IPC Gansow 1250 P User manual

PLDC02161 1
1250-1280 P / D, Quick guide
This guide is intended for quick consultation only and does not replace the user and maintenance manual.
Before using the machine, read the user and maintenance manual contained in the machine’s packaging thoroughly and strictly
follow all the instructions.
PREPARATION & OPERATION
Pull the STARTER lever.
Move the engine speed control lever to
the maximum position on the right.
Move the lever to the “START” position
and hold it there.
Switch the machine on by turning the
ignition key to START, when the engine
starts release the key in the ON position
and release the lever that had previously
been held in the “START” position.
Lower the main brush.
Lower the side brushes.
Activate suction using the lever, adjusting
air ow to ensure suction of the dust Do
not use suction on wet surfaces.
Press the accelerator pedal to start
travel, pressing it to the right the machine
will move forwards, pressing it to the left
the machine will move backwards.
To collect voluminous objects, press the
front ap lift pedal
To stop the machine, press the brake
pedal, which also acts as parking brake,
using the special locking lever.
Emptying the bottom unloading debris
bin, model 1250:
• Release the bin lock.
• Pull out the rear bin by means of its
handle.
• Take the bin (which is tted with
wheels) to the rubbish collection
point and empty it.
Emptying the bottom unloading debris
bin, model 1280:
• Lift the bin to the desired height,
holding the enabling button and
moving the selector located on the
instrument panel.
• Pull the lever to rotate the bin and
empty its contents.
O
F
F
O
N
S
T
A
R
T
O
F
F
O
N
S
T
A
R
T
O
F
F
O
N
S
T
A
R
T

PLDC02161 2
DAILY MAINTENANCE
When you have nished cleaning, pro-
ceed as follows:
• Switch the machine off, after having
moved the engine speed lever to the
minimum position.
• Activate the parking brake.
• Raise the centre brush and the side
brushes, to prevent damage.
CLEANING THE DUST FILTER
Deactivate suction using the lever.
Activate the lter shaker for 10 seconds
using the corresponding button.
Empty the debris bin.
Check and remove any debris wrapped
around the side brushes and on the
centre brush.
WEEKLY MAINTENANCE
Check that the suction lter is tight and
clean.
REPLACING THE CENTRE BRUSH
• Unscrew the knob and open the door on the left of the machine.
• Unscrew the three knobs securing the brush compartment cover.
• Pull out the brush cover compartment.
• Remove the brush, holding it on the plastic core.
• Remove the adapter from the core of the old brush and t it to the
new brush, taking care to keep the bristles aligned in the same direc-
tion.
• Fit the new brush and make sure that the adapter is inserted on the
drive hub.
• Replace the brush compartment cover using the knobs, following the
dismantling operations in reverse order.
ADJUSTING CENTRE BRUSH PRESSURE
• Unscrew the knob indi-
cated.
• Turn the lever anti-
clockwise to increase
pressure, making sure to
align the knob fastening
hole.
• Screw the knob back on.
ADJUSTING SIDE BRUSH HEIGHT
• Move the side brushes to the working
position.
• Loosen the two adjustment screws
underneath the brush lifting knob.
• Manually move the brush to the re-
quired position.
• Tighten the adjustment screws.
FLOW
