity.
Result if too high - Scale formation, cloudy water, shorter filter
runs, eye & skin irritation, poor chlorine
efficiency.
Total Alkalinity -Indicates the degree of the water’s resistance to change in pH. It
determines the speed and ease of pH change, so always adjust total
alkalinity before adjusting the pH level.
Result if too low - Corroded metals, eye & skin irritation. Low
alkalinity will cause the pH to be unstable.
Any chemical added to the water will have an
affect on pH.
Result if too high - Scale formation, cloudy water, eye & skin
irritation, poor chlorine efficiency.
Calcium Hardness -Refers to the amount of calcium and magnesium dissolved in the
water.
Result if too high - Eye & skin irritation, difficulty balancing water
and poor chlorine efficiency. Scale will form
and will cause the water to become cloudy.
Stabilizer
(Cyanuric Acid)
-Stabilizers extend the life of chlorine in swimming pools.

(130PO) MINI SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 05/31/2021
130
PO
SAVE THESE INSTRUCTIONS
English
Page 15
TROUBLESHOOTING GUIDE
INSUFFICIENT
SODIUM
HYPOCHLORITE
WHITE FLAKES IN
THE WATER
NO LED DISPLAY
• Insufficient operating hours of
the Saltwater System.
• The salt level in the pool water
is less than 2000ppm. This is
insufficient.
• Sodium hypochlorite loss due to
intense sunlight exposure.
• The bather load has increased.
• Clogged or dirty electrolytic cell.
• High UV level exposure.
• Excessive calcium hardness is
present in the pool water.
• No power supply.
• Household socket GFCI has not
reseted.
• A power fuse has blown.
• LED failure.
• Increase the daily Saltwater System
operating time. See “Operating Instructions”.
• Check the salt level with the Test Kit. Adjust
as needed. See “Salt & Pool Water Volumes”.
• Use a pool cover when the pool is not
in use and/or when the unit is operating.
• Increase the daily Saltwater System
operating time. See “Operating Instructions”.
• Remove the cell for inspection, clean it if
necessary. See “Maintenance”.
• Cover the pool with a pool cover for 2
days with the device running and then
test the water using the test strips.
• If the pool is clean and clear, add stabilizer
to the water and then test the water with the
device running.
• Drain about 20 to 25% of the pool
water and add fresh water to decrease
the calcium hardness. Inspect the
electrolytic cell for scale buildup. Clean
the electrolytic cell if necessary.
• Find out the switch and turn on.
• Reset the household socket GFCI.
• Contact Intex Service Center.
• Contact Intex Service Center.
PROBLEM CAUSE SOLUTION
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
WARNING: Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.

(130PO) MINI SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 05/31/2021
130
PO
SAVE THESE INSTRUCTIONS
English
Page 16
TROUBLESHOOTING GUIDE (continued)
IMPORTANT
If you continue to experience difficulty, please contact our Consumer Service Department for
assistance. See separate “Authorized Service Centers” sheet.
1. Filter pump not attached to
system and/or switch on.
2. Circulation line is blocked.
3. Incorrect inlet and outlet hose direction.
4. Scale on flow sensor pins inside the
titanium electrode.
5. Electrode cord is loose.
6. Inner timer conflict between
filter pump and saltwater system.
1. Dirt or scale on titanium plates.
2. Low salt level / No salt.
3. Electrolytic cell cord is loose.
4. Possible electrolytic cell failure.
1. High salt level.
2. Water temperature > 35ºC.
3. Titanium electrode failure.
• Ensure a filter pump with the correct flow
rate is attached and operating. See "Setup
Instruction".
• Remove the black hat-like plugs from the pool
strainer connectors.
• Clear your filter cartridge and cell from debris
and dirt. See “Maintenance”.
• Release all trapped air in the circulation line.
See the filter pump manual.
• Check the direction of the inlet and the outlet
hose. Reverse the hoses if necessary. See “Set
Up Instructions”.
• Clean the titanium electrode. See
“Maintenance” section.
• Plug the cord into the electrode and tighten the
plug collar firmly.
• Reset both timers on the filter pump and
saltwater system. See “Operating Instructions”.
• Remove the electrolytic cell for inspection.
Clean it if necessary. See “Maintenance”.
• Add salt. See “Salt & Pool Water Volumes”.
• Ensure that the cell cord is plugged firmly into
the cell housing receptacle.
• Contact Intex Service Center. Replace the cell
if needed.
• Partially drain the pool and refill it with fresh
water. See “Salt & Pool Water Volumes”.
• Contact Intex Service Center.
• Contact Intex Service Center.
LED PANEL
CODE PROBLEM SOLUTION
LED Panel Code Flash & Alarm On (NOTE: Always turn off the power before cleaning and servicing).

(130PO) MINI SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 05/31/2021
130
PO
SAVE THESE INSTRUCTIONS
English
Page 17
Your Krystal ClearTM Saltwater System has been manufactured using the highest
quality materials and workmanship. All Intex products have been inspected and
found free of defects prior to leaving the factory. This Limited Warranty applies only
to the Krystal ClearTM Saltwater System and accessories listed below.
The provisions of this Limited Warranty apply only to the original purchaser and is
not transferable. This Limited Warranty is valid for the period noted below from the
date of the initial retail purchase. Keep your original sales receipt with this manual,
as proof of purchase will be required and must accompany warranty claims or the
Limited Warranty is invalid.
Krystal ClearTM Saltwater System Warranty – 2 Years
Titanium electrode Warranty – 1 Year
Hoses & Fittings Warranty – 180 days
If a manufacturing defect is found within the periods noted above, please contact the
appropriate Intex Service Center listed in the separate “Authorized Service Centers”
sheet. The Service Center will determine the validity of the claim. If the Service
Center directs you to return the product, please carefully package the product and
send with shipping and insurance prepaid to the Service Center. Upon receipt of the
returned product, the Intex Service Center will inspect the item and determine the
validity of the claim. If the provisions of this warranty cover the item, the item will be
repaired or replaced at no charge.
Any and all disputes regarding the provisions of this Limited Warranty shall be
brought before an informal dispute settlement board and unless and until the
provisions of these paragraphs are carried forth, no civil action may be instituted.
The methods and procedures of this settlement board shall be subject to the rules
and regulations set forth by the Federal Trade Commission (F.T.C.). IMPLIED
WARRANTIES ARE LIMITED TO THE TERMS OF THIS WARRANTY AND IN
NO EVENT SHALL INTEX, THEIR AUTHORIZED AGENTS OR EMPLOYEES
BE LIABLE TO THE BUYER OR ANY OTHER PARTY FOR DIRECT OR
CONSEQUENTIAL DAMAGES OR LIABILITIES. Some states, or jurisdictions do
not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you.
This Limited Warranty does not apply if the products are subject to negligence,
abnormal use or operation, accident, improper operation, improper voltage or current
contrary to operating instructions, or to damage by circumstances beyond Intex’s
control, including but not limited to, ordinary wear and tear and damage caused by
exposure to fire, flood, freezing, rain, or other external environmental forces. This
Limited Warranty applies only to those parts and components sold by Intex. The
Limited Warranty does not cover unauthorized alterations, repairs or disassembly by
anyone other than Intex Service Center personnel.
DO NOT GO BACK TO THE PLACE OF PURCHASE FOR RETURN OR
REPLACEMENT. IF YOU ARE MISSING PARTS OR NEED ASSISTANCE,
PLEASE CALL US (FOR U.S. AND CANADIAN RESIDENTS): 1-310-549-8235
OR VISIT OUR WEBSITE: WWW.INTEXCORP.COM.
Proof of Purchase must accompany all returns or the warranty claim will be invalid.
LIMITED WARRANTY
