Invacare Aquatec Ocean Dual VIP Ergo User manual

Aquatec®OceanVIPErgo/
Aquatec®OceanDualVIPErgo
enShowerandToiletCommode
UserManual...............................3
deDusch-undToilettenrollstuhl
Gebrauchsanweisung........................33
frChaiseroulantepourdouche/toilettes
Manueld'utilisation.........................69
itCarrozzinadadocciaedatoilette
Manualed’uso..............................103
esSilladeduchaeinodoro
Manualdelusuario.........................137
ptCadeiradeducheesanitária
Manualdeutilização........................171
nlDouche-entoiletstoel
Gebruiksaanwijzing.........................205
elΠροσάρτημαντουςκαιτουαλέτας
Εγχειρίδιοχρήσης..........................239
ThismanualMUSTbegiventotheuseroftheproduct.
BEFOREusingthisproduct,thismanualMUSTbereadandsavedfor
futurereference.

©2019InvacareCorporation
Allrightsreserved.Republication,duplicationormodicationinwholeorinpartisprohibited
withoutpriorwrittenpermissionfromInvacare.Trademarksareidentiedby™and®.Alltrademarks
areownedbyorlicensedtoInvacareCorporationoritssubsidiariesunlessotherwisenoted.

Contents
ThismanualMUSTbegiventotheuseroftheproduct.
BEFOREusingthisproduct,thismanualMUSTbereadandsaved
forfuturereference.
1General.........................................4
1.1Introduction..................................4
1.2Symbolsinthismanual..........................4
1.3Warrantyinformation...........................4
1.4Compliance...................................5
1.4.1Product-specicstandards.....................5
1.5Intendeduse..................................5
1.6Servicelife...................................5
2Safety..........................................6
2.1Safetyinformation..............................6
2.2Labelsandsymbolsontheproduct.................6
3Components......................................9
3.1Overview....................................9
4Setup...........................................11
4.1Safetyinformation..............................11
4.2Assemblingtheshowerandtoiletcommode..........11
4.2.1Adjustingtheseatheight......................11
4.2.2Installingthebackrest........................12
4.2.3Installingtheactivationhandle..................13
4.2.4Installing/Removingtheseatplate...............14
4.2.5Adjustingtheheightofthearmrests.............14
4.2.6Installingthefootrests........................15
4.2.7Installingtheheadrest........................15
4.2.8Installingtherearantitippers...................16
4.2.9Installing/removingthebrakecovers/clamping
protectioncovers...........................17
5Accessory(optional)................................18
5.1Fitting/removingthetoiletpanholderandtoiletpan....18
6Usage..........................................20
6.1Safetyinformation..............................20
6.2Swivelingthearmrests..........................21
6.3Swivellingthefootrests..........................22
6.4Tiltingtheseatframewithbackrest.................22
6.5Tiltingthebackrest(OceanDualVIPErgoonly)........23
6.6Engaging/disengagingthecastorlocks...............24
7Transport........................................25
7.1Safetyinformation..............................25
8Maintenance.....................................26
8.1Maintenanceandinspection......................26
8.2Cleaninganddisinfection.........................26
9AfterUse........................................28
9.1Storage......................................28
9.2Re-use......................................28
9.3Disposal.....................................28
10Troubleshooting..................................29
10.1Identifyingandrepairingfaults...................29
11TechnicalData...................................30
11.1Dimensionsandweight.........................30
11.2Materials....................................32
11.3Environmentalparameters.......................32

Aquatec®OceanVIPErgo/Aquatec®OceanDualVIPErgo
1General
1.1Introduction
Thisusermanualcontainsimportantinformationaboutthe
handlingoftheproduct.Toensuresafetywhenusingthe
product,readtheusermanualcarefullyandfollowthe
safetyinstructions.
Notethattheremaybesectionsinthisdocument,whichare
notrelevanttoyourproduct,sincethisdocumentapplies
toallavailablemodels(onthedateofprinting).Ifnot
otherwisestated,eachsectioninthisdocumentreferstoall
modelsoftheproduct.
Themodelsandcongurationsavailableinyourcountrycan
befoundinthecountry-specicpricelists.
Invacarereservestherighttoalterproductspecications
withoutfurthernotice.
Beforereadingthisdocument,makesureyouhavethe
latestversion.YoundthelatestversionasaPDFonthe
Invacarewebsite.
Ifyoundthatthefontsizeintheprinteddocumentis
difculttoread,youcandownloadthePDFversionfromthe
website.ThePDFcanthenbescaledonscreentoafont
sizethatismorecomfortableforyou.
Formoreinformationabouttheproduct,forexample
productsafetynoticesandproductrecalls,contactyour
Invacarerepresentative.Seeaddressesattheendofthis
document.
1.2Symbolsinthismanual
Symbolsandsignalwordsareusedinthismanualandapply
tohazardsorunsafepracticeswhichcouldresultinpersonal
injuryorpropertydamage.Seetheinformationbelowfor
denitionsofthesignalwords.
WARNING
Indicatesahazardoussituationthatcouldresult
inseriousinjuryordeathifitisnotavoided.
CAUTION
Indicatesahazardoussituationthatcouldresult
inminororslightinjuryifitisnotavoided.
IMPORTANT
Indicatesahazardoussituationthatcouldresult
indamagetopropertyifitisnotavoided.
TipsandRecommendations
Givesusefultips,recommendationsand
informationforefcient,trouble-freeuse.
ThisproductcomplieswithDirective93/42/EEC
concerningmedicaldevices.Thelaunchdate
ofthisproductisstatedintheCEdeclaration
ofconformity.
Manufactureroftheproduct.
1.3Warrantyinformation
Weprovideamanufacturer’swarrantyfortheproduct
inaccordancewithourGeneralTermsandConditionsof
Businessintherespectivecountries.
41639504-C

General
Warrantyclaimscanonlybemadethroughtheprovider
fromwhomtheproductwasobtained.
1.4Compliance
Qualityisfundamentaltothecompany’soperation,working
withinthedisciplinesofISO13485.
ThisproductfeaturestheCEmark,incompliancewiththe
MedicalDeviceDirective93/42/EECClass1.
Wearecontinuouslyworkingtowardsensuringthatthe
company’simpactontheenvironment,locallyandglobally,
isreducedtoaminimum.
WeonlyuseREACHcompliantmaterialsandcomponents.
1.4.1Product-specicstandards
Theproducthasbeentestedandconformstothestandard
ISO17966(Assistiveproductsforpersonalhygienethat
supportusers)andrelatedstandards.Thisincludestesting
concerningammability.Progressivesmoulderingignition
andamingignitiondonotoccur.
Forfurtherinformationaboutlocalstandardsand
regulations,contactyourlocalInvacarerepresentative.See
addressesattheendofthisdocument.
1.5Intendeduse
Theshowerandtoiletcommodeisdesignedexclusivelyas
anaidforshoweringorbathing,goingtothetoilet,foruse
duringpersonalhygiene(e.g.infrontofthebasin)orfor
transferringpatientswhileindoors.Itisintendedtobeused
byyouthandadultpatientswithorwithoutcaregiverˈs
assistance,whohave:
•Difcultystandingorkeepingtheirbalance
•Weaklegsorlowerlimbdisability
•Medicalconditionsthatimpairtheirbalance
Theproductisintendedforinstitutionalandprivatehouse
holduse.Anyotheruseisprohibited.
WARNING!
Riskofinjury
–Neverusetheproductasanaidforgettinginto
oroutofabathtub,forclimbingordescending,
asasupportorforsimilarpurposes.
–Donotusetheproductoutdoors.
Asatoiletcommode,theproductcanbeusedover
astandardtoiletorindependentlywiththetoiletpan
(optional).
Temperatureforuse:10-65°C
1.6Servicelife
Theexpectedservicelifeofthisproductisveyearswhen
useddailyandinaccordancewiththesafetyinstructions,
maintenanceintervalsandcorrectuse,statedinthismanual.
Theeffectiveservicelifecanvaryaccordingtofrequency
andintensityofuse.
1639504-C5

Aquatec®OceanVIPErgo/Aquatec®OceanDualVIPErgo
2Safety
2.1Safetyinformation
WARNING!
Riskofinjuryordamage
–Donotusethisproductoranyavailable
optionalequipmentwithoutrstcompletely
readingandunderstandingtheseinstructions
andanyadditionalinstructionalmaterialsuch
asusermanuals,servicemanualsorinstruction
sheetssuppliedwiththisproductoroptional
equipment.
–Ifyouareunabletounderstandthewarnings,
cautionsorinstructions,pleasecontacta
healthcareprofessional,Invacareprovideror
qualiedtechnicianbeforeattemptingtouse
thisproduct.
WARNING!
Riskofinjury
–Donotstandontheproduct.
–Donotuseasaclimbingaid.
–Donotuseoutdoors.
WARNING!
Riskofinjury
–Donotuseifdefective.
–Intheeventofamalfunction,contactyour
providerimmediately.
–Donotmakeanyunauthorizedchangesor
alterationstotheproduct.
–Onlyuseaccessoriesintendedforthisproduct.
IMPORTANT!
Theinformationcontainedinthisdocumentis
subjecttochangewithoutnotice.
2.2Labelsandsymbolsontheproduct
Identicationlabel
Theidenticationlabelcontainsimportantinformation:
( 0 1 ) 0 4 0 2 8 6 9 8 1 3 2 6 1 8 ( 2 1 ) 1 8 AVP 3 0 0 0 0 1 ( 0 X)
S
N
OceanVIP Ergo
150kg
2018-01
AQUATEC Operations GmbH
Ale ma nne ns tra s s e 10
88316 Is ny - Ge rm a ny
4 0 2 8 6 9 8 1 3 2 6 1 8
1603139
R
EF
I
H
G
F
E
C
B
A
D
61639504-C

Safety
AProductdesignation
BReferencenumber
CSerialnumber
DMaximumuserweight
EDateofmanufacture
FReadusermanual
GConformitymark
HNote(useonlyonatsurfaces)
IManufactureraddress
Theidenticationlabelisattachedtotheinsideof
theleftsidepart.
Labelsontheproduct
Thefollowinglabelisattachedtothebacksideofthe
headrest:
LabelDescription
!
CAUTION!
Riskofimpact
Yourbodycanbehitbythe
backrest/headrestwhenpulling
theactivationhandle.
–Makesurethereisenough
spacebetweenyouandthe
backrest/headrestwhentiltingthe
seatframewithbackrest.
1639504-C7

Aquatec®OceanVIPErgo/Aquatec®OceanDualVIPErgo
Thefollowinglabelisattachedtothehandleofthe
backrest:
LabelDescription
WARNING!
Riskoftippingover
–Donotsteponthefootrest
whengettingintooroutofthe
showerandtoiletcommode.
–Pushthefootreststothesides
orfoldupthefootplatesbefore
gettingintooroutoftheshower
andtoiletcommode.
–Beforesittingdownorstanding
up,turnthecastorssothatthe
lockispointingforwards.
–Donotleantoofarforwards
whensittingintheshowerand
toiletcommode.
Thefollowinglabelsareattachedtotheactivationhandles:
LabelDescription
Activationhandleforseattilting.
Activationhandleonlyforbackrest
tilting.
81639504-C

Components
3Components
3.1Overview
Thefollowingcomponentsareincludedwithinthescope
ofdelivery:
AHeadsupport
B1OceanVIPErgo:
Backrestwithbackrestcoverandarmrests
B2OceanDualVIPErgo:
Backrestwithbackrestcover,armrestsand
activationhandleforbackresttilting
CScrews(4x)andwashers(4x)forbackrestxation
DSeatframewithseatplateandsidepartswithbase
frameandcastors
EClips(4x)forheightadjustment
FFootrestswithheelstraps(2x)
GClips(2x)forfootrests
HActivationhandleforseattilting
IUsermanual
JAllenkey
KRearantitipperwithscrew,washerandmounting
cap(2x)(OceanDualVIPErgoonly)
LBrakecover(2x)
MBrakelevercover(2x)
NClampingprotectioncover(2x)
OPushbar
1639504-C9

Aquatec®OceanVIPErgo/Aquatec®OceanDualVIPErgo
Accessory—Toiletpanholderwithtoiletpan
AToiletpanholder
BToiletpan
CLid
101639504-C

Setup
4Setup
4.1Safetyinformation
WARNING!
–Checkthepartsfortransportdamagebefore
commissioningandcontactyourproviderif
required.
–Ensureduringassemblythatthepartsare
positionedcorrectlywithrespecttoone
another.
–Self-lockingscrews/nutsorthread-locking
adhesiveareusedforseveralconnections.If
theseareloosened,theymustbereplacedby
newself-lockingscrews/nutsortheymustbe
securedusingnewthread-lockingadhesive.
4.2Assemblingtheshowerandtoiletcommode
Thissectiondescribestheassembly.Disassemblytakesplace
inthereverseorder.
Thearmrestheight,footrestheight,footrestangle,
headrest,heelstrap,tensionofbackrestcoverand
accessoriesmustbeadjustedtooptimallyttheuser.
4.2.1Adjustingtheseatheight
Thissectiondescribestheassembly.Disassemblytakesplace
inthereverseorder.
WARNING!
–Donotadjusttheseatheightofthecommode
whensomeoneissittingonit.
Theseatheightmustbeadjustedonbothsides
simultaneously.
1.SlightlyraisethecommodeatthesidepartA.
2.RemovethefourclipsC(twooneachside).
3.Setthecorrectheightbysimultaneouslymovingthe
seatframeupwardsordownwardsonthefourtubes
Bofthebaseframe.
4.Bringtheclipmountsonthesidepartinlinewitha
holeinthebaseframe.
5.Insertthefourclipsfromtheoutsideintothesidepart,
untiltheclipedgesenclosethebaseframetubeB.
WARNING!
Riskofinjury
–Makesurethatallfourclipsaresecurely
fastened.
–Makesurethatallfourtubesaresettothe
sameheight.
1639504-C11

Aquatec®OceanVIPErgo/Aquatec®OceanDualVIPErgo
Theseatheightcanbeadjustedtoaccommodate
differentsituationsofusee.g.transferfromabed
orawheelchairoruseabovetoiletetc.
4.2.2Installingthebackrest
1.Pushdownallfourfootpedalsofthecastorstolock
them.
2.PushthebackrestDfrombehindontotheseatframe
E,untilthecollarCtouchestheseatframetubeF.
IMPORTANT!
–FirmlytightenthescrewsusingtheAllenkey
supplied.
–Checkthescrewsregularlytoensuretheyare
fastenedsecurely.
3.PositionawasherBoneachscrewAandsecurethe
backrestoneachside.
4.Tightenthescrewswithatorqueof5Nm.
Adjustingthebackrestcover
Thetensionofthebackrestcanbeadjustedasneeded.
WARNING!
–Makesurethatatleastthreebeltsarealways
passedaroundthebackrestframe(onthe
outside)andtheirbeltbucklesarefastened.
Tightening:
1.PullthebeltsAofthebackrestcovertighter.
Loosening:
1.OpenthebucklesBbysqueezingtheretaininglugs
together(arrows).
2.Pushthebeltsbackalittlethroughthebuckle.
3.Fastenthebeltbuckles.
4.Retightenthebeltsgently.
121639504-C

Setup
WARNING!
Riskofinjuryduetodamagedbackrestbuckles!
Checkforsecurefasteningofthebackrest
buckleseachtimetheproductismaintainedor
reconditioned.
–Checkallbuckleclipsforsecurefasteningby
closingthebucklesandpullingonbothends.
–Replacethebackrest/backrestbucklesifa
buckleopensundertheappliedforce.
4.2.3Installingtheactivationhandle
1.RemovetheclampingpartCfromtheactivationhandle
AbylooseningthescrewsD.
2.PositiontheactivationhandleAforseattiltingfrom
theundersideattherightsideofthehandletubeB.
Thehandleshouldbeslightlyturnedinwardstothe
backrest.
3.Installtheactivationhandletothehandletubeusing
theclampingpartCandscrewsD.
1639504-C13

Aquatec®OceanVIPErgo/Aquatec®OceanDualVIPErgo
FortheOceanDualVIPErgo,theactivationhandleE
forbackresttiltingisalreadyinstalledtotheleftside
ofthehandletube.Thepositionoftheactivation
handlecanbechangedifrequired.
4.2.4Installing/Removingtheseatplate
Installing:
1.Placetheseatplateontheseatframewiththecutout
tothefront.
2.Withyourhandat,presstheseatplatedownatthe
sidesandthenatthefrontandbackuntiltheseatplate
snapsontotheseatframe.
Removing:
1.Pulltheseatplateupwardsattherear.
4.2.5Adjustingtheheightofthearmrests
1.Onthebackrestcover,openthesecondlowestbeltC
andloosentheotherbelts.
Thenutsareinsertedlooselyinthesecuringclamp
andcanfallout.
2.UnscrewthescrewsBofthearmrestbracketAusing
theAllenkeysupplied.
3.RemovethesecuringclampDwiththenutsfromthe
insideofthebackrestframe.
4.RemovethebackrestbracketAwiththearmrestand
moveitupwards.
Thesmallerholeservestoxthesecuringclamp.
5.Insertthescrewsinthearmrestbracketandguidethem
throughtheholesinthebackrestframe.
6.Ifrequired,putthenutsbackintothesecuringclamp.
7.Placethesecuringclamponthebackrestframeinserting
thexationpinintothesmallerhole.
8.Turnthescrewsinthenutsandtighten.
9.Dependingonthearmrestheight,passthesecond
lowestbeltontheoutsideofthebackrestframeoron
theinside,fastenandtightenallbelts.
10.Theheightadjustmentprocedureisthesameforthe
rightandleftarmrest.
Toattachaccessories,thesecondlowestbeltcanbe
openedandthebackrestcovercanbepassedbythe
backrestframeontheinside.
141639504-C

Setup
4.2.6Installingthefootrests
1.InsertthepinoftheclipGfromtheoutsideintothe
requiredholeonthefootrestB.Makesuretheclip
engagesaroundthetube.
2.PushthefootrestintotheguideHatthefrontofthe
sidepartuntilthepinofclipGengagesinthegroove
A.Thefootrestcannolongerbeturnedtotheside.
Theassemblyprocedureisthesamefortheright
andtheleftfootrest.
Adjustingtheheightofthefootrests
Thefootrestscanbeshortenedifrequired(referto
theservicemanual).Shorteningthefootrestsmust
beperformedbyaqualiedtechnician.
1.SlightlypullupthefootrestB.
2.PulltheclipGoutoftheholeinthefootrestand
re-insertitintotherequiredhole.Pulloutthefootrest
slightlyfurtherifnecessary.
3.PushdownthefootrestuntilthegrooveAcatchesthe
pinoftheclip.
4.Settheotherfootresttotherequiredheightas
described.
Adjustingtheinclinationofthefootplates
Theinclinationofthefootplatescanbeadjusted
innitelyvariably.
1.LoosentheAllenscrewConthefootplateusingasize
4Allenkey.
2.TurnthefootplateDtotherequiredposition.
3.Re-tightentheAllenscrew.
4.2.7Installingtheheadrest
1639504-C15

Aquatec®OceanVIPErgo/Aquatec®OceanDualVIPErgo
1.UsethestarhandleFtoinsertthescrewalittleinto
thebracketG.
2.Pushthebracketwiththescrewontothehandleofthe
backrestEfrombehindwiththescrewengaginginthe
holeofthebackrest’shandle.
3.InserttheplateDintothebracketfromthefrontso
thatbothlugsoftheplatefacedownandupandthe
curvedplatesidetouchesthehandleofthebackrest.
4.PushtheheightadjustmenttubeCfromaboveinto
therecessesofthebracket.
5.Usethestarhandletotightenthescrewuntiltheheight
adjustmenttubeisxedinplace.
6.PushthepadJandthepadholderBintotheholder
Hontheheightadjustmenttube.
7.UsethestarhandleAtotightentheupperscrewuntil
thepadholderisxedinplace.
Toadaptittotheuser,theheightadjustmenttube
canbettedwiththecurvefacingthefrontorthe
back.
TheheadrestpadJcanberemovedandreplaced
byotherpadshapes(optional).Toremoveit,loosen
theretainingboltsI.
Adjustingthelengthoftheheadrest
TheheadresttubesCandBcanbeshortenedif
required(refertotheservicemanual).Shortening
theheadresttubemustbeperformedbyaqualied
technician.
4.2.8Installingtherearantitippers
WARNING!
Riskoftipping
ThereisariskofsevereinjuryontheOcean
DualVIPErgowhenthebackrestistilted.The
completechaircantiltbackwards.
–BeforeusingtheOceanDualVIPErgo,make
surethatbothrearantitippersareinstalled.
WARNING!
Riskofinjury
–Neverstandontheantitippers.
A
BD
CFE
1.RemovethecovercapBfromthebaseframeA.
2.AttachthemountingcapDtothebaseframe.
3.InserttheantitippertubeC.
4.Fixtheantitipperthroughitssecondholeusingthe
screwEwiththewasherF.
5.Installthesecondantitipperontheotherside.
161639504-C

Setup
4.2.9Installing/removingthebrakecovers/clamping
protectioncovers
ABrakecover
BBrakelevercover
CClampingprotectioncover
Brakecover
1.AttachthebrakelevercoverAbypinninguptheslot
BtothesmallshaftC.
2.PositionthelowerpartofthebrakecoverDatanangle
frombelowoverthebrakehousingE.
3.Foldtheupperpartofthebrakecovertothebrake
housingsothattherecessesFsitushwiththeedges
G.
4.Installthesecondbrakecoverontheotherside.
Clampingprotectingcover
1.InstalltheclampingprotectingcoverAbysnappingit
ontotheframetubesB.MakesurethatallclipsC
arefullyengaged.
2.Installthesecondclampingprotectingcoveronthe
otherside.
1639504-C17

Aquatec®OceanVIPErgo/Aquatec®OceanDualVIPErgo
5Accessory(optional)
WARNING!
Riskofinjury
–Theassemblyofaccessories(optional)must
becarriedoutaccordingtothecorresponding
instructions.
5.1Fitting/removingthetoiletpanholderand
toiletpan
ThetoiletpanFcanbeinserted/removedwithor
withoutthelidG.
1.RemovetheseatBfromtheframeA.
2.PositiontheendsofthetoiletpanholderCintothe
holesoftherearcrosstubeE.
3.Engagethefrontpartofthetoiletpanholderwiththe
frontcrosstubeD.
4.Re-ttheseattotheframe.
5.Placethelidonorremoveitfromthetoiletpan.
6.HoldthetoiletpanbyitshandleHandinsertfromthe
rearsidebetweenthetoiletpanholderandtheseat.
Slightlypushdownthetoiletpanwheninsertingor
removing.
Thelidcanbehungontheplastichookatthe
undersideofthetoiletpanhandle.
Thereisalllevelindicatorontheinnerwallof
thetoiletpan.
181639504-C

Accessory(optional)
1639504-C19

Aquatec®OceanVIPErgo/Aquatec®OceanDualVIPErgo
6Usage
6.1Safetyinformation
WARNING!
–Onlyusetheshowerandtoiletcommodeona
atsurfaceandindoors.
–Observethespecicationsontheidentication
label.Donotoverloadtheshowerandtoilet
commode.
–Observethesafetylabelsonthebacksideofthe
headrestandonthehandleofthebackrest,2.2
Labelsandsymbolsontheproduct,page6.
–Donotplaceexcessiveweightontheshower
andtoiletcommode.
–Alwaysperformavisualinspectionofthe
productforexternaldamagebeforeeachuse.
WARNING!
Riskofslippingandrolling
–Beforeuse,makesurethattheseatissecurely
fastenedtotheseatframe
–Lockallcastorswithleversusingthefootlevers
beforesittingdownontheshowerandtoilet
commodeorstandingupfromit,aswellas
intheparkingposition.
WARNING!
Riskoftipping
–Swivelthefootreststothesideorfoldupthe
footplatesbeforesittingdownorstandingup.
–Beforesittingdownorstandingup,turnthe
frontcastorssothatthelockispointing
forwards.
–Neverstandonthefootrests.
–Donotleanexcessivelyforwards.
–Onlypushtheseateduseronthecommode
whentheseatframeandbackrestaresetinan
uprightposition.
–Onlytransfertheuserfromortothecommode
whentheseatframeandbackrestaresetinan
uprightposition.
–Neverremovethepneumaticsprings(Ocean
DualVIPErgoonly).
WARNING!
Riskofinjury!
–BeforeusingtheVariableSoftSeat(optional
accessory),thelateralcovers(part-no.
AP1605002)havetobeinstalled.
WARNING!
Riskoftippingbackwards!
–TheOceanDualVIPErgomustonlybeusedif
therearantitippersareinstalled.
201639504-C
