IPC Gansow CT70 Rider User manual

PLDC01873
CT70 Rider Quick Guide
This Guide is intended for quick consultation only and does not replace the Use and Maintenance Manual.
Before using the machine, read the Use and Maintenance Manual contained in the machine packaging thoroughly and rigorously respect all the
instructions.
PREPARATION/
OPERATION
1. Fill the detergent tank.
2. Turn the ignition key to
switch the machine on.
3. Press the brush button to
activate operation of the
head and suction motor.
4. Press the suction motor
button to disable suction if
you want to prewash the
surface.
5. Press the "H2O" button for
at least 2 seconds to
enable detergent flow. Set
the type of detergent flow
(MANUAL or AUTOMATIC)
on the machine’s software
(see the Use and
Maintenance Manual)
6. Choose the direction of
movement by moving the
direction selector
7. Turn the potentiometer to
set work speed.
8. Operate the accelerator
9. Begin working.
10. When you have finished
cleaning, proceed as
follows:
•Turn the brush motor off.
•Stop the detergent flow
•Turn the suction motor
off.
•Press the emergency
button
•If necessary, charge the
batteries.
DAILY MAINTENANCE
Empty the dirty water drum
through the drain hose.
Clean the dirty water drum.

PLDC01873
Check the suction filter is
undamaged and clean.
Check the detergent tank fill filter
is undamaged and clean.
Check the detergent output filter
is undamaged and clean.
Clean the brushes.
Check the squeegee is clean and
the blades are not damaged.
Check the battery charge.
To recharge, plug in the battery
charger connector
REPLACING THE SQUEEGEE BLADES
•release the clip;
•remove the two blade retainers by pushing them towards the outside of the squeegee then extracting them;
•remove the blade;
•reuse the same blade by reversing the edge in contact with the floor until all four edges are worn out, or replace with a
new blade, fitting it onto the screws on the body of the squeegee;
•reposition the two blade retainers by centring the widest part of the slots over the fixing screws on the squeegee body,
then pushing the blade retainers inwards;
•fasten the clip.
MANUAL BRUSH ATTACHMENT
Position the brushes under the head drive disk. Lift the right brush with your hands and turn it anticlockwise, locking it in position on the drive disk. Lift
the left brush with your hands and turn it clockwise, locking it in position on the drive disk.
AUTOMATIC BRUSH RELEASE
Stop the brushes and the suction motor by pressing the brush and suction motor buttons. Hold the automatic release button down for at least five
seconds and the machine releases the brushes from the head automatically.
TROUBLESHOOTING
THE MACHINE DOES NOT COME ON/START UP CHECK THE EMERGENCY BUTTON IS NOT PRESSED
CHECK THE BATTERY CHARGE
THE SUCTION MOTOR DOES NOT WORK CHECK THE DIRTY WATER DRUM IS NOT FULL
CHECK THE DIRTY WATER DRUM LEVEL SENSOR IS NOT BLOCKED/MALFUNCTIONING
THE MACHINE LEAVES THE FLOOR WET
CHECK THE SQUEEGEE BLADES ARE NOT WORN
CHECK THERE IS NO DEBRIS BETWEEN THE TWO SQUEEGEE BLADES
CHECK THERE IS NO DEBRIS IN THE SUCTION HOSE
CHECK THE SUCTION FILTER IS UNDAMAGED AND CLEAN
CHECK THE DIRTY WATER DRUM LID SEAL IS UNDAMAGED.
CHECK THE SUCTION HOSE IS CORRECTLY ATTACHED TO THE SQUEEGEE
THE MACHINE LEAVES THE FLOOR DIRTY CHECK THE TYPE OF BRUSH/PAD IN USE IS SUITABLE FOR THE TYPE OF DIRT AND FLOOR.
THE MACHINE LEAVES STRIPES OF WET FLOOR
CHECK THE FLOOR HAS BEEN BRUSHED BEFORE USING THE MACHINE
CHECK THERE IS NO DEBRIS BETWEEN THE TWO SQUEEGEE BLADES
CHECK THE SQUEEGEE BLADES ARE NOT WORN
CHECK THE SQUEEGEE IS CORRECTLY ADJUSTED
