InTouch INOF215 User manual

INOF215 USER MANUAL
COPYRIGHT 2020 - INTOUCH SCREENS
INOF215 - 21.5 inch PCAP Multi-point Touch Screen
1920 x 1080 Resolution
21.5 inch Active Area - 476.6 x 268.1 mm
16:9 Aspect Ratio
External Power Supply - Input 100-240V ~ 50/60Hz 1.2A, Output 12V - 3000mA
Power Consumption: 23W on - <2W standby
Weight: 5.0 KG
Product data available in DXF, 3D PDF and STEP formats
142.0
142.0
15.0
3.0
100.0
Chassis Mounting Holes
M4 Thread
142.0142.0
476.6
268.1
547.7
R 16.0
R 11.8
339.7
44.0
23.0
67.8180.0
100.0 117.8
Chassis Mounting Holes
M4 Thread
VESA Mount - 100 x 100
M4 Thread
15.0
3.0
52.048.0
330.0

INOF215 SPECIFICATIONS
Touch Screen INOF215
1
• 21” active viewable area
• 10-point PCAP multi-touch
• 1920 x 1080 Native Resolution
• Built-in stereo speakers
• Compatible with Windows 7,
8 & 10
CABLING INFORMATION
Step 1. Connect your desired
display cable.
Step 2. Connect USB touch
cable
HDMI VGA
COPYRIGHT 2020 - INTOUCH SCREENS
INDT550 (side view)
INDT420
INDT320
INDT215
INDT190
INDT156
INDT101
INOF-190
INOF215
INSS101 - Cutaway View
INSS156 - Cutaway View
INSS215 - Cutaway View
INDT320-NB (Side View)
COPYRIGHT 2020 - INTOUCH SCREENS
INOF215 - 21.5 inch PCAP Multi-point Touch Screen
1920 x 1080 Resolution
21.5 inch Active Area - 476.6 x 268.1 mm
16:9 Aspect Ratio
External Power Supply - Input 100-240V ~ 50/60Hz 1.2A, Output 12V - 3000mA
Power Consumption: 23W on - <2W standby
Weight: 5.0 KG
Product data available in DXF, 3D PDF and STEP formats
142.0
142.0
15.0
3.0
100.0
Chassis Mounting Holes
M4 Thread
142.0142.0
476.6
268.1
547.7
R 16.0
R 11.8
339.7
44.0
23.0
67.8180.0
100.0 117.8
Chassis Mounting Holes
M4 Thread
VESA Mount - 100 x 100
M4 Thread
15.0
3.0
52.048.0
330.0
Step 3. Connect 12V power
cable
USB Touch
Port
VGA Port HDMI Port
12V Power
Port

CLEANING INSTRUCTIONS
WARRANTY
Applicable to touch screens and kiosks:
InTouch suggests using an isopropyl alcohol spray and clean microbre cloth.
Caution: Be careful when cleaning your kiosk to avoid vinyled graphic areas so as not
to damage the artwork. DO NOT use abrasive cleaners, solvents or cloths.
For more information please visit www.intouchscreens.com.au/cleaning
For more information please visit www.intouchscreens.com.au/warranty
INOF215 - MOUNTING DIMENSIONS
COPYRIGHT 2020 - INTOUCH SCREENS
INOF215 - 21.5 inch PCAP Multi-point Touch Screen
1920 x 1080 Resolution
21.5 inch Active Area - 476.6 x 268.1 mm
16:9 Aspect Ratio
External Power Supply - Input 100-240V ~ 50/60Hz 1.2A, Output 12V - 3000mA
Power Consumption: 23W on - <2W standby
Weight: 5.0 KG
Product data available in DXF, 3D PDF and STEP formats
142.0
142.0
15.0
3.0
100.0
Chassis Mounting Holes
M4 Thread
142.0142.0
476.6
268.1
547.7
R 16.0
R 11.8
339.7
44.0
23.0
67.8180.0
100.0 117.8
Chassis Mounting Holes
M4 Thread
VESA Mount - 100 x 100
M4 Thread
15.0
3.0
52.048.0
330.0
