Invacare Spree 3G User manual

Invacare®
spree 3G
TIlT-In-space wheelchaIr
The Invacare®Spree 3G Pediatric Tilt-in-Space Wheelchair offers virtually all the enhancements available on the Solara
3G wheelchair, only in a smaller package. With a compact, sleek design, more configurations and additional accessories to
choose from, the Spree 3G pediatric wheelchair can easily match every child’s individuality.

Invacare Corporation
www.invacare.com
USA
One Invacare Way
Elyria, Ohio
44035-4190
[phone]
Canada
570 Matheson Blvd. E.,
Unit 8
Mississauga, Ontario
L4Z 4G4 Canada
[phone]
©2012
Invacare Corporation.
All rights reserved.
Trademarks are identified
by the symbols ™ and
®. All trademarks are
owned by or licensed
to Invacare Corporation
unless otherwise noted.
Specifications are subject
to change without
notification.
Form No. 12-249
Rev. 09/12
120364
Features
The unique Tilt Assist feature makes tilting easier by
reducing the effort required to tilt an occupied wheelchair.
With three settings, front, middle and rear, the simple
Tilt Assist adjustments help to correct for uneven weight
distribution
The innovative Low Shear Recline minimizes shearing forces
and prevents displacement of positioning tools such as
laterals and headrest. Used in combination with tilt, recline
can offer additional functional and clinical benefits to users
and caregivers
The contractive footrest system offers great strength and
adjustability. The bilateral fotplates offer inversion and
eversion while both the platform and footplates can be
adjusted laterally the full width of the chair
The DeGage Dynamic Rocker Back accommodates those
with involuntary thrusts by helping to reduce pain or
discomfort for the user. See www.degage.us for complete
details
HCPCS Code: E1233
All references to HCPCS codes: Providers are responsible for determining the appropriate billing codes when submitting claims
to the Medicare program, and should consult an attorney or other advisor to discuss specific situations in further detail.
Model # Overall Seat Seat-to-Floor Tilt Adjustable Front Frame Tubing
Dimensions Dimensions Height Range Back Angle Angle Diameter
SPREE3G Seat width 12"-18"W 12.5"- 19" -5°-50° 0°, 5°, 10°, 15°, N/A 1.25"
+8.5" 12"-19"D .5" increments 20°, 25°, 30°
Knee-to- Wheels Casters Total Weight Limited
Heel Range Weight** Capacity Warranty
4.5"-24" 12", 16", 18", 4", 5", 6", 8" 73 lb. 200 lb. 5 Years
20", 22", 24" Frame/
** 18x18 frame with 12" wheels Crossbraces
Please see the Owner's Manual and Invacare Configurator for complete option/specification combinations.
1. Low shear reclline
2. Contractive Footrest
3. DeGage Rocker back
4. Transport Ready Option (TRRO)*
5. Transport Brackets (TRBKTS)*
1
2
5
4
3
*TRRO includes four factory-installed brackets and wheelchair anchored pelvic belt. TRRO has been crash-tested in accordance
with ANSI/RESNA WC Vol 1. Section 19 Frontal Impact Test requirements for wheelchairs with a 168 lb. crash dummy, which
corresponds to a person with a weight of 114 lb. to 209 lb. TRBKTS includes four factory-installed wheelchair transport brackets.
TRBKTS has not been crash tested in accordance with WC19. Use these transport brackets only to secure an unoccupied
wheelchair during transport. As of this date, the Department of Transportation has not approved any tie-down systems for
transportation of a user while in a wheelchair, in a moving vehicle of any type. It is Invacare's position that users of wheelchairs
should be transferred into appropriate seating in vehicles for transportation and use be made of the restraints available by the
auto industry. Invacare cannot and does not recommend any wheelchair transportation systems.
