iS5 Raptor iMX Series User manual

IMX SERIES - QUICK START GUIDE
INTELLIGENT CYBER SECURE PLATFORM
i
iMX Series - Quick Start Guide
Intelligent Cyber Secure Platform
Version 1.3.04-2, June 2020
© 2020 iS5 Communications Inc. All rights reserved.

COPYRIGHT NOTICE
TRADEMARKS
i
Copyright Notice
© 2020 iS5 Communications Inc. All rights reserved.
No Part of this publication may be reproduced in any form without the prior written consent of iS5
Communications Inc. (iS5).
Trademarks
iS5Com is a registered trademark of iS5. All other trademarks belong to their respective owners.
Regulatory Compliance Statement
Product(s) associated with this publication complies/comply with all applicable regulations. For more
details, refer to the Technical Specifications.
Warranty
iS5 warrants that all products are free from defects in material and workmanship for a specified warranty
period from the invoice date (5 years for most products). iS5 will repair or replace products found to be
defective within this warranty period including shipping costs. This warranty does not cover product
modifications or repairs done by persons other than iS5-approved personnel, and this warranty does not
apply to products that are misused, abused, improperly installed, or damaged by accident. Refer to the
Technical Specifications for the actual warranty period(s) of the product(s) associated with this publica-
tion.
Disclaimer
Information in this publication is intended to be accurate. iS5 shall not be responsible for its use or
infringements on third-parties because of the use of this publication. There may occasionally be uninten-
tional errors on this publication. iS5 reserves the right to revise the contents of this publication without
notice.
Contact Information
iS5 Communications Inc. 5895 Ambler Dr., Mississauga, Ontario, L4W 5B7 Tel: 1+ 905-670-0004 // Fax:
1+ 289-401-5206 Website: http://www.is5com.com/ Technical Support: E-mail: s[email protected]
Sales Contact: E-mail: [e-mail]

i
Contents
Chapter: 1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Purpose and Scope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Chapter: 2 Console Port: Logging into the RAPTOR . . . . . . . . . . . . . . . . . . 2
Chapter: 3 SSH: Logging into the RAPTOR . . . . . . . . . . . . . . . . . . . . . . 10
Chapter: 4 Command Line: Switch Name . . . . . . . . . . . . . . . . . . . . . . 14
Chapter: 5 Command Line: Switch Prompt . . . . . . . . . . . . . . . . . . . . . . 15
Chapter: 6 Command Line: IP Address Configuration . . . . . . . . . . . . . . . . 16
Chapter: 7 Command Line: Admin Password . . . . . . . . . . . . . . . . . . . . 17
Chapter: 8 Command Line: Save and Restore Configuration . . . . . . . . . . . . 18
Chapter: 9 Command Line: Upgrading the RAPTOR . . . . . . . . . . . . . . . . . 19
Chapter: 10 Web Interface: Logging into the RAPTOR . . . . . . . . . . . . . . . . 22
Chapter: 11 Web Interface: System Settings . . . . . . . . . . . . . . . . . . . . . 24
Chapter: 12 Web Interface: IP Address and Default Routes . . . . . . . . . . . . . 25
Chapter: 13 Web Interface: User Password . . . . . . . . . . . . . . . . . . . . . . 29
Chapter: 14 Web Interface: Save and Restore Configurations . . . . . . . . . . . . 30

ii
Chapter: 15 Web Interface: Upgrade the RAPTOR . . . . . . . . . . . . . . . . . . 34

1
PURPOSE AND SCOPE
CHAPTER 1 INTRODUCTION
1. Introduction
The Quick Start Guide provides instruction for first time users on how to login to the RAPTOR through the
WebUI, Console or SSH interfaces. How to backup and restore configurations and how to upgrade the
device.
This document explains how to use Command Line Interface (CLI) interface and Web user interface (UI)
to perform the following tasks:
• Login to the RAPTOR
• Create an IP address for VLAN #1
• Set password, switch name, banner name, and prompt
• Save configuration
• Restore configuration
• Upgrade the RAPTOR
1.1. Purpose and Scope
This document covers the startup procedures and specifies the basic configuration commands. For more
information or support, email [email protected].
This document has been validated against the following products.
Product Firmware Version
iMX350 1.3.04
iMX950 1.3.04

2
CHAPTER 2 CONSOLE PORT: LOGGING INTO THE RAPTOR
2. Console Port: Logging into the RAPTOR
This section describes how the serial console interface on the RAPTOR is used to configure an IP Address,
save a configuration and upgrade the firmware.
1. On your laptop, install a terminal emulator. A popular option is Putty.
a. A link to download Putty is:
https://www.chiark.greenend.org.uk/~sgtatham/putty/latest.html
NOTE: The connection details are summarized in Figure 1 and the Console port is shown in Figure 2.
Figure 1: COM Port Connectivity

3
CHAPTER 2 CONSOLE PORT: LOGGING INTO THE RAPTOR
Figure 2: Console Port
2. Form a serial connection from your computer to the console port of the RAPTOR, by attaching the
console port to the USB port of your laptop or PC and the RJ45 termination to the console port on
the RAPTOR.
3. To determine the communications port being used on your computer, open Device Manager on
your PC or laptop.
a. Open Device Manager.
RESULT:The Device Manager window appears.

4
CHAPTER 2 CONSOLE PORT: LOGGING INTO THE RAPTOR
b. Navigate to Ports to determine which COM number the serial connection is using. You may
have to unplug and reinsert the USB connection on your PC to make a determination of which
COM number has been assigned to your serial connection.

5
CHAPTER 2 CONSOLE PORT: LOGGING INTO THE RAPTOR
RESULT:When the Ports leaf is exanded it will appear similar to the image below.
4. Putty can be configured by selecting the type of connection, entering the port number, and setting
the baud rate.
a. Additional serial parameters can be configured in Putty by selecting the Serial category found
at the bottom of the Category panel.
NOTE: The serial port configuration is as follows:
• Baud rate: 115200
• Data: 8
• Parity: none
• Stop: 1

6
CHAPTER 2 CONSOLE PORT: LOGGING INTO THE RAPTOR
• Flow Control: none
b. You should confirm in Putty’s user interface that it has been confirgured with the appropriate
Baud rate, Data, Parity, stop and flow control values.
STEP RESULT:The following image provides an image of the port and baud rate being set.
