ionmax ion612 User manual

User’s Manual
Inside you will find many helpful hints on how to use and maintain your dehumidifier properly.
Just a little preventative care can save you money and prolong the life of your unit.

INDEX
IMPORTANT SAFETY INSTRUCTIONS .................................................................................
FEATURES ..............................................................................................................................
SPECIFICATIONS ...................................................................................................................
PRODUCT DESCRIPTION ......................................................................................................
THE CONTROL PANEL ...........................................................................................................
UNIT SETUP.............................................................................................................................
TO OPERATE SAFELY ...........................................................................................................
OPERATING INSTRUCTIONS .............................................................................................
TO EMPTY THE BUCKET .......................................................................................................
TO DRAIN WATER (Continuous Drainage) .............................................................................
MAINTENANCE .....................................................................................................................
TROUBLESHOOTING .......................................................................................................
WARRANTY DETAILS ...........................................................................................................
1
2
3
3
4
5
5
6-8
9
9
10
11-12
13

IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE OPERATING.
WARNING - This appliance is intended for use in a domestic environment and light office
use only. Any other use is not recommended by the manufacturer and may cause fire,
electrical shocks or other injury to person or property.
When using electrical appliances, basic safety precautions should always be followed:
1. Do not operate the unit with a damaged cord or plug, after it malfunctions or has been
dropped or damaged in any way. Return to an authorized service facility for examination
and repair.
2. This unit should always be kept in an upright position to avoid any damage. The appliance
must be placed on a level flat surface during operation.
3. Check the household voltage to ensure it matches the units rated specification before
operating.
4. Operate this unit in an ambient temperature between 1°C and 40°C.
5. Ensure that the air inlets and outlets are not blocked or covered.
6. Do not place the unit too close to curtains or other objects - min 40cm.
7. When using the "LAUNDRY MODE" to speed up the drying of wet clothes in the room,
please keep the clothing at a safe distance from the unit to prevent water from dropping
onto the unit.
8. Never place anything on top of the unit and do not cover with any kind of material while
in use.
9. This product is intended for domestic and light office use ONLY and not for commercial,
industrial or outdoor use.
10. To protect against electrical shocks, do not immerse unit, plug or cord in water, or spray
with liquids.
11. Never unplug the power cord without press the "ON/OFF" key to off first, as this could
damage the unit.
12. Always unplug the unit when not in use or moving location. To disconnect from the
power supply, grip the plug and pull from the power socket. Never pull by the cord.
13. Always empty the water tank before storing the unit away.
14. Close supervision is necessary when any appliance is used by or near children and pets.
15. Do not run power cord under carpeting, or cover with rugs or runners. Arrange the
cord away from areas where it may be tripped over.
16. Never operate or store the unit in direct sunlight.
17. To repair the unit, take it to a qualified service engineer. Repairs carried out by
unqualified people may cause damage to the unit or injury to persons or property and
void the warranty.
18. Where possible, avoid the use of an extension cable as they may overheat and cause
a risk of fire. Only use an extension cord after ensuring it is in perfect condition.
19. Do not use the unit without the air filter.
SAVE AND READ THESE IMPORTANT SAFETY INSTRUCTIONS
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
1

FEATURES
• Compressorless dehumidifier - uses desiccant rotor technology
• Moisture removal - 7 litres/day (20°C RH60%)
• Water tank capacity - 2 litres
• Silver Nano technology filter
Kills bacteria on contact, improving the quality of air in your home or office
• Built-in ioniser
• Electronic louvre
• Laundry mode
• Up to 8 hour timer - for added convenience
• Temperature range for use ~ 1°C - 40°C
• Light & portable with carry handle
• Removable water bucket with handle
• Operating light
• Auto restart after power cut
2
SPECIFICATIONS
Model: Ionmax Ion612
Water tank capacity: 2 Litres
Power Consumption: 360W- 620W
Voltage: 220-240V ~ 50Hz
Net Weight: 6 Kg
- helps to dry out damp clothes
Once the power is restored after a power failure, the appliance will continue
to operate at the selected settings prior to the power failure.

Control panel
Air outlet
Bucket
Handle
Plug
Operation light
illuminates
when running
Hand grip to pull out
the bucket
Air inlet
Air filter
(Silver Nano Filter)
Continuous drain
hole
Water level indicator
(both sides)
PRODUCT DESCRIPTION
3 automatic
3D Louvre
louvre settings (main)
3

Ioniser Indicator
Water Full Indicator
Indicator lights up when the bucket is full of water or
incorrectly installed.
Check Indicator
Indicator lights up when the unit malfunctions.
Timer Indicators
Louvre Setting Indicators
Function Indicators
Ioniser Key
Timer Key
Louvre Settings
Control Key
Auto Dry Key
Power Key
Continuous / Laundry Mode Key
4
THE CONTROL PANEL

ON and OFF
Connect the power plug to the appropriate electrical socket outlet.
Press the ON/OFF button to turn the appliance ON.
Press the ON/OFF button again to turn the appliance OFF.
Note: In the event of a power failure
Once the power is restored after a power failure, the appliance will continue to operate at the
selected settings prior to the power failure.
This includes the drying mode, swing function and time remaining in timer mode.
Note: After turning the appliance OFF
After turning the appliance OFF using the ON/OFF button, the fan will continue to run for a two
minute period. This is a normal procedure and helps to cool & protect the internal components.
During this two minutes DO NOT remove the power plug from the electrical socket outlet;
wait for the fan to stop running.
6
OPERATING INSTRUCTIONS

AUTO DRY
Auto
Low (Quiet)
High
DESCRIPTION
Turbo
Saving
TurboSaving
OPERATING INSTRUCTIONS
Press the "AUTO DRY" Key for automatic dehumidification.
MODE DESCRIPTION
The unit automatically keeps room humidity
55~60% RH.
To keep the room at a comfortable Relative Humidity (RH)
level
To run low fan speed
The unit automatically dehumidifies in low fan
speed and low noise.
Super dry mode to prevent condensation
The unit automatically keeps room humidity
at 40~45% RH to prevent condensation in the room.
LAUNDRY MODE
Press the "LAUNDRY MODE" key for drying clothes or continuous running.
MODE
Suitable for summer to save power
The unit automatically provides warm dry air to
assist in clothes drying with low power.
Suitable in winter to dry clothes faster
The unit automatically provides heated air to dry
clothes faster with higher power.
55~60%RH
55~60%RH
40~45%RH
The fan speed & heater power are adjusted automatically.
7
ION
Press the "ION" Key to turn on and off the ioniser. When the LED is on
the unit release negative ions from the air outlet to purify the air.
Tip: Whilst the dehumidifier is running on fan mode only, turning on the ioniser effectively
purifies the air with negative ions and silver ion filtration.
Negative ions has a normalising effect on our bodies, providing the ideal conditions for the
body to function better, helps breathing and relaxation.

AUTO SWING LOUVRE
Press the "SWING" Key to select air louvre angle.
MODEDESCRIPTION
TOP
FRONT
WIDE
Up
Front
Wide
Hold
The automatic louvre swings in an upward
range of approx 100 °
TIMER MODE
P
Note: Do not touch the louvre with your hands while it is swinging. The range of swing will change.
ress the "TIMER" Key to select your desired running time (2,4 or 8 hours).
The unit will automatically switch off at the end of the selected time period.
As the time counts down the LED (4 or 2 hours) lights will indicate thetime remaining.
When no "TIMER" is set (the LED is off),the unit will run continuously, unless the
bucket is already full.
The automatic louvre swing in a wide
range of approx 150 °
The automatic louvre stops swinging when you press
"SWING" key and turns the LED off.
The automatic louvre swings inafront
range of approx 50 °
3D Louvre Adjustment
Wide airflow --- rotate to the WIDE position
Spot airflow --- rotate to the SPOT position
8
OPERATING INSTRUCTIONS

TO DRAIN WATER (Continuous Drainage)
You may use a hose with an inner diameter of 12mm for
continuous drainage:
1. Use a screwdriverto remove the knockout at the back. Attach
the hose to the connector through the hole.
2. The hose must lead to an appropriate drainat a downward
slope with no sharp bends.
Note:
1. Ensure the bucket is wellfitted in position before inserting the hose.
2. Before removing the bucket, ensure that the hose is disconnected.
TO EMPTY THE BUCKET
1. Whenthe bucket is full, the "FULL" LED lights and the unit stops
in a few minutes
2. Do not move the unit or remove the bucket, if the machine is still operating, as
water may leak, damage the unit or cause an electricshock.
3. To remove the bucket, pull it out gently by gripping the bottom of the bucket,
and lift carefully.
4. Remove the coverof bucket first, then pour the water away, clean the bucket and
restore the cover and the bucket to the correct position.
NOTE :
Clean the bucket with clean water if needed. Do not use detergent, solvent, abrasive
or hot water to avoid damage to the appliance.
Do not remove or damage the float in the bucket, or the unit cannot
work correctly.
The bucket cover must be wellfitted in position.
The "FULL" Led lights if the bucket is not well in place.
Knockout
Hose
Pull bucket out Lift by the handle Remove the cover Pour the water away
Restore the cover
and the handle Restore the bucket
9

MAINTENANCE
Cleaning the unit
1. Turn off the unit, wait for the fan to stop and unplug from the power socket.
2. Clean the surface with a soft damp cloth.
3. Dry thoroughly with a tower after cleaning.
4. In order to avoid damage, do not wash the machine with water, or let water
drip into the air inlet or outlet.
Cleaning the filter
If the filter is covered with dust, the airflow and the performance of the unit
will be affected. Check the filter periodically to ensure any dust is removed
(It is recommended to check and clean the air filter every 2 weeks or an
appropriate frequency depending on your usage and air environment).
1. Turn off the unit and remove the filter from the unit.
2. Clean the nano-silver filter only with a vacuum cleaner.
(Washing will weaken the germicidal effect of the filter)
3. Replace the filter in position.
Before storing
1. Turn off the unit, wait for it to stop and unplug from the power socket.
2. Clean and dry the bucket. Leave the unit to drain for approximately one day.
3. Clean the filter and the unit. Cover the unit to prevent it from
gathering dust. Store upright in a cool dry place.
4. Do not expose to direct sunlight.
How to Clean
0
10

!
TO OPERATE SAFELY
Do not insert small
objects into the unit or
this will damage it and
cause a hazard.
Do not remove
bucket when running
or water may leak.
Keep suitable space
as above
Ensure bucket is fitted correctly,
if the bucket is full or is not
in place, the "FULL" lights
and the machine stops.
5
f
l
Place the unit in an upright position on a stable,
flat surface.
Please ensure the unit is a safe distance away
from a wall or furniture (see the right graphic).
Please keep clothes at a safe distance
of 60 cm from air outlet of the unit to
prevent water dripping into the unit.
Where to position your dehumidifier?
For best results position the
dehumidifier somewhere central
like a landing or a hallway.
As long as the internal doors are open
the excess moisture from all of the rooms
in the house will migrate naturally towards
the dehumidifier and be processed.
Top
min 60cm
Air outlet
min 40cm
(When louvre closed)
min 20cm
(When louvre up)
Air inlet
min 20cm
min 20cm
min 50cm
CAUTION: Do not place the dehumidifier in a broom cupboard,
boiler room, small unventilated rooms etc. Avoid placing the
dehumidifier in small confined areas or in close proximity to a
radiator or heat source such as tumble driers, cookers etc. to
avoid the dehumidifier from overheating.
Do not use this dehumidifier in dusty or an industrial
environment where particles can get into the dehumidifier.
This will cause a malfunction and void your warranty.
UNIT SETUP

I
TROUBLESHOOTING
The following conditions are normal:
1. The fan is still running about 2 minutes after turning off the the unit.
2. The unit works within room temperature about 1~40ºC. It may stop operation
out of this range or when the air inlet or outlet is covered. (The "CHECK" LED light
will illuminate)
3. The unit includes heater function that could increase the room temperature.
If your Dehumidifier stops working or "CHECK" LED illuminates,
please check the following items first.
When the unit fails to run:
Is power cord unplugged or the power off?
Is "FULL" light on? Check the bucket is well in position?
Check and replace the bucket. Ensure unit is on a level and flat surface.
When the performance seems poor:
Is there any door or window open?
Is steam being generated in the room?
Is the room too big?
Is the filter dirty? Clean it. Refer to the filter cleaning instructions.
Is the inlet or the outlet covered?
When noise occurs:
Is the unit on a horizontal flat and level surface? Move and reset the unit.
Is the air filter dirty? Clean the filter.
NOTE:
1. If the "CHECK" LED illuminates, turn off the unit, unplug from the power socket,
check and clean the filter. If it is dirty, remove any obstacle that covers the air inlet
or outlet, and wait for at least ten minutes before plugging in and switching back on.
2. Please contact Andatech at 1300 800 200 if the problem continues.
Do not try to repair it by yourself, as this could cause an electrical shock and
void your warranty.
Try the laundry mode operation and let it run in this mode for a day.
Is the unit covered?
Is the unit positioned at the required minimum distances away from walls or objects?
(See page 6 Unit Setup)
11

TROUBLESHOOTING
Smell coming from the dehumidifier
When you first use the dehumidifier and periodically afterwards you might notice
a smell coming from the dehumidifier. This is caused by the Zeolite desiccant material
and is not a sign that the dehumidifier is faulty, nor is it harmful to humans or pets.
The smell occurs because the Zeolite absorbs odours from items like cigarettes,
cosmetics, hair sprays, building materials and new furniture and then when the
desiccant is heated the smell is discharged into the room. This smell has been
described as being like a burning smell or a sour smell. It is normal, will not last long
and is not a sign of a fault.
Amount of water collected
When you first use your dehumidifier it will work harder to reduce the room humidity
to it's target of eg. 55-60%RH (on Auto mode), this is the time when it will produce the most
water and need emptying most frequently. As the room becomes dryer the dehumidifier
collects less water and runs at a lower fan speed. This is normal. When the target relative
humidity has been reached the air coming out of the dehumidifier will not be heated and it
will only be running in low fan mode. This is because there is no need for dehumidification
at this point and the dehumidifier is sampling the air to check the current relative humidity
to see if dehumidification is required.
If you find that you still have condensation on your windows or you need to dry the air
further then using the High fan speed, or the Turbo Laundry mode, will force the
dehumidifier to dry the air further to 40-45%RH. This might well be necessary if you have
single glazed windows or if the outside air temperature drops to freezing.
Ventilation
The dehumidifier must not be placed in a confined space. Move the dehumidifier to a
well ventilated area for example in a hallway, landing or a ventilated room. Ensure that
its not in close proximity to any form of heat source, such as a radiator or appliances
that generate heat (eg tumble dryer or cooker). The air inlet and outlet must not
be obstructed.
12

WARRANTY DETAILS
13
WARRANTY D E TA I L S
Congratulations on your purchase! It is our aim to provide you with quality products that you can
trust. Our products come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or a refund for a major failure and for compensation for any
other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
The Guarantee
The product is guaranteed to be free from defects in workmanship and parts for a period of 12
months from date of purchase for domestic use and 3 months for commercial use. Defects
that occur within this warranty period, under normal use and care, will be repaired, replaced or
refunded at our discretion, solely at our option with no charge for parts and labour. The benefits
conferred by this warranty are in addition to all rights and remedies in respect of the product that
the consumer has under the Trade Practises Act and similar state laws.
Proof of Purchase
This warranty is valid for the original purchase and is not transferable. Please keep your purchase
docket or receipt as proof of purchase and as proof of date on which the purchase was made. The
purchase docket (or a copy) or receipt must be presented with the warranty when making a claim
under this warranty.
Service during the Warranty Period
Please ensure that the RA# (Return Authorization Number) is clearly stated on the outside of the
packaging. Don’t have one? Call us on 1300 800 200 and we’ll get you one. Please ensure the
product is properly packaged so as to ensure that no damage occurs to the product during transit.
Extent of Warranty
This warranty is limited to defects in workmanship or parts. All defective products or parts will be
repaired or replaced. This warranty does not cover manuals and packaging.
Normal Wear and Tear
This warranty does not cover normal wear and tear to the product or parts.
Exclusions
This warranty does not cover:
• Any defect caused by an accident, misuse, abuse, improper operation, lack of reasonable
care, unauthorised modification, loss of parts, tampering or attempted repair by a person not
authorised by the distributor.
• Any product that has been damaged by a lightning strike either directly or indirectly or a mains
power surge or liquid ingress.
• The product if it is located outside of Australia.
• Any damage caused by improper power input or improper cable connection.
Andatech Corporation Pty. Ltd.
Factory 7, 2-4 Apollo Court, Blackburn Victoria 3130
Phone: [phone] Fax: [phone] Email: [e-mail]
