Invacare XTERRA GT Instruction Manual

Yes, you can. ™
Xterra™ GT™
Power Wheelchair
Parts Catalog Issued: Apr 24, 2012

The information contained in this document is subject to change without notice. This catalog contains
service parts for Form No. 01-058. If you have any questions regarding this catalog, please contact one
of our Customer Service Representatives.
For Customer Service Support Call:
1-800-333-6900
For Faxed In Orders Call:
1-800-678-4682 or
1-440-366-0709
For Technical Service Call:
1-800-832-4707
Literature Can Be Found at:
www.invacare.com or
1-800-828-6272
SYMBOL DEFINITION
Throughout this catalog you will notice letters to draw your attention to specific footnotes which are located at the
bottom of the page or below specified charts.
HARDWARE MEASUREMENTS
Examples: = Special Comments
= General information pertaining to that specific page
= No Longer Available
NOTE:
NLA
The measurements for the hardware will be listed as follows:
Screws, Bolts
Washers
Spacers
For your convenience, we have supplied an area for you to list your Invacare Representatives.
A,B,C etc.
Diameter X Thread Count/Pitch X Length
Inside Diameter X Outside Diameter X Thickness
Inside Diameter X Outside Diameter X Length
Name Phone Numbers
© 2012 Invacare Corporation. Elyria, Ohio. Invacare, Yes, you can., and the Blue Medallion Design are registered trademarks and Xterra, GT, MKIV, and
RII, are trademarks, and Invacare virtual Service is a service mark name of the Invacare Corporation.
Tash is a registered trademark of Tash International Inc.. Therafin is a registered trademark of W/R/ Medical Electronics Co.. Bussman is a registered
trademark of Cooper Industries. MIDI is a registered trademark of Littelfuse Inc.. Dynamic is a registered trademark of Dynamic Controls Limited.
Parts Catalog Usage Guide
1
Form No. 01-058
To order call toll free 1-800-333-6900, or www.invacare.com

Accessories - Miscellaneous .................................................................................................... 115
Accessories - Power Wheelchair Tool Kit ................................................................................ 113
Arms - Adjustable Height (14" - 15" D) ..................................................................................... 36
Arms - Adjustable Height (16" - 20" D) ..................................................................................... 41
Arms - Captain Seat & Hardware (18" W) ................................................................................ 32
Arms - Captain Seat & Hardware (20" W) ................................................................................ 34
Arms - Fixed Height (16" - 20" D) ............................................................................................ 38
Battery Charger & Harness ...................................................................................................... 79
Battery Top Cover and Tray Assembly .................................................................................... 81
Canes - Back - Spreader Bars & Attaching Hardware ............................................................. 25
Casters & Forks - Front 8" & Rear 6" ....................................................................................... 73
Electronics - MKIV Controllers, Programmer and Hardware .................................................... 98
Electronics - MKIV Displays ..................................................................................................... 102
Electronics - MKIV Joystick Mounting Hardware and Joystick Accessories ............................ 87
Electronics - MKIV Joystick Options ......................................................................................... 108
Electronics - MKIV Joysticks - PSF and PSR ........................................................................... 85
Electronics - MKIV Joysticks - RII, TCHJOY, A, A+ ................................................................. 83
Electronics - MKIV Mid-Line Swing Bracket Assembly ............................................................ 90
Electronics - MKIV R.I.M. Head Control Assembly .................................................................. 105
Electronics - MKIV R.I.M. Head Control Mounting Hardware ................................................... 104
Electronics - MKIV Sip-N-Puff/Digital Interface and COM12 and COM34 ............................... 100
TABLE of CONTENTS
Description
Page
Number
2
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-058

Electronics - MKIV Swivel Joystick Hardware .......................................................................... 89
Electronics - Quad Link (QLA - ASBA) and (QL - Captain Seat) (After 4/06/06) ...................... 95
Electronics - Quad Link Assembly (Before 4/07/06) ................................................................. 92
Electronics - Tash and Therafin Accessories ........................................................................... 111
Fenders & Shrouds .................................................................................................................. 77
Frame - Base with Suspension Arms & Torsion Bar ................................................................ 67
Frame Finishes - Touch-Up Paints & Upholstery Options ........................................................ 5
Frames - Mounting Hardware ASBA & Captain Seat ............................................................... 13
Frames - Seat ASBA & Hardware (14" - 15" W) ...................................................................... 9
Frames - Seat ASBA & Hardware (16" - 20" W) ...................................................................... 11
Front Riggings - Adjustable Angle Footplates - AT5543 .......................................................... 61
Front Riggings - Cage Style Footrest ....................................................................................... 51
Front Riggings - Calf Pads and Attaching Hardware ................................................................ 55
Front Riggings - Footrest and Legrest Accessories ................................................................. 63
Front Riggings - Footrest Support Assemblies ......................................................................... 49
Front Riggings - Footrest Supports - PW93 ............................................................................. 56
Front Riggings - Front Rigging Hanger Assembly - Pin, Sector and Cage Style ..................... 47
Front Riggings - Legerst Supports - AT5544 ............................................................................ 53
Front Riggings - Pivot/Slide Tube and 1650, 1450, 1350 Aluminum Footplates ...................... 59
Front Riggings - Pivot/Slide Tube and 1651 Composite Footplates ......................................... 58
Front Riggings - Reference Chart (70ST) ................................................................................ 46
TABLE of CONTENTS
Description
Page
Number
3
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-058

Front Riggings - Reference Chart (AT5544, 60HD, 70NHD, and PW93) ................................. 44
Motors - 4-Pole & Gearbox Assembly ...................................................................................... 71
Packaging - Literature & Decals ............................................................................................... 7
Seat Pan & Mounting Hardware ............................................................................................... 19
Seat Plate - Flip Up .................................................................................................................. 15
Seat Plate - Flip-Up - Mounting Hardware ............................................................................... 17
Seats - Captain ......................................................................................................................... 21
Seats - Captain & Actuator Hardware ...................................................................................... 23
Suspension Arm - Mounting Hardware .................................................................................... 69
Suspension Spring - Front - Mounting Hardware ..................................................................... 70
Upholstery - Back ..................................................................................................................... 28
Warranty Replacement Parts ................................................................................................... 116
Wheels - 16" Drive Wheel & Mounting Hardware .................................................................... 75
TABLE of CONTENTS
Description
Page
Number
4
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-058

Frame Finishes, Touch-Up Paints, and Upholstery Options
Frame Finishes and Touch-Up Paints
Color Number Part Number Bottle Size Color
Deep Purple.6 oz.103145608P Cobalt Blue.6 oz.104631917P Anthracite.6 oz.103337622P Wet Black.6 oz.103145024P White.6 oz.103144729P Red.6 oz.103145533P Flat Black.6 oz.104632734P Electric Red.6 oz.104632161P Electric Blue.6 oz.104632062P Electric Purple.6 oz.104632266P Teflon Black.6 oz.1101320-NLA69P Silver VeinN/AN/A71P Evergreen with Navy.6 oz.107389280P Royal Blue with Grape.6 oz.107389583P Lavender.6 oz.107389684P Jeweled Green.6 oz.1101325101P Denim Blue.6 oz.1101327102P Mocha Frost.6 oz.1101324103P Electric Teal.6 oz.1101316104P Midnight Blue.6 oz.1101326105P
5
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-058

Frame Finishes, Touch-Up Paints, and Upholstery Options
Sparkle Frame Finishes
Color Number Color
Wet Black with Twilight Sparkle88P
Upholstery Option
Vinyl Colors Nylon Colors
U240 BlackU67 Black
6
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-058

Packaging, Literature and Decals
NOTE: When adjusting or replacing parts, please refer to your Owner's Manual for assistance.
7
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-058

Packaging, Literature and Decals
NOTE: When adjusting or replacing parts, please refer to your Owner's Manual for assistance.
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1106627-NLA NLA - Owner's Manual, Xterra GT 1 11 00077X031-NLA NLA - Warranty Card 1 12 1021149 Bag, Poly Zip-Lip (13" L x 9" W) 1 13 40131X161 Insert, Plain Pad 1 34 47449X003 Carton 1 15 1036028 Carton, Cover 1 16 1043198-NLA NLA - Tube, Paper 1 17 1015592 Bag, Poly (72" L x 35" W x 19" D) 1 18 40131X011 Carton, Front Riggings 1 19 1036027 Carton, Tray 1 210 1036026-NLA NLA - Wood Skid 1 111 1106637 Decal, Battery Removal/Installing 1 112 1079203 Decal, Warning Pinch Point 1 213 1035900 Decal, Transportation 1 114 1106653 Decal, Notice, Lower Seat 1 115 1079203 Decal, Warning Pinch Point 1 116 1108980-NLA NLA - Decal, Xterra GT 1 217 1090147 Decal, Invacare Medallion - Large 1 118 1095489 Decal, Invacare 3-D Logo (2-1/2" L) 1 119 1119281 Plate, Name, Patent Numbers 1 120 1129590 Carton, Corner Reinforcement 1 421
8
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-058

ASBA Seat Frame and Hardware
14-15" Wide
9
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-058

ASBA Seat Frame and Hardware
14-15" Wide
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1037610 Screw, Hex Head (1/4-20 x 1-5/8") 1 41 1026099 Spacer, Coved (1/4 x 11/16 x 1/2") 1 42 1047449 Spacer (1/4 x 3/8 x 3/16") 1 43 1025736 Locknut (1/4-20) 1 44 47471X074 Spring, Arm Lock 1 15 1028594 Pin, Arm Lock, Black 1 15 1090768 Kit, Lock Handle w/Rivets (Pair) 2 15 See Chart #'s 6-8 ASBA Seat Frame and Hardware 1 16-8
#'s 6-8 Seat Frames
Item
Number Description 14-15" Deep 16-17" Deep 18-19" Deep 20" Deep
1108944110894211089401108940
Seat Frame -
Right 6See Note(s) B
1108945110894311089411108941
Seat Frame - Left
6See Note(s) B
1070533107047610704761070476
Seat Frame -
Center
7
11089591108953
1108947
1108947
Seat Frame -
Assembly 8See Note(s) A See Note(s) A
A - Includes items 1-7
B - Seat frame includes item 5 arm lock assembly
NOTE:
10
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-058

ASBA Seat Frame and Hardware
16-20" Wide
NOTE: 14" and 15" seat depths are achieved by using CJ back mounting hardware.
11
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-058

ASBA Seat Frame and Hardware
16-20" Wide
NOTE: 14" and 15" seat depths are achieved by using CJ back mounting hardware.
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
See Chart # 1 ASBA Seat Frame and Hardware 1 11 A 1029501 Plug Button, Black (1") 1 22 1090768 Kit, Lock Handle w/Rivets (Pair) 2 13 47471X074 Spring, Arm Lock 1 24 1028594 Pin, Arm Lock, Black 1 25 A - Includes seat frame and items 2-5
NOTE:
# 1 - Seat Frame with Hardware
Seat Width 14-17" Deep 18-19" Deep 20" Deep
11089601108954110894816" Wide 11089611108955110894917" Wide 11089621108956110895018" Wide 11089631108957110895119" Wide 11089641108958110895220" Wide
12
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-058

ASBA and Captain Seat Frame Mounting Hardware
NOTE: All captin seats use seat frame mounting hardware part # 1109181.
13
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-058

ASBA and Captain Seat Frame Mounting Hardware
NOTE: All captin seats use seat frame mounting hardware part # 1109181.
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
See Chart #1 ASBA and Captain Seat Frame Mounting
Hardware 1 11
1070412 Screw, Hex Head (5/16-18 x 2-1/4") 1 42 1108426 Tube with End Seat Spacer Assembly, Black 1 23 1028769 Locknut (5/16-18) 1 44 1042484 Screw, Hex Head (5/16-18 x 2") 1 45 1082876 Spacer (3/8 x 3/4 x 3/8") 1 46 1108498 Plug Button, Square, Black (1-1/4") 1 47 1070398 Screw, Hex Head (5/16-18 x 1-1/2") 1 48
#1 Seat Frame Mounting Hardware
Seat Width 14-17" Deep 18-19" Deep 20" Deep
11091831109183110918314-15" Wide 11091821109181110918116-18" Wide 11091821109182110918119-20" Wide
14
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-058

Flip-Up Seat Plate Assembly
15
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-058

Flip-Up Seat Plate Assembly
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1107705-NLA NLA - Seat Plate Assembly, Flip-Up (14-20" D) 1 11 A,D 1107175 Plate, Seat, with Decals, Flip-Up (14-20" D) 1 12 B,D 1106637 Decal, Battery Removal/Installing 1 13 1106189 Bearing, Flange 1 44 1098944 Screw, Socket Head w/ Patch (1/4-20 x 3/4") 1 45 1107181 Bracket, Handle Release, Black 1 26 1107158 Bushing, Flanged (1/4 x 1/2 x 3/8") 1 27 1106621 Spring, Extension (13/32 x 1-5/32" L) 1 28 1107702 Hook Release Assembly 1 19 1107182 Bracket, Support Release, Black 1 110 7930335 Package, Screw, Phillips Pan Head (#10-32 x 1/2") 25 311 1107697 Handle, Release 1 112 1025731 Locknut (#10-32) 1 313 1108560-NLA NLA - Hardware, Hook Release 1 114 C 1035900 Decal, Transportation 1 115 1079203 Decal, Warning Pinch Point 1 216 1108678 Plate, Threaded 1 117 1108677 Plate, Threaded Prop 1 118
A - Includes Items 2 and 5-14.
B - Includes Items 3, 4, 15, and 16.
C - Includes Items 8-13.
D - 12/4/02 all seat depths now utilize only one flip-up seat plate assembly with a material depth of 13". For 20" deep models
made before 12/4/02 and measure 14", new adjustment brackets must be ordered. See page titled Flip-Up Seat Plate
Mounting Hardware.
NOTE:
16
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-058

Flip-Up Seat Plate Mounting Hardware
17
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-058

Flip-Up Seat Plate Mounting Hardware
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1108568 Hardware, Seat Plate Mounting, Flip-Up (14 - 20" D) 1 11 A,B 1000208 Screw, Shoulder Hex Socket Head (5/16" x 3/8",
1/4-20) 1 12
1016652 Washer (5/16 x 9/16 x 1/32") 1 13 1108986 Washer, Flat (7/8 x 11/32 x 1/16") 1 24 1108981 Bracket, Prop Seat with Decals, Black 1 15 1070379 Washer, Spring (5/8 x 1 x 1/16") 1 26 1108676 Washer, Flat (7/8 x 5/8 x 1/8") 1 27 1108675 Bushing, Stepped (3/8" I.D.) 1 28 1025704 Washer, Flat (5/16 x 5/8 x 1/16") 1 69 1028769 Locknut (5/16-18) 1 410 1026158 Locknut (5/16-18) 1 211 1107179 Bracket, Adjustment, Black - Right (14-20" Deep) 1 112 B 1107180 Bracket, Adjustment, Black - Left (14-20" Deep) 1 112 B 1065214 Washer, Flat (3/8 x 11/16 x 1/16") 1 713 1069421 Screw, Shoulder Hex Socket Head (3/8 x 1",
5/16-18) 1 214
1064455 Screw, Shoulder Hex Socket Head (3/8 x 1-3/4",
5/16-18) 1 115
1106653 Decal, Notice, Lower Seat 1 116 1079203 Decal, Warning Pinch Point 1 117 1107708 Screw, Shoulder Hex Socket Head (3/8 x 3/4",
5/16-18) 1 318
A - Includes Items 2-18.
B - 12/4/02 all seat depths now utilize only one flip-up seat plate assembly with a material depth of 13". For 20" deep models
made before 12/4/02 and measure 14", a new flip-up seat plate must be ordered. See page titled Flip-Up Seat Plate
Assembly.
NOTE:
18
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-058

Seat Pan and Mounting Hardware
NOTE: 14-15" Wide seat depths are achieved by using CJ back cane mounting hardware.
19
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 01-058
