Ipc Sg-10 User manual

IPC SG-10

STEAM CLEANER

OPERATOR MANUAL

Clemas & Co. Unit 16 Ashchurch Business Centre, Alexandra Way, Tewkesbury,

Gloucestershire, GL20 8NB.

Tel: 01684 850777 Fax: 01684 850707

Email: [email protected] Web: www.clemas.co.uk

MANUALE ISTRUZIONI

INSTRUCTION MANUAL

BETRIEBSANLEITUNG

MANUAL DE INSTRUCCIONES

Attenzione: Per l'uso dell'apparecchio, si consiglia di aver letto e compreso il contenuto di questo

manuale.

Attention: in order to use this machine, it is advisable to have read and understood the content of

this manual.

SG-10

Mod. S 5007 M –S6008 M

9

SG-10

Mod. S 5007 M –S 6008 M

OPERATING INSTRUCTION MANUAL

Attention: in order to use this machine, it is advisable to have read and understood the content of this

manual.

10

INTRODUCTION

This manual is an integral part of the

appliance and it contains all the

necessary information for its

operation and maintenance. The user

must read it carefully before starting

the appliance.

ORIGINAL INSTRUCTION

The text was scrupulously revised, however, any

eventual printing mistake should be indicated to the

manufacturer. Moreover, in order to improve the

product we reserve the right to modify and update this

publication without notice. Any reproduction of this

manual, even partial, is forbidden without the

authorization of the manufacturer.

INTENDED USE

Professional steam generator cleaner:

The functions provided for this appliance are exclusively

the cleaning of floor and washable surfaces compatible

with steam, textiles included; (not to be used on

electrified parts).Any other use other than that, it is to

be considered unauthorized and dangerous.

IDENTIFICATION AND TECHNICAL DATA

On the label attached on the back of the machine, you

can find the technical specification shown in the chart

below:

Model: SG-10 S 5007

S 6008

Electric power supply 230 V - 50 Hz

Max power 2,25KW

3,25KW

Steam pressure 500 kPa (5 bar)

600kPa (6 bar)

Steam production 60÷70 g/min.

65÷80 g/min.

Boiler capacity 1.8l

Heating time 4 min.

3 min.

Acceptable pressure 700 kPa (7 bar)

Boiler max power 2200 W

3200W

Boiler material inox Aisi 304

Steam max temperature 160° C

165°C

Weight 4.2 kg

4.5Kg

Dimensions LxPxH 350x460x310

350x460x330

Tolerated water conductivity values 80÷1500uS/cm

Appliance of class I

SAFETY DEVICES OF THE PRODUCT:

Ceramic thermostat 175 ° C "to restore manually"

(frontal to the boiler, it begins to work in the event of

excessive temperature)

“One Shot” ceramic thermostat 185 ° (placed inside the

boiler, it begins to work in case of excessive

temperature or pressure)

Safety valve 700 kPa (7 bar), (it allows the discharge of

the steam in excess in case of anomalous condition of

the machine under pressure).

Low voltage in the handle (safety voltage used for

connection to the inside of the hose).

USED SYMBOLS

GENERAL DANGER: when used,

this symbol indicates the need to

carefully pay attention to the

functions or notes described

MAINTENANCE: operations and

maintenance details

STEAM : attention hot steam jets

HOT SURFACES: attention burns

DECOMMISIONING: rules to be

followed at the end of the product

life

DO NOT DIRECT THE JET

towards persons, animals, electrical

equipment under pressure or the

machine itself

SAFEGUARDS RULES

- The Electric power connection must be made by a

qualified electrician and must conform to IEC 60364-1.

It is recommended that the electric supply to this

machine should include a residual current device that

interrupts the power supply if the leakage current to

ground exceeds 30 mA for 30 seconds or a device that

checks the grounding circuit.

- WARNING Children or unqualified persons should not

use the machines.

- The device can be use by persons with reduced

physical, sensory or mental capabilities, or lack of

experience or knowledge as long as they are under

surveillance or after having received instructions

regarding the safe use of the appliance and after the

comprehension of its dangers.

-Children must not play with the appliance.

- The appliance must be disconnected from the plug

after use and before the user performs maintenance on

the unit.

- The cleaning and maintenance meant to be performed

by the user should not be made by children without

supervision.

- The liquid or steam must not be directed towards the

devices which contain electrical components, such as

the interior of ovens.

- Do not use in swimming pools when they are full of

water.

- Do not leave the device unattended when it is

connected to the power.

- Do not use the device if it has been dropped, if there

are visible signs of damage or if there are losses.

- Maintain the machine out of reach of children when it

is used or it is cooling down.

11

- If the power cord is damaged, it must be replaced by

the manufacturer, its service agent or a similarly

qualified person in order to avoid any hazard.

- Do not use the machine if the power cord or important

parts of the machine are damaged, for example, the

safety devices, tubes under pressure, the gun trigger.

- If you are using an extension cord, the plug and

socket must be watertight.

- Inadequate extension cords can be dangerous.

- Do not spray or jet-wash the equipment.

- Jets can be dangerous if used improperly. The jet

must not be directed at persons, electrical equipment

under pressure or the machine itself.

- WARNING Risk of explosion. Do not spray flammable

liquids.

- WARNING Hoses, fittings and connections are

important for the safety the machine. Use only hoses,

accessories and couplings recommended by the

manufacturer.

- WARNING To ensure the safety of the machine, use

only original spare parts supplied by the manufacturer

or approved by him.

- WARNING The machine must be disconnected from

the power supply by disconnecting the plug from the

outlet during cleaning, maintenance and when replacing

parts or as it converts the machine to another function.

- The appliance must be always placed flat on the floor

during normal use, so as to prevent it from falling.

- WARNING The boiler of this machine is designed to

be used with water as described in the instructions, the

use of other cleaning agents or other chemicals may

jeopardize the safety of the machine.

-The steam generator must not be used in presence of

corrosive or potentially explosive atmospheres (gas,

vapors o inflammable mists and/or combustible dust).

- Do not immerse the appliance in water for cleaning.

WARNING DURING USE

During use, the following minimum instructions

should always be followed:

Be careful not to touch nozzles, they become hot

during the steam output.

Pay attention to the contact with the external

surfaces of the machine during use, they can

overheat.

The steam generator is equipped with a security

cap, its purpose is to regulate the pressure in the

tank if too high.

In case of foam or liquid leakage from the bottom,

turn off right away!

The appliance must be disconnected from the

power before performing any maintenance.

Never use the appliance without shoes.

Do not use the device or touch the plug with wet

hands.

Do not use the machine if there are people in its

range, unless they are wearing protective clothing.

Do not direct the jet towards yourself or other

people to clean clothes or footwear.

Do not open the filling orifice during use.

Do not spray or jet-wash equipment.

Do not use the appliance outdoors in case of rain,

or exposed to high temperatures under the sun.

Do not cover the machine with cloth or similar

things during its use or until it remains hot, give it

time to cool down.

► Do not tow with vapor pipe or cable, it could

get damaged!

► An inadequate extension of the cable

can also be dangerous

12

CONTROL PANEL

1 General switch

2 Display

3 Water-filling cap

4 Steam adjustment knob

5 Connector block for hose

PREPARATION and START TO USE

Open the cap (3) and fill the tank with tap water.

-Note: If the water available should be

"very hard"(>20°F), It is recommended the use of 50%

demineralized water or distilled water, (this to avoid

excessive limestone formations and to be sufficiently

conductive)

ATTENTION: Do not add detergents, anti-limestone

solutions or essential oils in the water tank boiler, these

can cause irreparable damage to the boiler and circuits.

The manufacturer is not responsible for any damage

caused by improper use.

Connect the plug to a socket on an electrical

interconnection conformed to the rules of the country,

equipped with a switch and an earth terminal efficient.

START TO USE:

Turn the main switch on (1).

The display (2) will turn on and indicate the

temperature-pressure status of the machine, when the

machine is ready, it will visualize “170”. (usually the

machine needs around 2÷3 minutes to be ready.)

The machine starts heating.

Choose the most suitable accessory for the needed

use and connected it to the multifunction handle, by

means of the extension tubes, then insert the hose

connector as shown by the white arrow in the picture.

When the machine is ready, to release steam through

the handle of the flexible, press the lever button (6).

Now use the brush or accessory in the surfaces to be

cleaned.

Attention: it is recommended to perform the first

release of steam after the heating on a container for

about a minute, this is to collect any condensate water

generated in the initially cold ducts.

Attention: if you are working on delicate

surfaces or things, keep the steam jet at an

adequate distance of at least 20-40cm.

STEAM RELEASE REGULATION:

Through the regulation knob (4) placed

frontally on the machine, you can gradually adjust the

release of the steam.

END OF WATER: The acoustic and the visual

indicator of the display (2), indicates when there is no

more water inside the tank by showing "H2O", this is

why the machine will stop the steam release.

WATER SUPPLY:

Proceed as decribed:

Open the cap (3) and refill the tank with water (see

note PREPARATION).

Close the cap.

Push the lever button (6) of the hose handle to re-start

working. (you can hear the pump starting to work)

please wait a few seconds and then re-start your

cleaning operation with steam.

1

2

3

4

5

2

3

1

6

13

ACCESSORIES AND USE:

FLEXIBLE HOSE AND HANDLE

To release steam

just keep pushed

the button placed in

the handle, the

product is designed

to ensure maximum

practicality.

EXTENSION TUBES

The extension tubes can

be used in pairs or

individually, depending on

the desired distance and

they should be used with

floor brush, triangular

brush or other specific

accessories.

WINDOW SQUEEGEE

This accessory

can be applied

directly to the

flexible.

It is ideal for

cleaning glass,

tiles, windows and

other flat surfaces.

With the lower

rubber brush you can clean and with the top you can

remove the film of water.

WARNING! When cleaning cold glass (in winter),

apply the steam from a distance of at least 50 cm.

RECTANGULAR BRUSH

This accessory must

be connected to the

hose or the extension

tube, after having

plugged it to the

JOINT.

This brush is ideal

for large surfaces

and floors. With two

bristle row, this brush is indicated for the treatment of

hard surfaces: Marble - Ceramics - Cotto.

The brush has on the top of two pliers for cloth, it can

be used with or without cloth.

The cloth offers a great power of absorption and

cleaning, and it is designed to mitigate the power of

steam released during the treatment of very delicate

surfaces such as wood - Laminate - Parquet - treated

Cotto.

TRIANGULAR BRUSH

STEAM LANCE

This accessory can be

applied directly to the

flexible.

Suitable for having a

powerful jet of steam

conveyed the nozzle

exit. Pay attention

when cleaning delicate

surfaces, start the

steam release

maintaining a minimum distance of 20-40cm and

then bring it closer depending on the desired result

and the treated surface.

JOINT

This accessory is necessary to use the

two brushes, RECTANGULAR and

TRIANGULAR.

Use this joint with the desired brush by

inserting it into its seat, making sure that

to hook it must be rotated of 90° with

respect to the working or vertical

position.

BRUSHES

These brushes are

to use with the

accessory STEAM

LANCE. They are

used to remove

resistant dirt and for

deep cleaning, even

in the corners or

small spaces. Choose the nylon or brass type

according to the surface to be treated.

This accessory must be

connected to the hose or

the extension tube, after

having plugged it to the

JOINT.

Used for cleaning corners

and clothes.

Ideal also for cleaning

mattresses, sofas, chairs,

car seats,other products

with fabrics and in general

in all those places not accessible by the rectangular

floor brush.

14

MANTAINANCE

*Always remove the plug before

cleaning or carrying out operations

on the machine.

For the safety of the operator and to ensure an always

perfect performance, we recommend the following

checks and maintenance:

AFTER EVERY USE:

For a correct cleaning, it is advice to clean the machine

and its accessories with a clean cloth moistened only

with a few drops of water. Do not use alcohol or other

solvents, they may damage the plastics and

components.

To maintain efficient and easy to couple the

accessories, check the o-ring seal (steam sealing

gaskets) and possibly wet them with a little silicone

grease.

PERIODICALLY:

Periodically check that the power cord does not show

signs of wear or aging. If it is damaged, it is absolutely

necessary to get it replaced by specialized personnel

before being able to re-use the appliance again.

BOILER CLEANING

Clean the boiler in our authorized centers once a year.

RINSE: It’s recommended at least every 50 hours of

operation or 4 months.

a) DISCHARGE: The machine must be cold or definitely

discharged from the steam pressure and the plug

disconnected. Open it by pulling the rubber cap placed

under the machine in correspondence of the boiler (see

image below) and with an allen wrench 6mm open the

drain plug, shake slightly the machine to let the water

and the completely dissolved limestone out.

When the boiler is empty, clean and close carefully the

cap tightening it with the wrench.

b) FILLING: Fill the water tank (3), turn the machine on

and make it start again, waiting for the boiler to be re-

charged again.

(att: Att: it may be that during the first charge cycle, the

“end of water” light turns on and you need to shut

down/restart the machine to complete the load)

BOILER CLEANING:

The boiler cleaning is recommended at least every

100 hours of operation or 8 months.

After having necessarily made the boiler exhaust (see

paragraph RINSE in step a), ensure that the water

level in the plastic refill tank (3) is at least up to the

middle. Shake the machine well and then turn it

upside down to discharge any residual deposits in the

tank.

Dissolve in 1 liter of water about 15% of citric acid (if

in powder or granules, 150g of citric acid dissolved for

each liter of water).

(Alternatively it is possible to use 0,3 liter of water with

0,7 liter vinegar).

Insert the prepared liquid in the refill tank of the

machine. (3).

Connect the power plug, turn on the main switch.

Wait for the pump to finish filling the boiler. (Att: it may

be that during the first charge cycle, the “end of water”

light turns on and you need to shut down/restart the

machine to complete the load).

When fully charged, turn off the main switch, unplug

the power plug and let the machine to rest for 6-7

hours.

(Att: do not let inside the solution over the indicated

time period to avoid damaging the steel of the boiler)

With the machine cold, shake it well and then open

the drain plug, now empty well all the limestone

dissolved in the solution, rinse it again entering from

the drain hole a couple of glasses of clean water.

Now clean and close the drain plug carefully.

* Fill the charging tank (see Preface) with clean water

and turn on the machine. Wait for it to charge and

heat.

Now, for about 10 minutes the steam supply will smell

of lemon given by the washing performed.

When the boiler cleaning is finished, restart the

machine, following the instructions in “Start to use”.

►* after the cleaning operations of the boiler, it is

advisable to check if the caps under the machine leak,

in this case check their closure with a wrench or

replace the seal after the machine cools down.

15

PROBLEMS AND SOLUTIONS

FAULT

Steam leaks from the accessories

SOLUTION

due to wear or damage of o-rings. Replace them taking

care not to damage them and insert them with attention.

FAULT

Steam tube plug is difficult to insert into the outlet of the

machine

SOLUTION

Do not force to insert it, but put a bit of silicone lubricant

on the o-rings and into the joint connection .

FAULT

The boiler needs more time to warm up.

SOLUTION

Clean the boiler as described. In case, make the

absorption with the power rating indicated in the

technical data check.

FAULT

Pressure drops quickly while using the steam

SOLUTION

It is due to limestone, clean the boiler as described.

FAULT

Intervention of the circuit breaker during use.

(Probable dispersion from the resistance or electric

valve to ground)

SOLUTION

Check that the power cord is not visibly damaged.

Try connecting the plug into a different socket.

Verify that there are no spills or leakage of water from

the machine, in this case have it checked by a qualified

center.

DECOMMISSIONING:

DISPOSAL AND RECYCLING

Do not discard the components of the appliance

into the environment. For more information on

proper disposal of the household appliances,

holders may contact the public service responsible

or resellers.

The symbol of the crossed bin on the appliance or

its packaging indicates that at the end of its life

the product must be collected separately from

other waste. This product complies with the EU

Directive2011/65/UE. Within the meaning of the EU

Directive 2012/19/EU in the field of electric and

electronic equipment, do not dispose of the

appliance with the normal household waste but

hand it over to a center of differentiated collection

journal. The user must take the appliance to an

appropriate center for electronic goods and

electro-technical ones or return it to the seller

when purchasing of a new equivalent device, on

a one-for-one basis. An appropriate recycle,

treatment and compatible environmental disposal

of the device help to avoid possible negative

effects on the environment and on the health and

facilitates the recycling of the materials of which

the device is composed. Abusive disposal of the

product by the user implicates sanctions in

accordance with the current law. For more

information regarding the recycling methods,

please contact the competent local authorities.

DICHIARAZIONE DI CONFORMITA’ “CE”

Dichiariamo sotto la nostra esclusiva responsabilità che

il prodotto al quale questa dichiarazione si riferisce è

conforme alle seguenti Direttive Comunitarie:

“CE” CONFORMITY DECLARATION

We declare on our own responsibility that the product

to which this declaration refers is in accordance with

the following European Community Directives :

“CE” KONFORMITÄTSERKLÄRUNG

Auf unserer Alleinverantwortung erklären wir, daß das

Produkt, auf das sich diese Erklärung bezieht

entspricht den folgenden Richtlinien der Europäischen

Gemeinschaft:

DECLARACIÓN “CE” DE CONFORMIDAD

Bajo nuestra exlusiva responsabilidad, declaramos que

el producto, al que esta declaraciòn se refiere, es

conforme con las siguientes directivas comunitarias:

DECLARAÇÃO “CE” DE CONFORMIDADE

Declaramos sob a nossa exclusiva responsabilidade que

o produto ao qual esta declaração se refere está em

conformidade com as seguintes directivas comunitárias:

DECLARATION DE CONFORMITE “CE”

Nous déclarons sous notre exclusive responsabilité

que le produit auquel cette déclaration se réfère est

conforme aux directives européennes suivantes

communautaire

2006/42/CE –2014/30/UE - 2011/65/UE

NOTE

..............................................................................................................................................................................

NOTE

..............................................................................................................................................................................

IPC SG-10 User manual

Popular Steam Cleaner manuals by other brands
