Invacare Aquatec Ocean User manual

Aquatec®Ocean/OceanXL
enShowerandToiletCommode
UserManual...............................3
deDusch-undToilettenrollstuhl
Gebrauchsanweisung........................27
frChaiseroulantepourdouche/toilettes
Manueld'utilisation.........................53
itCarrozzinadadocciaedatoilette
Manualed’uso..............................77
esSilladeduchaeinodoro
Manualdelusuario.........................101
ptCadeiradeducheesanitária
Manualdeutilização........................125
nlDouche-entoiletstoel
Gebruiksaanwijzing.........................149
ThismanualMUSTbegiventotheuseroftheproduct.
BEFOREusingthisproduct,readthismanualandsaveforfuturereference.

©2018InvacareCorporation
Allrightsreserved.Republication,duplicationormodicationinwholeorinpartisprohibited
withoutpriorwrittenpermissionfromInvacare.Trademarksareidentiedby™and®.Alltrademarks
areownedbyorlicensedtoInvacareCorporationoritssubsidiariesunlessotherwisenoted.
____
AlleRechtevorbehalten.DieWeiterveröffentlichung,VervielfältigungoderÄnderungimGanzenoder
inTeilenohnevorherigeschriftlicheGenehmigungvonInvacareistuntersagt.Markenzeichensind
durch™und®gekennzeichnet.AlleMarkenzeichensindEigentumderoderzugelassenaufdie
InvacareCorporationbzw.derenTochtergesellschaften,sofernnichtandersangegeben.
____
Tousdroitsréservés.Larepublication,laduplicationoulamodicationdetoutoupartieduprésent
documentestinterditesansl'accordécritpréalabled'Invacare.Lesmarquescommercialessont
identiéespar™et®.Touteslesmarquescommercialessontdétenuesparoucédéessouslicence
àInvacareCorporationousesliales,saufstipulationcontraire.
____
Tuttiidirittiriservati.Èproibitalariproduzione,laduplicazioneolamodicaparzialeocompleta,
salvopreviaautorizzazionescrittadapartediInvacare.Imarchisonocontrassegnatida™e®.Tutti
imarchisonodiproprietàolicenzadiInvacareCorporationodisueafliate,salvoindicazione
contraria.
____
Todoslosderechosreservados.Quedaprohibidovolverapublicar,copiaromodicarelpresente
documento,enparteoporcompleto,sinelprevioconsentimientoporescritodeInvacare.Las
marcascomercialesseidenticanconlossímbolos™y®.Todaslasmarcascomercialesson
propiedaddeInvacareCorporationodesusliales,obienInvacareCorporationosuslialescuentan
conlascorrespondienteslicencias,amenosqueseindiquelocontrario.
____
Todososdireitosreservados.Arepublicação,duplicaçãooumodicaçãototalouparcialestáinterdita
semaautorizaçãopréviaporescritodaInvacare.Asmarcascomerciaissãoidenticadaspelos
símbolos™e®.TodasasmarcascomerciaissãopropriedadedaouestãolicenciadasàInvacare
Corporationouàssuassubsidiárias,excetoquandoapresentadainformaçãoemcontrário.
____
Allerechtenvoorbehouden.Herpublicatie,duplicatieofgeheleofgedeeltelijkewijzigingisverboden
zondervoorafgaandeschriftelijketoestemmingvanInvacare.Handelsmerkenzijnteherkennenaan
™en®.AllehandelsmerkenzijneigendomvanofgelicentieerdaanInvacareCorporationofhaar
dochterondernemingen,tenzijandersaangegeven.

Contents
ThismanualMUSTbegiventotheuseroftheproduct.
BEFOREusingthisproduct,readthismanualandsaveforfuture
reference.
1General.........................................4
1.1Generalinformation............................4
1.2Symbolsinthisusermanual......................4
1.3Warranty.....................................4
1.4Compliance...................................4
1.5Intendeduse..................................5
1.6Servicelife...................................5
2Safety..........................................6
2.1Safetyinformation..............................6
2.2Labelsandsymbolsontheproduct.................6
3Components......................................8
3.1Overview....................................8
4Setup...........................................10
4.1Safetyinformation..............................10
4.2Assemblingtheshowerandtoiletcommode..........10
4.3Accessory(optional)............................15
5Usage..........................................16
5.1Safetyinformation..............................16
5.2Usingtheshowerandtoiletcommode..............17
6Transport........................................19
6.1Safetyinformation..............................19
7Maintenance.....................................20
7.1Maintenanceandinspection......................20
7.2Cleaninganddisinfection.........................20
7.3Changingthecastors............................21
8AfterUse........................................22
8.1Storage......................................22
8.2Re-use......................................22
8.3Disposal.....................................22
9Troubleshooting...................................23
9.1Identifyingandrepairingfaults....................23
10TechnicalData...................................24
10.1Dimensionsandweight.........................24
10.2Materials....................................24
10.3Environmentalparameters.......................25

Aquatec®Ocean/OceanXL
1General
1.1Generalinformation
ThisUserManualcontainsimportantinformationabout
usingtheproduct.Inordertoensuresafetywhenusing
theproduct,readtheUserManualcarefullyandfollowthe
safetyinformation.
Ifyourvisionisimpaired,youcanviewtheusermanual
asaPDFleontheInternetandenlargeiton-screen
asrequired.Ifyoucannotenlargethetextandgraphics
sufciently,pleasecontacttheInvacare®distributorforyour
country.Foraddresses,seebackpageofthismanual.If
necessary,wewillprovideyouwithahighresolutionPDF
leoftheusermanual.
1.2Symbolsinthisusermanual
Inthisusermanual,warningsaremarkedwithsymbols.The
titlenexttothewarningsymbolindicatesthelevelofdanger.
WARNING
Indicatesadangeroussituationwhichcould
leadtodeathorseriousinjuryifnotavoided.
CAUTION
Indicatesadangeroussituationwhichcould
leadtominorinjuriesifnotavoided.
IMPORTANT
Indicatesadangeroussituationwhichcould
leadtodamageifnotavoided.
Usefultips,recommendationsandinformation
toensureefcientandsmoothoperation.
Thisproductcomplieswiththedirective
93/42/EECformedicalproducts.Thelaunch
dateforthisproductisspeciedintheCE
declarationofconformity.
Manufacturer
1.3Warranty
Weprovideamanufacturer’swarrantyfortheproduct
inaccordancewithourGeneralTermsandConditionsof
Businessintherespectivecountries.Warrantyclaims
canonlybemadethroughtheproviderfromwhomthe
appliancewasobtained.
1.4Compliance
Qualityisoftheutmostimportanceforourcompany;all
processesarebasedontheISO13485standard.
ThisproductfeaturestheCEmark,incompliancewiththe
MedicalDeviceDirective93/42/EECClass1.
Invacareiscontinuouslyworkingtowardsensuringthatthe
company’simpactontheenvironment,locallyandglobally,
isreducedtoaminimum.
•WeonlyuseREACHcompliantmaterialsand
components.
ForfurtherinformationpleasecontactInvacareinyour
country(foraddresses,seeendofthisdocument).
41552757-G

General
1.5Intendeduse
Theshowerandtoiletcommodeisdesignedexclusivelyas
anaidforshoweringorbathing,goingtothetoilet,foruse
duringpersonalhygiene(e.g.infrontofthebasin)orfor
transferringpatientswhileindoors.Itisintendedtobe
usedbyadultpatient,withorwithoutcaregiverassistance,
whohave:
•Difcultystandingorkeepingtheirbalance
•Weaklegsorlowerlimbdisability
•Medicalconditionsthatimpairtheirbalance
Theproductisintendedforinstitutionalandprivatehouse
holduse.Anyotheruseisprohibited.
WARNING!
Riskofinjury
–Neverusetheproductasanaidforgettinginto
oroutofabathtub,forclimbingordescending,
asasupportorforsimilarpurposes.
–Donotusetheproductoutdoors.
Asatoiletcommode,theproductcanbeusedovera
standardtoiletorindependentlywiththecommodepan
(optional).
Theshowerandtoiletcommodemayonlybeusedasa
bathingstoolinapool,ifthepooldoesnotcontainsalt
waterandanattendantispresentatalltimes.
Temperatureforuse:10-65°C
1.6Servicelife
Weestimatealifeexpectancyofveyearsforthese
products,providedtheyareusedinstrictaccordance
withtheintendeduseassetoutinthisdocumentand
allmaintenanceandservicerequirementsaremet.The
estimatedlifeexpectancycanbeexceedediftheproduct
iscarefullyusedandproperlymaintained,andprovided
technicalandscienticadvancesdonotresultintechnical
limitations.Thelifeexpectancycanalsobeconsiderably
reducedbyextremeorincorrectusage.Thefactthatwe
estimatealifeexpectancyfortheseproductsdoesnot
constituteanadditionalwarranty.
1552757-G5

Aquatec®Ocean/OceanXL
2Safety
2.1Safetyinformation
WARNING!
–Donotusethisproductoranyavailable
optionalequipmentwithoutrstcompletely
readingandunderstandingtheseinstructions
andanyadditionalinstructionalmaterialsuch
asusermanuals,servicemanualsorinstruction
sheetssuppliedwiththisproductoroptional
equipment.Invacareproductmanualsare
availableontheinternetoratyourlocaldealer
(Addressesaredisplayedonthebackcoverof
thismanual).
–Ifyouareunabletounderstandthewarnings,
cautionsorinstructions,pleasecontacta
healthcareprofessional,dealerortechnical
personnelbeforeattemptingtousethis
equipment–otherwise,injuryordamagemay
occur.
WARNING!
Riskofinjury
–Donotstandontheproduct.
–Donotuseasaclimbingaid.
–Donotuseoutdoors.
WARNING!
Riskofinjury
–Donotuseifdefective.
–Intheeventofamalfunction,contactyour
dealerimmediately.
–Donotmakeanyunauthorizedchangesor
alterationstotheproduct.
–Onlyuseaccessoriesintendedforthisproduct.
IMPORTANT!
Theinformationcontainedinthisdocumentis
subjecttochangewithoutnotice.
2.2Labelsandsymbolsontheproduct
Identicationlabel
Theidenticationlabelcontainsimportantinformation:
A
H
B
C
D
E
FG
( 0 1 ) 0 4 0 2 8 6 9 8 1 1 3 2 0 4 ( 2 1 ) 1 5 CE C0 1 0 0 0 1 ( 0 X)
OCEAN(XL)
150 kg
(XL 180 kg)
1
7
2
8
3
9
4
10
5
11
6
12
2014 2015 2016
AQUATEC Operations GmbH
Ale ma n ne n s tra s s e 10
88316 Is ny - Ge rma ny
4 0 2 8 6 9 8 1 1 3 2 0 4
S
N
61552757-G

Safety
AConformitymark
BSerialnumber
CMaximumuserweight
DNote(useonlyonatsurfaces)
EReadusermanual
FProductdesignation
GManufactureraddress
HDateofmanufacture
Theidenticationlabelisattachedtotheinsideof
therightsidesection.
1552757-G7

Aquatec®Ocean/OceanXL
3Components
3.1Overview
Thefollowingcomponentsareincludedwithinthescope
ofdelivery:
AUserManual
BBackrestwithbackrestcoverandarmrests
CSeatframewithseatplate
DSidepartswithwheels(2x)
EFootrestswithheelstrap(2x)
FClips(2x)forfootrest(inserted)
GClips(4x)forseatframe
HAllenkeyAF4
IScrews(4x)andwashers(4x)
JBasestabilizationtubewithscrews(4x)andnuts
(4x)-OceanXLonly
Thefollowingpartsareincludedwithinthescopeofdelivery
oftheself-propellingwheelswithparkingbrake:
D
81552757-G

Components
ASelf-propellingwheels(2x)
BParkingbrakes(2x)
CHubsincl.axles(2x)
Notethechangeindimensionswhenthe
self-propellingwheelsaretted.Fordetailssee
chapterTechnicalData.
1552757-G9

Aquatec®Ocean/OceanXL
4Setup
4.1Safetyinformation
WARNING!
–Checkthepartsfortransportdamagebefore
commissioningandcontactyourdealerif
required.
–Ensureduringassemblythatthepartsare
positionedcorrectlywithrespecttoone
another.
–Selflockingscrews,nutsorthreadlocking
adhesiveareusedforseveralconnections.If
theseareloosened,theymustbereplacedby
newselflockingscrews,nutsortheymustbe
securedusingnewthreadlockingadhesive.
4.2Assemblingtheshowerandtoiletcommode
Thissectiondescribestheassembly.Disassemblytakesplace
inthereverseorder.
Fittingtheseatframetubeforheightadjustment
1.RemovetheenclosedclipsFfromthebag.
2.Placetheseatframeonitsside.
IMPORTANT
–Pushthesidepartevenlyontotheframeand
donottwist.
–Securethesidepartatthesameheight,front
andrear.
3.PushthesidepartAwiththeguidesforthefootrests
DforwardsontheseatframeB.
4.BringtheclipmountsEonthefrontandbackofthe
sidepartinlinewithaholeintheseatframeC.
5.InserttheclipsFfromtheoutsideintothesidepart,
untilbothendsGenclosetheseatframetubeB.
IMPORTANT
–Ensurethattheleftandtherightsidepartsare
settothesameheight.
101552757-G
