Automatic Passenger Counting
IRMA 6
Installation Manual
IRMA6-SENSOR-HD-00-SWITCH-IO-00-(R)
IRMA6-SENSOR-HD-00-SWITCH-00-(R)
Rev. 1.4
12/2020

IRMA6
-SENSOR-HD-00-SWITCH-(IO)-00-(R)(1) Installation Manual | Released
Rev. 1.4 | 12/2020
2 / 27
Model Sensor:
IRMA 6
Sensor variant:
for Switch
Function:
Automatic passenger counting system with
80.000 px ToF (Time-of-Flight)-technology for
vehicle and railway application, consisting of
sensor unit and interface unit. Generates real-time
counting data for further processing via Ethernet
to on-board computer. Mounted above doors.
Used symbols
Please note. See document on our website.
See annex. Please note down.
Information. Download.
Instruction.
Disclaimer The information contained in this document is based on product data resulting from the development and
approval phases as well as the production of initial samples. These specifications do not claim to be error-free
and will need to be updated or corrected. Such modifications may be made by iris-GmbH without notice.
Characteristic or typical values given are based on our experience and are approximate values to be expected;
they are by no means guaranteed by iris-GmbH.
Contact iris-GmbH
Schnellerstrasse 1–5
12459 Berlin
Germany
Phone: [phone]
E-mail: [e-mail]

IRMA6
-SENSOR-HD-00-SWITCH-(IO)-00-(R)(1) Installation Manual | Released
Rev. 1.4 | 12/2020
3 / 27
Table of content
1IRMA 6 overview ......................................................................................................................................................... 4
2Mounting ...................................................................................................................................................................... 6
2.1 Mounting 2 sensors per door.................................................................................................................................. 9
3Connecting IRMA 6 (optionally with angled M12 connectors) ...................................................................11
3.1 Ensuring power supply ...........................................................................................................................................14
3.2 Connector types........................................................................................................................................................15
4Configuring IRMA 6..................................................................................................................................................16
5IRMA 6 components.................................................................................................................................................25
6Check of the installation.........................................................................................................................................26
7Drilling templates.....................................................................................................................................................27

IRMA6
-SENSOR-HD-00-SWITCH-(IO)-00-(R)(1) Installation Manual | Released
Rev. 1.4 | 12/2020
4 / 27
1IRMA 6 overview
Fig. 1: IRMA 6 in vehicles – placement above doors, cross section in vehicle, door area in vehicle
• The mounting height must not exceed 2.40 m (3 m in
preparation).
Table 1: Dimensions depending on door height
• The door-to-IRMA 6 distance must not exceed 20 cm if the
installation height is less than 2 m.
Door height Covered door width Distance max
• The inclination angle of IRMA 6 must not exceed 5°. 1.90 m 1.50 m 20 cm
For the relation between maximal distance
(door – sensor), counting width and the door height see Table 1,
p. 4.
These values are standard values. In many cases wider ranges can
be covered. Please consult [e-mail].
2.00 m 1.65 m 20 cm
2.10 m 1.80 m 35 cm
2.20 m 1.95 m 40 cm

IRMA6
-SENSOR-HD-00-SWITCH-(IO)-00-(R)(1) Installation Manual | Released
Rev. 1.4 | 12/2020
5 / 27
IRMA 6 components Travel direction
Fig. 2: IRMA 6 components
1 Mounting screws
2 M12 Ethernet connector (f)
3 M12 Ethernet connector
4 Leaf spring
5 Internal connector
6 Mounting hook
7 Sensor unit
8 Door panel
9 M12 power supply connector (m)
10 M12 door contact connector (on demand) (f)
11 Interface unit
IRMA 6 comes with normal M12 connectors or with angled M12 connectors to save space.

IRMA6
-SENSOR-HD-00-SWITCH-(IO)-00-(R)(1) Installation Manual | Released
Rev. 1.4 | 12/2020
6 / 27
Needed Tools
Drilling machine
with twist drill (10 mm)
Jig saw Hex Key
size 4 mm
Most relevant steps at a glance Essential directives for installation
1. Prepare needed tools and drilling templates, IRMA 6 sensors as well as
cables for doors to be equipped.
2. Install IRMA 6 into vehicle doors panels and connect IRMA 6 via Ethernet
to data transmission, to power supply and (optionally) to door contacts.
3. Configure IRMA 6 via web interface, while using RJ 45 service cable and
ETH interface.
4. Perform a commissioning test on your pc or on-board computer.
•In all considerations with regard to installation positions and orientation, it is
assumed that the observer is inside the vehicle.
•The sensor-to-door distance must not exceed 20 cm if the installation height is less
than 2 m, see Table 1, p. 4.
•Install IRMA 6 on a horizontal surface. The maximum permissible deviation from the
horizontal plane is ±5°.
•IRMA 6 must be installed by staff that follows the pertinent regulations and the
installation manual.
2Mounting

IRMA6
-SENSOR-HD-00-SWITCH-(IO)-00-(R)(1) Installation Manual | Released
Rev. 1.4 | 12/2020
7 / 27
Choose position in door panel Drill 4 holes and saw out template for IRMA 6
Travel direction
Drill 4 holes with drilling machine and saw ou the template with jig saw in the
door panel according to measures in attached drilling templates, see Drilling
templates, p. 27.
Put sensor unit in Fit sensor unit into interface unit
Put the IRMA 6 sensor unit via the mounting hook into the drilled hole
in the door panel.
Fit in in the internal connector and the attaching form of the senor unit
into the interface unit which is above the door panel.
Interface unit
Sensor unit
Door panel
1.7 -8 mm
Outside
Door panel
Inside

IRMA6
-SENSOR-HD-00-SWITCH-(IO)-00-(R)(1) Installation Manual | Released
Rev. 1.4 | 12/2020
8 / 27
Tighten screws with hex key
Max. 3 Nm Max. 3 Nm
Tighten both screws max. 3 Nm with a hex key (4 mm) on the interface unit.For easy and correct connection to the cables: Align the M12 connector so that the stop lug is
centered toward the top of the labels!
Connect IRMA 6
Connect IRMA 6 via (angled) M12 connectors to the Ethernet
network, to voltage supply and optionally to the door contacts.
Angled M12 connectors, slewable (180°), optionally available.

IRMA6
-SENSOR-HD-00-SWITCH-(IO)-00-(R)(1) Installation Manual | Released
Rev. 1.4 | 12/2020
9 / 27
2.1 Mounting 2 sensors per door
If a door is observed by 2 sensors, iris recommends the following installation parameters:
Figure 1: Installation of 2 sensors per door
Mounting height
Sensor distance
2060 mm
780 mm

IRMA6
-SENSOR-HD-00-SWITCH-(IO)-00-(R)(1) Installation Manual | Released
Rev. 1.4 | 12/2020
10 / 27
In a 2-doors scenario, the door contact signal is connected only to the master sensor.
The master sensor is identified in the following way:
Standing inside the vehicle, view from inside to the outside – the left sensor is the master sensor, the right sensor is the slave sensor.

IRMA6
-SENSOR-HD-00-SWITCH-(IO)-00-(R)(1) Installation Manual | Released
Rev. 1.4 | 12/2020
11 / 27
3Connecting IRMA 6 (optionally with angled M12 connectors)
Connect IRMA 6 to power supply
Connect IRMA 6 from component
to the on-board power supply via the wire strands of the power
supply cable K-M12POW-B-oE-04-2m.
Mind the correct connection points (+, - and shield) in the
connection block of the vehicle and See section "Ensuring
power supply", p. 14 for time relay for 30 min overrun power.
Connect IRMA 6 with Ethernet
Connect IRMA 6 from component with the switch via the
M12 system Ethernet cable K-M12CAT5-XX-xm. Via Ethernet
the connection to the OBU and to the service PC is made.
Only possible with service PCs having an Ethernet interface.
1061818736_p
M12 power supply
connector (m)
Switch-M12-5-Port-eCon
M12 Ethernet
connector (f)

IRMA6
-SENSOR-HD-00-SWITCH-(IO)-00-(R)(1) Installation Manual | Released
Rev. 1.4 | 12/2020
12 / 27
Connect IRMA 6 to PC
Connect IRMA 6 with the PC via switch from component with
the M12 system Ethernet cable K-M12CAT5-XX-xm and the
outgoing adapter cable KQ-M12CAT5-RJ45-01-xm for service
purposes (update, configuration).
Only possible with service PCs having an Ethernet interface.
Connect IRMA 6 to door contact (on
demand)
Connect the wire strands of the cable from component either
directly to the door control unit or establish a circuit with the wire
strands via a limit switch (external power supply from vehicle
required).
See cabling diagram for wiring overview of IRMA 6 in the vehicle,
see Fig. 3, p. 13.
Adapter cable
KQ-M12CAT5-RJ45-01-xm
Variant 1
Variant 2
M12 door contact
connector (f)

IRMA6
-SENSOR-HD-00-SWITCH-(IO)-00-(R)(1) Installation Manual | Released
Rev. 1.4 | 12/2020
13 / 27
Cabling diagram
Fig. 3: Installation of IRMA 6 (Ethernet version) as door contact variant
1 IRMA 6 SWITCH variant (rear view on interface unit)
2 Power cable for IRMA 6 K-M12POW-B-oE-04-2m
3 M12 system cable, Ethernet K-M12CAT5-XX-xm
4 Fuse 5 A, quick-acting
5 Switch-M12-5Port-eCon
6 Power supply of switch, K-Switch-Power (= K2),
length 3 m or SAC-4P-5,0-28R/FS SCO RAIL (= K3)
7 Adapter cable for PC connection for service
purposes KQ-M12CAT5-RJ45-01-xm
8 Wires for setting door contacts (and opt. Door Clear)
ADistribution of the vehicle-provided power supply to each
door for the connection of IRMA 6 and switch. The distribution of
the vehicle-provided power supply to each door is not part of the
standard scope of delivery of iris-GmbH!
S PC connection for service purposes D1 to Dn
Doors with 1 IRMA 6
M12 connector (f), ETH type
M12 connector (m), ETH type
M12 connector (f), 4 poles, A coded (K-Switch-
Power)
B Connection to on-board computer/on-board
unit (On-Board Computer/Unit)

IRMA6
-SENSOR-HD-00-SWITCH-(IO)-00-(R)(1) Installation Manual | Released
Rev. 1.4 | 12/2020
14 / 27
3.1 Ensuring power supply
1 Fuse 5 A, quick-
acting
2 Timing relais,
(dropout/OFF delay)
for 30 min minimum
3 Power cable for
IRMA 6 K-M12POW-
B-oE-04- 2m
4 IRMA 6
Fig. 4: Power supply of the IRMA 6 sensor with fuse and time relay for 30 min overrun power

IRMA6
-SENSOR-HD-00-SWITCH-(IO)-00-(R)(1) Installation Manual | Released
Rev. 1.4 | 12/2020
15 / 27
3.2 Connector types
• Ethernet interface
•D-coded (f)
•5 poles
• Voltage supply connector
• A-coded (m)
• 5 poles
• Ethernet interface
• D-coded (f)
• 5 poles
• Optional GPIO
connector for door contact
•B-coded (f)
•5 poles
Fig. 5: Pin assignment – Rear view on interface unit with connectors (Cf. Fig. 2)

IRMA6
-SENSOR-HD-00-SWITCH-(IO)-00-(R)(1) Installation Manual | Released
Rev. 1.4 | 12/2020
16 / 27
4Configuring IRMA 6
Provide a DHCP server in the LAN. Open DNS. Connect IRMA 6 via the RJ45
service cable with your pc. Enter the device number in the browser bar.
Start configuring IRMA 6. Change the language via “English”.
On the left side you find the navigation:
•for configuring IRMA 6
•updating IRMA 6
•checking logged error messages
•visualizing counting data of IRMA 6
Click on CONFIGURATION to get to the points INSTALLATION and ETHERNET At the point INSTALLATION you set:
•door/function area
•sabotage detection
• status LEDs
•installation parameter

IRMA6
-SENSOR-HD-00-SWITCH-(IO)-00-(R)(1) Installation Manual | Released
Rev. 1.4 | 12/2020
17 / 27
In the section “Door /Function Area” you set the:
•“Function Area Address”
•with the “FA” according to real door / fa number in vehicle
•“Door Address”with the setting value which is, as a rule, identical to the
“Function Area Address” (FA) in an Ethernet installation; and
•“Door Close Delay” with the value of the time determined between the door
closing signal sent by the on-board computer and the actual mechanical
closing of the door.
In the section “Status LEDs” you set “OFF”, as this is the default LED setting of the
sensor.
In the section “Installation Parameter” you set the parameters
for the placement of IRMA 6 according to the measures in the vehicle.
Measure the values for each installation parameter in the vehicle
and enter them. (See graphics below for each installation parameter
in vehicle).

IRMA6
-SENSOR-HD-00-SWITCH-(IO)-00-(R)(1) Installation Manual | Released
Rev. 1.4 | 12/2020
18 / 27
Mounting height Door to sensor distance
without steps with steps without steps with steps
Side view
Mounting height indicates the mounting height of the sensor in mm.
Drop a perpendicular from the sensor centre to the floor and mark the foot
of the perpendicular on the floor with an adhesive marker. The distance
from the sensor to the adhesive marker is the mounting height. Measure
the distance and enter the value measured
Door to sensor distance is the horizontal distance from the sensor to
the (closed!) door.
This parameter marks the boundary between the inside and the outside
of the vehicle in order to differentiate between boarding the vehicle
and alighting from it. If the installation distance exceeds 20 cm, absolutely
contact iris-GmbH.Measure the distance and enter the value measured.
Adhesive marker

IRMA6
-SENSOR-HD-00-SWITCH-(IO)-00-(R)(1) Installation Manual | Released
Rev. 1.4 | 12/2020
19 / 27
Vehicle edge offset Rotation angle X
positive value negative value positive angle negative angle
Side view
Vehicle edge offset is the difference in level between the adhesive marker
and the vehicle edge with the door open. The vehicle edge may be below or
above the adhesive marker. Measure the difference in height between
the vehicle edge and the adhesive marking and:
Rotation angle X is the inclination angle of the sensors visual axis (=x axis)
when the vehicle is stationary on a level plane. Sensors directed towards
the inside have a positive angle. This angle must not be > 5°; otherwise
the counting accuracy is reduced. Measure the sensor‘s angle of rotation
(e.g. using a suitable smartphone app) and enter the value measured.
•Set the measured value as positive (> 0 mm)
if the vehicle edge is below the adhesive marker.
•Set the measured value as negative (< 0 mm)
if the vehicle edge is above the adhesive marker.
Adhesive marker

IRMA6
-SENSOR-HD-00-SWITCH-(IO)-00-(R)(1) Installation Manual | Released
Rev. 1.4 | 12/2020
20 / 27
Left / right wall distance Left / right door clearance
Left/right wall distance is the left-hand/right-hand sensor monitoring
area up to the left/right lateral boundary in the vehicle interior.
Left/right door clearance (passage width) is the horizontal distance
between the sensor and the left/right opened door parallel to the vehicle edge.
Enter 0 mm if there is no opened door in the sensor viewing range.
Set 0 mm if there is no obstacle between the adhesive marker and
the left/right lateral boundary when the door is open.
Top view
Left wall
distance
Right wall
distance
Left door
clearance
Right door
clearance
Top view
Top view
