Isotech 988 User manual

TH
ISSUE 2, 18 MARCH 2020
Blackbody
Source
45.00
CONTROLLER
!Read handbook before use
Not for use in hazardous areas
Check supply voltage
I
O
Blackbody
Source
Description
This blackbody source is particularly suitable for
the calibration of thermal imagers.
It comprises a heat / cool ridged blackbody
source of 70mm diameter whose temperature
can be set from 20°C to 45°C to a resolution of
0.1°C.
Features
Combined stability / accuracy of ±0.2°C using
contact thermometry.
Emissivity is better than 0.97 ± 0.02.
Evaluation at Land Pyrometers showed the
advantages of fitting a stainless steel tube
around the plate to give better uniformity and
less sensitivity to draughts and ambient
temperature effects.

Altering the Block Temperature, (Setpoint)
1. Switch the unit on. The power switch is located
on the front panel.
2. After Power Up the nominal temperature will
be shown on the display.
3. To display the set point (the desired
temperature) press Þ.
4. To increase the set point: Press Þ ▲together.
5. To decrease the set point: Press Þ ▼together.
The other controller functions are hidden from the
operator. The values are pre-set and should not be
changed.
Model No. 988
Temperature
Range
20°C to 45°C
(70°F to 115°F)
Resolution
±0.1°C
Target Size 70mm diameter
Emissivity Greater than 0.97 ± 0.02
Combined
Accuracy / Stability
±0.2°C
(±0.3°F)
Power 70W
Voltage 12 V.D.C.
Dimensions Height
Width
Depth
230mm
225mm
115mm
Weight 4kg
Accessories Switch Mode Power Supply
Supplied as Standard
How to Order 988
Safe Use
Do not use in wet or damp environments.
Care should be taken to avoid handling the calibration
area when hot - Risk of Burns - Keep flammable items
away.
Cool before placing in carry case.
No liquids should be used.
Read this instruction leaflet before use.
No user Serviceable parts, do not dismantle.
Not for use in Hazardous Areas.
Disconnecting device: The 988 Blackbody can be
isolated by removing the power cable.

The 988 Blackbody's optional power supply is
provided with an approved power cord. If the plug is
not suitable for your location then the plug should be
removed and replaced with an appropriate plug.
Take care to ensure the old plug is disposed safely.
The cable is colour coded as follows:
COLOUR
Green / Yellow
Brown
Blue
FUNCTION
Earth (Ground)
Live (Line)
Neutral
Please ensure that your unit is correctly connected to
the electricity supply.
Cautionary Note
Failure to follow these instructions could result in fatal
injury or cause damage to the product.
Isotech products are intended for use by technically
trained and competent personnel familiar with good
measurement practices.
It is expected that personnel using this equipment will
be competent with the management of apparatus
which may be powered or under extremes of
temperature, and are able to appreciate the hazards
which may be associated with, and the precautions to
be taken with, such equipment.
Trouble Shooting
Error Message What it Means What to Do
dAtA : FAiL Memory Error Cycle Power; If the error message persists
contact Isotech or supplier for advice.
inPt: FAiL Control Sensor Fault Contact Isotech or supplier for advice.
WARNING Do not remove the panels.
There are no user serviceable parts inside.
Contact your nearest Isotech agent for repair.
Unpacking and Initial Inspection
Our packing department uses custom designed
packaging to send out your unit, after unpacking the
unit, to inspect it for any sign of shipping damage, and
confirm that your delivery is in accordance with the
packing note. If you find any damage or that part of the
delivery is missing please notify us or our agent, and
the carrier immediately. If the unit is damaged you
should keep the packaging for possible insurance
assessment.

EMC INFORMATION
This product meets the requirements of the European
Directive on Electromagnetic Compatibility (EMC)
89/336/EEC as amended by EC Directive 92/31/EEC
and the European Low Voltage Directive 73/25/EEC,
amended by 93/68/EEC.
The product meets the susceptibility requirements of
EN 50082-1, criterion B.
System
Identification
Publication Description
ISO3864 Caution
(Refer to
this leaflet)
IEC 417 Caution
Hot
Surface
Warning: Do not remove the panels.
There are no user serviceable parts inside. Contact
your nearest Isotech agent for repair.
Voltage transients on the supply must not exceed
2.5kV.
Conductive pollution, eg Carbon dust, must be
excluded from the apparatus. EN61010 pollution
degree 2.
Environmental Ratings
Operating Temperature 5 - 35°C
Relative Humidity 5 - 95%, non condensing
ISOTHERMAL TECHNOLOGY LIMITED
Pine Grove, Southport, Merseyside, PR9 9AG, England
Telephone [phone] Fax [phone]
Email [email protected] http://www.isotech.co.uk
GUARANTEE
This instrument has been manufactured to exacting
standards and is guaranteed for twelve months
against electrical break-down or mechanical failure
caused through defective material or workmanship,
provided the failure is not the result of misuse. In the
event of failure covered by this guarantee, the
instrument must be returned, carriage paid, to the
supplier for examination and will be replaced or
repaired at our option.
FRAGILE CERAMIC AND/OR GLASS PARTS
ARE NOT COVERED BY THIS GUARANTEE.
INTERFERENCE WITH, OR FAILURE TO
PROPERLY MAINTAIN THIS INSTRUMENT
MAY INVALIDATE THIS GUARANTEE.
RECOMMENDATION
The life of your ISOTECH Instrument will be
prolonged if it is kept clean and free from general
dust and debris.
The company is always willing to give technical advice
and assistance where appropriate. Equally, because
of the programme of continual development and
improvement we reserve the right to amend or alter
characteristics and design without prior notice. This
publication is for information only.
