Ironman4x4 SWIFT 1400 User manual

Brackets can be used on either side of the SWIFT1400 Roof Top Tent to mount awnings and
other accessories
Supplied as Left & Right hand configuration
Secure to base section of Swift 1400 using the channels on the side and bottom extrusions
Use hardware supplied regularly check all fixings and tighten as required
Once mounted to tent install awning - Max length 2.5mtr / Max weight 35kg
Base - Swift1400
LEFT
RIGHT
Instruction Manual
www.ironman4x4.com www.ironman4x4america.com
SWIFT 14OO

Secures Swift 1400 Roof Top Tent to your vehicle
Brackets designed to be used with multi fit roof bars and platforms
Can be adjust for angled fitments
Brackets to be used on both sides of tent
Bracket A - Secures to tent mounting rails on base of tent can be used to replace standard mounting brackets as
supplied with the tent from factory
Bracket B - Secures to tent via channels on side of tent base
While the use of either bracket will be suitable for mounting of the tent, it is recommended that both are installed if
the tent will be exposed to excessive off road use
Use hardware supplied
BRACKET A
BRACKET B
SWIFT 14OO
Instruction Manual
www.ironman4x4.com www.ironman4x4america.com
Mounting rail on base of tent
Side Channel of Tent Base
