  9. Isotech ICM A7-4 User manual

Isotech ICM A7-4 User manual

Off / On
Auto Power Off
Volts AC
Volts DC
Warning
. . . . . . . . . .
. . . . . . . . . .
. . . . . . . . . .
. . . . . . . .
Safety sheet
. . . . . . . . .
. . . . . . . . . .
. . . . . . . . . .
. . . . . . . .
. . . . . . . . .

Read First
Safety Information
To ensure safe operation and service of
this Clamp-multimeter, read these
instructions completely before use and
comply with them fully when using it.
Failure to observe these warnings can
result in severe injury or death.
30min
TEST EQUIPMENT RISK ASSESSMENT
Users of this equipment and or their
employers are reminded that Health and
Safety Legislation require them to carry
out valid risk assessments of all electri-
cal work so as to identify potential
sources of electrical danger and risk of
electrical injury such as from inadvertent
short circuits. Where the assessments
show that the risk is significant then the
use of fused test leads constructed in
accordance with HSE guidance note
GS38 “ Electrical Test Equipment for
use by Electricians” should be used.
Symbols as marked on the
instrument and instructions.
Risk of electric shock
Refer to operating instructions.
DC measurement
Equipment protected by double or
reinforced insulation
<Battery
Earth
AC measurement
Conforms to EU directives
EMay be used on uninsulated
Conductors.
Warning
Do not apply more than 600V rms
ac between the instrument terminals
and earth ground .
-Avoid working alone, so assistance can
be rendered if required.
- Do not use test leads or the instrument
if they look damaged.
- Do not use the instrument if it is not
operating properly or if it is wet.
- Use the instrument only as specified in
these Operating Instructions, or the
protection provided by the instrument
may be impaired.
- Use extreme caution when working
around bare conductors or bus bar.
Contact with a hazardous live conduc-
tor could result in electric shock.
-Wear appropriate Personal Protective
Equipment if working where hazardous
live parts are accessible.
-Do not hold the instrument beyond the
Tactile Barrier, or allow fingers to pro-
trude past it.
The purpose of the barrier is to provide
adequate clearance between the op-
erator and a hazardous live conductor.
- Use caution with voltages above 30 V
ac rms, or 60 V dc. These voltages
pose a shock hazard.
Warning
Do not apply more than 600V rms
dc between the instrument terminals
and earth ground .
A7-4
ICM
Instruction Manual
ICM A7-4
Electrical Clamp-Multimeter
EN

Amps AC
Display Hold
190A
190A
I + (-I) = 0
I
I
Battery Replacement
SPECIFICATIONS
1-1 General Specifications
LCD display digits :
3 1/2 digit large scale LCD readout.
Display count : 2000 counts.
Measuring rate : 2.5 times / sec.
Overrange display :
“OL” is displayed for “A” and “Ω”
functions, shows the real value for
“V” function.
Automatic power off time :
Approximately 30 minutes after
power on. To resume operation,
turn the instrument off, then turn on
again.
Low battery indicator :
<is displayed. Replace the battery
when the <indicator appears in the
display.
Power requirement :
ALKALINE 9V battery.
Battery life :
ALKALINE PP3; 9V 250 hours.
Conductor Size : 16mm (0.63”)
diameter.
1-2 Environmental Conditions
Indoor Use.
Calibration :
One year calibration cycle.
Operating temperature :
0°C ~ 30°C (≦80% RH)
30°C ~ 40°C (≦75% RH)
40°C ~ 50°C (≦45%RH)
Operating altitude : 2000m (6562 ft)
Overvoltage category :
IEC 61010-1 600V CAT.Ⅲ.
CAT.Ⅲequipment is designed to
protect against the transients in the
equipment in fixed installations,
such as distribution panels, feeders,
short branch circuits and lighting
systems in large buildings.
Pollution degree : 2
EMC : EN 61326-1
1-3 Electrical Specifications
Accuracy is ±(% reading + number
of digits) at 23°C ±5°C < 80%RH.
Temperature coefficient :
0.2 x (Specified accuracy) / °C,
< 18°C, > 28°C .
Function Range Accuracy
V600 Vrms ±(1.5%+ 3 dgt)
40Hz ~ 500Hz
V600 V ±(1% + 2 dgt)
Overload protection : 600 Vrms
Input impedance : 1MΩ// less
than 100pF.
Resistance & Continuity
Function Range Accuracy
Ω 2000Ω±(1% + 2 dgt)
Overload protection : 600V rms
Max. open circuit voltage : 3V
Continuity check : The internal
sounder activates if the resistance
of the circuit under test is less than
25Ω.
It will then turn off if the resistance
is increased beyond 400Ω.
AC Current
Function Range Accuracy
A200.0A ±(3% + 3 dgt)*
45Hz ~ 66Hz
Overload protection : 200A
* Adjacent conductor influence :
<0.05 A/A
√
√
X
X
Shock vibration :
Sinusoidal vibration per MIL-T-
28800E (5 ~ 55 Hz, 3g maximum).
Cleaning
Periodically wipe the case with a
dry cloth and detergent. Do not use
abrasives or solvents.
Do not hold
the meter beyond
the barrier
Tactile Barrier
CAT.Ⅲ.600V
with respect to
earth for the jaw.
Resistance
Continuity
Limited Warranty
This instrument is warranted to the original
purchaser against defects in material and
workmanship for 3 year from the date of
purchase. During this warranty period, RS
Components will, at its option, replace or
repair the defective unit, subject to verifica-
tion of the defect or malfunction. This war-
ranty does not cover fuses, disposable
batteries, or damage from abuse, neglect,
accident, unauthorized repair, alteration,
contamination or abnormal conditions of
operation or handling.
Any implied warranties arising from the
sale of this product, including but not lim-
ited to implied warranties of merchantability
and fitness for a particular purpose, are
limited to the above. The manufacturer
shall not be liable for loss of use of the
instrument or other incidental or conse-
quential damages, expenses, or economic
loss, or for any claim or claims for such
damage, expense or economic loss.
Some states or countries laws vary, so the
above limitations or exclusions may not
apply to you.
For full terms and conditions, refer to the
current RS Catalogue.
Asia
Iso-Tech
460 Alexandra Road, #15-01A
PSA Building
Singapore 119963
USA
7410 Pebble Drive
Fort Worth
Texas 76118-6961
Europe
Iso-Tech
PO Box 99
Corby
Northamptonshire
NN17 9RS
United Kingdom
Canada
1701 Woodward Drive
Ste 108 Ottawa
Ontario K2C 0R4, Canada
Japan
West Tower (12th Floor)
Yokohama Business Park
134 Godocho, Hodogaya
Yokohama,
Kanagawa 240-0005 Japan
South America
Av. Pdte. Eduardo Frei M. 6001-71
Centro Empresas El Cortijo
Conchali, Santiago, Chile
