Invacare 9000 Topaz Instruction Manual

Yes, you can. ™
9000 Topaz™
Wheelchair
Parts Catalog Issued: Mar 9, 2012

The information contained in this document is subject to change without notice. This catalog contains
service parts for Form No. 00-103. If you have any questions regarding this catalog, please contact one
of our Customer Service Representatives.
For Customer Service Support Call:
1-800-333-6900
For Faxed In Orders Call:
1-800-678-4682 or
1-440-366-0709
For Technical Service Call:
1-800-832-4707
Literature Can Be Found at:
www.invacare.com or
1-800-828-6272
SYMBOL DEFINITION
Throughout this catalog you will notice letters to draw your attention to specific footnotes which are located at the
bottom of the page or below specified charts.
HARDWARE MEASUREMENTS
Examples: = Special Comments
= General information pertaining to that specific page
= No Longer Available
NOTE:
NLA
The measurements for the hardware will be listed as follows:
Screws, Bolts
Washers
Spacers
For your convenience, we have supplied an area for you to list your Invacare Representatives.
A,B,C etc.
Diameter X Thread Count/Pitch X Length
Inside Diameter X Outside Diameter X Thickness
Inside Diameter X Outside Diameter X Length
Name Phone Numbers
© 2012 Invacare Corporation, Elyria, Ohio. Invacare, the Medallion Design, and Yes, you can. are registered trademarks; Topaz is a registered trademark of
Invacare Corporation.
Parts Catalog Usage Guide
1
Form No. 00-103
To order call toll free 1-800-333-6900, or www.invacare.com

Accessories - I.V. Oxygen Holder - T1496 - Oxygen Holder -T1497 ....................................... 54
Accessories - I.V. Rod - Telescoping - T1322 .......................................................................... 56
Accessories - Miscellaneous .................................................................................................... 50
Accessories - Push Bar - T1483 ............................................................................................... 58
Arms - Adjustable Height .......................................................................................................... 20
Arms - Adjustable Height - Bariatric ......................................................................................... 23
Arms - Fixed Height .................................................................................................................. 25
Arms - Fixed Height - Bariatric ................................................................................................. 28
Canes - Back and Hardware .................................................................................................... 13
Casters - Front & Hardware ..................................................................................................... 31
Crossbraces and Hardware ...................................................................................................... 11
Forks and Hardware ................................................................................................................. 30
Frame Finishes, Packaging, and Upholstery Colors ................................................................ 4
Frames and Hardware .............................................................................................................. 5
Frames and Hardware - Bariatric ............................................................................................. 9
Front Riggings - Calf Pads ....................................................................................................... 47
Front Riggings - Footrest Support Assembly - TZ33A ............................................................. 42
Front Riggings - Legrest Support Assembly - TZ34A ............................................................... 43
Front Riggings - One Piece Footboard ..................................................................................... 48
Front Riggings - Pivot Slide Tube with Footplate ..................................................................... 45
Upholstery - Back and Seat & Hardware .................................................................................. 15
TABLE of CONTENTS
Description
Page
Number
2
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 00-103

Wheel - Rear and Hardware ..................................................................................................... 33
Wheel Locks - Clamp-On (After 9/1/05) ................................................................................... 40
Wheel Locks - Disk Style (Between 8/15/03 - 8/31/05) ............................................................ 38
Wheel Locks - Push & Pull - Chrome Chairs (Before 9/1/05) ................................................... 34
Wheel Locks - Push & Pull - Color Chairs (Before 9/1/05) ....................................................... 36
TABLE of CONTENTS
Description
Page
Number
3
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 00-103

Upholstery Colors
Part Number Description
Black NylonU240 Black VinylU67 Midnight Blue VinylU550
Frame Finishes
Part Number Color Description Touch-Up Paint
Not Available
Chrome15P See Note(s) A
1031450Wet Black24P 1046320
Electric Blue62P See Note(s) B
N/ASilver Vein71P 1101316
Electric Teal104P See Note(s) B
A - The chrome finish is no longer available for chairs manufactured after 1/30/01.
B - The painted finish is no longer available for chairs manufactured after 3/5/01.
NOTE:
Packaging and Literature
Part Number Description
Carton1100551 Insert, Carton40131X039 Insert, Top Carton40131X041 Insert, Top Carton40131X011 Insert, Carton1102229 NLA - Warranty Card00077X031-NLA Owner's Manual, 9000 Topaz1100869 Decals, Topaz1102154
Frame Finishes, Packaging, and Upholstery Colors
NOTE: When adjusting or replacing parts, please refer to your Owner's Manual for assistance.
4
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 00-103

Frames and Hardware
5
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 00-103

Frames and Hardware
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
8881139590 Side Frame Assembly, Color - Right 1 11 A,B,C Washer, Nylon (3/16 x 7/16 x 1/8") 1 32 Rivet (3/16 x 7/16") 1 33 Handle, Lock, Black - Right 1 14 Rivet, Tubular 1 15 Spring, Arm Lock 1 16 Pin, Locking 1 17 Bearing (5/8") 1 28 Frame, Side, Color - Right 1 19 8881139591 Side Frame Assembly, Color - Left 1 11 A,B,C Washer, Nylon (3/16 x 7/16 x 1/8") 1 32 Rivet (3/16 x 7/16") 1 33 Handle, Lock, Black - Left 1 14 Rivet, Tubular 1 15 Spring, Arm Lock 1 16 Pin, Locking 1 17 Bearing (5/8") 1 28 Frame, Side, Color - Left 1 19 8881139600 Kit, Frames and Push to Lock Wheel Locks, Color 1 117 C,D,E Washer, Nylon (3/16 x 7/16 x 1/8") 1 62 Rivet (3/16 x 7/16") 1 63 Handle, Lock, Black - Right 1 14 Handle, Lock, Black - Left 1 14 Rivet, Tubular 1 15 Spring, Arm Lock 1 26 Pin, Locking 1 27 Bearing (5/8") 1 48 Frame, Side, Color - Right 1 19 Frame, Side, Color - Left 1 19 Clamp, Wheel Lock, Threaded (7/8") 1 210 Clamp, Wheel Lock, Non-Threaded (7/8") 1 210 Screw, Allen Head (1/4-20 x 1") 1 411 Wheel Lock, Hi-Mount, Push to Lock - Right 1 112 Wheel Lock, Hi-Mount, Push to Lock - Left 1 112 Plug Button, Black (3/4") 1 213 H-Block 1 414 Screw, Hex Head (1/4-20 x 1-1/2") 1 415 Locknut (1/4-20) 1 416 8881139601 Kit, Frames and Pull to Lock Wheel Locks, Color 1 117 C,D,E Washer, Nylon (3/16 x 7/16 x 1/8") 1 62 Rivet (3/16 x 7/16") 1 63 Handle, Lock, Black - Right 1 14 Handle, Lock, Black - Left 1 14 Rivet, Tubular 1 25
6
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 00-103

Frames and Hardware
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
Spring, Arm Lock 1 26 Pin, Locking 1 27 Bearing (5/8") 1 48 Frame, Side, Color - Right 1 19 Frame, Side, Color - Left 1 19 Clamp, Wheel Lock, Threaded (7/8") 1 210 Clamp, Wheel Lock, Non-Threaded (7/8") 1 210 Screw, Allen Head (1/4-20 x 1") 1 411 Wheel Lock, Hi-Mount, Pull to Lock - Right 1 112 Wheel Lock, Hi-Mount, Pull to Lock - Left 1 112 Plug Button, Black (3/4") 1 213 H-Block 1 414 Screw, Hex Head (1/4-20 x 1-1/2") 1 415 Locknut (1/4-20) 1 416 1096781 Hardware Kit, Hinge Replacement 1 118 Wrench, Allen (3/32") 1 1
Cap, Threaded 1 4
Washer, Locking Split (#10) 1 4
Screw, Regulator (8-32 x 3/8") 1 4
1100792 Kit, Frame Hardware (Pair) 1 1F,G Plug Button, Black (3/4") 1 2
H-Block 1 4
Screw, Hex Head (1/4-20 x 1-1/2") 1 4
Locknut (1/4-20) 1 4
8881101479-NL
ANLA - Frame w/ Bearings, Rivets & Lock Handles, Color - Right 1 1F
8881101480-NL
ANLA - Frame w/ Bearings, Rivets & Lock Handles, Color - Left 1 1F
1101481-NLA NLA - Frame w/ Bearings, Rivets & Lock Handles,
Chrome - Right 1 1F
1101482-NLA NLA - Frame w/ Bearings, Rivets & Lock Handles,
Chrome - Left 1 1F
7100053 Arm Lock Assembly, Black - Right 1 1H Handle, Lock, Black - Right 1 1
Rivet, Tubular 1 2
Pin, Locking 1 2
Spring, Arm Lock 1 2
7100054 Arm Lock Assembly, Black - Left 1 1H Handle, Lock, Black - Left 1 1
Rivet, Tubular 1 2
Pin, Locking 1 2
Spring, Arm Lock 1 2
7
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 00-103

Frames and Hardware
A - Includes items 2-9.
B - For replacement of chairs with clamp-on style wheel locks only. Any other style wheel lock will need the complete kit
including side frames and wheel locks.
C - Specify frame color when ordering. See category titled, " Frame Finishes, Packaging, and Upholstery Colors."
D - Includes items 2-16.
E - Effective 9/1/05, due to style change of side frame and the option of clamp-on wheel locks, side frames will have to be
replaced in pairs.
F - Not shown.
G - Includes items 13, 14, 15 and 16.
H - Not shown. Includes items 4-7.
NOTE:
8
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 00-103

Bariatric Frame and Hardware
9
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 00-103

Bariatric Frame and Hardware
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
8881140874 Frame Assembly, Side, Color - Right 1 11 A,B Washer, Nylon (3/16 x 7/16 x 1/8") 1 32 Rivet (3/16 x 7/16") 1 33 Frame, Side, Color - Right 1 14 Handle, Lock, Black - Right 1 15 Rivet, Tubular 1 16 Spring, Arm Lock 1 17 Pin, Locking 1 18 Bearing (5/8") 1 29 8881140875 Frame Assembly, Side, Color - Left 1 11 A,B Washer, Nylon (3/16 x 7/16 x 1/8") 1 32 Rivet (3/16 x 7/16") 1 33 Frame, Side, Color - Left 1 14 Handle, Lock, Black - Left 1 15 Rivet, Tubular 1 16 Pin, Locking 1 17 Spring, Arm Lock 1 18 Bearing (5/8") 1 29 7100053 Arm Lock Assembly, Black - Right 1 1C Handle, Lock, Black - Right 1 1
Rivet, Tubular 1 1
Pin, Locking 1 1
Spring, Arm Lock 1 1
7100054 Arm Lock Assembly, Black - Left 1 1C Handle, Lock, Black - Left 1 1
Rivet, Tubular 1 2
Pin, Locking 1 2
Spring, Arm Lock 1 2
A - Includes items 2-9.
B - Specify color when ordering. See category titled, "Frame Finishes, Packaging and Upholstery Colors."
C - Not shown. Includes items 5-8.
NOTE:
10
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 00-103

Crossbraces and Hardware
11
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 00-103

Crossbraces and Hardware
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
See Chart #1 Crossbraces without Hardware 1 11 1100791 Hardware, Crossbrace (20" W) 1 12 A 1100828 Hardware, Crossbrace (22" W) 1 12 A 1100829 Hardware, Crossbrace (24" W) 1 12 A 1100830 Hardware, Crossbrace (26" W) 1 12 A 1100831 Hardware, Crossbrace (28" W) 1 12 A 1100832 Hardware, Crossbrace (30" W) 1 12 A 1027095 Plug Button, Black (7/8") 1 43 1008495 Screw, Socket Button Head (1/4-20 x 1-1/2") 1 104 1100833 Link, Black (20" W) 1 25 1100834 Link, Black (22" W) 1 25 1100835 Link, Black (24" W) 1 25 1100836 Link, Black (26" W) 1 25 1100837 Link, Black (28" W) 1 25 1100838-NLA NLA - Link, Black (30" W) 1 25 60264X001 Locknut (5/16-24) 1 16 40317X001 Screw, Hex Head (5/16-24 x 2-3/4") 1 27 1012180 Bracket, Pivot, Black 1 28 60275X000 Locknut (1/4-20) 1 19 1012172 Clamp, Saddle 1 410 A - Includes Items 3-10.
NOTE:
#1 Crossbraces without Hardware
Chair Width: Side 18" Chair Depth 20" Chair Depth
10988051098803Right20" 10988061098804Left 10988361098834Right22" 10988371098835Left 10988411098839Right24" 10988421098840Left 10988461098844Right26" 10988471098845Left 10988511098849Right28" 10988521098850Left 10987901098782Right30" 10987911098783Left
12
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 00-103

Back Canes and Hardware
13
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 00-103

Back Canes and Hardware
Back Canes and Hardware
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1100785 Kit, Back Cane Hardware (Pair) 1 11 A Plug Button, Black (7/8") 1 22 Grip, Foam Hand (6-7/8" L) 1 23 Locknut (5/16-18) 1 44 Screw, Socket Head (5/16-18 x 1-1/2") 1 45 1100769 Cane, Back, Black 1 16 A - Includes items 2-5. Hardware quantity accommodates the right and left side frames
NOTE:
14
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 00-103

Back / Seat Upholstery & Hardware
15
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 00-103

Back / Seat Upholstery & Hardware
Back Upholstery
Upholstery
Type 30" Chair Width20" Chair Width 22" Chair Width 24" Chair Width 26" Chair Width 28" Chair Width
110150511015041101503110150211015011101500Nylon
8881101477 8881101476 8881101475 8881101474 8881101473 8881101472
Expanded
Vinyl,
Embossed See Note(s) A See Note(s) A See Note(s) A See Note(s) A See Note(s) A See Note(s) A
A - Specify upholstery color when ordering. See category titled, "Frame Finishes, Packaging and Upholstery Colors."NOTE:
Back Upholstery Hardware
Part Number Description
Back Upholstery Hardware Includes: (18) Washer (1/4 x
3/4 x 3/32")
(18) Screws (#12 x 7/8")
1101446
16
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 00-103

Back / Seat Upholstery & Hardware
Nylon - Seat Upholstery
Depth 30" W20" W 22" W 24" W 26" W 28" W 11021301101510110150911015081101507110150618" Depth 11014991101498110149711014961101495110149420" Depth
Expanded Vinyl, Embossed - Seat Upholstery
Depth 30" Wide20" Wide 22" Wide 24" Wide 26" Wide 28" Wide 8881101439
8881101438 8881101437 8881101436 8881101435 8881101434
18" D See Note(s) A See Note(s) A See Note(s) A See Note(s) A See Note(s) A See Note(s) A
8881101471 8881101470 8881101469 8881101468 8881101467 8881101466
20" D See Note(s) A See Note(s) A See Note(s) A See Note(s) A See Note(s) A See Note(s) A
17
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 00-103

Back / Seat Upholstery & Hardware
A - Specify upholstery color when ordering. See category titled, "Frame Finishes, Packaging and Upholstery Colors."NOTE:
18
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 00-103

Back / Seat Upholstery & Hardware
Seat Hardware
Part Number Description Quantity
Seat Upholstery Hardware Includes:
(16) Washer (1/4 x 3/4 x 3/32")
(16) Screws (#12 x 7/8")
Seat Hardware, 18" Deep Chair1101447
Seat Upholstery Hardware Includes:
(18) Washer (1/4 x 3/4 x 3/32")
(18) Screws (#12 x 7/8")
Seat Hardware, 20" Deep Chair1101446
19
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 00-103
