1. Introduction
1.1. Document description
This manual is intended for experienced PC users. It describes the device and the operation of the GSM
modem iRZ TC65i-485GI.
1.2. Service data
Document version Issue date
2.11 09.20.2013
Prepared by V.N. Golovin Approved by P.A. Kosolapov
1.3. Safety rules
Restrictions on the use of the device near other electronic devices:
Turn the modem off in hospitals or when located near medical equipment such as pacemakers, hearing
aids and so on. Interference for medical equipment may occur
Turn the terminal off when on an airplane. Take measures to avoid accidental turning on
Turn the modem off in the vicinity of gas stations, chemical plants, and places where demolition work is
conducted. Interference for technical devices may occur
At a close range, the modem may produce interference for television sets and radio transmitters
Maintenance requirements:
Protect the modem against external hazards (high temperatures, caustic chemicals, dust, water and so
on)
Keep the modem safe from blows, falls, and strong vibrations
Do not attempt to take apart or modify the modem on your own. Such actions will void your warranty
Note: Make sure you follow the operation manual for this device. Improper use of the device will disqualify
your warranty.

5
2. General Information
2.1. Purpose
iRZ TC65i-485GI is an industrial GSM modem for receiving and transmitting data, text messages and
faxes. It is perfectly suited both for providing mobile access to the Internet and for industrial applications
including telemetry, wireless data collection from sensors, remote monitoring, control, and signaling.
Built-in Java platform, ADC and digital inputs/outputs allow integrating the modem into a wide variety of
solutions. The modem is controlled by standard AT-commands. The device is equipped with LEDs to monitor
connection status and signal for emergency.
2.2. Set
The set of the GSM modem iRZ TC65i-485GI includes:
iRZ TC65i-485GI modem;
Mounting bracket for attaching to a din-rail;
Factory package.
2.3. Features
Key features:
Frequency ranges: GSM 850/900/1800/1900MHz;
Output power:
2W (class 4 for EGSM850);
2W (class 4 for EGSM900);
1W (class 1 for GSM1800);
1W (class 1 for GSM1800);
GPRS class 12;
TCP/IP stack accessed via AT-commands;
MS class B;
CSD up to 14.4kbps;
USSD;
SMS;
Fax group 3, class 1;
Open platform for the development of Java applications;
Java parameters:
CLDC 1.1 HI;
J2ME with IMP 2.0 support;
secured data transferring with HTTPS and PKI support;
TCP, UDP, HTTP, FTP, SMTP, POP3 support;
remote java-application update (OTAP);

6
Power characteristics:
Power supply from 9 to 28V
Consumption current not exceeding:
with the supply voltage of +12V — 400mА;
with the supply voltage of +24V — 200mА;
Physical characteristics:
Dimensions not exceeding 76х85х30 mm;
Weight not exceeding 130g;
Operating temperatures from -30°Сto +65°С;
Storage temperatures from -40°Сto +75°С;
Interfaces:
TJ6-6P6C for RJ12 power connector for powering the modem including 2 keys to “ground” and 2 ADC
channels;
TJ6-6P6C for RJ12 digital connector with 4 digital inputs/outputs, output +3.3V, “ground”;
Plug-in terminal connector for powering the modem, connecting the communication cable with RS485
interface;
SMA Jack for connecting the GSM antenna.
The device can be powered using either of the first two connectors.

7
2.4. Appearance
TC65i-485GI modem is a compact device in an aluminum case. Its appearance is displayed on Fig. 2.4.1
and Fig. 2.4.2.
Fig. 2.4.1. Front view
Fig. 2.4.2. Back view
The numbers on Fig. 2.4.1 and Fig. 2.4.2 stand for:
1. LEDs (Emergency and Network);
2. SMA connector for connecting the GSM antenna;
3. SIM-card tray;
4. SIM-card tray ejector button;
5. Power connector;
6. Plug-in terminal connector;
7. Digital input/output connector (GPIO).

8
2.5. Interfaces
2.5.1. Plug-in terminal connector
This connector is used for communication with a controlling device, interface RS485. The AT-commands
are used to control the modem operation (see the module description).
Factory settings: Speed: 115200 bps, Data Bit: 8, Parity: None, Stop Bit: 1.
Fig. 2.5.1. Plug-in terminal connector
Table 2.5.1: Using terminal connector pins
Pins Signal Purpose
1 +Vin “+” modem power supply
2 -Vin “-” modem power supply
3 SHLD “Shield” of RS485 interface
4 “B” “d-“ of RS485 interface;
inverse differential I/O
5 “A” “d+“ of RS485 interface;
direct differential I/O
Interface lines are protected by self-healing fuses anda
circuit of impulse noise suppression, as well as
overvoltage protection
6 +5V Output ”+5V” (RS485), 100mA (to power external devices)*
*For instance, it might be used to power RS485 interface of heat and electricity counters, etc.
Notes: RS485 interface is half duplex. It needs to be considered in case of data transfer. When echo is
enabled, data is sent to the modem will return. This can lead to collision. In this case we recommend to
disable echo (AT-command ate0).

9
2.6. Power connector
TJ6-6P6C for RJ12 power connector is used to power the device. Also displayed on Fig. 2.5.2 are two keys
to the “ground” and two ADC channels.
Fig. 2.6.1. Power connector
Table 2.6.1: Using connector power pins
Contact Signal Purpose
1 + 12V The positive pole of DC supply voltage. Fused circuit and overvoltage
protection (when input voltage of over 30V is applied) and reverse polarity
2 Output of the “dry
contact” type to the
ground
Controlled by GPIO4 module output. When “logical 1” exits from the module
output, the “dry contact” output shortens to the “ground”
3 ADC2 Analog to digital converter. Parameters of the input circuit include input
resistance of 180kOhms and input voltage divider by 10. Connected to the
ADC2 pin of the GSM module
4 ADC1 Analog to digital converter. Parameters of the input circuit include input
resistance of 180kOhms and input voltage divider by 10. Connected to the
ADC1 pin of the GSM module
5 Output of the “dry
contact” type to the
ground
Controlled by GPIO5 module pin. When “logical 1” exits from the module
output, the “dry contact” output shortens to the “ground”
6 GND Ground
Output of the “dry contact” type goes through a 10 Ohm resistor to the collector of the BC817 transistor.
The output of the GSM module goes to the transistor base. The emitter of the transistor is connected to the
“ground”. The maximum current of the “dry contact” output is 80mA.

10
2.6.1. Digital connector
The connector has 4 digital pins. Both inputs and outputs can be used, which is specified in the GSM
module settings.
Fig. 2.6.2. Digital connector
Table 2.6.2: Using digital connector pins
Contact Signal Purpose
1 GND Body of the system or “ground”
2 GPIO2 Digital output controlling pin of GPIO2 module
3 GPIO1 Digital output controlling pin of GPIO1 module
4 GPIO10 Digital output controlling pin of GPIO10 module
5 GPIO3 Digital output controlling pin of GPIO3 module
6 +V +3.3V voltage of the modem
Parameters:
VOLmax=0.2V, I=2mA;
VOHmin=2.5V, I=-0.5mA;
VOHmax=3.0V;
VILmax=0.8V;
VIHmin=2.2V;
VIHmax=3.0V.
The input/output resistance of digital pins is 1kOhm. In order to send the controlling signals to the digital
pins it is recommended to use the first and the sixth pins of the connector.
