IOGear GMP8K User manual

GearPower 8000mAh/16,000mAh
Capacity Mobile Power Station
Quick Start Guide
GMP8K / GMP16K
PART NO. Q1343 / Q1344
www.iogear.com

Package Contents 1
1 x 8000mAh/16,000mAh Mobile Power Station
1 x USB to Micro USB Charging Cable
1 x Carrying Pouch
1 x Quick Start Guide
1 x Warranty Card
Overview
1. USB Type A Female Port (Output): 5V 1A
2. Micro USB Female Port (Input): 5V 2A
3. USB Type A Female Port (Output): 5V 2.4A
4. LED Charging/Capacity Indicator
5. Battery Capacity Check/On Button
8000mAh Mobile Power Station 16,000mAh Mobile Power Station
5
1 2 3
4
1 2 3
5
4

Connect the GearPower Mobile Power Station to a power
source using the included Micro USB cable.
1. Plug the USB type A connector into the USB port of any
standard 5V 1A or 2A USB power adapter. Plug power
adapter into power outlet.
2. Insert the Micro USB connector into the Micro USB port
of the Mobile Power Station.
3. The LED charging indicator will light up “Blue” and blink.
Once the Mobile Power Station is fully charged, all four
LED charging indicators will light up solid “Blue”.
The USB charging cable can be plugged into your
computer’s available USB port or any wall-plug style
power source.
Charging GearPower 2

3
Users need to identify the power supply current they need
for their devices. It usually can be found in the mobile
device manual.
• 1A output port supports: cell phones, smartphones,
iPhones, iPods, Windows phones, digital cameras and
most MP3 players and other devices which require 1A
power supply (This port will not support devices requiring
2.1A power source).
• 2.4A output port supports: iPads, tablets and other devices
which require 2.4A as well as cell phones, smartphones,
iPhones, iPods, BlackBerry phones, digital cameras and
most MP3 players.
1. Connect the USB Type A connection end of the charging
cable to the desired power output port (1A or 2.4A).
2. Connect the other end to your mobile device.
3. Once connected to the device, charging
will begin automatically. If charging does
not begin, simply press the battery
check button once to
wake the Mobile
Power Station.
Charging Mobile Devices
or

4
Product Caring
• Keep Mobile Power Station dry and away from moisture
and corrosive materials.
• Do not wash Mobile Power Station.
• Re-charge Mobile Power Station once every three
months when not in use.
When your device is done charging, the Mobile Power
Station and its LED charging indicators will automatically
turn off. To stop the charging process at any point during
device charging, simply long press the battery check
button for 2 seconds to turn off the Mobile Power Station.
Users need to identify the power supply current they need
for their devices. It usually can be found in the mobile
device manual.
• 1A output port supports: cell phones, smartphones,
iPhones, iPods, Windows phones, digital cameras and
most MP3 players and other devices which require 1A
power supply (This port will not support devices requiring
2.1A power source).
• 2.4A output port supports: iPads, tablets and other devices
which require 2.4A as well as cell phones, smartphones,
iPhones, iPods, BlackBerry phones, digital cameras and
most MP3 players.
1. Connect the USB Type A connection end of the charging
cable to the desired power output port (1A or 2.4A).
2. Connect the other end to your mobile device.
3. Once connected to the device, charging
will begin automatically. If charging does
not begin, simply press the battery
check button once to
wake the Mobile
Power Station.
LED Battery Indicator
This chart shows the
various stages of power
availability and
consumption on the
Mobile Power Station’s
LED battery indicator.
*When 1st LED flashes,
there is < 20% power.
1st LED*
20-40%
40-60%
60-80%
80-100%

5
Charging:
Discharging:
off off off
offoff off off
off off off
off off
off
off off
off
bright
bright bright
bright bright
bright bright
bright
bright bright bright
bright
bright
bright bright bright
bright bright bright bright
flash
flash
flash
flash
LED1 LED2 LED3 LED4
Level
0~25%
25~50%
50~75%
75~95%
100%
LED1 LED2 LED3 LED4
Level
0~5%
5~25%
25~50%
50~75%
100%

6
Warning
Do not damage the rechargeable battery. A damaged
battery can cause an explosion or fire, and can result
in personal injury and/or property damage.
To prevent injury or damage:
- Do not use or charge the battery if it appears to be
damaged. Signs of damage include, but are not limited to,
discoloration, warping, and leaking battery fluid.
- Do not expose the battery to fire, high temperature, or
direct sunlight.
- Do not immerse the battery in water.
- Do not use or store the battery inside a vehicle during
hot weather.
- Do not drop or puncture the battery.
- Do not open the battery or short-circuit its contacts.
Use the battery only for its intended use and according
to the instructions in the product documentation.
Avoid contact with the rechargeable battery if it
appears to be leaking. Battery fluid is corrosive, and
contact with it can result in personal injury and/or
property damage. To prevent injury or damage:
- If the battery leaks, avoid contact with the battery fluid.
- If battery fluid gets into your eyes, immediately rinse your
eyes with clean water and seek medical attention. Do not
rub your eyes!
- If battery fluid gets onto your skin or clothing, immediately
use clean water to wash off the battery fluid.
Charge and use the rechargeable battery only in strict
accordance with the instructions.
- Charging or using the battery in unauthorized equipment
can cause an explosion or fire, and can result in personal
injury and/or equipment damage.
To prevent injury or damage:
- Do not charge or use the battery if it appears to be
damaged or leaking.
- Discontinue charging a battery that gives off extreme heat
or a burning odor.
- Use the battery only in the equipment that is specified to
use it.
Never dispose of batteries in the garbage.
Disposal of batteries in the garbage is unlawful under
state and federal environmental laws and regulations.
Always take used batteries to your local
battery-recycling center.

7
Do not damage the rechargeable battery. A damaged
battery can cause an explosion or fire, and can result
in personal injury and/or property damage.
To prevent injury or damage:
- Do not use or charge the battery if it appears to be
damaged. Signs of damage include, but are not limited to,
discoloration, warping, and leaking battery fluid.
- Do not expose the battery to fire, high temperature, or
direct sunlight.
- Do not immerse the battery in water.
- Do not use or store the battery inside a vehicle during
hot weather.
- Do not drop or puncture the battery.
- Do not open the battery or short-circuit its contacts.
Use the battery only for its intended use and according
to the instructions in the product documentation.
Avoid contact with the rechargeable battery if it
appears to be leaking. Battery fluid is corrosive, and
contact with it can result in personal injury and/or
property damage. To prevent injury or damage:
- If the battery leaks, avoid contact with the battery fluid.
- If battery fluid gets into your eyes, immediately rinse your
eyes with clean water and seek medical attention. Do not
rub your eyes!
- If battery fluid gets onto your skin or clothing, immediately
use clean water to wash off the battery fluid.
Charge and use the rechargeable battery only in strict
accordance with the instructions.
- Charging or using the battery in unauthorized equipment
can cause an explosion or fire, and can result in personal
injury and/or equipment damage.
To prevent injury or damage:
- Do not charge or use the battery if it appears to be
damaged or leaking.
- Discontinue charging a battery that gives off extreme heat
or a burning odor.
- Use the battery only in the equipment that is specified to
use it.
Never dispose of batteries in the garbage.
Disposal of batteries in the garbage is unlawful under
state and federal environmental laws and regulations.
Always take used batteries to your local
battery-recycling center.

Compliance Information
FCC Statement
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential setting. This product generates, uses, and can
radiate radio frequency energy and, if not installed and
used as directed, it may cause harmful interference to radio
communications. Although this product complies with the
limits for a Class B digital device, there is no guarantee that
interference will not occur in a particular installation.
CE Compliance
This device has been tested and found to comply with the
following European Union directives: Electromagnetic
Capability (2004/108/EC), Low Voltage (2006/95/EC) and
R&TTED (1999/5/EC).
Canada, Industry Canada (IC) Notices
Complies with the Canadian ICES-003
Class B specifications.
Declaration of Conformity and related documents can be
downloaded directly from our website:
http://www.iogear.com/product/GMP8K/certifications
http://www.iogear.com/product/GMP16K/certifications
Charge and use the rechargeable battery only in strict
accordance with the instructions.
- Charging or using the battery in unauthorized equipment
can cause an explosion or fire, and can result in personal
injury and/or equipment damage.
To prevent injury or damage:
- Do not charge or use the battery if it appears to be
damaged or leaking.
- Discontinue charging a battery that gives off extreme heat
or a burning odor.
- Use the battery only in the equipment that is specified to
use it.
Never dispose of batteries in the garbage.
Disposal of batteries in the garbage is unlawful under
state and federal environmental laws and regulations.
Always take used batteries to your local
battery-recycling center.

Contact
Limited Warranty
iogear.custhelp.com
[e-mail]
www.iogear.com
19641 Da Vinci, Foothill Ranch, CA 92610
WE’RE HERE TO HELP YOU!
NEED ASSISTANCE SETTING UP THIS PRODUCT?
Make sure you:
1. Visit www.iogear.com for more product information
2. Visit www.iogear.com/support for live help and
product support
Warranty Information
This product carries a 1 Year Limited Warranty. For the
terms and conditions of this warranty, please go to
http://www.iogear.com/support/warranty
Register online at http://www.iogear.com/register
Important Product Information
Product Model
Serial Number
