Invacare®ActionVertic
enMediumactivewheelchair
UserManual
ThismanualMUSTbegiventotheuseroftheproduct.
BEFOREusingthisproduct,thismanualMUSTbereadandsavedfor
futurereference.

©2019InvacareCorporation
Allrightsreserved.Republication,duplicationormodicationinwholeorinpartisprohibited
withoutpriorwrittenpermissionfromInvacareCorporation.Trademarksareidentiedby™and®.
AlltrademarksareownedbyorlicensedtoInvacareCorporationoritssubsidiariesunlessotherwise
noted.

Contents
1General.........................................5
1.1Introduction..................................5
1.2Symbolsinthismanual..........................5
1.3WarrantyInformation...........................6
1.4LimitationofLiability............................6
1.5StandardsandRegulations........................6
1.6Intendeduse..................................6
1.7Servicelife...................................7
2Safety..........................................8
2.1Safetyinformation..............................8
2.2Safetyinformationonelectromagneticinterference.....9
2.3Safetyinformationonchangesandmodications.......10
2.4Safetydevices.................................12
2.5Labelsandsymbolsontheproduct.................12
3Componentsandtheirfunctions......................14
3.1Overview....................................14
3.2Parkingbrakes.................................15
3.3Backrest.....................................16
3.3.1Backrestcover..............................16
3.4Armrests.....................................16
3.4.1Tubulararmrest.............................17
3.5Legrests.....................................17
3.5.1Onepiecefootboard.........................17
3.6ChestandKneecushions.........................18
3.7Anti-tipper...................................19
3.8Pushhandle..................................20
3.9Tires........................................21
3.10Seatcushion.................................21
4Accessories......................................22
4.1Posturebelt..................................22
4.2Tabletray....................................23
4.3Airpump....................................24
4.4Passiveillumination.............................24
5Setup...........................................25
5.1Safetyinformation..............................25
6Usingthewheelchair...............................26
6.1Safetyinformation..............................26
6.2Brakingduringuse.............................27
6.3Moveto/fromthewheelchair.....................27
6.4Drivingandsteeringthewheelchair.................28
6.5Negotiatingstepsandkerbs......................29
6.6Goingupanddownstairs........................31
6.7Negotiatingrampsandslopes.....................32
6.8Stabilityandbalancewhenseated..................33
6.9Verticalpositioning.............................34
6.10Batterycharging..............................37
7Transport........................................39
7.1Safetyinformation..............................39
7.2Foldingandunfoldingthewheelchair...............39
7.3Liftingthewheelchair...........................40
7.4Removingandttingtherearwheels...............40
8Maintenance.....................................42
8.1Safetyinformation..............................42
8.2MaintenanceSchedule..........................42
8.3Cleaning.....................................44
8.4Disinfection...................................45
9Troubleshooting...................................46
9.1Safetyinformation..............................46
9.2Identifyingandrepairingfaults....................47
10AfterUse.......................................48
10.1Storage.....................................48
10.2Re-use.....................................48
10.3Disposal....................................48
11TechnicalData...................................49
11.1Dimensionsandweight.........................49

11.2Materials....................................50
11.3Environmentalconditions........................50
12Service.........................................51
12.1Inspectionsperformed..........................51

General
1General
1.1Introduction
Thisusermanualcontainsimportantinformationaboutthe
handlingoftheproduct.Toensuresafetywhenusingthe
product,readtheusermanualcarefullyandfollowthe
safetyinstructions.
Notethattheremaybesectionsinthisdocument,whichare
notrelevanttoyourproduct,sincethisdocumentapplies
toallavailablemodels(onthedateofprinting).Ifnot
otherwisestated,eachsectioninthisdocumentreferstoall
modelsoftheproduct.
Themodelsandcongurationsavailableinyourcountrycan
befoundinthecountry-specicpricelists.
Invacarereservestherighttoalterproductspecications
withoutfurthernotice.
Beforereadingthisdocument,makesureyouhavethe
latestversion.YoundthelatestversionasaPDFonthe
Invacarewebsite.
Ifyoundthatthefontsizeintheprinteddocumentis
difculttoread,youcandownloadthePDFversionfromthe
website.ThePDFcanthenbescaledonscreentoafont
sizethatismorecomfortableforyou.
Formoreinformationabouttheproduct,forexample
productsafetynoticesandproductrecalls,contactyour
Invacarerepresentative.Seeaddressesattheendofthis
document.
Incaseofaseriousincidentwiththeproduct,youshould
informthemanufacturerandthecompetentauthorityin
yourcountry.
1.2Symbolsinthismanual
Symbolsandsignalwordsareusedinthismanualandapply
tohazardsorunsafepracticeswhichcouldresultinpersonal
injuryorpropertydamage.Seetheinformationbelowfor
denitionsofthesignalwords.
WARNING
Indicatesahazardoussituationthatcouldresult
inseriousinjuryordeathifitisnotavoided.
CAUTION
Indicatesahazardoussituationthatcouldresult
inminororslightinjuryifitisnotavoided.
IMPORTANT
Indicatesahazardoussituationthatcouldresult
indamagetopropertyifitisnotavoided.
TipsandRecommendations
Givesusefultips,recommendationsand
informationforefcient,trouble-freeuse.
ThisproductcomplieswithDirective93/42/EEC
concerningmedicaldevices.Thelaunchdate
ofthisproductisstatedintheCEdeclaration
ofconformity.
Manufactureroftheproduct.
1648806-B.005

Invacare®ActionVertic
1.3WarrantyInformation
Weprovideamanufacturer’swarrantyfortheproduct
inaccordancewithourGeneralTermsandConditionsof
Businessintherespectivecountries.
Warrantyclaimscanonlybemadethroughtheprovider
fromwhomtheproductwasobtained.
1.4LimitationofLiability
Invacareacceptsnoliabilityfordamagearisingfrom:
•Non-compliancewiththeusermanual
•Incorrectuse
•Naturalwearandtear
•Incorrectassemblyorset-upbythepurchaserora
thirdparty
•Technicalmodications
•Unauthorisedmodicationsand/oruseofunsuitable
spareparts
1.5StandardsandRegulations
Qualityisfundamentaltothecompany’soperation,working
withinthedisciplinesofISO13485.
Thevehiclewassuccessfullytestedaccordingtointernational
standardsastoitssafety.Itsatisestherequirements
accordingtoRoHS2011/65/EU,REACH1907/2006/EC,EN
12183includingatestforammability(EN1021-2orISO
8191–2)andISO7176–14.Itwasalsotestedsuccessfully
accordingtoEN60529IPX4astoitsresistancetospray
water,andisthereforewellsuitedforweatherconditions
suchastypicalEuropeanweatherconditions.
1.6Intendeduse
Themediumactivewheelchairispropelledmanuallyand
shouldonlybeusedforindependentorassistedtransport
ofadisabledpersonwithmobilitydifculties.Thismanual
wheelchairisintendedtoprovidemobilitytopersons
ages15andup(adolescentsandadults)withamaximum
weightcapacityof115kg.Thedeviceisindicatedto
providemobilitytopersonslimitedtosittingposition.Itis
intendedforactiveuserswhowishtopositionthemselves
verticallyduringthedayformedicalorprofessionalreasons.
Whenusedwithoutanassistant,itshouldonlybeusedby
personswhoarephysicallyandmentallyabletousethe
wheelchairsafely(e.g.topropelthemselves,steer,brake).
Thewheelchairshouldonlybeusedonlevelgroundand
accessibleterrain,aswellasindoors.
Thismediumactivewheelchairneedstobe
subscribedandttoyourspecichealthcondition.
Itisimportantthatyoucomplywiththevertical
positioningprotocol(duration,frequency,posture,
maximumverticalityangle,…)whichhasbeen
prescribedbyyourphysicaltherapist.
WARNING!
Anyotherorincorrectusecouldleadto
hazardoussituations.
Therearenocontraindicationsknown,whenusingthe
wheelchairasintended.
61648806-B.00

General
CAUTION!
–Insomecongurations,theoveralldimensions
ofthewheelchairwhenitisreadyforuse
exceedtheauthorizedlimits,theaccessto
emergencyescaperoutesisnotpossible.
–Insomecongurations,thewheelchairexceed
thesizerecommendedfortravellingbytrain
intheEU.
Theftandmetaldetectionsystems:inseldomcases
thematerialsusedinthewheelchairmayactivate
theftandmetaldetectionsystems.
1.7Servicelife
Theexpectedservicelifeofthisproductisveyearswhen
useddailyandinaccordancewiththesafetyinstructions,
maintenanceintervalsandcorrectuse,statedinthismanual.
Theeffectiveservicelifecanvaryaccordingtofrequency
andintensityofuse.
1648806-B.007

Invacare®ActionVertic
2Safety
2.1Safetyinformation
Thissectioncontainsimportantsafetyinformationforthe
protectionofthewheelchairuserandassistantandforsafe,
trouble-freeuseofthewheelchair.
WARNING!
Riskofaccidentsandseriousinjury
Accidentswithresultingseriousinjurycanoccur
ifthewheelchairiswronglyadjusted.
–Adjustmentsatthewheelchairalwaysmustbe
carriedoutbyanauthorizeddealer .
WARNING!
Riskduetodrivingstylebeingunsuitablefor
theconditions
Thereisariskofskiddingonwetground,gravel
oruneventerrain.
–Alwaysadjustyourspeedanddrivingstyleto
theconditions(weather,surface,individual
ability,etc.).
WARNING!
Riskofinjury
Inacollisionyoucouldsustaininjurytopartsof
yourbodythatextendbeyondthewheelchair
(e.g.feetorhands).
–Avoidanunbrakedcollision.
–Neverdriveintoanobjecthead-on.
–Drivecarefullythroughnarrowpassages.
WARNING!
Riskduetowheelchairbeingoutofcontrol
Athighspeedyoucouldlosecontrolofyour
wheelchairandoverturn.
–Neverexceedaspeedof7km/h.
–Avoidcollisionsingeneral.
WARNING!
Riskoftilting
Thepositionoftherearwheelaxleandtheangle
ofyourwheelchair’sbackrestaretwoofthekey
adjustmentsthatcanaffectyourstabilitywhilst
sittinginthewheelchair .
–Thesechanges,anyfrontwheelsposition
and/orangleforkadjustmentstotheset-upof
yourwheelchairmustonlybeperformedatthe
directionofacompetentpersonwhohasfully
riskassessedtheimplicationofanychanges
tothewheelchairconguration.Therefore,
consultwithyourdistributor .
CAUTION!
Riskofburning
Thewheelchaircomponentscanheatupwhen
exposedtoexternalsourcesofheat.
–Donotexposethewheelchairtostrongsunlight
beforeuse.
–Beforeusage,checkallcomponentsthat
comeintocontactwithyourskinfortheir
temperature.
81648806-B.00

Safety
WARNING!
Riskofinjuryduringtransport
Thewheelchairisnotapprovedtobetransported
invehicles,usingtheordinaryattachmentpoints.
–Donottransferthewheelchaireitheroccupied
orunoccupiedinvehiclesusingtheordinary
attachmentpoints.
–Transportthewheelchairasluggage,for
exampleinthetrunkofavehicle.
WARNING!
WheelchairTieDownRestraints
–WheelchairusersshouldNOTbetransportedin
vehiclesofanykindwhileinwheelchairs.As
ofthisdate,theDepartmentofTransportation
hasnotapprovedanytie-downsystemsfor
transportationofauserwhileinawheelchair,
inamovingvehicleofanytype.
–ItisInvacare’spositionthatusersofwheelchairs
shouldbetransferredintoappropriateseating
invehiclesfortransportationandusebe
madeoftherestraintsmadeavailablebythe
autoindustry.Invacarecannotanddoesnot
recommendanywheelchairtransportation
systems.
CAUTION!
Riskofgettingngerscaught
Thereisalwaysariskofgetting,e.g.ngers
orarms,caughtinthemovingpartsofthe
wheelchair.
–Makesurewhenactivatingthefoldingor
insertionmechanismsofmovingparts,suchas
theremovableaxleoftherearwheel,folding
backrestorantitipper,thatnothingbecomes
caught.
CAUTION!
Riskoftipping
Thehangingofadditionalload(backpackor
similaritems)ontoyourchairbackpostscanaffect
therearwardstabilityofyourchair,especially
whenusedincombinationwithreclinerbackrests.
–Invacarestronglyrecommendtheuseof
anti-tippers(availableasanoption)whenusing
yourbackpostswithadditionalload.
2.2Safetyinformationonelectromagnetic
interference
Thiswheelchairwassuccessfullytestedinaccordance
withInternationalstandardsastoitscompliancewith
ElectromagneticInterference(EMI)regulations.However,
electromagneticelds,suchasthosegeneratedbyradioand
televisiontransmitters,andcellularphonescaninuence
thefunctionsofwheelchairswithelectricdevice.Also,the
electronicsusedinourwheelchairscangeneratealowlevel
ofelectromagneticinterference,whichhoweverwillremain
1648806-B.009

Invacare®ActionVertic
withinthetolerancepermittedbylaw.Forthesereasonswe
askyoutopleaseobservethefollowingprecautions:
WARNING!
Riskofmalfunctionduetoelectromagnetic
interference
–Donotswitchonoroperateportable
transceiversorcommunicationdevices(suchas
radiotransceiversorcellularphones)whenthe
electricdeviceisswitchedon.
–Avoidgettingnearstrongradioandtelevision
transmitters.
–Addingelectricalaccessoriesandother
componentsormodifyingtheelectricdevice
inanywaycanmakeitsusceptibleto
electromagneticinterference.Keepinmind
thatthereisnosurewaytodeterminethe
effectsuchmodicationswillhaveonthe
overallimmunityoftheelectronicsystem.
–Reportalloccurrencesofunintentional
movementoftheelectricdevicetoyour
authorizeddealer .
2.3Safetyinformationonchangesand
modications
WARNING!
Riskofseriousinjuryordamage
Useofincorrectorimproperreplacement
(service)partsmaycauseinjuryordamage
–ReplacementpartsMUSTmatchoriginal
Invacareparts.
–Alwaysprovidethewheelchairserialnumberto
assistinorderingthecorrectreplacementparts.
101648806-B.00

Safety
CAUTION!
Riskofinjuriesanddamageduetounapproved
componentsandaccessoryparts
Seatingsystems,additionsandaccessoryparts
whichhavenotbeenapprovedbyInvacarefor
usewiththismobilitydevicecanaffectthe
tippingstabilityandincreasetippinghazards.
–Onlyeveruseseatingsystems,additionsand
accessorypartswhichhavebeenapprovedby
Invacareforthismobilitydevice.
Seatingsystemswhicharenotapprovedby
Invacareforusewiththismobilitydevicedo
not,undercertaincircumstances,complywith
thevalidstandardsandcouldincreasethe
ammabilityandtheriskofskinirritation.
–Onlyuseseatingsystemsthathavebeen
approvedbyInvacareforthismobilitydevice.
Electricalandelectroniccomponentswhichhave
notbeenapprovedbyInvacareforusewiththis
mobilitydevicecancauserehazardsandlead
toelectromagneticdamage.
–Onlyeveruseelectricalandelectronic
componentswhichhavebeenapprovedby
Invacareforthismobilitydevice.
Batterieswhichhavenotbeenapprovedby
Invacareforusewiththismobilitydevicecan
causechemicalburns.
–Onlyeverusebatterieswhichhavebeen
approvedbyInvacareforthismobilitydevice.
CAUTION!
Riskofinjuries,anddamage,ifunapproved
backrestsareused
Aretrottedbackrestwhichisnotapprovedby
Invacareforusewiththismobilitydevicemay
overloadthebackresttubeandthusincreasethe
riskofinjuriesandofdamagetothemobility
device.
–Pleasecontactyourauthorizeddealerwhowill
performriskanalyses,calculations,stability
checksetc.toensurethatthebackrestcanbe
usedsafely.
CEmarkingofthemobilitydevice
–Theconformityassessment/CEmarkingwas
carriedoutinaccordancewithDirective93/42
EECandonlyappliestothecompleteproduct.
–TheCEmarkingisinvalidatedifcomponentsor
accessoriesarereplacedoraddedthathave
notbeenapprovedforthisproductbyInvacare.
–Inthiscase,thecompanythataddsorreplaces
thecomponentsoraccessoriesisresponsible
fortheconformityassessment/CEmarkingor
forregisteringthemobilitydeviceasaspecial
designandfortherelevantdocumentation.
1648806-B.0011

Invacare®ActionVertic
2.4Safetydevices
WARNING!
Riskofaccidents
Safetydevicesthatareincorrectlysetornolonger
working(brakes,antitipper)cancauseaccidents.
–Alwayscheckthatthesafetydevicesare
workingbeforeyouusethewheelchairand
havethemcheckedregularlybytheauthorized
dealer.
Thefunctionsofthesafetydevicesaredescribedinchapter
ProductOverview.
2.5Labelsandsymbolsontheproduct
Identicationlabel
Theidenticationlabelisattachedtotheframeofyour
wheelchairandgivesthefollowinginformation:
AManufacturer’saddress
BProductdescription
CDateofmanufacture
DCEmark
EMaximumuserweight
FPartnumber
GSerialnumberbarcode
HSerialnumber
I“crossedoutwheeliebin”
121648806-B.00

Safety
Readusermanual
Indicatesahazardoussituationthatcould
resultinseriousinjuryordeathifitisnot
avoided.
Snaphooksymbols
WARNINGSymbol
Thiswheelchairisnotconguredfor
passengertransportinamotorvehicle.This
symbolisattachedtotheframeclosetothe
identicationlabel.
WEEEconform
Thisproductmaycontainsubstancesthat
couldbeharmfultotheenvironmentif
disposedofinplaces(landlls)thatarenot
appropriateaccordingtolegislation.
The“crossedoutwheeliebin”symbolis
placedonthisproducttoencourageyouto
recyclewhereverpossible.
Electricalshockprotection
TypeBappliedpart
AccordingtoIEC60601–1,complywith
protectionagainstelectricalshockspecied
requirements
1648806-B.0013

Invacare®ActionVertic
3Componentsandtheirfunctions
3.1Overview
AChestcushion
BBack
CRearwheelwithhandrim
DParkingbrake
EFrame
FFrontwheelforkwithfrontwheel
GOnepiecefootboard
HKneecushion
ISeat/Cushion
JRaising/loweringbutton
KTubularArmrest
Shortdescription
Thisisamediumactivewheelchairwithstandupmechanism
andfoldedbackrest.
Theequipmentofyourwheelchairmaydifferfrom
thediagramaseachwheelchairismanufactured
individuallytothespecicationsintheorder.
141648806-B.00

Componentsandtheirfunctions
3.2Parkingbrakes
Theparkingbrakesareusedtoimmobilizethewheelchair
whenitisstationarytopreventitfromrollingaway.
WARNING!
Riskofoverturningifyoubrakesharply
Ifyouapplytheparkingbrakeswhileyouare
moving,thedirectionofmovementcanbecome
uncontrollableandthewheelchairmaystop
suddenly,whichcanleadtoacollisionortoyou
fallingout.
–Neverapplytheparkingbrakeswhileyouare
moving.
WARNING!
Riskduetowheelchairbeingoutofcontrol
–Theparkingbrakesmustbeoperated
simultaneously.
–Donotapplytheparkingbrakestoslowdown
thewheelchair .
–Donotleanontheparkingbrakesforsupport
ortransfer.
WARNING!
Riskofoverturning
Theparkingbrakeswillnotoperatecorrectly
unlessthereissufcientairinthetires.
–Ensurethecorrecttirepressure,3.9Tires,page
21.
CAUTION!
Riskofpinchingorcrushing
Theremaybeaverysmallgapbetweentherear
wheelandtheparkingbrakewiththeriskthat
youcouldtrapyourngers.
–Keepyourngersawayfrommovableparts
whenusingthebrake,alwayskeepyourhand
onthebrakelever .
Thedistancebetweenthebrakeshoeandthetire
canbeadjusted.Theadjustmentmustbecarried
outbyanauthorizeddealer .
Standardbrake
1.Toapplythebrake,pushthebrakeleverforwardsas
faraspossible.
2.Toreleasethebrake,pullthebrakeleverbackwards.
Theleverofthepushhandlecanbefoldedbackto
facilitatetransfers.Todoso,pulluptheleverand
folditbackwards.
1648806-B.0015

Invacare®ActionVertic
3.3Backrest
Fixedbackrestdonotrequireadjustment.
WARNING!
Riskoftipping
Thehangingofadditionalload(backpack
orsimilaritems)ontoyourwheelchairback
postscanaffecttherearwardstabilityofyour
wheelchair.Thiscancausethechairtotip
backwardscausinginjury.
–Therefore,Invacarestronglyrecommendthe
useofanti-tippers(availableasanoption)
whenusingyourbackpostswithadditional
load(backpackorsimilaritems).
3.3.1Backrestcover
Youcanadjustthetensionofthebackrestcoverasrequired.
Adjustingthebackrestcover
1.RemovethebackrestcushionA.
2.LoosenthehookandloopstripsBontherearofthe
backrestcoverbysimplypullingonthem.
3.Tightenorloosenthestripsasrequiredthenreattach
them.
WARNING!
Riskoftipping
Ifthebandsaresetveryloose,thetippingpoint
ofyourwheelchairischangedfortheworse.
–Ensurethatthebandsaresetcorrectly.
IMPORTANT!
–Donotovertightenthebands;thisistoensure
thatthegeometryofthewheelchairisnot
changed.
3.4Armrests
WARNING!
Thearmrestdoesnotengageintothewheelchair .
–Thereforedonotholditinordertoliftthe
wheelchair.
CAUTION!
Riskofpinching
–Keepyourngersawayfrommovableparts
duringremoving,ttingoradjustingthe
armrest.
161648806-B.00

Componentsandtheirfunctions
3.4.1Tubulararmrest
Folding
1.Applytheparkingbrakeonbothsides.
2.Gripthetubulararmrestbythearmpadandfolditback.
Settingtheheight
1.Looseningthe2screwsAwith5mmAllenkey.
2.Slidetubulararmrestsupporttothedesiredheightand
rmlytightenthe2screws(10Nm)A.
3.Adjustothersideaccordingly,ifrequired.
Invacarerecommendsthattubulararmrestadjustmentis
carriedoutbyanauthorizeddealer.
3.5Legrests
WARNING!
Riskofinjury
–Neverliftthewheelchairbythefootrest
supportsorlegrests.
CAUTION!
Riskofpinchingorcrushingngers
Thereareswingmechanismswhereyoucould
trapyourngers.
–Becarefulwhenusing,swinging,disassembling
oradjustingthesemechanisms.
IMPORTANT!
Riskofdamagetothelegrestmechanism
–Donotplaceanythingheavy,orletchildren
sitonthelegrest.
3.5.1Onepiecefootboard
Angleanddepthadjustment
Theonepiecefootboardhas2anglepositions.
1648806-B.0017

Invacare®ActionVertic
1.UnscrewthelowerlockingscrewsAwith4mmAllen
key.
2.RemovetheupperlockingscrewsAwith4mmAllen
key,sideways.
3.Positiontheonepiecefootboardassemblyintotheone
ofthetwoanglepositions.
4.InserttheupperlockingscrewsAintothepre-setholes
andrmlytightenupperandlowerscrews(10Nm).
Depthadjustment.
1.RemovethetwolockingscrewsAwith4mmAllenkey,
sideways.
2.Positiontheonepiecefootboardassemblyforwardsor
backwardstotheappropriatedepth.
3.InsertthetwolockingscrewsAintothepre-setholes
andrmlytightenthescrews(10Nm).
Heightadjustment
Theonepiecefootboardhasthreeheightadjustment
options.
1.Removecalfstrapifnecessary.
2.RemovethetwolockingscrewsAwith4mmAllenkey,
sideways.
3.Positiontheonepiecefootboardassemblyintooneof
threepresetpositions.
4.InsertthetwolockingscrewsAintothepre-setholes
andrmlytightenthescrews(10Nm)intothedesired
position.
Invacarerecommendsthatangleanddepthadjustmentare
carriedoutbyanauthorizeddealer.
Calfstrapadjustment
Toensureagoodpositionofthefeetthecalfstrap
Aisattachedtothelegrestsupportandadjustable
byhookandloopfasteners,makesuretheyperfectly
overlap.
3.6ChestandKneecushions
Chestandkneecushionscontributetocomfortandgood
postureduringverticalization.
WARNING!
Riskoffalling
Chestandkneecushionsthatareincorrectlyset
orxedcanleadtofalling.
–Alwayscheckthatthecushionsarecorrectly
ttedbeforeusingthewheelchairandhave
themsetorreadjustedbyanauthorizeddealer
whenrequired.
181648806-B.00

Componentsandtheirfunctions
WARNING!
Riskofdiscomfort
–Whenadjustingthetensionofthecheststrap,
makesuretheribcageisnotcompressed
baseduponuser’smorphology.
Alwayscheckthathookandloopfastenersarewell
positionedandmakesuretheyperfectlyoverlap.
Chestcushion
ChestcushionAanditsstrapBinstallationandassessment,
mustbecarriedoutbyanauthorizeddealer .
WARNING!
Riskofinjury
–Theadjustmentsofthechestcushionmustbe
carriedoutbyanauthorizeddealer .
Kneecushion
KneecushionCanditsstrapDinstallationandassessment,
mustbecarriedoutbyanauthorizeddealer .
WARNING!
Riskofinjury
–Theadjustmentsofthekneecushionmustbe
carriedoutbyanauthorizeddealer .
Theseadjustmentsarerequiredwithreferencetothe
user’smorphologyandhisparticularphysicallimits.
Makesurethatthekneecushionisttedcorrectly
oneachside.ThexationsEmustbelockedinto
position.
3.7Anti-tipper
Ananti-tipperpreventsthewheelchairfromtipping
backwards.
WARNING!
Riskofoverturning
Anti-tippersthatareincorrectlysetornolonger
workingcanleadtooverturning.
–Alwayscheckthattheanti-tipperisworking
beforeusingthewheelchairandhaveitset
orreadjustedbyanauthorizeddealerwhen
required.
–Insomecongurations,thestaticstabilityof
thewheelchairmaybelowerthan10°;Invacare
stronglyrecommendstheuseofanti-tipper
(availableasanoption).
1648806-B.0019

Invacare®ActionVertic
WARNING!
Riskofoverturning
Onunevenorsoftground,theanti-tippercansink
intopotholesordirectlyintotheground,thereby
curtailingoreliminatingitssafetyfunction.
–Onlyusetheanti-tipperwhentravellingon
evenandrmground.
Anti–tipperinstallation
Anti-tipperAinstallationmustbecarriedoutbyan
authorizeddealer.
WARNING!
Riskoftipping
Anactivatedanti-tippercancatchwhen
negotiatingasteporanedge.
–Onlyusetheanti-tipperwhentravellingon
levelgroundandatsurfaces.
Settingtheheight
WARNING!
Riskofoverturning
–Theadjustmentsoftheanti-tippermustbe
carriedoutbyanauthorizeddealer .
Thisadjustmentisrequiredwithreferencetothe
positionanddiameteroftherearwheelaswellas
theuserconditionsandhisparticularsafetylimits.
Makesurethattheanti-tipperdeviceistted
correctlyoneachside.ThexationsBmustbe
lockedintoposition.
3.8Pushhandle
IMPORTANT!
–Alwayscheckthepushhandlesbeforeusing
thewheelchair,astowhetherthehandgrips
aresecure,cannotbeturnedandcannotbe
pulledoff.
CAUTION!
Ifthexingscrewsarenotcorrectlytightened,
thepushhandlecouldaccidentallycomeoffthe
backresttubewhilepushingitupwards.
–Makesurethatthexationisrmlytightened.
Pushhandleinstallation
PushhandlesAinstallationmustbecarriedoutbyan
authorizeddealer.
201648806-B.00
