Invacare Aquatec Ocean Ergo User manual

enShowerandToiletCommode
UserManual...............................3
deDusch-undToilettenrollstuhl
Gebrauchsanweisung........................31
frChaiseroulantepourdouche/toilettes
Manueld'utilisation.........................61
itCarrozzinadadocciaedatoilette
Manualed’uso..............................91
esSilladeduchaeinodoro
Manualdelusuario.........................121
ptCadeiradeducheesanitária
Manualdeutilização........................151
nlDouche-entoiletstoel
Gebruiksaanwijzing.........................179
elΠροσάρτημαντουςκαιτουαλέτας
Εγχειρίδιοχρήσης..........................209
ThismanualMUSTbegiventotheuseroftheproduct.
BEFOREusingthisproduct,thismanualMUSTbereadandsavedfor
futurereference.
Aquatec® Ocean Ergo / Ocean Ergo XL /
Aquatec® Ocean 24” Ergo / Ocean 24” Ergo XL

©2019InvacareCorporation
Allrightsreserved.Republication,duplicationormodicationinwholeorinpartisprohibited
withoutpriorwrittenpermissionfromInvacare.Trademarksareidentiedby™and®.Alltrademarks
areownedbyorlicensedtoInvacareCorporationoritssubsidiariesunlessotherwisenoted.

Contents
ThismanualMUSTbegiventotheuseroftheproduct.
BEFOREusingthisproduct,thismanualMUSTbereadandsaved
forfuturereference.
1General.........................................4
1.1Introduction..................................4
1.2Symbolsinthismanual..........................4
1.3Warrantyinformation...........................4
1.4Compliance...................................5
1.4.1Product-specicstandards.....................5
1.5Intendeduse..................................5
1.6Servicelife...................................5
2Safety..........................................6
2.1Safetyinformation..............................6
2.2Labelsandsymbolsontheproduct.................6
3Components......................................8
3.1Overview....................................8
4Setup...........................................10
4.1Safetyinformation..............................10
4.2Assemblingtheshowerandtoiletcommode..........10
4.2.1Installingtheseatframetubeforheight
adjustment................................10
4.2.2Installingthebackrest........................12
4.2.3Installing/Removingtheseatplate...............13
4.2.4Adjustingtheheightofthearmrests.............13
4.2.5Installingthefootrests........................14
4.2.6Installing/Removingself-propellingwheels
(optional).................................15
5Accessory(optional)................................16
5.1Fitting/removingthetoiletpanholderandtoiletpan....16
6Usage..........................................18
6.1Safetyinformation..............................18
6.2Swivelingthearmrests..........................19
6.3Swivellingthefootrests..........................19
6.4Engaging/disengagingthecastorlocks...............20
6.5Engaging/disengagingtheparkingbrakes.............20
7Transport........................................22
7.1Safetyinformation..............................22
8Maintenance.....................................23
8.1Maintenanceandinspection......................23
8.2Cleaninganddisinfection.........................23
9AfterUse........................................25
9.1Storage......................................25
9.2Re-use......................................25
9.3Disposal.....................................25
10Troubleshooting..................................26
10.1Identifyingandrepairingfaults...................26
11TechnicalData...................................27
11.1Dimensionsandweight.........................27
11.2Materials....................................29
11.3Environmentalparameters.......................29

Aquatec®OceanErgo/OceanErgoXL/Aquatec®Ocean24”Ergo/Ocean24”ErgoXL
1General
1.1Introduction
Thisusermanualcontainsimportantinformationaboutthe
handlingoftheproduct.Toensuresafetywhenusingthe
product,readtheusermanualcarefullyandfollowthe
safetyinstructions.
Notethattheremaybesectionsinthisdocument,whichare
notrelevanttoyourproduct,sincethisdocumentapplies
toallavailablemodels(onthedateofprinting).Ifnot
otherwisestated,eachsectioninthisdocumentreferstoall
modelsoftheproduct.
Themodelsandcongurationsavailableinyourcountrycan
befoundinthecountry-specicpricelists.
Invacarereservestherighttoalterproductspecications
withoutfurthernotice.
Beforereadingthisdocument,makesureyouhavethe
latestversion.YoundthelatestversionasaPDFonthe
Invacarewebsite.
Ifyoundthatthefontsizeintheprinteddocumentis
difculttoread,youcandownloadthePDFversionfromthe
website.ThePDFcanthenbescaledonscreentoafont
sizethatismorecomfortableforyou.
Formoreinformationabouttheproduct,forexample
productsafetynoticesandproductrecalls,contactyour
Invacarerepresentative.Seeaddressesattheendofthis
document.
1.2Symbolsinthismanual
Symbolsandsignalwordsareusedinthismanualandapply
tohazardsorunsafepracticeswhichcouldresultinpersonal
injuryorpropertydamage.Seetheinformationbelowfor
denitionsofthesignalwords.
WARNING
Indicatesahazardoussituationthatcouldresult
inseriousinjuryordeathifitisnotavoided.
CAUTION
Indicatesahazardoussituationthatcouldresult
inminororslightinjuryifitisnotavoided.
IMPORTANT
Indicatesahazardoussituationthatcouldresult
indamagetopropertyifitisnotavoided.
TipsandRecommendations
Givesusefultips,recommendationsand
informationforefcient,trouble-freeuse.
ThisproductcomplieswithDirective93/42/EEC
concerningmedicaldevices.Thelaunchdate
ofthisproductisstatedintheCEdeclaration
ofconformity.
Manufactureroftheproduct.
1.3Warrantyinformation
Weprovideamanufacturer’swarrantyfortheproduct
inaccordancewithourGeneralTermsandConditionsof
Businessintherespectivecountries.
41639501-B

General
Warrantyclaimscanonlybemadethroughtheprovider
fromwhomtheproductwasobtained.
1.4Compliance
Qualityisfundamentaltothecompany’soperation,working
withinthedisciplinesofISO13485.
ThisproductfeaturestheCEmark,incompliancewiththe
MedicalDeviceDirective93/42/EECClass1.
Wearecontinuouslyworkingtowardsensuringthatthe
company’simpactontheenvironment,locallyandglobally,
isreducedtoaminimum.
WeonlyuseREACHcompliantmaterialsandcomponents.
1.4.1Product-specicstandards
Theproducthasbeentestedandconformstothestandard
ISO17966(Assistiveproductsforpersonalhygienethat
supportusers)andrelatedstandards.Thisincludestesting
concerningammability.Progressivesmoulderingignition
andamingignitiondonotoccur.
Forfurtherinformationaboutlocalstandardsand
regulations,contactyourlocalInvacarerepresentative.See
addressesattheendofthisdocument.
1.5Intendeduse
Theshowerandtoiletcommodeisdesignedexclusivelyas
anaidforshoweringorbathing,goingtothetoilet,foruse
duringpersonalhygiene(e.g.infrontofthebasin)orfor
transferringpatientswhileindoors.Itisintendedtobeused
byyouthandadultpatientswithorwithoutcaregiverˈs
assistance,whohave:
•Difcultystandingorkeepingtheirbalance
•Weaklegsorlowerlimbdisability
•Medicalconditionsthatimpairtheirbalance
Theproductisintendedforinstitutionalandprivatehouse
holduse.Anyotheruseisprohibited.
WARNING!
Riskofinjury
–Neverusetheproductasanaidforgettinginto
oroutofabathtub,forclimbingordescending,
asasupportorforsimilarpurposes.
–Donotusetheproductoutdoors.
Asatoiletcommode,theproductcanbeusedover
astandardtoiletorindependentlywiththetoiletpan
(optional).
Theshowerandtoiletcommodemayonlybeusedasa
bathingstoolinapool,ifthepooldoesnotcontainsalt
waterandanattendantispresentatalltimes.
Temperatureforuse:10-65°C
1.6Servicelife
Theexpectedservicelifeofthisproductisveyearswhen
useddailyandinaccordancewiththesafetyinstructions,
maintenanceintervalsandcorrectuse,statedinthismanual.
Theeffectiveservicelifecanvaryaccordingtofrequency
andintensityofuse.
1639501-B5

Aquatec®OceanErgo/OceanErgoXL/Aquatec®Ocean24”Ergo/Ocean24”ErgoXL
2Safety
2.1Safetyinformation
WARNING!
Riskofinjuryordamage
–Donotusethisproductoranyavailable
optionalequipmentwithoutrstcompletely
readingandunderstandingtheseinstructions
andanyadditionalinstructionalmaterialsuch
asusermanuals,servicemanualsorinstruction
sheetssuppliedwiththisproductoroptional
equipment.
–Ifyouareunabletounderstandthewarnings,
cautionsorinstructions,pleasecontacta
healthcareprofessional,Invacareprovideror
qualiedtechnicianbeforeattemptingtouse
thisproduct.
WARNING!
Riskofinjury
–Donotstandontheproduct.
–Donotuseasaclimbingaid.
–Donotuseoutdoors.
WARNING!
Riskofinjury
–Donotuseifdefective.
–Intheeventofamalfunction,contactyour
providerimmediately.
–Donotmakeanyunauthorizedchangesor
alterationstotheproduct.
–Onlyuseaccessoriesintendedforthisproduct.
IMPORTANT!
Theinformationcontainedinthisdocumentis
subjecttochangewithoutnotice.
2.2Labelsandsymbolsontheproduct
Identicationlabel
Theidenticationlabelcontainsimportantinformation:
(01) 0 4 0 2869 8 1 3 2 5 3 3 ( 2 1 ) 1 8 AVP 3 0 0 0 0 1 ( 0 X)
S
N
OceanErgo
150kg
2018-01
AQUATEC Operations GmbH
Ale ma nne n stra s s e 10
88316 Is ny - Ge rm a ny
4 0 2 8 6 9 8 1 3 2 5 3 3
1604208
R
EF
I
H
G
F
E
C
B
A
D
AProductdesignation
BReferencenumber
61639501-B

Safety
CSerialnumber
DMaximumuserweight
EDateofmanufacture
FReadusermanual
GConformitymark
HNote(useonlyonatsurfaces)
IManufactureraddress
Theidenticationlabelisattachedtotheinsideof
theleftsidepart.
Labelsontheproduct
Thefollowinglabelisattachedtothehandleofthe
backrest:
LabelDescription
WARNING!
Riskoftippingover
–Donotsteponthefootrest
whengettingintooroutofthe
showerandtoiletcommode.
–Pushthefootreststothesides
orfoldupthefootplatesbefore
gettingintooroutoftheshower
andtoiletcommode.
–Beforesittingdownorstanding
up,turnthecastorssothatthe
lockispointingforwards.
–Donotleantoofarforwards
whensittingintheshowerand
toiletcommode.
1639501-B7

Aquatec®OceanErgo/OceanErgoXL/Aquatec®Ocean24”Ergo/Ocean24”ErgoXL
3Components
3.1Overview
Thefollowingcomponentsareincludedwithinthescope
ofdelivery:
ASidepartwithcastors(leftandright)
BBackrestwithbackrestcoverandarmrests
CSeatframe
DSeat
EFootrestwithheelstrap(leftandright)
FClips(2x)forfootrest(inserted)
GClips(4x)forseatframe
HScrewsandwashers(4x)
IBasestabilisationtubewithscrews(4x),washers
(8x)andnuts(4x)-OceanXLonly
JPushbar
KUsermanual
LAllenkeyAF4
Thefollowingpartsareincludedwithinthescopeofdelivery
oftheself-propellingwheelswithparkingbrake:
D
ASelf-propellingwheels(2x)
BParkingbrakes(2x)withscrews(4x),washers(4x)
andnuts(4x)
81639501-B

Components
CHubsinc.axlesandwashersandnuts(2x)
DAssemblyinstruction
Notethechangeindimensionswhenthe
self-propellingwheelsaretted.Fordetailssee
chapterTechnicalData.
Accessory—Toiletpanholderwithtoiletpan
AToiletpanholder
BToiletpan
CLid
1639501-B9

Aquatec®OceanErgo/OceanErgoXL/Aquatec®Ocean24”Ergo/Ocean24”ErgoXL
4Setup
4.1Safetyinformation
WARNING!
–Checkthepartsfortransportdamagebefore
commissioningandcontactyourproviderif
required.
–Ensureduringassemblythatthepartsare
positionedcorrectlywithrespecttoone
another.
–Self-lockingscrews/nutsorthread-locking
adhesiveareusedforseveralconnections.If
theseareloosened,theymustbereplacedby
newself-lockingscrews/nutsortheymustbe
securedusingnewthread-lockingadhesive.
4.2Assemblingtheshowerandtoiletcommode
Thissectiondescribestheassembly.Disassemblytakesplace
inthereverseorder.
Thearmrestheight,footrestheight,footrestangle,
heelstrap,tensionofbackrestcoverandaccessories
mustbeadjustedtooptimallyttheuser.
4.2.1Installingtheseatframetubeforheightadjustment
1.RemovetheenclosedclipsFfromthebag.
2.Placetheseatframeonitsside.
IMPORTANT
–Pushthesidepartevenlyontotheframeand
donottwist.
–Securethesidepartatthesameheight,front
andrear.
3.PushthesidepartAwiththeguidesforthefootrests
DforwardsontheseatframeB.
Makesurethattheidenticationlabelisattachedto
theinsideoftheleftsidepart.
Makesurethattheorientationoftheseatframeis
correct(seegraphicinchapter3.1).
101639501-B

Setup
4.BringtheclipmountsConthefrontandbackofthe
sidepartinlinewithaholeintheseatframeE.
5.InserttheclipsFfromtheoutsideintothesidepart,
untiltheclipedgesGenclosetheseatframetubeB.
IMPORTANT
–Ensurethattheleftandtherightsidepartsare
settothesameheight.
6.Turntheseatframeandrepeattheprocedureonthe
secondsidepart.
7.Settheseatframewiththettedsidepartsonits
wheels.
Adjustingtheseatheight
WARNING!
–Theseatheightmustbeadjustedtothesame
heightonbothsides.
–Donotadjusttheseatheightwhensomeoneis
sittingontheshowerandtoiletcommode.
1.Raisetheshowerandtoiletcommodeslightlyonone
sidebytheseatframeB.
2.RemovebothclipsFonthisside.
3.PulltheseatframeoutofthesidepartAorpushit
intothesideparttoadjusttheseatheight.
4.Pushbothclipsbackincompletely.
5.Repeatstep1-4ontheotherside.
Theseatheightcanbeadjustedtoaccommodate
differentsituationsofusee.g.transferfromabed
orawheelchairoruseaboveatoiletetc.
Installingthebasestabilizationtube(OceanErgoXLonly)
1.InstallthebasestabilizationtubeAusingthescrews
andnutsBsuppliedbetweenthesidepartsC.Make
surethestabilizationtubeisfacingupwards.
2.Tightenthescrewswithatorqueof5Nm.
1639501-B11

Aquatec®OceanErgo/OceanErgoXL/Aquatec®Ocean24”Ergo/Ocean24”ErgoXL
4.2.2Installingthebackrest
1.Pushdownallfourfootpedalsofthecastorstolock
them.
2.PushthebackrestDfromtherearsideontotheseat
frameE,untilthecollarCtouchestheseatframe
tubeF.
IMPORTANT!
–FirmlytightenthescrewsusingtheAllenkey
supplied.
–Checkthescrewsregularlytoensuretheyare
fastenedsecurely.
3.PositionawasherBoneachscrewAandsecurethe
backrestoneachside.
4.Tightenthescrewswithatorqueof5Nm.
Adjustingthebackrestcover
Thetensionofthebackrestcovercanbeadjustedasneeded.
WARNING!
–Makesurethatatleastthreebeltsarealways
passedaroundthebackrestframe(onthe
outside)andtheirbeltbucklesarefastened.
Tightening:
1.PullthebeltsAofthebackrestcovertighter.
Loosening:
1.OpenthebucklesBbysqueezingtheretaininglugs
together(arrows).
2.Pushthebeltsbackalittlethroughthebuckle.
3.Fastenthebeltbuckles.
4.Retightenthebeltsgently.
121639501-B

Setup
WARNING!
Riskofinjuryduetodamagedbackrestbuckles!
Checkforsecurefasteningofthebackrest
buckleseachtimetheproductismaintainedor
reconditioned.
–Checkallbuckleclipsforsecurefasteningby
closingthebucklesandpullingonbothends.
–Replacethebackrest/backrestbucklesifa
buckleopensundertheappliedforce.
4.2.3Installing/Removingtheseatplate
Installing:
1.Placetheseatplateontheseatframewiththecutout
tothefront.
2.Withyourhandat,presstheseatplatedownatthe
sidesandthenatthefrontandbackuntiltheseatplate
snapsontotheseatframe.
Removing:
1.Pulltheseatplateupwardsattherear.
4.2.4Adjustingtheheightofthearmrests
1.Onthebackrestcover,openthethirdbuckleofthebelt
andloosentheotherbelts.
Thenutsareinsertedlooselyinthesecuringclamp
andcanfallout.
2.UnscrewthescrewsBofthearmrestbracketAusing
theAllenkeysupplied.
3.RemovethesecuringclampDwiththenutsfromthe
insideofthebackrestframe.
4.RemovethebackrestbracketAwiththearmrestand
moveitupwards.
Thesmallerholeservestoxthesecuringclamp.
5.Insertthescrewsinthearmrestbracketandguidethem
throughtheholesinthebackrestframe.
6.Ifrequired,putthenutsbackintothesecuringclamp.
7.Placethesecuringclamponthebackrestframeinserting
thexationpinintothesmallerhole.
8.Turnthescrewsinthenutsandtighten.
1639501-B13

Aquatec®OceanErgo/OceanErgoXL/Aquatec®Ocean24”Ergo/Ocean24”ErgoXL
9.Movethebackrestcoversothatthethirdbeltruns
eitheraboveorbelowthearmrest.
10.Passthethirdbeltofthebackrestcoverontheoutside
ofthebackrestframe,closeandtightenallbelts.
11.Theheightadjustmentprocedureisthesameforthe
rightandleftarmrest
Toattachaccessories,thethirdbeltfromabovecan
beopenedandthebackrestcovercanbepassedby
thebackrestframeontheinside.
4.2.5Installingthefootrests
1.InsertthepinoftheclipGfromtheoutsideintothe
requiredholeonthefootrestB.Makesuretheclip
engagesaroundthetube.
2.PushthefootrestintotheguideHatthefrontofthe
sidepartuntilthepinofclipGengagesinthegroove
A.Thefootrestcannolongerbeturnedtotheside.
Theassemblyprocedureisthesamefortheright
andtheleftfootrest.
Adjustingtheheightofthefootrests
Thefootrestscanbeshortenedifrequired(referto
theservicemanual).Shorteningthefootrestsmust
beperformedbyaqualiedtechnician.
1.SlightlypullupthefootrestB.
2.PulltheclipGoutoftheholeinthefootrestand
re-insertitintotherequiredhole.Pulloutthefootrest
slightlyfurtherifnecessary.
3.PushdownthefootrestuntilthegrooveAcatchesthe
pinoftheclip.
4.Settheotherfootresttotherequiredheightas
described.
Adjustingtheinclinationofthefootplates
Theinclinationofthefootplatescanbeadjusted
innitelyvariably.
1.LoosentheAllenscrewConthefootplateusingasize
4Allenkey.
2.TurnthefootplateDtotherequiredposition.
3.Re-tightentheAllenscrew.
141639501-B

Setup
4.2.6Installing/Removingself-propellingwheels(optional)
IMPORTANT!
–Whentheself-propellingwheelsaretted,the
rearcastorsmustremainlocked.
–Thehubsandtheparkingbrakesforthe
self-propellingwheelsmustbettedbya
qualiedtechnician.Assemblyisdescribedin
theassemblyinstructions“Assemblingthehubs
andbrakesforAquatec®Ocean24"wheels“.
1.Alignallfourcastorsinthedrivingdirection.
2.Lockallcastors.
3.PushtheaxleDontheself-propellingwheelinwards.
(Thehandrimsprojectoutwards.)
4.PressandholdthebuttonFontheoutsideoftheaxle.
ThisreleasestheretainingballsCattheendoftheaxle.
5.Raisetheshowerandtoiletcommodeslightly.
6.InserttheaxleintothehubBandpushinthe
self-propellingwheelontotheaxleuntiltheendstopE.
7.ReleasethebuttonF.
8.CheckthattheretainingballsarebehindthehexnutA.
9.Theassemblyisthesamefortherightandleft
self-propellingwheel.
Toremovethewheels,carryoutthesameprocedurein
thereverseorder.
1639501-B15

Aquatec®OceanErgo/OceanErgoXL/Aquatec®Ocean24”Ergo/Ocean24”ErgoXL
5Accessory(optional)
WARNING!
Riskofinjury
–Theassemblyofaccessories(optional)must
becarriedoutaccordingtothecorresponding
instructions.
5.1Fitting/removingthetoiletpanholderand
toiletpan
ThetoiletpanFcanbeinserted/removedwithor
withoutthelidG.
1.RemovetheseatBfromtheframeA.
2.PositiontheendsofthetoiletpanholderCintothe
holesoftherearcrosstubeE.
3.Engagethefrontpartofthetoiletpanholderwiththe
frontcrosstubeD.
4.Re-ttheseattotheframe.
5.Placethelidonorremoveitfromthetoiletpan.
6.HoldthetoiletpanbyitshandleHandinsertfromthe
rearsidebetweenthetoiletpanholderandtheseat.
Slightlypushdownthetoiletpanwheninsertingor
removing.
Thelidcanbehungontheplastichookatthe
undersideofthetoiletpanhandle.
Thereisalllevelindicatorontheinnerwallof
thetoiletpan.
161639501-B

Accessory(optional)
1639501-B17

Aquatec®OceanErgo/OceanErgoXL/Aquatec®Ocean24”Ergo/Ocean24”ErgoXL
6Usage
6.1Safetyinformation
WARNING!
–Onlyusetheshowerandtoiletcommodeona
atsurfaceandindoors.
–Observethespecicationsontheidentication
label.Donotoverloadtheshowerandtoilet
commode.
–Observethesafetylabelonthehandleof
thebackrest,2.2Labelsandsymbolsonthe
product,page6
–Donotplaceexcessiveweightontheshower
andtoiletcommode.
–Alwaysperformavisualinspectionofthe
productforexternaldamagebeforeeachuse.
–Regularlycheckthefunctionoftheparking
brake(self-propellingwheelsoptiononly).
WARNING!
Riskofslippingandrolling
–Beforeuse,makesurethattheseatissecurely
fastenedtotheseatframe.
–Lockallcastorswithleversusingthefootlevers
beforesittingdownontheshowerandtoilet
commodeorstandingupfromit,aswellas
intheparkingposition.
–Applytheparkingbrakewhentheself-propelling
wheelsaretted(optional).
WARNING!
Riskoftipping
–Swivelthefootreststothesideorfoldupthe
footplatesbeforesittingdownorstandingup.
–Beforesittingdownorstandingup,turnthe
frontcastorssothatthelockispointing
forwards.
–Neverstandonthefootrests.
–Donotleanexcessivelyforwards.
WARNING!
Riskoftipping
–Theshowerandtoiletcommodemustonly
bemovedbyusingthepushbarorthe
self-propelledwheels(optional).
CAUTION!
Riskofburningyourskin
Theproductcomponentscanheatupwhen
exposedtoexternalsourcesofheat.
–Considerheatedupsurfaceswhenusingthe
showerandtoiletcommodeinthesaunaor
whenitisexposedtohotwater.
–Donotexposetheproducttodirectsunlight
beforeuse.
181639501-B

Usage
CAUTION!
Riskofpinchingorcrushing
Theremaybeaverysmallgapbetweentherear
wheelandtheparkingbrakewiththeriskof
trappingngers.
–Keepngersawayfrommovablepartswhen
usingthebrake,alwayskeephandonthebrake
lever.
CAUTION!
Riskofpinching
–Whenusingtheself-propellingwheels
(optional),donotinsertngersbetweenthe
spokesorbetweentherotatingself-propelling
wheelsandtheseatframewhilemoving.
IMPORTANT!
Riskofdamagetotheproduct
–Donotlifttheshowerandtoiletcommode
usingthefootrests,armrestsoranyaccessories.
Foruserswithhighriskofstandingonthe
footrests(e.g.dementia),frontantitippers(part
no.AP1601986)areavailableasaccessoriesto
preventtheshowerandtoiletcommodefromtipping
forward.
6.2Swivelingthearmrests
CAUTION!
Riskofgettingngerscaughtinthefolding
mechanism
–Donotinsertngersinthearticulatedjoint
whenfoldingthearmrestsupordown.
–Donotinsertngersbetweenthearmrestand
thebackrestwhenfoldingbackthearmrests.
–Makesurethatnopartsgetcaughtinthe
joints.
6.3Swivellingthefootrests
Entryposition/exitposition:
1.SlightlypullupthefootrestAintheguideBuntilthe
pinofclipDnolongerengagesinthegrooveC.
2.Swivelthefootresttotheside.
1639501-B19

Aquatec®OceanErgo/OceanErgoXL/Aquatec®Ocean24”Ergo/Ocean24”ErgoXL
Drivingposition:
CAUTION!
Riskofaccidentduetoloosefootrest
–Fixfootrestsinthedrivingposition.
1.TurnthefootrestAinwards.
2.Pushthefootrestdownward,untilthepinoftheclipD
engagesinthegrooveC.
Alternatively,thefootplatesGcanbeswivelled
upwardstoenter/exittheshowerandtoilet
commode.
Removing/ttingtheheelstrap
1.OpenthehookandloopstripEontheheelstrap.
2.RemovethescrewFfromtheundersideofthefoot
plate.
3.Removetheheelstrapfromtheexibleplasticpin.
Toattachthestrap,carryoutthesameprocedure
inthereverseorder.
Wheninstallingensurethatthehookandloopstrip
oftheheelstrapisfacingbackwards.
6.4Engaging/disengagingthecastorlocks
CAUTION!
Riskoftrapping/squeezing
Allcastorlocksarefoot-operated.
–Donotoperatethecastorlocksbyhand.
1.Tolockthecastorlocksstepontherearendofthe
pedalAuntilitengages.
2.Tounlockthecastorlockssteponthefrontendofthe
pedaluntilitdisengages.
Castorwithbluelever(option)isusedtoengagethe
directionlockforeasierstraightmovement.
6.5Engaging/disengagingtheparkingbrakes
Theparkingbrakesareusedtoimmobilisetheshowerand
toiletcommodewith24”wheelstopreventitfromrolling
awaywhenitisstationary.
201639501-B
