IO-Power Technology IOP-WPD-2409-B2 User manual

IO-Power Technology Co., Ltd 1F,No.100, Jinzhu Rd., North Dist., Hsinchu City 30055, Taiwan
ht tp:// www.io - power. com e-mail: [e-mail] Tel:[phone] Fax: [phone]
Form No.：IOP-OAPA-001-001 1/ 22 Retention date：6Years
Industry WiFi SIP Phone
Model：IOP-WPD-2409-B2
User Manual
Ver. 1.1

IO-Power Technology Co., Ltd 1F,No.100, Jinzhu Rd., North Dist., Hsinchu City 30055, Taiwan
ht tp:// www.io - power. com e-mail: [e-mail] Tel:[phone] Fax: [phone]
Form No.：IOP-OAPA-001-001 2/ 22 Retention date：6Years
Table of Content
FOR YOUR SAFETY ................................................................................................................................................4
START.........................................................................................................................................................................5
PACKAGE CONTENTS ..................................................................................................................................................5
PHONE SPECIFICATION................................................................................................................................................5
HANDSET DESCRIPTION ..............................................................................................................................................6
KEY PAD DEFINE AND TEXT ENTRY............................................................................................................................7
WRITE TEXT .................................................................................................................................................................7
CHARGE BATTERY .......................................................................................................................................................8
POWER ON /OFF..........................................................................................................................................................8
KEYPAD LOCK ..............................................................................................................................................................8
FLASHLIGHT..................................................................................................................................................................9
WLAN AND VOIP SETTING.........................................................................................................................................9
A: SEARCH AVAILABLE WLAN.................................................................................................................................9
B: CONNECT WLAN.................................................................................................................................................10
C: SIP SERVER REGISTER ........................................................................................................................................11
DIAL/ANSWER CALL...................................................................................................................................................12
SOS ALARM ...............................................................................................................................................................13
P2P.............................................................................................................................................................................14
MENU FUNCTION...................................................................................................................................................15
CALL ...........................................................................................................................................................................15
MESSAGE ...................................................................................................................................................................16

IO-Power Technology Co., Ltd 1F,No.100, Jinzhu Rd., North Dist., Hsinchu City 30055, Taiwan
ht tp :/ /w ww .i o -p ow er . co m e-mail: io[email protected].tw Tel:[phone] Fax: [phone]
Form No.：IOP-OAPA-001-001 3/ 22 Retention date：6Years
PTT.............................................................................................................................................................................16
UTILITIES ....................................................................................................................................................................19
SETTING .....................................................................................................................................................................19
STATUS SUMMARY.....................................................................................................................................................21
BASIC TROUBLE SHOOTING..............................................................................................................................22

IO-Power Technology Co., Ltd 1F,No.100, Jinzhu Rd., North Dist., Hsinchu City 30055, Taiwan
ht tp :/ /w ww .i o -p ow er . co m e-mail: io[email protected].tw Tel:[phone] Fax: [phone]
Form No.：IOP-OAPA-001-001 4/ 22 Retention date：6Years
For your safety
Read these simple guidelines. Not following them may be dangerous or illegal.
Read the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the phone on when wireless phone use is prohibited or when it may cause
interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while driving.
Your first consideration while driving should be road safety.
INTERFERENCE
All wireless phones may be susceptible to interference, which could affect performance.
SWITCH OFF IN RESTRICTED REGIONS
Follow any restrictions.
Switch the phone off in restricted regions.
USE SENSIBLY
Use only in the normal position as explained in the product documentation.
Do not touch the antenna unnecessarily.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ENHANCEMENTS AND BATTERIES
Do not replace components.
Use only approved enhancements and batteries.
Do not connect incompatible products.
Replacing batteries must be done in a safe place with the same type batteries.
Do not disassemble, recharge or replace the battery in hazardous locations.
Charging must be conducted in a safe place with the charger provided by manufacturer.
Do not use or recharge the battery in heat, fire or direct sunlight locations.
THE PERFORMANCE OF THREE-PROOF
Your phone has a waterproof, explosion-proof, dust-proof and anti-drop performance, but
uses it with care.
BACK-UP COPIES
Remember to make back-up copies or keep a written record of all important information
stored in your phone.
CONNECTING TO OTHER DEVICES
When connecting to any other device, read its user guide for detailed safety instructions.
Do not connect incompatible products.

IO-Power Technology Co., Ltd 1F,No.100, Jinzhu Rd., North Dist., Hsinchu City 30055, Taiwan
ht tp :/ /w ww .i o -p ow er . co m e-mail: io[email protected].tw Tel:[phone] Fax: [phone]
Form No.：IOP-OAPA-001-001 5/ 22 Retention date：6Years
Start
Please read the manual before installing and using this product.
Package Contents
WiFi phone x1
Charger x1
USB cable x1
User Manual CD x1
Phone Specification
Dimension
121.8* 57.8* 28.7 mm
Weight
168g (including battery)
Battery
Rechargeable Lithium Manganese battery, PL123450, 3.7V, 1500mAh;
(removable)
Adapter
Input AC 100-240V / output DC 5V 1A
Protocol
SIP v2，RFC3261/STUN、RTP
LCD
Color LCD 1.8”, 128*160
NOTE
The standby time depends on the network conditions, phone usage and surrounding area.
The phone consumes more battery power under the following conditions:
1. In areas with weak signals, with high or low temperatures, or when used outside the service
coverage area.
2. When the phone frequently searches for network signal due to location changes.
3. When users talk on the phone for long periods of time (+ - 3hrs).
4. When users send and receive messages frequently.
5. The Alarm, Backlight or Vibration function is active.
6. Ring or listening volume is set to maximum.
7. When flashlight is used frequently.
8. Sometimes the matching between the phones and AP can influence the standby time.

IO-Power Technology Co., Ltd 1F,No.100, Jinzhu Rd., North Dist., Hsinchu City 30055, Taiwan
ht tp :/ /w ww .i o -p ow er . co m e-mail: io[email protected].tw Tel:[phone] Fax: [phone]
Form No.：IOP-OAPA-001-001 6/ 22 Retention date：6Years
Handset Description
Key
Function
Left soft key
Select/done
Right soft key
Back/clear/exit
Answer key
Answer/dial
End key
Reject/end/back/power on/power off
Up
Up/increase
Down
Down/decrease
Left
Before/decrease
Right
Next/increase
OK
Same to the left soft key
Number key 1
Number 1 and symbols in common use “．” “－” “？” “＠” “１”
Number key 2
Number 2 and characters ABC
Number key 3
Number 3 and characters DEF
Number key 4
Number 4 and characters GHI
Number key 5
Number 5 and characters JKL
Number key 6
Number 6 and characters MNO

IO-Power Technology Co., Ltd 1F,No.100, Jinzhu Rd., North Dist., Hsinchu City 30055, Taiwan
ht tp :/ /w ww .i o -p ow er . co m e-mail: io[email protected].tw Tel:[phone] Fax: [phone]
Form No.：IOP-OAPA-001-001 7/ 22 Retention date：6Years
Number key 7
Number 7 and characters PQRS
Number key 8
Number 8 and characters TUV
Number key 9
Number 9 and characters WXYZ
Number key 0
Number 0/+-*% and for blank
Symbol *
Symbol * / symbols
Symbol #
Symbol # /shift input
PTT key
PTT call
SOS key (top
key)
One key alarm
Flashlight key
Flashlight On/Off
Key Pad Define and Text Entry
Write Text
The number keys are not labeled all the letters that they can input. Letters that can be input
refer to the language you select. This phone support English and Simple Chinese input.
English:
Press the number keys 1 to 9 continuously until the right character appear.
Press the key that character is labeled, once for the first character, twice for the second, so
on and so forth.

IO-Power Technology Co., Ltd 1F,No.100, Jinzhu Rd., North Dist., Hsinchu City 30055, Taiwan
ht tp :/ /w ww .i o -p ow er . co m e-mail: io[email protected].tw Tel:[phone] Fax: [phone]
Form No.：IOP-OAPA-001-001 8/ 22 Retention date：6Years
If the letter you want is at the same key with the before letter, you can press the left or right
key, then enter the new letter.
Press the key of number 1; you can input some inter punitions you frequently use.
Select “clear”to delete the character before the cursor.
Select “#”to switch the input method.
Charge Battery
1. This WiFi Phone has a built-in non-removable lithium cobalt battery or a built-in
non-removable lithium manganese battery. Please check if there is spare capacity in the
battery the first time you use the phone. If you cannot boot the phone or the phone display
low power consumption after booting, please recharge it before using.
2. Connecting the charge base to the power supply, open the charging column protection
cover at the bottom of the phone, then insert the charge column to the charge base to start
charging.
3. After that, the battery indication will start to roll while charging; when the phone finish charge,
the indication will stop rolling, please pull out the adapter to use.
Power On /Off
Power On
Press the End key for 2 seconds, the phone start to respond and power on. You need to
setup the phone first, if you have finished setting, the phone will search for the set WLAN
automatically.
Power Off
Press the End key for 2 seconds, the phone will start to respond and power off.
Keypad Lock
Active: at standby mode, press * key first, and then # key
Unlock press the * key first, and then # key

IO-Power Technology Co., Ltd 1F,No.100, Jinzhu Rd., North Dist., Hsinchu City 30055, Taiwan
ht tp :/ /w ww .i o -p ow er . co m e-mail: io[email protected].tw Tel:[phone] Fax: [phone]
Form No.：IOP-OAPA-001-001 9/ 22 Retention date：6Years
Flashlight
The flashlight key is on the right side of the WIFI phone. Press the key, flashlight is turned on;
Release the key, flashlight is turned off.
WLAN and VOIP Setting
This product support IEEE802.11b/g and SIP protocol, the default setting is without SIP
information, you should get the SIP name, password and domain from operator first.
For example, the information of the WLAN you are going to use is:
SSID: WIFIAP
Security type: WEP-open
Password/Text: WIFI (or Hex key: 1016A386E)
The information of the SIP server you are going to use is:
SIP server（domain）: 31.108.26.51
User name (SIP phone number):123456
SIP phone number: 123456
(Phone number could be the same to user name or not, that due to the setting of SIP server.)
Password: 1234
The detailed settings are as follows:
A: Search Available WLAN
1. At standby mode, press the left soft key or OK key to enter the main menu. (The default
initial password: 000000)
2. Select Settings> WLAN setup, select one from the default 1-8 AP in WLAN setup, these
eight factory default configurations are empty, the default display is "Default + list No.".
3. After entering the "Options" menu, first select "WLAN Search". After searching, there will be
a list to show you the available AP, with security type and signal strength. Select the one
with highest strength (if this AP is permitted to use), press left soft key or OK key to setting.
Note: The security type of the selected AP was shown at the searched AP list. We take the type
of WEP-OPEN for example here; you can set other types by following the indication.

IO-Power Technology Co., Ltd 1F,No.100, Jinzhu Rd., North Dist., Hsinchu City 30055, Taiwan
ht tp :/ /w ww .i o -p ow er . co m e-mail: io[email protected].tw Tel:[phone] Fax: [phone]
Form No.：IOP-OAPA-001-001 10 / 22 Retention date：6Years
B: Connect WLAN
1. Set the SSID name WIFIAP first (the default name is the one you have just selected, the
name is consistent to AP currently), press left soft key or OK key to enter change menu.
Enter SSID
2. Select Security Type> WEP-OPEN〉WEP Key index〉WEP Key 1, press left soft key or OK
key and enter the WEP-OPEN menu again. If the security type is “Open”, go to Step 3
directly.
Select Key / Pass〉Passphrase/ Hex Key, press left soft key or OK key enter the Enter key
（Hex）mode, key of the SSID is the one of the AP you have just selected., then press the left
soft key or OK key enter change menu again.
Enter passphrase Enter hex key
or
3. Select IP setting> use DHCP (If the WLAN you selected support DHCP server), press left soft
key or OK key to enter change menu again.
You can also select static IP, follow the indications, and enter the IP address, net mask,
gateway, DNS address in turn. And back to change menu after setting.
4. The functions of configuration item "Options" menu are as follows:
Use - use the configuration item
Change - set the configuration item
Rename - rename the configuration item
Search - search an AP for the configuration item
WPS - connect the configuration item in WPS
Reconnect - reconnect the AP under the configuration item
WIFIAP
WIFIAP
WIFIAP
