Invacare®
Tracer®eX2
WheelchaIr
The Invacare®Tracer®EX2 wheelchair sets the benchmark in manual wheelchairs. A true dual axle position allows for
repositioning the 24" rear wheels and 8" casters for adult and hemi seat-to-floor heights. Offset permanent arms offer full
seat width up to 20" with a permanent arm, hemi-spaced footrest and full range of accessories. Incorporating the design and
technology of the Invacare®9000 series, the Tracer EX2 wheelchair has interchangeable components with the 9000 series
chairs.

Invacare Corporation
www.invacare.com
USA
One Invacare Way
Elyria, Ohio
44035-4190
[phone]
Canada
570 Matheson Blvd. E.,
Unit 8
Mississauga, Ontario
L4Z 4G4 Canada
[phone]
©2012
Invacare Corporation.
All rights reserved.
Trademarks are identified
by the symbols ™ and
®. All trademarks are
owned by or licensed
to Invacare Corporation
unless otherwise noted.
Specifications are subject
to change without
notification.
Form No. 11-224
Rev. 03/13
130293
Features
Durable, low-maintenance, carbon steel frame is long-lasting
Dual axle positions allow variation of seat-to-floor heights
Offset permanent arms available in 16", 18" and 20" widths
14-gauge crossbraces add strength and durability
Urethane rear tires mounted on “no flex“ wheels offer superior performance
Low-maintenance, dual-sealed precision bearings
Heavy-duty inner liners keep seat and back from stretching
Upholstery is dual-embossed
Meets RESNA standards for manual wheelchairs in product performance
1. Dual axle positions
2. Dual-embossed upholstery
3. Offset permanent arms
4. Seating options available
HCPCS Code: K0001/K0002
Model # Overall Width Overall Overall Depth Folded Seat Seat Seat-to-
(1" increments) Height w/o riggings Width Width Depth Floor Height
TREX20 23.25"-28.25" 34" 31.88" 13" 20" 16" 17.5", 19.5"
TREX26 23.25"-28.25" 34" 31.88" 13" 16" 16" 17.5", 19.5"
TREX28 23.25"-28.25" 34" 31.88" 13" 18" 16" 17.5", 19.5"
Back Caster Wheel Weight Shipping Carton Limited
Height Height Height Capacity Weight Dimensions Warranty
TREX20 16" 8" 24" 250 lb. 43 lb. 32"x13"x 38" 5 Years
TREX26 16" 8" 24" 250 lb. 43 lb. 32"x13"x 38" 5 Years
TREX28 16" 8" 24" 250 lb. 43 lb. 32"x13"x 38" 5 Years
1
2
3 4
All references to HCPCS codes: Providers are responsible for determining the appropriate billing codes when submitting claims to the Medicare program, and should
consult an attorney or other advisor to discuss specific situations in further detail.
