IronStrike FOUNDRYF-30 User manual

1
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
FOUNDRY FACE KIT
INSTALLATION INSTRUCTIONS FOR INSTALLING THE FOUNDRY FACE KIT
FOR USE WITH RAVENNA™, DESIGNER™ AND RAVELLE™ 30 GAS APPLIANCES
P/N 900146-00
Rev. A, 04/2014
HEARTH PRODUCTS
KITS AND ACCESSORIES
KIT CONTENTS
Please ensure that all these parts are in the packaging.
1 ea. Face
2 ea. Upper mounting brackets with four washers and four 10-24 nuts -
Used with model Ravelle™ 30 fireplace only
2 ea. Lower mounting brackets with four washers and four 10-24 nuts -
Used with model Ravelle 30 fireplace only
2 ea. Mounting Brackets - Used with models Ravenna™ and Designer™
fireplace inserts only
GENERAL INFORMATION
If you encounter any problems, need clarification of these instructions
or are not qualified to properly install this kit, contact you local distribu-
tor or dealer.
Read this instruction sheet in its entirety before beginning the installation.
All of these parts may scratch and bend, great care should be used
in handling them.
ALL WARNINGS AND PRECAUTIONS IN THE INSTALLATION AND
OPERATION MANUAL PROVIDED WITH THE APPLIANCE APPLY TO
THESE INSTRUCTIONS.
TURN OFF THE APPLIANCE AND ALLOW IT TO COMPLETELY COOL
BEFORE PROCEEDING.
Check the contents of the kits upon receipt and check for any damaged
or missing parts. If there is hidden damage, notify your freight company
or IHP dealer immediately.
Be sure to clean plated surfaces with a soft cloth and household glass
cleaner prior to burning the appliance. Fingerprints left on plated
surfaces while burning may remain on the finish permanently.
INSTALLATION INSTRUCTIONS - Ravenna™ and Designer™
fireplace inserts
NOTE: See face installation instructions for Ravelle™ 30 Fireplaces
on Page 2.
Face Assembly
Step 1. Locate the two mounting brackets provided that will be used for
mounting this face on the Ravenna or Designer fireplace inserts
(see Figure 2).
Cat. No. Model Description
75034 FOUNDRYF-30 Black Face / Black Nickel Hand-Hammered
Straps
TOOLS NEEDED
Standard Flat Screwdriver
Figure 1 - Foundry Face Kit
Figure 2 - Ravenna and Designer Mounting Brackets
fire-parts.com

2
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Step 1. Mount the top brackets on the available studs using the washers
and nuts provided (see Figure 6).
A
B - Top Bracket
Figure 6 - Install Top Brackets
Step 2. Remove the 3/8” nuts securing the face spacer on the right and
left side of the face (see Figure 3). Discard the spacers (used
for Ravelle™ 30 installations only). Save the nuts for attaching
the mounting brackets.
3/8”
7/16”
7/16”
7/16”
Step 3. Remove the three 7/16” nuts (see Figure 4). Place the mount-
ing bracket on three 7/16” screws and 3/8” stud. Make sure the
hooks on the bracket are toward the outside of the face. Secure
the bracket by replacing the four nuts. Repeat this process for
the opposite side.
Step 4. The top and bottom hooks will hook onto the surround brackets
on the fireplace insert (see Figure 5). Hold the face close to the
surround panels on the fireplace insert, then hook both hooks
at the same time.
Figure 3 - Remove Nuts and Face Spacers
Figure 4 - Install Mounting Brackets
Figure 5 - Install Mounting Brackets
INSTALLATION INSTRUCTIONS - Ravelle™ 30 Fireplaces
fire-parts.com

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
3
Figure 7 - Install Lower Brackets
Step 2. Mount the lower brackets on the available studs using the washers
and nuts provided (see Figure 7).
Step 3. To mount the face, rest the lower brackets on the one inch lower
lip of the appliance (see Figure 8). Tilt the top of the face up
toward the keeper nut. As you can see in the picture, the screw
on the mounting bracket will thread into the keeper nut.
Step 4. Guide a slender screwdriver through the mesh screen to thread
the right and left screws into the keeper nuts, securing the face
to the appliance.
Figure 8
Figure 9
Figure 10
C - Lower Bracket
Figure 11 - Completed Installation
fire-parts.com

4
Printed in U.S.A. © 2014 IHP LLC
P/N 900146-00 Rev. A 04/2014
IHP reserves the right to make changes at any time, without notice, in design, materials,
specifications, prices and also to discontinue colors, styles and products. Consult your local
distributor for fireplace code information.
1508 Elm Hill Pike, Suite 108 • Nashville, TN 37210
