Isotech ICM36R User manual


INSTRUCTION MANUAL
ICM36R CLAMP MULTIMETER
ICM 36R
EN FR IT DE

1
ISO-TECH ICM36R
CLAMP MULTIMETER
INSTRUCTION MANUAL

2

3
INTRODUCTION
1-1 Unpacking and Inspection
Upon removing your new Current Meter from its packing, you should have the following items:
1. Current meter.
2. Carrying case.
3. Instruction Manual.
1-2 Meter Safety
Terms as Marked on Equipment
Attention — Refer to Manual.
Double Insulation — Protection Class II
DANGER — Risk if electric shock.
Symbols in Manual
This symbol indicates where cautionary or other information is found in the manual.
Battery

4
1-3 Front Panel
Refer to Figure 1 and the following numbered steps to familiarize yourself with the meter's front panel controls.
1. Digital Display — The digital display has a 3 1/2 digit LCD readout (maximum reading 1999) plus auto polarity,
decimal point, <, DC,AC, and =.
2. Drop-Proof Wrist Strap — Prevents the instrument from slipping off the hand while in use.
3. Function Switch — Slide switch is used to select the desired range.
4. DC Zero Adj. Knob — Zero adjusts on DC current ranges.
5. AC/DC Slide Switch — Selects a.c. or d.c. current measurement.
6. Data Hold Switch — Holds display reading for all functions and ranges.
7. Trigger — Press the lever to open the current transformer jaws. When the pressure on the lever is released, the
jaws will close again.
8. Current transformer Jaws — Designed to pick up the current flowing through the conductor.

5
Figure 1

6
SPECIFICATIONS
2-1 General Specifications
Display : 3 1/2 Digital Liquid Crystal Display (LCD) with a maximum reading of 1999.
Polarity : Automatic polarity indicated.
Overrange Indication : "1" or "-1" indicated.
Measuring Rate : 2 times per second, nominal.
Position Error : ± 1% of reading.
Type of Sensing : Hall effect sensing for AC and DC.
Low Battery Indication : "<" is displayed when the battery voltage drops below the operating voltage.

7
2-2 Environmental Conditions
Indoor use only.
Maximum Altitude : 2000 meters.
Installation Category : IEC 1010 Cat. II 600V, Cat. III 300V.
Pollution Degree : 2
Operating Ambient : 0°C ~ 50°C, < 75% R.H.
Storage Temperature : -20°C ~ 60°C, < 80% R.H.
Temperature Coefficient : 0.2 x (Specified accuracy) / °C, < 18°C or > 28°C.
Power Requirement : Alkaline 9V battery.
Battery Life : 40 hours typical (Alkaline).
Max/Conductor Size : 34mm diameter or 20 x 40mm busbar.
Size : 600mm (W) x 203mm (L) x 29mm (H).
Weight : 310 grams.
Supplied Accessories : Battery (installed), manual and carrying case.

8
2-3 Electrical Specifications
Accuracy is ± (% reading + number of digits) at 23°C ± 5°C, less than 75% R.H.
(1) DC A
Range Resolution Accuracy
200A 0.1A ±(1.9%reading + 5digits) for 0 ~ 20A
±(1.9%reading + 3digits) for 20A ~ 200A
600A 1A ±(1.9%reading + 3digits) for 200A ~ 600A

9
(2) AC A
Range Resolution Accuracy
200A 0.1A ±(1.9%reading + 7digits) for 0 ~ 20A
±(1.9%reading + 5digits) for 20A ~ 200A
600A 1A ±(1.9%reading + 5digits) for 200A ~ 600A
Frequency Response: 40Hz ~ 400Hz.
Data Hold: Hold display reading for all functions and ranges.
(3) Auto Power Off
The meter will automatically shut itself off approximately 30 minutes after power on.

10
OPERATION
This instrument has been designed and tested in accordance with IEC Publication 1010, Safety Require-
ments for Electronic Measuring Apparatus and has been supplied in a safe condition. This instruction
manual contains some information and warnings which have to be followed by the user to ensure safe
operation and to retain the instrument in safe condition.
3-1 Precautions and Preparations for Measurement
1. Make sure that the battery is properly connected.
2. The instrument should only be operated between 0°C ~ 50°C and at less than 75% R.H.
3. Do not use or store this instrument in a high temperature or high humidity environment and do not store the unit in
direct sunlight.
4. Do not replace battery with power switch set to ON.
5. If the unit is not to be used for a long period of time, remove the battery.
6. Remember to turn power switch off after use.
7. The responsible bodyshall be made aware thatif the equipmentis used in a manner not specified bythe manufacturer,
the protection provided by the equipment may be impaired.

11
THIS INSTRUMENT MUST NOT BE USED ON UNINSULATED CONDUCTORS AT A VOLTAGE GREATER THAN
600V ac/dc.
3-2 AC Current Measurement
1. Set the AC/DC switch tothe ACposition.
2. Set the functionswitch to the desired range, if unsure select600A range.
3. Press the trigger to open the current transformer jaws and clamp around one conductoronly, making sure that the jaw is
firmly closed around the conductor, then take the reading from the digital display.
3-3 DC Current Measurement
1. Set the AC/DC switch tothe DCposition.
2. Set the functionswitch to the desired range, if unsure selectthe 600A range.
3. Adjust the "DCA ZeroAdj. Knob" until the displayshows "0".
4. For DC measurement, the reading is a positive value when the current flows fromthe lower sideto the upper sideof the
instrument as Fig. 2.
5. Press the trigger to open the transformer jaws and clamp one conductor only, making sure that the jaw is firmly closed
around the conductor, then take the reading from the digital display.

12
Figure 2

13
MAINTENANCE
WARNING : TO AVOID ELECTRICAL SHOCK REMOVE JAW FROM CONDUCTOR BEFORE OPENING
THE BATTERY COVER.
General Maintenance
1. Repairs or servicing not covered in this manual should only be performed by qualified personnel.
2. Periodically wipe the case with a damp cloth and detergent, do not use abrasives or solvents.
Battery Replacement
This instrument is powered by a single 9V alkaline battery. Use the following procedure to replace the
battery.
1. Turn the power off.
2. Position the instrument face down and remove the screw from the battery cover.
3. Slide off the battery cover and remove the battery.
4. Replace with a new 9V alkaline battery and reinstall the battery cover.
